Cooper wheelock S8 series User manual

Sheet 1 of 4

273 Branchport Avenue Thank you for using our products.

Long Branch, NJ 07740

(800) 631-2148 INSTALLATION INSTRUCTIONS

www.cooperwheelock.com SERIES S8 EIGHT INCH SPEAKER AND MULTI-CANDELA SPEAKER STROBE

(CEILING MOUNT VERSION)

Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Series S8-70/25 Eight Inch Speaker, S8-24MCC Multi-Candela Eight Inch Speaker Strobe and S8-24MCCH Multi-High Candela are UL Listed under Standard 1971

(Signaling Devices for the Hearing Impaired) and Standard 1480 (Speakers for Fire Protective Signaling Systems) for indoor fire protection service. The S8-24MCC

and S8-24MCCH with amber, red, blue or green lens is UL Listed under Standard UL1638 (Visual Signaling Appliance) for Private Mode Emergency and General

Utility Signaling. The S8 Eight Inch Speaker is designed for multiple power requirements with high dBA output at each power tap and offers a choice of field

selectable taps, 1/4W to 8W for either 25.0VRMS or 70.0VRMS audio systems. The speaker has a molded, flame retardant cone.

NOTE: In order to maintain proper UL 1480 listing, the CBB-8 Speaker Backbox (available separately) must be installed. The CBB-8 Backbox is required for use in

ceiling plenums that are part of return air handling systems.

The S8-24MCC Strobe provides four selectable light output intensities (15,30,75,95cd) in one unit. The S8-24MCCH Strobe provides two selectable light intensities

(115,177cd) in one unit. The Strobe can provide a non-synchronized strobe appliance when connected directly to a fire alarm control panel (FACP), or provide a

synchronized strobe appliance when used in conjunction with a Sync Module (SM), Dual Sync Module (DSM) or Wheelock’s Power Supplies. The strobe uses a

xenon flashtube with solid state circuitry enclosed in a polycarbonate lens to provide maximum visibility and reliability for effective visible signaling. The S8-70/25,

S8-24MCC and S8-24MCCH are Listed for indoor use, ceiling mount only with the backboxes specified in these instructions (see wiring and mounting information).

S8 series speakers are UL rated to meet the NFPA 72 requirement for 520Hz signals in sleeping areas when used in conjunction with Wheelock Safepath

products (see SP40S manual for more details).

WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY. FAILURE TO COMPLY WITH ANY OF THE FOLLOWING

INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, CANDELA SETTING, INSTALLATION AND/OR

OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS

INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Table 1: UL Listed Models and Ratings

Models

Speaker

Strobe

Mounting

Options

Voltage

(VRMS)

dBA at 10 Feet

(Rated Watts)

Regulated

Voltage

(VDC/VRMS)

Voltage

Range

(VDC/VRMS)

Candela

1/8

1/4

1/2

S8-70/25

25/70

-----

-------

--------

See Fig. 1

S8-24MCC

25/70

16.0-33.0

15/30/75/95

See Fig. 1

S8-24MCCH

25/70

16.0-33.0

115/177cd

See Fig 1

NOTES:

1. The strobe will produce 1 flash per second over the "Regulated Voltage" range.

2. Strobes with clear and amber lens meet the required light distribution patterns defined in UL 1971.

3. The Series S8-70/25, S8-24MCC and S8-24MCCH are UL Listed for indoor use with a temperature range of +32F to +120F (0C to +49C) and maximum

humidity of 85% RH.

4. A 10F blocking capacitor for DC supervision of audio lines by the FACP is factory wired in series with the speaker input. The maximum supervision voltage is

33 volts DC. Frequency range of speakers is 400-4000Hz.

5. Ratings listed in Table 1 are for clear lens. Derate approximately 25% for amber lens, 55% for green, 70% for blue, 80% for red.

WARNING: THESE APPLIANCES WERE TESTED TO THE REGULATED VOLTAGE LIMITS OF 16.0-33.0 VOLTS FOR 24V MODELS USING

FILTERED DC OR UNFILTERED FULL-WAVE-RECTIFIED VOLTAGE. DO NOT APPLY VOLTAGE OUTSIDE OF THIS RANGE.

WARNING: CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY AND SUBTRACT THE

VOLTAGE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPLIED VOLTAGE TO THE STROBES. THE MAXIMUM

WIRE IMPEDANCE BETWEEN STROBES SHALL NOT EXCEED 35 OHMS.

WARNING: CANDELA SETTING WILL DETERMINE THE CURRENT DRAW OF THE PRODUCT.

Table 2: UL Current Ratings with Strobe Only

Maximum RMS Current (AMPS)

UL Voltage

15cd

30cd

75cd

95cd

115cd

177cd

16-33VDC

0.065

0.105

0.189

0.249

0.300

0.420

FWR

16-33VRMS

0.110

0.170

0.280

0.375

0.455

0.645

WARNING: MAKE SURE THAT THE TOTAL RMS CURRENT REQUIRED BY ALL APPLIANCES THAT ARE CONNECTED TO THE

SYSTEM’S PRIMARY AND SECONDARY POWER SOURCES, NAC CIRCUITS, SM, DSM SYNC MODULES OR WHEELOCKS POWER SUPPLIES

DO NOT EXCEED THE POWER SOURCES’ RATED CAPACITY OR THE CURRENT RATINGS OF ANY FUSES ON THE CIRCUITS TO WHICH

THESE APPLIANCES ARE WIRED. OVERLOADING POWER SOURCES OR EXCEEDING FUSE RATINGS COULD RESULT IN LOSS OF POWER

AND FAILURE TO ALERT OCCUPANTS DURING AN EMERGENCY, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY

OR DEATH TO YOU AND/OR OTHERS.

P84478 J

Sheet 2 of 4

When calculating the total currents: Use Table 2 to determine the highest value of “RMS Current” for an individual strobe (a cross the expected operating voltage

range of the strobe), then multiply these values by the total number of strobes; be sure to add the currents for any other appliances, including audible signaling

appliances, powered by the same source and include any required safety factors.

NOTE: The maximum number of strobes on a single notification appliance circuit shall not exceed 50.

CAUTION: The Strobe is not designed to be used on coded systems in which the applied voltage is cycled on and off.

MOUNTING INFORMATION

Figure 1:

CAUTION: The maximum number of field wires (conductors) that can enter the CBB-8 or other listed equivalent backbox shall comply with the National

Electrical Code (NEC). If this limit is exceeded, there may be insufficient space in the backbox to accommodate the field wires. Stresses from the wires could

damage the product.

Cooper Wheelock also recommends the use of approved stranded field wires, whenever possible, to provide additional wiring room for easy installation and minimum

stress on the product from wiring.

The S8-70/25, S8-24MCC and S8-24MCCH models are designed to mount flush in a hung tile ceiling. The CBB-8 or other listed equivalent backbox is required per

UL Standard 1480 Speakers for Fire Protective Signaling Systems. When the speaker and backbox cannot be installed directly through a ceiling tile, a support bridge

must be used. Refer to P84239 and P81490 for additional mounting information.

WIRING INFORMATION:

Figure 2:

Figure 3:

1. The Low Profile Speaker Strobe model has in-out wiring terminals

that accept two #12 to #18 American Wire Gauge (AWG) wires

at each screw terminal. Strip leads 3/8 inches and connect to

screw terminals.

2. Break all in-out wire runs on supervised circuits to assure integrity

of circuit supervision as shown in Figure 3. The polarity shown in

the wiring diagrams is for operation of the appliances.

3. Connect speaker wires to common and positive of terminal block

and select the power tap terminal for 1/8W, 1/4W, 1/2W, 1W, 2W,

4W or 8W; 25V or 70V as required (see Figures 2, 3, 4, 5 and

Table 4).

+ STROBE - COM+

(OPTIONAL)

FROM PRECEDING SPEAKER

OR FIRE ALARM

CONTROL PANEL (FACP)

FROM PRECEDING STROBE

APPLIANCE OR SYNC MODULE

TO NEXT APPLIANCE

OR EOLR

TO NEXT SPEAKER

OR END OF LINE RESISTOR

(EOLR)

* Refer to Sync Module instruction sheets SM (P83123), DSM (P83177) or

Wheelock power supplies for additional information.

GROUNDING: Connect ground wire to backbox. Install signaling appliance to backbox using mounting screws provided.

WARNING: THE SPEAKER STROBE APPLIANCE MUST BE FIELD SET TO THE DESIRED dBA SOUND OUTPUT LEVEL BEFORE IT IS

INSTALLED. THIS IS DONE BY PROPERLY INSERTING JUMPER PLUGS IN ACCORDANCE WITH THESE INSTRUCTIONS. INCORRECT

SETTINGS WILL RESULT IN IMPROPER PERFORMANCE, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR

DEATH TO YOU AND/OR OTHERS.

Figure 4:Jumper plug is used to select tap settings which = dBA loudness.

Figure 5:Tap Settings (Factory setting is 70V @ 0.5W (H))

A B C D E F G H I J

Each letter corresponds to a plug position of the header located on the

printed circuit board. Select voltage and wattage as shown in Table 3.

NOTE: Use needle nose pliers to pull and properly insert the jumper plug to the desired tap setting.

P84478 J

Sheet 3 of 4

Table 3: Speaker Voltage and Wattage Connection Chart

Position

25V

70V

------

1/2

1/4

1/8

------

1/2

------

1/4

------

1/8

Figure 6: Light Output Chart

WARNING: CHECK ELECTRICAL RATINGS SPECIFIED IN TABLES 1 AND 2 (AS APPROPRIATE) TO ENSURE PROPER ELECTRICAL

INPUT. BE SURE THAT SPEAKER WIRING IS CONNECTED TO SPEAKER TERMINALS ONLY AND STROBE WIRING IS CONNECTED TO

STROBE TERMINALS ONLY. CHECK TO INSURE THAT WIRING AT FACP IS CORRECT. IMPROPER ELECTRICAL INPUT CAN DAMAGE

THE PRODUCT OR CAUSE IT TO MALFUNCTION, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO

YOU AND/OR OTHERS. Figure 7:

CANDELA

POINTER

BOTTOM VIEW

30 1575

CANDELA

SELECTOR

SLOT

177

CANDELA

POINTER

BOTTOM VIEW

115

CANDELA

SELECTOR

SLOT

NOTE: The S8-24MCC comes pre-set at 15cd. NOTE: The S8-24MCCH comes pre-set at 177cd

WARNING: THE CANDELA SELECT SWITCH MUST BE FIELD SET TO THE REQUIRED CANDELA INTENSITY BEFORE INSTALLATION.

WHEN CHANGING THE SETTING OF THE CANDELA SELECT SWITCH, MAKE CERTAIN THAT IT “CLICKS” IN PLACE. AFTER CHANGING

THE CANDELA SETTING, THE APPLIANCE MUST BE RETESTED TO VERIFY PROPER OPERATION. IMPROPER SETTING OF THE

CANDELA SELECT SWITCH, MAY RESULT IN OPERATION AT THE WRONG CANDELA, WHICH COULD RESULT IN PROPERTY DAMAGE

AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

NOTE: All cable splices and connections to Speaker/Transformer pigtails must be made inside of Listed enclosure.

P84478 J

Sheet 4 of 4

WIRING PROCEDURES:

CAUTION: Check that the installed product will have sufficient clearance and wiring room prior to installing backboxes and conduit, especially if sheathed

multiconductor cable or 3/4" conduit fittings are used.

1. Set each speaker to the required wattage and voltage according to Table 3.

2. To insure proper speaker phasing, maintain a consistent color code to all speakers. To simplify phasing, use interconnecting cable with color coded wires.

A. Connect the same color wire (in the interconnecting cable) to the amplifier output terminal marked COM (Common), and to the "COM" terminal of all

speakers.

B. Connect one other color wire (in the interconnecting cable) to the amplifier output terminal marked 25V or 70V and to all of the “+” terminals at each speaker

input. The setting of “J1” must match the amplifier output of 25V or 70V.

C. If shielded cable is used, then connect the shield (in the interconnecting cable) to the amplifier output terminal marked GND (Ground). The shield is not

connected to the speakers. The shield is made continuous using wire nuts and taped off at the last speaker on the cable run.

3. The total system wattage requirement should not exceed 85% of the system amplifier’s rated output. The total system wattage requirement is the summation of

the wattage tap selections of all system speakers.

4. When terminating field wires, do not use more lead length than required. Excess lead length could result in insufficient wiring space for the signaling appliance.

5. Set the strobe to the required candela. To move selector switch, insert screwdriver into slot shown on the side of the strobe. The setting is indicated by a pointer

and can be seen on the side of the lens. See Figure 7.

6. Conduit entrances to the backbox should be selected to provide sufficient wiring clearance for the installed product.

7. Do not pass additional wires (used for other than the signaling appliance) through the backbox. Such additional wires could result in insufficient wiring space

for the signaling appliance.

8. Use care and proper techniques to position the field wires in the backbox so that they use minimum space and produce minimum stress on the product. This is

especially important for stiff, heavy gauge wires and wires with thick insulation or sheathing.

9. If this appliance is required to produce a distinctive three-pulse Temporal Pattern Fire Alarm Evacuation Signal (for total evacuation) in accordance with NFPA

72, the appliance must be used with a UL864 listed fire alarm control unit. Refer to manufacturer’s installation manual for details.

CAUTION: Always operate audio amplifiers and speakers within their specified ratings. Excessive input may distort sound quality and may damage audio

equipment. Do not exceed +100% of speaker input voltage per UL 1480. Improper input voltage can damage speaker. If distortion is heard, check for clipping of the

audio appliance with an oscilloscope and reduce the amplifier input level or gain level to eliminate any clipping.

WARNING: 1) THESE DEVICES ARE NOT INTENDED FOR USE IN HAZARDOUS LOCATIONS AS DEFINED BY THE NATIONAL

ELECTRICAL CODE (NEC) AND BY THE NATIONAL FIRE PROTECTION ASSOCIATION (NFPA). 2) THESE DEVICES ARE DESIGNED FOR

INDOOR USE ONLY. DO NOT EXPOSE TO RAIN OR MOISTURE.

WARNING: THE SPEAKER STROBE APPLIANCE IS A "FIRE ALARM DEVICE - DO NOT PAINT."

WARNING: WHEN INSTALLING STROBES IN AN OPEN OFFICE OR OTHER AREAS CONTAINING PARTITIONS OR OTHER VIEWING

OBSTRUCTIONS, SPECIAL ATTENTION SHOULD BE GIVEN TO THE LOCATION OF THE STROBES SO THAT THEIR OPERATING EFFECT

CAN BE SEEN BY ALL INTENDED VIEWERS, WITH THE INTENSITY, NUMBER, AND TYPE OF STROBES BEING SUFFICIENT TO MAKE

SURE THAT THE INTENDED VIEWER IS ALERTED BY PROPER ILLUMINATION, REGARDLESS OF THE VIEWER'S ORIENTATION.

FAILURE TO DO SO COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS

The S8-24MCCH’s 177cd setting is Listed for use in sleeping or non-sleeping areas when installed in accordance with appropriate NFPA Standards and the Authority

Having Jurisdiction.

If this appliance is required to produce a distinctive three-pulse Temporal Pattern Fire Alarm Evacuation Signal (for total evacuation) in accordance with NFPA 72, the

appliance must be used with a fire alarm control unit that can generate the temporal pattern signal. Refer to manufacturer’s installation manual for details.

NOTE: NFPA 72/ANSI 117.1 conform to ADAAG Equivalent Facilitation Guidelines in using fewer, higher intensity strobes within the same protected area.

WARNING: A SMALL POSSIBILITY EXISTS THAT THE USE OF MULTIPLE STROBES WITHIN A PERSON'S FIELD OF VIEW, UNDER

CERTAIN CIRCUMSTANCES, MIGHT INDUCE A PHOTO-SENSITIVE RESPONSE IN PERSONS WITH EPILEPSY. STROBE REFLECTIONS IN A

GLASS OR MIRRORED SURFACE MIGHT ALSO INDUCE SUCH A RESPONSE. TO MINIMIZE THIS POSSIBLE HAZARD, COOPER

WHEELOCK STRONGLY RECOMMENDS THAT THE STROBES INSTALLED SHOULD NOT PRESENT A COMPOSITE FLASH RATE IN THE

FIELD OF VIEW WHICH EXCEEDS FIVE (5) Hz AT THE OPERATING VOLTAGE OF THE STROBES. COOPER WHEELOCK ALSO STRONGLY

RECOMMENDS THAT THE INTENSITY AND COMPOSITE FLASH RATE OF INSTALLED STROBES COMPLY WITH LEVELS ESTABLISHED

BY APPLICABLE LAWS, STANDARDS, REGULATIONS, CODES AND GUIDELINES.

CAUTION: Check the installation instructions of the manufacturers of other equipment used in the system for any guidelines or restrictions on wiring and/or

locating Notification Appliance Circuits (NAC) and notification appliances. Some system communication circuits and/or audio circuits, for example, may require

special precautions to assure electrical noise immunity (e.g. audio crosstalk).

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the

receiving antenna, 2) Increase the separation between the equipment and receiver, 3) Connect the equipment into an outlet on a circuit different from that to which the
