Cooper Lighting AMETRIX C-Scroll P4R User manual

Exploded view and part call-out
Canopy
Set screw
1/4-20 x 4 1/2"
Hex cap bolts
(4x)
(by others)
J-box
#8- 2 x /8"
(2x)(4x)
1/4" Fastener
Cover plate
Wiring the fixture
1. Remove all 1/4-20 x4 1/2" hex bolts from bottom of pendant.
2. Remove both #8- 2 x /8" set screws and allow canopy to
slide down pendant.
3. Run wires from J-box into pendant, ensure there is enough
wire to reach cover plate.
4. Using appropriate fasteners, secure fixture to ceiling. Use
additional bracing around J-box to support fixture.
. Replace canopy and secure using both set screws.
Yoke arm
indicator
Aiming the fixture
Fixture head
indicator
1. To aim fixtures, loosen both #10- 2 end screws on one
fixture. When both indicators are lined up, the slope of the
lens face is 40-degrees. Each subsequent notch is an
additional +/- 10-degrees.
2. When fixture head is rotated to the desired angle, retighten
end screws to secure the position.
3. Repeat for remaining fixture heads.
Set screw
Mounting pendant to J-box
(4x)
(by others)
1/4" fasteners (by others)
J-box
(2x)
(4x)
Hex cap bolts
1/4-20 x4 1/2"
#8- 2 x /8"
Canopy
Cover plate
Use additional bracing
around J-box to support
fixture.
4.
Cover plate
Push connections into pendant and secure cover plate.
properly matched.
1/4-20 x4 1/2" Fixture wire
Hex cap bolts
(4x)
1. With pendant secure, slide fixture assembly onto pendant
and secure with four 1/4-20 x4 1/2" hex bolts.
2. Remove cover plate and insert wires from fixture heads into
pendant and pull through opening.
3. Attach appropriate wires and ensure all connections are
Attention:
Quad fixture assemblies require additional bracing/structure
around J-box to support fixture.
2
that all sources of power are turned off. All
Sheet 1 of 2
performed by a certified electrician.
ADY071466 REV B(ECN80481)
Warning: Before starting any work ensure
work must meet local/national codes and be
Do not
mount fixtures vertically.
Installation Instructions
Vault C-Scroll Roundel
These installation instructions are valid with the above Ametrix styles.
1
3
Small, INDOOR
P4R
(Pendant, 4-way, Remote ballast)
Visor and Non-Visor

1
2"
12.70
on order
Length dependant
4
3
32
19.05
(4x)
"
13
10.16
"
114.30
152.40
"
6"
2
1
6"
4
152.40
2"
"
114.30
2
50.80
41
3
4"
19.05
Front ViewSide View
Use only GE or Sylvania
CFL lamps
Mounting Plate Dimensions In [mm]
Lamping Size Chart
: Before starting any work ensure
work must meet local/national codes and be
Do not
mount fixtures vertically.
Visor and Non-Visor
These installation instructions are valid with the above Ametrix styles
Sheet 2 of 2
C-Scroll w/ visor
that all sources of power are turned off. All
(lamps provided by others)
Installation Instructions
Warning
Vault w/ visor Roundel w/ visor performed by a certified electrician.
Small, INDOOR
P4R
(Pendant, 4-way, Remote ballast)
ADY071466 REV B(ECN80481)
FIXTURE SIZE
(inches/ mm) WATTAGE # OF LAMPS LAMP TYPE LAMP DESCRIPTION
10 3/4 / 273.05 39 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 70 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 150 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 26 W 1 4-Pin Triple
Tube Compact Fluorescent
12 3/4 / 323.85 32 W 1 4-Pin Triple
Tube Compact Fluorescent
12 3/4 / 323.85 42 W 1 4-Pin Triple
Tube Compact Fluorescent
10 3/4 / 273.05 100 W 1 T4 Halogen (Single Ended)
12 3/4 / 323.85 150 W 1 T4 Halogen (Single Ended)
12 3/4 / 323.85 250 W 1 T4 Halogen (Single Ended)
LAMP
(not to scale)
