RECOMMENDED ACTION FOR FIELD MACHINES
!AT SETUP !NEXT SERVICE CALL
!NEXT PM )INFORMATION ONLY
TECHNICAL BULLETIN Ri 2530/3530
Bulletin #
Ri 2530/3530-01 Model Ri 2530/3530 Date 09/19/01
Affected Serial Number
From introduction
Subject NEW MODEL PRODUCT INFORMATION
In this Bulletin, you will find Specifications and relevant Technical Information concerning the All
New Ri 2530/3530 Digital Copier/Network Printer. The Ri 2530/3530 shares the same engine and
enhancement devices with the Printer version, the FS-9100DN/9500DN (see FS-
9100DN/9500DN Technical Bulletin #1 for more details). Some special features unique to the Ri
2530/3530 are as follows:
•The new Kyocera Mita designed, embedded
Print/Scan System (N) Controller
•Optional Fax System (C)
•32 MB standard RAM on base machine
•Various enhancement Devices.
1. DF-71 (3,000 sheet Finisher w/punch)
2. DF-75 (Saddle Stitch Finisher)
3. PF-70 (Dual 500 sheet Drawers)
4. PF-75 (3,000 sheet Drawer)
5. Enhanced SRDF-2
6. STDF-3 (2530 only)
(See Page 2 for a complete list)
•High Productivity
•Long Life Components
•Low Service Cost.
We recommend reading the Ri 2530/3530 Operation Guide to understand the full capabilities of
the Machine functions.
Training for the Ri 2530/3530 is available at our Regional Offices. The length of the class is 3 days.
Please contact your Regional Office to sign up for Training Certification.
If you have any additional questions, please contact the Copystar Diagnostic Center or email us at
[email protected].
Ri-2530

Ri 2530/3530-01
September 19, 2001
Page 2
SERVICE DOCUMENTATION
Description Part Number Price
Ri 2530/3530 Service Manual 2BH70950 $50.00
Ri 2530/3530 Parts List 2BH70940 $15.00
Ri 2530/3530 Operation Guide 2BH80020 $25.00
Ri-2530 PM List 8992BH55 $1.50
Ri-3530 PM List 8992BJ55 $1.50
Printing System (N) Operation Guide (Function Edition) Available on Dealernet Only N/C
Printing System (N) Operation Guide (Setup Edition) Available on Dealernet Only N/C
SRDF-2 Parts List 3C070770 $15.00
DF-35/71 Service Manual 3CG70760 $20.00
DF-71 Parts List 3CG70770 $15.00
DF-75 Service Manual 5FG70760 $25.00
DF-75 Parts List 5FG70770 $15.00
Ri 2530/3530 Parts Price List Available on Dealernet Only N/C
Note: The 2530/3530 Service Manual contains the AD-63, DF-78, J-1402, PF-70, PF-75, RA-1 and, Fax System C
Manuals.
The 2530/3530 Parts List contains the AD-63, DF-78, J-1402, PF-70, PF-75, RA-1, Fax System C, and
Printing System (N), Scan System (B) Lists.
ACCESSORIES
ITEM Part Number Description
Print/Scan System (N) 023CS513 Network Print Controller and Network Scanner
Fax System (C) 023CM503 Optional Fax capabilities
PF-75 00103255 3,000 Sheet Drawer
PF-70 023CF503 Dual 500 Sheet Drawers
AD-63 023CX500 Duplex Unit
J-1402 023B6500 Job Separator
SRDF-2 ¬023C0503 Auto Reversing Document Feeder
STDF-3 ¬023A7503 Auto Document Processor (2530 only)
DF-71 023CG103 3,000 Sheet Finisher w/Punch
M-2107 023AX100 Mailbox for DF-71
DF-75 00105034 Saddle Stitch Finisher
RA-1 023CP500 Reversing Adapter for DF-75
DF-78 023B5500 Internal Finisher
BC-1 87800130 Barcode Reader for Printer
PH-2A 5FG82010 Punch Unit for DF-75
HD-3 -87800194 Hard Drive for the Printer
Set Original Holder 2AV82040 Original Holder
AK-70C 3CG82010 Attachment Kit for DF-75 and DF-71
FM1-8MB ®3B182010 Optional Memory for Fax System
Stand 80080743 Stand
Staple Cartridge for DF-71 36882040 5,000 Pieces/Cartridge, 3 Cartridges/case
Staple Cartridge for DF-75 5GH82010 5,000 Pieces/Cartridge, 3 Cartridges/case
Staple Cartridge for DF-78 5AX82010 3,000 Pieces/Cartridge, 3 Cartridges/case
¬SIM 211 must be run on the Ri-2530 to select the Document Feeder being installed.
-HD-3 (Hard Disk) must be installed to enable Multi Set Printing and Finishing capabilities.
®Optional Fax System Memory Enables ultra fine mode.

Ri 2530/3530-01
September 19, 2001
Page 3
Ri-2530 CONSUMABLE YIELDS & COST PER COPY
Description Part Number Yield (Prints) Price CPC
Toner (1,900g) ¬370AB016 34,000
(Based on a 6%original) $105.17 0.003093
MK-705 -
(Maintenance Kit) 2BJ82020 400,000 $400.00 0.0010000
Drum Ass’y 2BJ93020 400,000
Parts Developer Ass’y 2BJ93010 400,000
Parts Fixing Ass’y 2BJ93040 400,000
(TR-700) Transfer Ass’y 84395575 400,000
¬The Toner Cartridge is exclusive to the Ri 2530/3530.
A Main Charger Cleaner and two Waste Toner Bottles are included with each Toner Kit.
-The Maintenance Kit contains the Drum Ass’y, Developer Ass’y, Fixing Unit and Transfer Ass’y.
Ri-3530 CONSUMABLE YIELDS & COST PER COPY
Description Part Number Yield (Prints) Price CPC
Toner (1,900g) ¬370AB016 34,000
(Based on a 6%original) $105.17 0.003093
MK-705 -
(Maintenance Kit) 2BJ82020 500,000 $400.00 0.000800
Drum Ass’y 2BJ93020 500,000
Parts Developer Ass’y 2BJ93010 500,000
Parts Fixing Ass’y 2BJ93040 500,000
(TR-700) Transfer Ass’y 84395575 500,000
¬The Toner Cartridge is exclusive to the Ri 2530/3530.
A Main Charger Cleaner and two Waste Toner Bottles are included with each Toner Kit.
-The Maintenance Kit contains the Drum Ass’y, Developer Ass’y, Fixing Unit and Transfer Ass’y.
The Maintenance Kits are warranted to be free of Manufacturer’s Defects for a period of 3 years from the
date of end user installation or the defined number of prints whichever should occur first.
All Replacement Maintenance Kits supplied for Warranty are warranted to be free of Manufacturer’s
Defects for a period of 3 years from the date of installation or the defined number of prints whichever
should occur first.
Note that this warranty is against manufacturer defects and does not cover problems caused by foreign
objects, improper use, or Non Copystar Toners.
To obtain Credit for either the Drum Ass’y, Developer Ass’y, Fixing Unit or Transfer Ass’y, return the Unit
with a Defective Parts Claim Form to the National Processing Center showing the original date of install
and proof of purchase.

Ri 2530/3530-01
September 19, 2001
Page 4
EP-ROM INFORMATION
File
Number
Description Location Check
Sum
Blank ROM
(See below)
2BJ29136 Main (Level 6H) Compact Flash
2BJ29143 MMI (Level 3E) Compact Flash
2BJ29152 Language (Level 2D) Compact Flash
Available on Dealernet
only
3CM68010 IC-ROM 1 Fax System C 98CB A
3CM68020 IC-ROM 2 Fax System C E501 A
3CG27011 IC-ROM DF-71 F9BC C
N/A IC-ROM DF-75 B438 B
Note: Ri 2530/3530 Firmware is only upgradeable via CompactFlash Card . The requirements are as follows:
Either a standard PCMCIA Type I & II slot, eFilm CompactFlash Type I & II Parallel Port Reader, or eFilm
CompactFlash Type I & II USB Port Reader are needed to copy firmware files to the CF Card. An 8MB or larger CF
Card can be used. These devices are available from Delkin Devices at: www.delkin.com.
BLANK EP-ROM INFORMATION
For dealers that download software updates from the Technical Web Site on Dealernet, we have included part
numbers for ordering blank EP-ROMS as follows:
Blank EP-ROM Description Part Number Price
AEP-ROM (4Mb) 40 Pin 120ns 84900054 $
BEP-ROM (1MB) 32 Pin 80ns 84900072 $
CEP-ROM (1MB) 32 Pin 100ns 84900020 $
If obtaining Blank EP-ROMS from a source other than the National Processing Center, please confirm that the
processing speed (ns) of the blank EP-ROM is equal to or higher than the number given in the chart above.
Operation problems can occur if the processing speed is a lesser value.

Ri 2530/3530-01
September 19, 2001
Page 5
NEW & REPAIR PRINTED CIRCUIT BOARDS
PCB NAME NEW PCB P/N REPAIR PCB P/N REPAIR PCB PRICE *
PCB Engine Ass’y 2BJ01010 8492BJ10 $
Power Source PCB 100 2BL28030 8492BL30 $
Desk PCB (PF-70) 3CF01011 8493CC10 $
Main PCB Ass’y (RA-1) 3CP01011 8493CP10 $
PBA CONT (PF-75) 5FF07100 8495FF00 $
Main PCB (DF-78) 3B501014 8493B510 $
Main Ass’y Fax 3CM01020 8493CM00 $
PCB Main Ass’y
(Printing System N) 3CR01010 8493CR00 $
Scanner NIC Ass’y
(Scan System B) 3B301010 8493B300 $
Parts Driver PCB SP (SRDF-2) 3AL93020 8493AL20 $
Part numbers and pricing subject to change without notice.
Defective PCB’s being returned within the 1-Year warranty period must be returned to the National Processing
Center utilizing a Defective Parts Claim Form. Any associated mounting brackets, hardware, system software and
original packaging must be included with the claim. Credit will then be issued to your account.
Defective PCB’s out of warranty may be returned for repair to the National Processing Center using the Printed
Circuit Board Repair Form.
During the 1-year initial warranty period, boards that are replaced under warranty will be warranted for a minimum
of 90 days from the day of installation.
Example: If a Board is replaced under warranty on day 360 of the 1-Year initial warranty period, the board will still
be warranted for an additional 90 days from the date of its installation.
*Repair PCB Price includes credit issued after return of old Board.
PREVENTATIVE MAINTENANCE
Ri 2530 PM CYCLE Ri 2530 MAX MONTHLY VOLUME
400K prints 85K prints
Ri 3530 PM CYCLE Ri 3530 MAX MONTHLY VOLUME
500K prints 120K prints
Information is subject to change without notice.

Ri 2530/3530-01
September 19, 2001
Page 6
Ri 2530/3530 Machine Specifications
Type...............................................Desktop
Copying system..............................Indirect electrostatic system
Originals.........................................Sheets and books
Maximum size: 11" x 17"
Original feed system ....................... Fixed
Copy paper.....................................Drawer: Plain paper (17~21lb.)
Bypass table: Plain paper (16~53lb Bond, 53lb. Bond = 110lb. Index)
Special paper: Transparencies, tracing paper, colored paper, letterhead and envelopes (when
using the printer function only)
Note: Use the bypass table for special paper.
Copying sizes .................................Maximum: 11" x 17"
Minimum: 51/2" x 81/2" (When the bypass table is used)
Magnification ratios .........................Manual mode: 25 – 400%, 1% increments
Auto copy mode: fixed ratios
Inch
1:1 ± 1.0%, 1:4.00/1:2.00/1:1.29/1:1.21/1:0.78/1:0.64/1:0.50/1:0.25
Copy speed ....................................At 100% magnification in copy mode:
25 cpm copier
11" x 8 1/2": 25 copies/min.
11" x 17": 15 copies/min.
8 1/2" x 14": 18 copies/min.
81/2" x 11R": 20 copies/min.
35 cpm copier
11" x 8 1/2": 35 copies/min.
11" x 17": 19 copies/min.
81/2" x 14": 23 copies/min.
8 1/2" x 11R": 25 copies/min.
First copy time................................ From 3.9s (11" x 81/2")
Warm-up time ................................60s or less (room temperature 20°C/68°F, 65% RH)
In preheat/energy saver mode: 30s or less (room temperature 20°C/68°F, 65% RH) [priority to
power save]
In preheat/energy saver mode: 10s or less (room temperature 20°C/68°F, 65% RH) [priority to
recovery]
Paper feed system..........................Automatic feed
Capacity:
Drawers: 500 sheets x 2 (standard)
Manual feed
Capacity:
Bypass: 200 sheets
Continuous copying ........................ 1 - 999 sheets
Photoconductor ..............................a-Si (drum diameter 40 mm)
Charging system............................. Single positive corona charging
Exposure light source......................Semiconductor laser
Exposure scanning system .............Polygon mirror
Developing system..........................Dry, reverse developing (magnetic brush)
Developer: mono-component toner
Toner replenishing: automatic from a toner container
Transfer system.............................. Transfer roller
Separation system..........................Separation electrode
Fixing system .................................Heat roller
Heat source: halogen heaters (120 V specifications: main 600 W, sub 400W)
Control temperature: 165°C/329°F (at normal ambient temperature)
Abnormally high temperature protection device: 170°C/338°F thermostat
Fixing pressure: 107.8 N
Charge erasing system...................Exposure by cleaning lamp
Cleaning system.............................Cleaning blade
Scanning system............................Flat bed scanning by CCD image sensor

Ri 2530/3530-01
September 19, 2001
Page 7
Ri 2530/3530 Machine Specifications (continued)
Bit map memory ............................. 9 MB (standard)
Image storage memory ................... 23 MB (standard)
......................................................32 MB total on Main Board
Resolution ......................................600 x 600 dpi
Light source....................................Inert gas lamp
Dimensions..................................... 23" (W) x 25 2/5" (D) x 29 1/3" (H)
Weight ...........................................Approx. 165 lbs.
Floor requirements ......................... 53 3/8" (W) x 25 2/5" (D)
Power source.................................120 V AC, 60 Hz, 11 A
Power consumption ........................ 1320 W (120V)
Options........................................... STDF-3*, SRDF-2, paper feed desk, large paper deck, duplex unit, job separator, finisher,
booklet stitcher, built-in finisher, key counter, fax board, printer board, network printer board,
network scanner board
*Optional for 25 cpm copier only.
AD-63 Specifications
Type...............................................Enclosed
Paper .............................................Plain paper: (21lb.)
Special paper: colored paper
Paper sizes.....................................11" x 17" – 5 ½ " x 8 ½"
Power source.................................Electrically connected to the copier
DF-78 Specifications
Type...............................................Built-in
Number of trays..............................1 (intermediate tray)
Stapling limit...................................11" x 8 ½ " or smaller: 30 sheets
Other sizes than above: 20 sheets
Power source.................................Electrically connected to the copier
Weight ...........................................Approximately 24.2 lbs.
PF-70 Specifications
Paper .............................................Plain paper (21lb.)
Paper size......................................11" x 17" – 5 ½ " x 8 ½ "
Capacity.........................................500 x 2 sheets
Power source.................................Electrically connected to the copier.
Dimensions..................................... 23 1/16" (W) x 23 1/4" (D) x 12 3/8" (H)
Weight ...........................................55 lbs.
PF-75 Specifications
Paper .............................................Plain paper (21lb)
Paper size......................................11" x 8 1/2"
Capacity.........................................3000 sheets (1500 sheets x 2)
Power source.................................Electrically connected to the copier
Dimensions .................................... 23 1/16" (W) x 23 1/4" (D) x 12 3/8" (H)
Weight ...........................................77.2 lbs.

Ri 2530/3530-01
September 19, 2001
Page 8
J-1402 Specifications
Type...............................................Enclosed
Tray capacity..................................100 sheets of 9.3~43lb paper
Paper .............................................Plain paper: 21lb.
Special paper: colored paper
Paper sizes.....................................11" x 17" – 5 ½ " x 8 ½ "
Power source.................................Electrically connected to the copier
Weight ...........................................Approximately 2.21 lbs.
SRDF-2 Specifications
Original feed system ....................... Automatic feed
Originals.........................................Sheets
Original weights.............................. Single-sided original mode, 9.3~43lb. Bond
......................................................Double-sided original mode, 13~32lb. Bond
Original paper .................................Plain paper, thermal paper, art paper, colored paper
Original sizes.................................. (11" x 17" – 5 ½ " x 8 ½ ")
No. of originals................................ Up to 70 sheets (11" x 17", 8 ½ " x 14")
......................................................Up to 100 sheets (11" x 8 ½ ") 13~21lb.
......................................................Art or thermal paper must be fed individually.
......................................................Power source Electrically connected to the copier.
DF-75 Specifications
Stacking......................................... 2 Locations
......................................................Delivery Tray (descending type; 1 tray
......................................................Face Down
......................................................Bind Tray (fixed type)
Feed reference...............................Center reference
Stack paper size.............................(11” × 17”), LGL, LTR, LTR R STMT, STMTR
Paper weight................................... Finisher assembly: 17~24lb.
......................................................Saddle Assembly: 17~24lb.
Mode.............................................. Non-sort stack
......................................................Sort stack
......................................................Staple stack
......................................................Bind stack
Stack height (Note 1)...................... Non-Sort Staple
......................................................Large-size: 500 sheets
......................................................Small-size: 1000 sheets (Note 2)
......................................................Staple Sort
......................................................Large-size: 30 sets or 500 sheets
......................................................Small-size: 30 sets or 1000 sheets
......................................................Folded stack
......................................................Stack of 6 to 10 sheets: 10 sets
......................................................Stack of 1 to 5 sheets: 20 sheets
Mixed stack....................................Size mix: 500 sheets (Note 3)
......................................................Staple mix: 30 sheets (same paper configuration)
Paper detection...............................Delivery tray: No
Control panel .................................. Bind tray: Yes
......................................................No
Note 1:
The number of sheets is computed based on 21lb. Paper.
Note 2:
Alignment is not guaranteed if the stack consists of 750 sheets or more.
Note 3:
Alignment is not guaranteed if the stack consists of sheets of different sizes.

Ri 2530/3530-01
September 19, 2001
Page 9
DF-75 Specifications (continued)
Display ...........................................No
Size................................................26.18(W) × 24.21(D) × 21.85(H)
Weight ...........................................59.40 lb. (approx.)
Power supply.................................. 24 VDC from host machine
Maximum power consumption......... At standby: 13 W
......................................................In operation: 84 W (staple sort)
Stapling.......................................... Rotary cam type
Stapling position.............................. See F01-201-01
Stapling thickness........................... Finisher
......................................................Large-size: 25 sheets
......................................................Small-size: 50 sheets
......................................................Saddle: 10 sheets
Staple supply..................................Cartridge of special staples (5000 staples)
Staples...........................................Special staples
Staple detection..............................Yes (nearly empty: 40 remaining staples)
Stapling size...................................Front 1-Point Stapling:
......................................................(11” × 17”), LGL, LTR-R
......................................................Rear 1-Point Stapling:
......................................................(11” × 17”), LGL, LTR, LTR-R
......................................................Middle 2-Point Stapling: With Saddle in use
......................................................(11” × 17”), LGL, LTR, LTR-R
......................................................Middle 2-Point Stapling:
......................................................(11” × 17”), LGL, LTR, LTR-R
Manual stapling............................... None
Folding method............................... Roller contact
Folding mode.................................. Double-folding (single-sheet non-stapling available)
Folding position............................... Middle of sheet Requires a margin of±5mm / ±0.2in from the
......................................................middle of the sheet as a middle margin. No Special Paper.
Saddling size.................................. (11” × 17”), LTR R
DF-71 Specifications
Type ..............................................Floor standing
Number of trays .............................Sort tray: 1
......................................................Non-sort tray: 1
Tray capacity ................................. Sort tray (20~21lb. paper)
......................................................When not stapling:
......................................................1500 sheets: 11" x 17", 8 ½ " x 14"
......................................................3000 sheets: 8 ½ " x 11", 11" x 8 ½ "
......................................................When stapling 2 sheets:
......................................................450 sheets: 11" x 17"
......................................................600 sheets: 8 ½ " x 14"
......................................................700 sheets: 8 ½ " x 11"
......................................................850 sheets: 11" x 8 ½ "
......................................................When stapling 3 or 4 sheets:
......................................................400 sheets: 11" x 17"
......................................................700 sheets: 8 ½ " x 14"
......................................................750 sheets: 8 ½ " x 11"
......................................................800 sheets: 11" x 8 ½ "
......................................................When stapling 5 to 10 sheets:
......................................................500 sheets: 11" x 17"
......................................................800 sheets: 8 ½ " x 14"
......................................................900 sheets: 8 ½ " x 11", 11" x 8 ½ "
......................................................When stapling 11 to 20 sheets:
......................................................950 sheets: 11" x 17"
......................................................1000 sheets: 8 ½ " x 14"
......................................................1200 sheets: 8 ½ " x 11", 11" x 8 ½ "

Ri 2530/3530-01
September 19, 2001
Page 10
DF-71 Specifications (continued)
......................................................When stapling 21 to 29 sheets:
......................................................1400 sheets: 11" x 17"
......................................................1500 sheets: 8 ½ " x 14"
......................................................When stapling 21 to 49 sheets:
......................................................3000 sheets: 8 ½ " x 11", 11" x 8 ½ "
......................................................When stapling 30 sheets:
......................................................1500 sheets: 11" x 17", 8 ½ " x 14"
......................................................When stapling 50 sheets:
......................................................3000 sheets: 8 ½ " x 11", 11" x 8 ½ "
......................................................Non-sort tray:
......................................................150 sheets: 11" x 17", 8 ½ " x 14"
......................................................250 sheets: 11" x 8 ½ ", 8 ½ " x 11"
Stapling limit ..................................30 sheets: 11" x 17", 8 ½ " x 14" (20~21 lb.)
......................................................50 sheets: 11" x 8 ½ ", 8 ½ " x 11" (20~21 lb.)
Power source ................................Electrically connected to the copier
Dimensions ....................................27 1/8" (W) x 23 9/16" (D) x 41 1/2" (H)
Weight . ......................................... Approx. 110 lbs.
Noise and Ozone Levels
Noise.............................................. Pursuant to JIS Z-8731 (acoustic pressure level, equivalent noise)
(1) Stand-by ...................................35db Fan Motor Rotating
(2) During warm-up.........................55db
(3) During Copying..........................Main Body 60db
......................................................Main Body + SRDF 65db
......................................................Main Body + SRDF+ Finisher+6
......................................................65db
Ozone Generation...........................Average Value 0.1ppm or less
......................................................Max. Value 0.3ppm or less
•All Specifications subject to change without notice.

Ri 2530/3530-01
September 19, 2001
Page 11
Print/Scan System (N) Specifications (Optional Printer Scanner Kit)
Type CPU.......................................POWER PC 750 350MHz
System ROM..................................4MB Flash (DIMM Slot Type)
Font ROM ...................................... 4MB (SOP Type, mask number: 713)
Main RAM ......................................SDRAM
Standard:........................................ 32MB
Option: ...........................................16 ~128 MB ×2 slots
100pin-DIMM..................................(16, 32, 64, 128MB)
Network Connection........................100Base-TX, 10 Base-T
Interface.........................................Ethernet
Drivers ...........................................Windows 95/98, NT 4.0, Macintosh
Protocols........................................TCP/IP, IPX/SPX, and AppleTalk
Network OS....................................Workstation 9x/Me/NT-4/2000/Mac
Resolution ......................................Fast 1200, 600dpi without smoothing, 300dpi
Print Size .......................................11 x 17, 8.5 x 14, 11 x 8.5, 8.5 x 11R, 5.5 x 8.5R, envelopes
Print Speed (KM-2530)...................One-sided 11 x 8.525 +1.4, -0.5 sheets per min.
...................................................... 11 x 17 15 +1.4, -0.5 sheets per min.
...................................................... 8.5 x 14 18 +1.4, -0.5 sheets per min.
Print Speed (KM-3530) .................. One-sided 11 x 8.5 35 +1.4, -0.5 sheets per min.
...................................................... 11 x 17 19 +1.4, -0.5 sheets per min.
...................................................... 8.5 x 14 23 +1.4, -0.5 sheets per min.
Print Description Language............. Prescribe2e
Emulation .......................................PCL6 (5e, XL, PJL), KPDL3 (Postscript compatible), Line Printer, IBM Proprinter X24E,
......................................................Epson LQ-850, Diablo 630, KC-GL, AES Support
Fonts..............................................Online Fonts 80 Fonts (PCL6)
......................................................136 Fonts (KPDL3)
......................................................Bitmap Fonts 1 Font
Scan System Specifications
Type...............................................PPC Network Scanner Option
......................................................Scanner NIC (NS-30)
......................................................Clock PCB
......................................................CD-ROM (Scanner Library)
......................................................CD-ROM (Paper Port)
Supporting Models..........................Ri 2530/3530
Basic Function................................Network Scanner (B/W)
......................................................PC Transmission (with Scanner File Utility)
......................................................E-mail Transmission
......................................................TWAIN Scan (with TWAIN Source)
Interface Card................................. NS-30
Interface.........................................10BaseT, 100BaseT (auto recognition)
Protocol..........................................TCP/IP
Resolution ......................................Main scan x sub scan 600 x 600
......................................................Switching section 600/400/300/200dpi
Original Scanning Speed (with DF).. KM-2530 25 ppm
......................................................KM-3530 35 ppm
Attached Application ....................... Paper Port Deluxe 6.5
Transmission Size ..........................11”×17”, 11”×15”, 8.5”×14”, 8.5”×11”, 5.5”×8.5”
Gradation Level:..............................
Text Mode ......................................2 tones / 1 dot, 256 gradations (error diffusion)
Photo Mode....................................2 tones / 1 dot, 256 gradations (error diffusion)
Mix (text and photo mode)............... 2 tones / 1 dot, 256 gradations (error diffusion)
OCR mode..................................... 2 tones / 1 dot, 2 gradations
Multiple Scanning............................Max. 250 pages
Transmission Setting:
Transmission Mode.........................Send to PC/Send to e-mail/TWAIN scan

Ri 2530/3530-01
September 19, 2001
Page 12
Scan System Specifications (continued)
Send from Selection........................ Max. 40 destinations, password check available
Destination selection :
(when sending to PC)
Shared address book ..................... Max 100 destinations
......................................................Password check available
......................................................Multiple selection: max. 20 destinations
......................................................Possible to search address from the initial letter
Personal Address Book................... Max. 100 destinations
......................................................Share address book, Max 100 destinations
......................................................Password check available
......................................................Multiple selection: max. 20 destinations
......................................................Possible to search address from the initial letter
Save to User PC............................. Possible
Destination selection:
(when sending to e-mail)
Shared address book...................... Max 100 destinations
......................................................Multiple selection: max. 20 destinations
......................................................Possible to search address from the initial letter
Personal Address Book................... Max. 100 destinations
......................................................Multiple selection: max. Destinations
......................................................Possible to search address from the initial letter
Direct Address Input....................... Use Keys on touch panel
Fax System (C) Specifications (Optional Fax Kit)
Product name.................................FAX System (C)
Type...............................................(a) FAX board
......................................................(b) Power source board for FAX
......................................................(c) NCU
Memory
Type:..............................................Standard memory board
Bitmap memory: .............................Capacity: Standard: 4MB
......................................................(For transmission 2MB/for reception 2MB)
......................................................Max: 8MB
......................................................(for transmission 4MB/for reception 4MB)
......................................................Common use: Only for FAX
Image storage:................................Capacity: Standard 4MB(work memory: Approx. 1MB)
......................................................Max: 8MB
......................................................Common use: Only for FAX
Number of slot for add-on memory: .one
Type of add-on memory: ................. M1-8MB
......................................................(Bitmap 4MB + image storage 4MB)
Telephone Handset......................... Option
Telephone unit:............................... One-piece phone
Select signal:..................................10pps, 20pps, DTMF
Line connection:..............................Modular connector
Transmission size........................... Width Metric: 148 297 mm
...................................................... Inch: 140 279 mm
......................................................Length 148 ~1600mm
Resolution: .....................................normal mode transmission
Size of recording paper ...................inch:11”×17”R 5.5”×8.5”R
Phone lines.....................................Subscriber lines
Number of transmission lines .......... One
Compatible with.............................. G3
Transmission mode.........................Half-duplex

Ri 2530/3530-01
September 19, 2001
Page 13
Fax System (C) Specifications (continued)
Modulation......................................TCM, QAM, PhM
Coding............................................ MMR, MR, MH, JBJG
......................................................JBIG is applicable by the running change
Transmission speed........................ 33.6/31.2/28.8/26.4/24.0/21.6/19.2/16.8/14.4/
......................................................12.0/9.6/7.2/4.8/2.4 (KBPS)
Minimum transmission time............. Normal: 10 ms/line
Fine: 5ms/line
Transmission time...........................Less than 3 sec.
......................................................(Measurement condition)
......................................................Kyocera Mita ITU-T #1 original,
......................................................Memory transmission (ECM),
......................................................Resolution:normal, no JBIG, TTI
......................................................Exposure level: center
Short protocol.................................Kyocera Mita proprietary (Transmission between Kyocera Mita machines
......................................................with short protocol, excluding V.34 transmission.)
Pre-procedure:................................Less than 5 sec.
Post-procedure: .............................Less than 3 sec.
Quick scanning...............................Less than 2 sec./sheet•11”×8.5”
......................................................[Measurement condition]
......................................................Kyocera Mita ITU-T #1 original,
......................................................Memory transmission (ECM),
......................................................Resolution:normal, Exposure level: center
......................................................When bitmap is available
Modem
Transmission mode V34 V17 V29 V27ter
Modulation method TCM TCM QAM PhM
Transmission speed (bps) 33600, 31200
28800, 26400
24000, 21600
19200, 16800
14400,12000
9600, 7200
4800, 2400
14400
12000
9600
7200
9600
7200 4800 2400
Speed variation ±0.01% ±0.01% ±0.01% ±0.01%
Modulation speed (bps) 3429, 3200
3000, 2800
2400
2400 2400 2400
1600
Low HighCarrier frequency (Hz) 1800
1680
1600
2000
1867
1800
1700 1700 1800
Frequency variation ±0.01% ±0.01% ±0.01% ±0.01%
Detection Synchronous
Automatic equalization Yes
Tonal signal name CNG, CED
Tonal signal frequency 1100Hz, 2100Hz
Modem signal detection level
range -9 to -43dBm 0 to -43dBm
Output level 0dBm or less to -15dBm or less

Ri 2530/3530-01
September 19, 2001
Page 14
2530/3530 Memory Management (Main PCB)
The Ri 2530/3530 has two slots on the Main PCB (See Chart Below) with one standard 32MB
DIMM. It uses 9 MB of Bitmap memory for both scanning and printing. 23MB is used for image
storage. One 128MB DIMM can be added for a total of 160MB of Memory.
STORING CAPACITY OF PAGE MEMORY
Location Capacity Total
Memory
Approximate # of pages that can be
stored (6% original)
Slot 1 32MB (standard) 32MB Approx. 122
Slot 2 128MB (Upgrade) 160MB Approx. 802
Printing System (N) Printer Board Memory
The Printer Board has two slots (See Chart Below) with one standard 32MB DIMM. The Printer
Board is upgradeable with two 128MB DIMMs for a total of 256MB of Memory.
STANDARD MEMORY
Slot 1 Slot 2 Total Memory
32MB (standard) Empty 32MB
UPGRADEABLE
Slot 1 Slot 2 Total Memory
128MB 128MB 256MB
Optional Memory (DIMMs) can be purchased from Delkin Devices at www.delkin.com or:
TechWorks
4030 W Braker Lane #350
Austin, Texas 78759
Sales Department
[phone] (voice)
[phone] (fax)
www.techworks.com

Ri 2530/3530-01
September 19, 2001
Page 15
Ri 2530/3530 Option Chart
Note: The DF-71 and DF-75 require the Attachment Kit (AK-70C).
It is not possible to install a DF-78 with a DF-71 or DF-75 attached.
It is possible to install a J-1402 with a DF-71or DF-75.
