Teletek electronics IRIS Assembly instructions

ANALOGUE ADDRESSABLE
FIRE PANEL
INSTALLATION AND
PROGRAMMING MANUAL

2 Addressable Fire Panel IRIS - Installation and Programming Manual
CONTENTS
1. INTRODUCTION.......................................................................................................................5
1.1 General Description ............................................................................................................................5
1.2 General Specications........................................................................................................................5
1.2.1  ....................................................................................................................6
1.2.2 ..................................................................................................................6
 .......................................................................................................................................6
1.2.4  .....................................................................................................................................6
2. INSTALLATION.........................................................................................................................8
2.1 Mounting ..............................................................................................................................................8
2.1.1  ....................................................................................................................................................8
2.1.2  ...................................................................................................................................9
2.2 System Components...........................................................................................................................10
2.2.1 .........................................................................................................................................................10
 .....................................................................................................................................10
.......................................................................................................11
............................................................................................12
..................................................................................................................................................13
...............................................................................................................14
 ...........................................................................................................................................15
.................................................................................................................................16
2.3 Main Board Schematic........................................................................................................................17
2.4 Network Connection Diagram.............................................................................................................17
3. PROGRAMMING ......................................................................................................................18
3.0 Basic knowledge for operating with LCD touch-screen display..................................................... 18
3.0.1  .......................................................................................................................................................18
3.0.2  .................................................................................................................................................18
3.0.3 ................................................................................................................................................18
3.1 Access Codes......................................................................................................................................19
3.2 Menu System-Programming...............................................................................................................21
3.3 Devices.................................................................................................................................................22
3.3.1  .............................................................................................................................................22
3.3.1.1 Physical Address of Periphery Device..............................................................................................................22
3.3.1.2 Current Status of the Device ............................................................................................................................22
3.3.1.3 Adding a new periphery device to the panel ....................................................................................................23
3.3.2  .....................................................................................................................................................24
3.3.2.1 Conrm Change Button....................................................................................................................................25
3.3.2.2 Device Enable/Disable Button..........................................................................................................................25
3.3.2.3 Module or Sensor Selection Button..................................................................................................................25
3.3.2.4 Address Navigation Button ...............................................................................................................................25
3.3.2.5 Loop Number Navigation Button ......................................................................................................................25
3.3.2.6 Zone Selection Button ......................................................................................................................................25
3.3.2.7 Device Current Status ......................................................................................................................................25
3.3.2.8 Button for Changing of the Device Current Status ...........................................................................................25
3.3.2.9 Change Device Type Status.............................................................................................................................25
3.3.2.10 Active Field for Text Introducing .....................................................................................................................25
3.3.2.11 Additional Settings Button...............................................................................................................................25
3.3.2.12 Maintained Loop Devices...............................................................................................................................27
3.4 Zones....................................................................................................................................................32
3.4.1 ...........................................................................................................32
3.4.2  .........................................................................................................32
3.4.3 ......................................................................................................................32
3.4.4  ...................................................................................................................................................32
3.4.5 ...............................................................................................................................................32
3.4.6 ............................................................................................................................32
3.4.7 ......................................................................................................................32
3.5 Inputs....................................................................................................................................................33
3.5.1  .........................................................................................................................................................33
3.5.2  ...........................................................................................................................33
3.5.3 ...........................................................................................................................................................33
3.5.4  ...............................................................................................................................33

Addressable Fire Panel IRIS - Installation and Programming Manual 3
3.5.5 ....................................................................................................................33
3.6 Outputs.................................................................................................................................................35
3.6.1  ............................................................................................................................35
.................................................................................................................35
3.6.3  ......................................................................................................................................................35
3.6.4  ........................................................................................................................35
3.6.5 .............................................................................................................................................35
3.6.6...........................................................................................................................................................36
3.6.7.............................................................................36
3.7 Panel.....................................................................................................................................................37
...................................................................................................................37
 ..............................................................................................................................................................38
3.7.2.1 Network Parameters Setting.............................................................................................................................38
3.7.2.2 Panels Menu.....................................................................................................................................................39
..........................................................................................................................................................40
..................................................................................................................................................40
................................................................................................................................................41
 ..............................................................................................................................................41
4. MAINTENANCE........................................................................................................................42
4.1 Menu System-Maintenace...................................................................................................................42
4.2 Time Setting.........................................................................................................................................42
4.3 Date Setting..........................................................................................................................................42
4.4 Daytime Mode......................................................................................................................................43
4.5 Outputs Delay Introducing .................................................................................................................44
4.5.1  ...................................................................................................................................................44
4.5.2 ...............................................................................................................................................45
4.5.3 ............................................................................................................................45
4.6 LOG-File Viewing.................................................................................................................................45
4.7 Testing..................................................................................................................................................46
4.8 Disabling ..............................................................................................................................................46
....................................................................................................................................47
.................................................................................................................................................47
..............................................................................................................................................48
4.9 Software Version.................................................................................................................................48
4.10 Display................................................................................................................................................48
..........................................................................................................................................49
 .........................................................................................................................................50
...........................................................................................................................50
5. USER INSTRUCTIONS.............................................................................................................51
5.1 Status Line...........................................................................................................................................51
5.1.1 .......................................................................................................................51
5.1.2  ........................................................................................................51
5.1.3  .............................................................................................................51
5.1.4  ..............................................................................................................51
5.1.5 .........................................................................................................51
5.2 Panel Status Icons...............................................................................................................................52
5.2.1  ................................................................................................................................................52
5.2.2 ........................................................................................................................................52
5.2.3 .....................................................................................................................................52
5.2.4 ..................................................................................................................52
5.3 Messages .............................................................................................................................................53
5.4 Access Level........................................................................................................................................53
5.5 Main Screen .........................................................................................................................................53
5.5.1 .......................................................................................................................................53
5.5.2  ......................................................................................................................................................53
5.5.3 .......................................................................................................................................53
5.5.4  ........................................................................................................................................53
5.5.5  ................................................................................................................................................53
6. APPENDIX ................................................................................................................................54

4 Addressable Fire Panel IRIS - Installation and Programming Manual
Guarantee
During the guarantee period the manufacturer shall, at its sole discretion, replace or repair any defective product when
it is returned to the factory. All parts replaced and/or repaired shall be covered for the remainder of the original guaran-
tee, or for ninety (90) days, whichever period is longer. The original purchaser shall immediately send manufacturer a
written notice of the defective parts or workmanship, which written notice must in all cases be received prior to expiry
of the guarantee.
International Guarantee
Foreign customers shall enjoy the same guarantee rights as those enjoyed by any customer in Bulgaria, except that
manufacturer shall not be liable for any related customs duties, taxes or VAT, which may be payable.
Guarantee Procedure
This guarantee will be granted when the appliance in question is returned. The manufacturer shall accept no product
whatsoever, of which no prior notice has been received.
Conditions for waiving the guarantee
This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its
normal use. It shall not cover:
• Damages resulting from transportation and handling;
• Damages caused by natural calamities, such as re, oods, storms, earthquakes or lightning;
• Damages caused by incorrect voltage, accidental breakage or water; beyond the control of the manufacturer;
• Damages caused by unauthorized system incorporation, changes, modications or surrounding objects:
• Damages caused by peripheral appliances (unless such peripheral appliances have been supplied by the
Manufacturer:
• Defects caused by inappropriate surrounding of installed products;
• Damages caused by failure to use the product for its normal purpose;
• Damages caused by improper maintenance;
• Damages resulting from any other cause, bad maintenance or product misuse.
In the case of a reasonable number of unsuccessful attempts to repair the product, covered by this guarantee, the
Manufacturer’s liability shall be limited to the replacement of the product as the sole compensation for breach of the
guarantee. Under no circumstances shall the manufacturer be liable for any special, accidental or consequential dam-
ages, on the grounds of breach of guarantee, breach of agreement, negligence, or any other legal notion.
Waiver
This Guarantee shall contain the entire guarantee and shall be prevailing over any and all other guarantees, explicit
or implicit (including any implicit guarantees on behalf of the dealer, or adaptability to specic purposes), and over any
other responsibilities or liabilities on behalf of the manufacturer.The manufacturer does neither agree, nor empower, any
person, acting on his own behalf, to modify or alter this Guarantee, nor to replace it with another guarantee, or another
liability with regard to this product.
Unwarranted Services
The manufacturer shall repair or replace unwarranted products, which have been returned to its factory, at its sole
discretion under the conditions below. The manufacturer shall accept no products for which no prior notice has been
received.
The products, which the manufacturer deems repairable, will be repaired and returned. The manufacturer has prepared
a price list and those products, which can be repaired, shall be paid for every repaired appliance.
The closest equivalent product, available at the time, shall replace the products manufacturer deems unrepeatable.
The current market price shall be charged for every replaced product.
ATTENTION!
This manual contains an information about the limitations in using and operation of the product, as and infor-
mation about the limits in the responsibility of the manufacturer.
Please read the operation manual carefully before starting the installation.
Whileevery efforthasbeen madeto ensurethat theinformation inthis manualis accurate
and complete, no liability can be accepted for any errors or omissions.
The manufacturer reserves the right to change the specications of the equipment
described in that manual without notice.
!

Addressable Fire Panel IRIS - Installation and Programming Manual 5
1. INTRODUCTION
1.1 General Description
IRIS is an analogue addressable re panel with maximum coverage of 96 zones and connecting 1 to 4 loops.
The panel supports two communication protocols: System Sensor series 200/500 (Loop SS) and Teletek
Electronics (Loop TTE) according the type of used devices. In the conguration of the IRIS panel can be
implemented both Loops SS and TTE at the same time.
An arbitrary number of devices can be added to each zone thus ensuring the easy adaptation of the system
to any type of conguration.
To avoid or signicantly diminish problems when mounting the system it must be carefully planned prior to
installation. This includes: establishing an address for every device and planning a name of maximum 40
digits (including the spaces) for each address, thereby ensuring easy access to the device.
According to the acting standards for establishing re systems and the plan of the building, the devices must
be grouped in zones.
Every Loop SS provides up to 99 detectors and 99 modules - “IRIS” Solution.
Every Loop TTE provides up to 250 devices (detectors and modules, regardless of the
type) - “IRIS light” Solution.
General view of the IRIS Fire Panel
1.2 General Specications
The front panel consists of color graphic LCD display (dimensions 240x320) with a built-in touch screen and
a light-emitting diode indication. Separate operator and engineer passwords provide access to the functions
of the panel. The internal space of the box is protected with the help of secret screws.
Up to four loop controllers, Loop SS and Loop TTE, can be supplemented to the mother board.
The system can be expanded by connecting several re panels IRIS to the Ethernet, using TCP/IP for
communication between them.
The panel has a built-in real time clock and calendar, allowing day and night time modes of work.
Switching over between the two modes can be automatic or manual. Events like FIRE, RESET, FAULT, etc.,
are saved in the memory, thereby creating an event log-le. It contains the time and date, the address of the
device, the type (module or detector), the name of the device, the zone, the name of the zone, etc.
!

6 Addressable Fire Panel IRIS - Installation and Programming Manual

• Loops - from 1 to 4 loops (Loop SS and/ or Loop TTE in a random combination)
• Up to 99 detectors and 99 modules per Loop SS
• Up to 250 devices (detectors and modules, regardless of the type) per Loop TTE
• Zones - 96 displayed zones
• Inputs - 4 programmable for volt-free Normal Open contact
• Monitored relay outputs - 4 (Sounder, Fire, Fault and Fire Protection)
• Non monitored relay outputs - 4 programmable, 230V/ 10A
• Display - 320x240 CSTN color graphic display (118.8 x 89.38 mm) with a touch panel
• Real time clock
• Up to 128 programmable Inputs/Outputs per panel
• Comprehensive day/night mode facility
• 2 Steps of alarm levels (T1 and T2)
• Based on Windows graphical conguration utility via Ethernet or USB
• Simple Http monitoring utility
• Loop less panel option (repeater)
• Thermal printer (optional)
• Flush mounting enclosure
• Multilanguage support
• Easy software update
• Compatible with the requirements of EN54-2/4

Maximum conguration:
- Main Board
- Power Supply Source
- LED-indication
- Input/Output Module
- 4 Relay Module
- 4 Loop Controllers (Loop SS and/ or Loop TTE)
- Modem
- Heat Printer (optional)

- Working Temperature: -10˚C up to +50˚C
- Relative Humidity: up to 95% (without condense)
- Storage Temperature: -10˚C up to +60˚C
- Weight (without the battery): 6kg.

Earth connection
The earth connection has to be realized in accordance with the rules for the electrical safety with the total
resistance in the circuit lower than 10Ω. It is mandatory to connect the main power supply cable to the middle
input of the re panel terminal - see .
Main power supply
In normal operating conditions the re panel is powered from the mains voltage line. In case of mains volt-
age line loss the re panel is equipped with one rechargeable battery. The characteristics of the main power
supply are as follows:
- Main Power Supply: ~230V ±10%
- Frequency: 50/ 60Hz
- Electrical output: 1A
ATTENTION: Do not instal the re panel near power electromagnetic elds (radio equip-
ment, electric motors, etc.)!
Minimum conguration:
- Main Board
- Power Supply
!

Addressable Fire Panel IRIS - Installation and Programming Manual 7
Battery Power Supply
- Voltage output (U): 13,8V
- Current output (I): 2A
- Number of the Batteries: 1, 12V/ 18Ah
- Battery Size: 167x181x76mm
- Type of the Battery connection: with a at terminal lug - Ø5mm (M5)
List of the fuses
- General Power Supply: 2A, T Type
- Outputs: 0,3A, PTC Type
- Battery: 7.5A, PTC Type
List of the additional components, included in the set of the re panel IRIS:
1. Resistor 10K ±5%, 0,25W 2
2. Anchor 6х30mm 4
3. Fuse 2А, T type 5x20mm (for the mains power supply) 1
4. Screw М4х40 Cross slot DIN7985 4
5. Screw М4х30 Cross slot DIN965 2
6. Screw М4,2х35 Cross slot DIN7981 4
7. Washer М4 DIN522 4
8. Cable tie 2,5/160mm 2
9. Plastic cap 21
The panel should be installed by qualied specialists only.
The electronic components of the panel are vulnerable to electrostatic discharge.
Never add or turn off components which are being power supplied!
!

8 Addressable Fire Panel IRIS - Installation and Programming Manual
2. INSTALLATION
2.1 Mounting
• The panel must be installed in a clean dry place and must not be subjected to impact or vibrations (Figure 1). It must
be situated far form heating appliances. The temperature must be within -5ºС and + 50ºC. The re panel is not water-
proof!
• Unscrew the two secret bolts situated above and under the box cover - see Figure 2.
• Remove the front cover as rst disconnect the at-cable for panel indication. After that unscrew the hinge bolts on the
side of the front panel - Figure 3. (Note: You can unscrew and the hinge bolts on the side of the metal box. The special
here is the presence of two plastic pads situated under the hinges. The pads have to be returned back under the hinges
at closing the front cover.)
• Choose inlets for the cables, and put plastic taps on those ones which you will not use.
Figure 1 Figure 2 Figure 3

• Use the template in the set to x the mounting holes of
the metal box on the wall - see Figure 4.
• Drill holes (suitable for anchors Ø6mm) on the wall and
x the metal box - see Fig 5.
• Route the external cables onto the back box, make off
connection glands etc., BUT DO NOT make any con-
nections at this stage. ENTER THE MAINS CABLE
THROUGH ITS OWN CABLE ENTRY POINT AND KEEP
MAINS WIRING AWAY FROM SYSTEM AND OTHER
LOW VOLTAGE WIRING.
• Connect the mains supply and earth to the power sup-
ply terminal (see Figure 17) BUT DO NOT apply the main
electrical supply at this stage.
• Position the battery in an upright position and x the
metal clamp - Figure 10.
Figure 4 Figure 5

Addressable Fire Panel IRIS - Installation and Programming Manual 9

• Analogue-addressable re panel IRIS is provided for ush mounting. The accessory set contains two special hangers
(see Figure 7) for ushed wall mounting of the re alarm panel on 25 mm thick drywall.
• Use given on Figure 6 dimensions to outline and to cut the mounting hole in the drywall.
• Fix the hinges on the back side of the gypsum plaster wall with the screws M4x30 cross slot DIN965 from the supplied
kit, as shown on Figure 7, Position 1.
• Route the external cables onto the back box, make off connection glands etc., BUT DO NOT make any connections
at this stage. ENTER THE MAINS CABLE THROUGH ITS OWN CABLE ENTRY POINT AND KEEP MAINS WIRING
AWAY FROM SYSTEM AND OTHER LOW VOLTAGE WIRING.
• Place the metal box in the mounting hole and x as use the washers M4 DIN522 and the screws M4x40 cross slot
DIN7985 - Figure 7, Position 2.
• Connect the mains supply and earth to the power supply terminal (see Figure 17) BUT DO NOT apply the main electri-
cal supply at this stage.
• Position the accumulator battery in an upright position and x the metal clamp - Figure 10.
Figure 6. Dimensions of the metal box Figure 7. Action sequence for ush
and the mounting hole. mounting.
Figure 8. Flush mounting holes.
Main view of the xed to the wall hinge and the bolts supporting the metal box.
HANGER
SCREWS FOR
HANGER FIXING
SCREWS FOR
FLUSH MOUNTING
METAL BOX
25mm THICK
DRYWALL
WASHER
HANGER
SCREWS FOR
HANGER
FIXING
WASHER
SCREWS FOR
FLUSH MOUNTING
METAL BOX
25mm THICK
DRYWALL

10 Addressable Fire Panel IRIS - Installation and Programming Manual
2.2 System components

Figure 9.
Main view of the front panel.

Figure 10. Conguration of the basic modules in the system.


GENERAL FIRE - General FIRE Indication
PREALARM - Indication for zones in Pre-Alarm Condi-
tion
GENERAL FAULT - General FAULT Indication
SYSTEM FAULT - General SYSTEM FAULT Indication
SYSTEM SILENCE - General Indication for Silenced
Sounders
DELAY - General Indication forActive Delay in any of
the Outputs
DISABLE - General Indication for introduced Disability
TEST - General Indication for Test
POWER ON - Presence of mains power supply 230V
AC
LED indication
for the events LED indication
for the zones
Heat printer
(option) LCD Display
(320x240)
Power Supply
Unit
Loop
Controller
1
Loop
Controller
2
Loop
Controller
3
Loop
Controller
4
4 Relay
Module
I/O Module
Accumulator
Battery
12V / 18 Ah
Clamp for supporting
the main power
supply cable.
Clamp for supporting
the main power
supply cable.
A slow type fuse 2A
situated into
the terminal.
Terminal for
connection
between the mains
power supply and
the power source.
Mains power supply opening.
Metal clamp for
supporting
the battery.

Addressable Fire Panel IRIS - Installation and Programming Manual 11

The I/O Module (Figure 11) is a basic part of the re panel IRIS, see the description of the terminals below. The 4 Relay
Module is integrated onto the I/O Module and has 4 relays with programmable relay outputs.
ATTENTION: The Main Board could not work independently.
Figure 11. I/O Module with integrated 4 relay module.
Description of the Outputs Module terminal:
• +24V - DC Auxiliary outputs, 20 VA @ 0,3A;
• GND - Common earth
• SND - Monitored output for connecting of a sounder, 24 VDC / 0,3 A;
• FIRE R, FIRE P - Monitored outputs for connecting of auxiliary devices (e.g. signalling devices), 24V / 0,3A.
These outputs are activated in case of a re alarm condition.
• FAULT R - Monitored output for connecting of auxiliary devices, 24V / 0,3A.
This autput is activated in case of system trouble ot fault.
Description of the 4 relay module terminal:
• REL1, REL2, REL3 and REL4 - Programmable volt free change over relay contacts each, 110V/ 1A. Each
relay has one NO (normal open) and one NC (normal closed) contact with common lead on a terminal. When a relay
output is activated the NO contact is closed and the NC contact is opened - see Figure 11b.
Other:
 - Ribbon cable interface connector to the front panel*;
 - Interface connector for connecting Loop Expander Module*;
 - Fuse 0,3A, type Resettable (on the back side of the I/O module);
- Mounting holes.
- Jumper for enable/disable indication for earth fault.
For example, if you want to enable the earth fault indication set a jumper on position 5.
The items and  are situated on the back side of the Outputs module PCB.
!
Input-output
Module
4 Relay Module
a)
b)







Metal clamp for
supporting
the battery.

12 Addressable Fire Panel IRIS - Installation and Programming Manual

The monitored outputs SND, FIRE R, FIRE P and FAULT R, at activation, provide
24VDC@0,3A to the load connected between them and GND (the earthing point of the
panel).
It is necessary to connect in parallel to the last device in the loop a 10k terminate resistor,
so to ensure that the panel is able to detect any break or short circuit in the loop - see
Fig. 12.
Figure 12. Example for connecting of end device (an illuminated exit sign)
to the Monitored FIRE Output.
To the monitored output SND could be connected several sounders - Figure 13. The maximum number of
sounders that could be connected in the circuit, depends on their total current consumption, which must not
exceed 0,3A.
Before connecting the last sounder in the circuit, parallel to it must be added resistor 10k.
Figure 13. Connecting of sounders.
!

Addressable Fire Panel IRIS - Installation and Programming Manual 13

The IRIS re panel operates with two loop controllers: Loop SS (System Sensor communication protocol) and
Loop TTE (Teletek Electronics communication protocol).
The Loop Controller (Figure 14) realizes the connection between the I/O Module and devices connected to
the communication line. The Loop Expander has two basic functions: 1. Gathers data from the devices in
the communication line and transfers it to the I/O Module; 2. Receives commands from the I/O Module and
transfers them to the devices connected in the communication line.
Every Loop SS provides up to 99 detectors and 99 modules.
Every Loop TTE provides up to 250 devices (detectors and modules, regardless of the type)..
The maximum current consumption of the devices in the communication line is Imax = 500mA. If the consump-
tion exceeds this value an over-load protection would be turned on.
In the conguration of analogue-addressable re panel IRIS could be mounted up to 4 loop controllers.
1 - Interface connector for connecting the Loop expander to the I/O Module.
2- Interface connector for connecting second loop expander.
Figure 14. General view of Loop Expander and an example for connecting devices to it.

First
Loop Expander
I/O Module Second
Loop Expander
1 - Connect the interface connectors of the rst and the second loop expanders.
2 - Fix the second loop expander with supplied bolts in the kit to the metal box of the re panel.
       
!
Figure 15. Connecting of a second loop expander in the re panel conguration.
The method of adding third and forth loop expander is analogical to that shown on Fig. 15.
Loop Controller
I/O Module First
Loop Expander Second Loop Expander

14 Addressable Fire Panel IRIS - Installation and Programming Manual

• Loop Controller “Loop SS”
The maximum length of the loop in the system could vary according to the cross-section and the ohmic resist-
ance of the used cable. To make possible identifying devices with identical addresses (double addresses) in
the system conguration, the cable resistance should not exceed denite calculated value. According to the
ohmic cable resistance, calculate:
· Formula 1: L C1MAX = 21 / RC · Formula 2: LC2MAX = 80 / RC,
Where:
LC1MAX and LC2MAX - are maximum permissible length of the used cable, [km];
RC- is total ohmic resistance of the two wires of the used able; its value shows the magnitude of the cable
resistance at length 1km [Ω/km].
If LCis the necessary length of the cable used in the loop, then:
· At LC ≤ LC1MAX - the re pane will be able to communicate with the devices in the circuit and also will
be able to identify the presence of double address.
· At LC1MAX < LC ≤ LC2MAX - the re panel will be able to communicate with the devices in the circuit
but will not be able to identify the presence of double addresses.
· At LC> LC2MAX - the re panel will not be able neither to communicate with the devices nor to identify
the presence of double addresses.

RC= 39 Ω/km, then
LC1MAX = 21 / RC = 21 / 39 ≈ 0,540km
LC2MAX = 80 / RC = 80 / 39 ≈ 2km
LC= 1km
In this case it is possible to use the chosen cable in the system, but the re panel will not be able to identify
devices with double addresses. If this could not satisfying the requirements of the system it must be chosen
cable with lower ohmic resistance RC.
• Loop Controller “Loop SS”
The maximum length of the loop in the system could vary according to the cross-section and the ohmic resist-
ance of the used cable.
To ensure the correct operation of the system is necessary to make some calculations in advance:
1. To ensure the ability of the re
panel to receive the signals from the
devices in the loop, calculate:
LC1max ≤ 123 / RC
2. To ensure the ability of the re
panel to recognize the double ad-
dresses in the system, calculate:
LC2max ≤ 62 / RC
3. To ensure the ability of the devices
in the loop to receive command sig-
nals from the panel, calculate:
LC3max ≤ (12 / Imax - Ri)/ RC
Where:
LC1MAX , LC2MAX and LC3MAX - are maximum permissible length of the used cable, [km];
RC- is total ohmic resistance of the two wires of the used able; its value shows the magnitude of the cable
resistance at length 1km [Ω/km];
RI- is the total resistance of the isolator modules in the loop;
Imax - is the maximum current consumption in the loop - total amount of the current consumption of all devices
in the loop.
( In case of using addressable base IRIS ligth B24A, the total amount for I includes: the maximal current con-
sumption in alarm mode of 15 devices with base IRIS ligth B24A, and for the rest of the devices with base IRIS ligth
B24A - the total consumption in stand-by mode.)
LCis the necessary length of the cable for the loop.

Addressable Fire Panel IRIS - Installation and Programming Manual 15
After calculating, the maximal length of the cable is determined according:
· If LC ≤ LC2max and LC ≤ LC3max - the re pane will be able to communicate with the devices in the
loop and also will be able to identify the presence of double address.
· If LC2max <LC ≤ LC1max and LC ≤ LC3max - the re panel will be able to communicate with the devices
in the loop but will not be able to identify the presence of double addresses.
ATTENTION:
Always calculate the maximal cable length according the mentioned above formulas!
IF LC > LC1max or LC > LC3max - the re panel would not be able to communicate with the devices.
The connection diagram shown on Figure 16, gives the possibility to protect devices against opening and
short-circuit. For example, short-circuit in section 2 will not inuence the operation of sections 1 and 3. The
isolator modules at the both ends of section 2 will isolate it, and section 1 and 3 will continue working properly,
as section 1 will operate by supply from the channel “A” and section 3 - by supply from channel “B”. Since
the re panel will not be able to communicate with the devices from section 2, it will generate an alarm signal
for lost devices and open circuit.
Isolator
module
Section 1
Protected
premises
Isolator
module
Isolator
module
Section 3
Protected
premises
Section 3
Protected premises
Figure 16. Example for connecting of detectors and call points to a loop expander.
The maximum number of devices between two isolator modules is 30!
!
!

16 Addressable Fire Panel IRIS - Installation and Programming Manual
 
Red LED for
indication of V.220
Black
Black
Yellow-green
Black
Black
Yellow-green
Fuse
F-Type
2
А
Main
Power
Source
LED-indication for the status
of Main Power Source.
Terminal block for
external power supply.
1
2
3
4
5
61
2
3
4
Figure 17. General view of the power source and the terminal.
LED-indication of the power source
LED Function Description
1AC LOSS Main power supply loss 220V.
2 Charger Fault Problem with the battery charging.
3BATT LOSS Battery loss.
4 BATT Low Discharged battery.
5EARTH FAULT Resistance to GND ≤ 10kΩ.
6 Rx / Tx Shows the communication with the panel.
Terminal Block for connecting to external power supply.
Terminal Function Description
1GND Input for connecting of external power supply EARTH.
2FAULT OUT Fault output, turns on when a problem with the main power supply
occurred. Connect it to the input (Fault In) of the external power
supply.
3FAULT IN Input for connecting the Fault output of the external power supply.
4+13.8V External power supply input.
Before the mains supply is switched on, check the correct connection of each loop, sounderor any
other input or output.
Black
Black
Red
LED indication for the status
of Main power source
Terminal block for
external power supply
Main
Power
Source
Fuse 2
AF type
Red LED for
220V indication
Black
Black
Yellow-green
Black Black Yellow-green

Addressable Fire Panel IRIS - Installation and Programming Manual 17

Figure 18. Connecting the accumulator battery to the main power source.
· Connect the red cable to the positive pole of the battery, and the black cable - to the nega-
tive battery pole. Both of the cables are connected to the battery by means of a at terminal lug
Ø5mm.
ATTENTION: The connection between the accumulator battery and the main power source has some spe-
cial features. It is strongly recommended to use only battery with electrical characteristics and dimensions
pointed from the manufacturer. Before connecting to the power source check the polarity of the battery. The
battery cannot power up the panel before the mains supply has been switched on. Connect the battery after
the mains supply is turned on. If the battery is new it will take a few hours before its complete charging!
The charging of the accumulator battery is done at maximum current I=2A and charging voltage U < 13,8V.
Sealed lead acid type
rechargeable battery
12V / 18Ah
Main
Power
Source
Red
Black

18 Addressable Fire Panel IRIS - Installation and Programming Manual
2.3 Main Board Schematics
The main board is situated on the back side of the front cover. On the main board is factory integrated a control module
- uPC Module, for control of the panel functions and operations.
ATTENTION: Adjustment on the main board can be done from an authorized personnel only!
Figure 19. Main Board with integrated Control Module.
Main board elements:
• Restore Defaults - Resetting the panels with default parameters.
• RS-232 - Serial interface
• LAN - Connecting to Ethernet network.
• USB - Mini USB connector.
• ±12V - Additional power supply.
• uPC Module !FAIL! - Yellow LED for uPC failure.
• uPC Module - Control module integrated to the Main board
• BUZ1/2 - Buzzers for sound signalization.
• Contrast - Adjusting the display contrast.
2.4 Network connection diagram
It is possible to connect some individual IRIS re panels in a network by means of a HUB and TCP/IP protocol - Figure
20. A supervisor PC, which could follow the current status of the individual re panels, monitors the current panel state.
Figure 20.
!

Addressable Fire Panel IRIS - Installation and Programming Manual 19
3. PROGRAMMING
3.0 Basic knowledge for operating with LCD touch-screen display
The touch-screen display of the re panel IRIS provides easy moving down the programming menus and
entering of system parameters. The access to the programming menus is done with light pressing of the
desired button. You can use also and a special pen for touch-screen display.
According to the chosen menu and/or the access level there are active and inactive buttons on the screen.
Choosing an active button leads to changing of the screen - you can move to a list of additional or submenus
for programming, or you can enter new parameters in the system.
3.0.1 
• Active Button -Pressingthebuttonyoucanperform
different operations: stop the sirens, reset the system
parameters or move to other programming menus.
• Inactive Buttons - The buttons do not respond
when pressed. The parameters denition elds are
also inactive. They just provide information of the
parameter type.
 The status of the buttons can alternatively
change (active-inactive) according the programming
menu and access level.
• Panel Status Icons - The icons give information
about the status of the re panel and the programmed
working mode. The icons are inactive if pressed.The
different re panel states are indicated with different
colour of the icon. The icons and their state are
described in item 5.2, page. 50.
• Used symbols
- Press the pointed button - Use a special pen for touch-screen display.
3.0.2 
When turned on, the panel always conducts a procedure of loading the parameters, which usually takes
about 30 sec. There is no access to the menus of the panel during that procedure.
Upon the initial start up, the panel does not hold any congurations. Initialization may take several minutes.
The initialization time needed depends on the number of periphery and loop devices. After the panel has
been turned on, it performs a procedure for detecting newly installed periphery and loop devices - see also
The APPENDIX E on page 58.
3.0.3 
The re panel IRIS can support different languages of the programming menus. The factory default setting of
the language is in English. You can change the language after the initial power-up as enter in sequence:
Access 1 → 3333 → OK → System → Programming → Panel → Languages →
→ Choose a language → Apply
After choosing the Apply button, you can return to the main screen by choosing the MENU button.
Date and time
information Panel Status Icons
Active
Buttons
Inactive
Buttons

20 Addressable Fire Panel IRIS - Installation and Programming Manual
3.1 Access Codes
To access the Programming and Maintenance Menus is necessary to enter a valid access code.
Fig. Screens 1.
There are 4 access codes programmed by default. The Installer/User can enter 3 access levels in the system.
The introduced code combinations are visualized with “*“ symbol.
Code
Number Code Combination Access Level Functions
1 0000 1 Only Silence Buzzer and Delay Override buttons are active.
It is not allowed to enter the Programming and Maintenance Menus.
21111 1
3 2222 2 System, Delay Override, Silence Buzzer, Silence Alarm, RESET and Evacuate buttons are active.
It is allowed to enter only a few Maintenance Menus.
4 3333 3 System, Delay Override, Silence Buzzer, Silence Alarm, RESET and Evacuate buttons are active.
It is allowed to enter both the Programming and Maintenance Menus
The entered code combination is conrmed by pressing the OK button. You can delete the entered digits by
pressing the CLR button. Exit from the access level is by pressing the LOG OUT or Esc button. The other
active buttons are general for all the menus and submenus and have the following functions:
EXIT - Step back to the previous menu or submenu;
MENU - Moves back to the Main Screen of the related access level.
All access codes could be viewed and edited in the “Access Codes“ submenu based in “Panels“ menu, see
also item 3.7.1, page 36.
Enter the access
code menu
