CORBERO CCSF5222GF User manual

CHIMNEY HOOD
[EN] SAFETY, INSTALLATION and OPERATING MANUAL
CCSF5222GF
CCSF5222GFW
CCSF5222GFN

EN
2

EN
3
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE
Please first read this manual!
Dear Customer,
Please read this manual thoroughly prior to using the product and keep it for
reference purpose. If you transfer the product to another person, give the
manual as well.
The manufacturer will not accept any responsibility for any damage or fire
caused by possible problems arising from failure to comply with the
instructions given in this manual.
Please contact with the authorized service center for all questions.
Operating manual help you use the product correctly and safely.
Read the operating manual prior to setting up and operating the product.
Comply with the safety-related instructions definitely.
Please keep the operating manual in a handy place for any possibleneed.
Read other documents given together with the product as well.
Please remember that the present operating manual may also apply for other
versions. There may be differences among the versions due to different
manufacturers, but the cleaning and maintenance conditions are same.
: General Warning : Fire Warning : Electric Warning

EN
4
TECHNICAL SPECIFICATIONS OF THE EQUIPMENT………………………………….…5
WARNING AND SAFETY PRECAUTIONS………………………………………..…………..8
INSTALLATION AND ACCESSORIES……………………………………………………………14
INSTALLATION OF THE HOOD…………………………………………………………………..15
OPERATING AND USE OF THE HOOD………………………………………..………………20
CLEANING AND MAINTENANCE……………………………………………..………………...22
SERVICE, SPARE PARTS AND WARRANTY………………………………..………………..25
CONTENT

EN
5
OVERALL VIEW
TECHNICAL SPECIFICATIONS OF THE HOOD
Product Components
1. Body
2. Control PAnel
3. Filter
4. Front Panel
5. Lighting
(Figure 1)

EN
6
(Figure 2)

EN
7
TECHNICAL SPECIFICATIONS
Voltage & Frequency
220-240Vac 50Hz
Total product power
Min. 2W- Max. 102W
Motor power
100W
Lamp power
2 x 1W
Control Panel
3-Speed
Air outlet connection
diameter
Ø120mm
Product width
525 / 530 mm
Product depth
275 mm
Product height
202,5 / 206 mm

EN
8
This product is designed for domestic use as a version to exhaust or filter
the air. It is not designed for operating outdoors.
Warning: This product may be used for children above 8 years old and by
persons with restricted physical, perceptual or mental skills only if they are kept
under supervision or given instructions for safety use of the product and they are
well aware ofthe product-related risks. Children should not play with the product. If
they are not above 8 years old and under supervision, cleaning and maintenance of
the product should not be performed by the children. Keep the product and its cable
in a place out ofreach of the small children under 8 years old.
When the electric range hood is simultaneously used with other equipment
using gas or other fuels, the room should be ventilated well (It may not be
applicable for equipment which only recirculate the air in the room).
Keep the packaging materials in places out of reach of the children or
destroy them. Access to the packaging materials by the children may lead to
dangerous consequences.
Unless there is no supervision and management with respect to use of the
product by a person responsible for safety of the product, this product is not
intended to be used by persons (including children) who are restricted physical,
sensual and metal skills or lack of experience and knowledge.
Assure that the plug is easily accessible in order to switch it off in
case of any risk.
Electric products are dangerous for children. When the equipment operates,
keep children away from the electric equipment. Do not allow children to play with
the equipment.
Electric products are dangerous for children. When the equipment
operates, keep children away from the electric equipment. Do not allow
children to play with the equipment.
Mains values should match with those given in the nameplate of the
WARNING AND SAFETY PRECAUTIONS

EN
9
hood. Lift the glass cover and remove the filter in order to have access to the
nameplate.
Use “Maximum 6A” fuse in the power installation to which the hood is
connected both for your own safety and product safety.
During installation, power cable should not be subject to compression or
crush. If the power cable is damaged, it should be replaced by an authorized service
centre or a qualified electrician. It also applies to any possible damage of the power
cable in future.
Product should be connected to the mains only by an authorized and
qualified electrician. Product warranty starts only after correct installation of it.
Do not plug the product before you fix it on the wall.
Grounded plug is installed to the power cable of your product. This cable
should definitely be insert into a grounded socket.
Disconnect power connection of the product prior to cleaning and
maintenance. (Remove the plug of the product from the socket for disconnection.)
Warning: Failure to fix the screws or fastening elements according to the
instructions may lead to electric risks.
When installation of the product is completed, leave a distance of 60 cm
between the product and electric ranges or minimum 65 cm between the product
and ranges using gas or other fuels. If larger distance is specified in the installation
instructions of the gas-fueled ranges, you should stick to them.

EN
10
Warning: Failure to fix the screws or fastening elements according to the
instructions may lead to electric risks.
When installation of the product is completed, leave a distance of 60 cm
between the product and electric ranges or minimum 65 cm between the product
and ranges using gas or other fuels. If larger distance is specified in the installation
instructions of the gas-fueled ranges, you should stick to them.
CAUTION: When the hood is used together with the cooking equipment, the
accessible parts may be heated.
Flammable food should not be cooked under the hood.
Bare flame is very harmful for the hood and may lead to fire risk; it should,
therefore, be avoided.
In case of flaming, disconnect power of the hood and cooking equipment
(Disconnect the power by removing the plug of the product from the socket).
Operate the hood after you put pot, frying pan or cooking containers on the
range. Otherwise, high heat may cause deformation of your product.
Switch the range off before you take the cooking containers such as pot or
frying pan from the range.
Do not leave the cooking containers such as pot or frying pan on the range
when they contain hot oil. Cooking containers with hot oil in them may cause to self-
ignition. Especially be careful when you fry. Watch the curtains and cloth covers due
to easily flammable character of the oil.
