Copernicus iRover2 IFP550 User manual

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
1
TM
iRover2 Base Model for Interactive Flat Panels
IFP550
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at [e-mail].
Have your packing slip ready for reference.
WARNING
ŸThis product is meant to be assembled by an adult.
ŸIn its unassembled state, small parts present a hazard.
ŸTo be used under direct supervision of an adult.
ŸThis cart is intended for institutional use.
Warning – Supports a maximum screen size of 90”.
Warning – For use with flat panel screens weighing 250 lbs (113.4 Kg) or less. Use with heavier flat
panel screens may result in instability causing tip over resulting in death or serious injury.
Avertissement – Peut supporter une taille d'écran maximale de 90".
Avertissement – À utiliser seulement avec des écrans plats pesant jusqu'à 250 lb (113,4 kg) ou moins.
L'utilisation avec des écrans plats plus lourds peut causer une instabilité provoquant un basculement
qui risque la mort ou des blessures graves.
Shown with 65” Flat Panel (sold separately)

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
2
Dear Educator,
TM
Thank you for purchasing the iRover2 Base Model for Interactive Flat Panels. We hope it meets your expectations and
you and your students enjoy using it at your school.
Every day we see and hear stories of teachers going above and beyond to help students thrive. Thank you so much for all
you do – you are awesome, and you make a difference.
Thank you for inspiring us.
If you have any questions, concerns or ideas on how we can improve please let us know by contacting our Customer
Solutions Ninjas at 1-800-267-8494 or [email protected].
Happy teaching,
Kaylyn Belcourt, President
[e-mail]
We do not inherit the earth
from our ancestors, we
borrow it from our children.
- NATIVE AMERICAN PROVERB
Change is the end result of all
true learning.
- LEO BUSCAGLIA
What you leave behind is not
what is engraved in stone
monuments, but what is
woven into the lives of others.
- PERICLES
Education is the most
powerful weapon which you
can use to change the world.
- NELSON MANDELA
Need Support?
Have a Question?
Email Customer Service www.copernicused.com
Check out some of our
other great products!
For missing parts and other issues regarding your product:
Please contact Customer Service, where we will be happy to help.
Telephone: [phone], Monday - Friday 8:00am - 4:30 pm EST
Email: [e-mail]
My flat panel isn’t working, who should I call?
Please contact the reseller that you bought the product from.
Register your Product
Registering your warranty ensures we have all the information we need to make any future warranty claims quick
and easy. Please visit www.copernicused.com/warranty and complete the form within 10 business days from product
assembly. By registering your product, you will be entered into a draw to win Copernicus product.
Make a Warranty Claim
We offer a Lifetime Warranty on almost everything we make. Please call 1-800-267-8494 or email
[email protected]om to start your warranty claim. Proof of purchase will be required upon warranty claim (i.e.
copy of invoice).
Lifetime
Warranty
Customer Service & Warranty Information

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
3
Tips for Assembly
Before You Begin:
ŸLay out and identify all of the included parts.
ŸThe hardware has been packed according to together in one bag
ŸRead the assembly guide over once to familiarize yourself with them.
As You Assemble the Unit:
ŸFollow the steps in sequence.
ŸBefore beginning each step, find the part(s) that you need for that step.
ŸThe title of each step states what you will be doing. Review the text and the
pictures as you build the unit.
Please read the warnings below for important safety information regarding your product. Failure to read these
warnings or to follow the instructions below could result in personal injury or damage to your product that could
void your warranty.
Ensure that any cables extending across the floor to your product are properly bundled and
marked to avoid tripping or falling which may lead to personal injury.
Cable Trip
Hazard
Indoor Use
Only
This product is intended for indoor comercial use only. To reduce the risk of fire or electric
shock, do not expose this product to rain or moisture. The internal components are not
sealed from the environment.
In its unassembled state, this product contains parts that can be hazardous to small children.
This product should be assembled by an adult.
Small Parts
This product is to be used under the supervision of an adult.
Adult
Supervision
Read your power strip electrical specifications. Only plug in devices that are approved for
use with this power strip. Connect the supplied power strip directly to a wall outlet.
Do not connect to another power strip or use an extension cord. Turn off power strip
before unplugging. Unplug when not in use.
Power Strip
Specifications
Read the electrical specifications of any electronic equipment you are using with your
Copernicus products. Failure to read these specifications and follow their instructions could
result in damage to your equipment or personal injury.
Relocating audio and/or video equipment to furniture not specifically designed to support
audio and/or video equipment may result in death or serious injury due to the furnishing
collapsing or over turning onto a child.
Electronic
Equipment
Do not install or use the electrical components of this unit during a lightning storm.
Electrical
Shock
Climb
Hazard
Important Information! Warning!
The symbol denotes a
step needing extra
attention to ensure it is
done correctly.
Watch for These Helpful Symbols:
For safety, please have
someone help you when
working on steps
displaying this symbol.
2-Person Task
Death or serious injury may occur when children climb on audio and/or video equipment
furniture. A remote control or toys placed on the furnishing may encourage a child to climb
on the furnishing and as a result the furnishing may tip over on to the child. Do not climb on,
hang from or suspend objects from any components of your product unless otherwise
specified.

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
4
Contents IFP550-0
Before beginning, you should have:
Additional tools required:
Adjustable wrench (2x) OR +Screwdriver
Phillips #2 or #3
Laptop Tray
1x
(320832)
Mounting
Frame
1x
(33157)
Contents IFP550-1
Base Frame
1x
(51102)
Flat Panel Mount Riser
2x
(33149)
Flat Panel Mount Stretcher
2x
(33148)
PQ
M5 x 16mm
Screw
3x
M5 Square
Nut
3x
*Laptop Tray and
hardware packaged
together
20 lbs Weight Limit
Base Foot Right
1x
(33188R)
5” Caster
2x
(410066)
5” Locking
Caster
2x
(410065)
Base Foot Left
1x
(33188L)
>>> Hardware Inside This Box <<<
Hardware shown on next page
Parts

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
5
Before beginning, you should have:
Hardware:
3/8” x 1-3/4” Bolt
4x
(430204)
A
1/4” x 1-1/2” Bolt
4x
(4302060)
B
C
1/4” x ” Screw3/4
4x
(4300510)
D
L
M6 x 80mm Bolt
2x
(432210)
MM x 15mm8
4x
(432764)
M6 x mm15
4x
(432151)
F
M6 x 20mm
4x
(43222)
M8 x 25mm
4x
(432765)
#10-24 x 1/2” Self Tapping Screw
8x
(4302012)
3/8” Lock Nut
4x
(430122)
I
J
1/4” Lock Washer
14x
(43010)
1/2” Lock Washer
4x
(43010211)
K
5 16/ ” Lock Washer
4x
(43025)
G
H#10-24” Lock Washer
8x
(4301002)
Metric hardware for VESA Mounting
N O
Caster Wrench (not to scale)
1x
(32095S)
Allen Key 5mm (not to scale)
1x
(432811)
M8 x 40mm
4x
(432762)
3/4” Spacer
4x
(4303141)
PQ
Hardware
3/8” x 1-3/4” Bolt
6x
(430204)
A
1/4” x 1-1/2” Bolt
4x
(4302060)
B
C
1/4” Keps Lock
Nut
2x
(4301621)
Metric Hardware for Protective Handles
1/4” x ” Screw3/4 Self Tapping
6x
(4300510)
D#10-24 x 1/2” Self
Tapping Screw
8x
(4302012)
3/8” Lock Nut
6x
(430122)
I
1/4” Lock Washer
14x
(43010)
H
G
5 16/ ” Lock Washer
4x
(43025)
#10-24” Lock Washer
8x
(4301002)
F
E
Caster Wrench (not to scale)
1x
(32095S)
Double Sided Foam Tape
(not to scale)
2x
(700012)
Hook & Loop Straps
(not to scale)
6x
(433211)
1/2” Lock
Washer
4x
(43010211)
J
1/4” x 3-1/2” Screw
2x
(430091)
T
U1/4" Flat Washer
4x
(430192)

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
6
2
Install Casters
You will need: (Not to Scale)
Actual Size:
1
Assemble Base Frame
You will need: (Not to Scale)
Actual Size:
5” Caster
2x
Base Frame
1x
Base Foot Left
1x
Base Foot Right
1x
4x
B C
4x 4x 4x
5” Locking Caster
2x
2-Person Task
4x
2-Person Task
Install locking casters
on back of unit.
Tighten using supplied
Caster Wrench.
(Front)
(Back)
Caster Wrench
1x
Adjustable wrench (2x)
OR
Tip: Tighten
side bolts first
GI
K
K
K K
K
Screwdriver
Phillips #2 or #3
Holes on
this side
I
B
C
B
C
I
(Front)
U
4x
U
U
GG
Keep wrench with unit.
Casters must be tightened
every 6 months for proper
maintenance.

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
7
Installing Mounting Frame
3
You will need: (Not to Scale)
Actual Size:
Mounting Frame
1x
A
2x 2x
23”
33”
10”
Shown with 65” Flat Panel installed.
Measurements are approximate and will vary depending on your flat panel.
A
Choose Flat Panel Height
A
Secure Mounting Frame
B
Lowest Position
Highest Position
I
I
AI
10” of height
adjustment
upon assembly
Do NOT use these
bottom holes
Allen Key 5mm
1x
Remove appliance
tape from bushings
before installing
Mounting Frame

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
8
IJL N
O
4
Actual Size:
You will need: (Not to Scale)
4x 4x 4x 4x 4x
4x
M6x15mm M6x20mm M8x15mm
M8x25mm
Compatible flat panel
(sold separately)
1x
Flat Panel Mount Riser
2x
IJ
L M N O
Screwdriver
Phillips #2 or #3
(Showing 65” Flat Panel)
(4x)
ororor
or
(4x)
Check your flat panel owners manual to determine correct VESA screw size and torque specifications to
avoid causing damage to your flat panel.
4x
M8x40mm
P
or
4x
4x 4x
For TVs without a flat back (Ex. Promethean) use the provided
3/4” spacers and longer screws. Install spacers between mount and TV.
PQ
PQ
M
Center Risers
Vertically
on Flat Panel

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
9
5
You will need: (Not to Scale)
Actual Size:
Install Flat Panel Mount Stretchers
Flat Panel Mount Stretcher
2x
Screwdriver
Phillips #2 or #3
Do not secure in these
holes, they are used
for attaching an optional
soundbar mount
FH
8x 8x
H
F
H
F
H
F
H
F
H
F
H
F
H
F
H
F
Install screws in
holes with threads,
only 2 of 4 holes
will have threads
(Showing 65” Flat Panel)

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
10
6
You will need: (Not to Scale)
Actual Size:
Secure Flat Panel To Cart
4x4x
D
Screwdriver
Phillips #2 or #3
I
2-Person Task
Lock all casters
before attaching
flat panel to cart
D
I
Insert all 4 adapters
into keyholes.
A
BInsert all 4 Safety Screws

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
11
Laptop Tray
1x
7
Assemble Laptop Tray
You will need: (Not to Scale)
Actual Size:
8
Securing Your Device
You will need: (Not to Scale)
Actual Size:
3x 3x
20 lbs Weight Limit
Laptop Tray
1x
20 lbs Weight Limit
PQ
P
Q
Slide bracket
into slot
1
2
Lift up strap
Slide in your device
*Laptop not included

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
12
Stored Position on
Back of Cart
9
Attaching Laptop Tray To Cart
You will need: (Not to Scale)
Actual Size:
10
Final Assembly Checks
You will need: (Not to Scale)
Actual Size:
Check entire assembly for loose parts; tighten all casters, bolts, screws and nuts
Caster Wrench
1x
++
Adjustable wrench (2x)
OR
Screwdriver
Phillips #2 or #3
Tighten all casters using
supplied Caster Wrench.
Keep wrench with unit.
Casters must be tightened
every 6 months for proper
maintenance.
In-use Position on
Back of Cart
Laptop Tray
1x
20 lbs Weight Limit

IFP550 - Version A - Released June 16, 2022 - Copernicus Educational Products Inc.
13
Warning - When moving your flat panel cart
through a door ensure that the unit is shorter
than the height of the door.
IWB100
IWB102
1 2
Must be
lower than
doorway
ONLY ADULTS SHOULD
MOVE THIS UNIT
APPLY MOVING FORCE
ON NARROW
DIMENSION
NEVER APPLY FORCE AT
TOP - ALWAYS PUSH
NEAR MIDDLE
PUSH, DON’T PULL
Warning - Can tip over resulting in risk of injury.
Do not allow children under 16 to move cart.
Move cart slowly.
IWB100
IWB102
Always turn off and unplug the flat panel screen before moving.
Stow away laptop tray before moving.
