Cord Tech 17AGR User manual

Model
17AGR
Max Power Rating
230
-240V AC, 10A, 2400W
Power Cable & Plug
2M
Heavy Duty (1.0mm2)
Power Cable & Socket
15M
Heavy Duty (1.0mm2)
Use
For Indoor Use Only
Retractable CABLE Reel
Instruction Manual
PLEASE READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND OPERATING
INSTRUCTIONS IN THIS MANUAL BEFORE USING THIS EQUIPMENT. Failure to follow
all instructions may result in electric shock, fire and/or serious personal injury.

IP44 Socket
Cover
Power Cable
& Plug
Power Cable &
Lock-On Socket
Thermal Cut-Out
Casing
1
Product Overview
•DO NOT OPERATE unless the cord is fully unreeled.
•Before reeling & unreeling remove plugs from sockets.
•Do not modify this product in any way.
•Do not step on, fold or knot the cables.
•Do not cover.
•Do not overload.
•Keep away from high temperature objects.
•For Indoor Use Only.
•Keep out of reach of Children.
•Do Not connect large electrical appliances e.g. heaters, air conditioners etc.
•If this product is damaged in any way cease use immediately.
2
Warnings
Mounting Bracket
On/Off Switch
Stopper

•Ensure you are a suitably qualified professional who can complete the installation
in a safe and secure manner.
•When selecting a mounting location, always choose an area where you can firmly
attach to a solid support structure i.e. timber nogs, concrete wall. We do not
recommend installing into areas without a solid structure.
•Ensure the product is positioned so the power cable & plug can easily reach your
wall socket. There should be no stress on the cable or plug on any angle.
•Check your mounting location carefully for cables or pipes before beginning. You
must be careful not to drill into or pierce a cable or pipe inside the wall structure.
•Always ensure the supporting surface will safely support the combined weight of
the attached equipment and all attached hardware and components.
•Always double check your measurements and work before proceeding.
•Use a spirit level.
•Check you have the right tools, accessories and safety equipment to complete the
installation.
3
Before You Begin
4
Operation
•Always ensure the cable is fully un-reeled prior to use.
•Plug into a standard 10A wall socket. Turn on at the wall and on the cable reel.
•The IP44 cover on the socket is supplied for temporary use to deter light dust or
liquids that might splash onto the socket.
•When reeling or un-reeling remove plugs from sockets.
•Always ensure the Lock-On mechanism is set to the UNLOCKED position when
plugging in or unplugging from the socket.
•To stow, have the cable fully extended and in a straight line –pull gently to release
the retraction mechanism and allow the cable to fully retract.
•Make sure there are no people or obstacles in the way during retraction.
NOTE: The last approx. 1M of cable will retract by the momentum, it will not remain
under heavy load or tension. This is by design to prevent undue strain on the cable.
TIP: If you have not fully un-reeled the cable, or if you have stopped or interfered
with the retraction, the cord may not fully retract. Always fully un-reel when in use
and allow the cable to retract freely.

4
Operation
Cont
Thermal Cut-Out:
•If the over temperature device activates it will stop power supply to the cable and
socket.
•Turn off and remove the plug from the wall socket.
•Check your attached equipment to ensure you are not overloading the device.
•Check to ensure there are no faults with the attached equipment.
•Check the cable is fully unreeled.
•Ensure there is no damage to the device, if found cease use immediately.
•If operation is normal or you have corrected the fault - push the red thermal cut-
out button to reset.
•Wait 5 min.
•Re-connect to wall socket.
Distributed BY: Cord Tech www.cordtech.com
5
Maintenance
Warranty
Products are protected by warranty for a period of 1 year from date of purchase
against manufacturing defects in material and functionality. Should a product fail to
perform as described within the warranty period, return to the original place of
purchase and provide a copy of the proof of purchase for warranty claim.
•Ensure the product is turned off at the wall and the plug is disconnected prior to
cleaning.
•Check regularly for a build up of dust or debris, keep the surfaces clean by wiping
with a dry cloth.
•Do not use liquids, abrasive chemicals or detergents for cleaning.
•Check regularly for damage, if found cease use immediately.
•Always store in a dry location.
Thermal Cut-Out
