Corega BTSHS01 User manual

Bluetooth
Stereo Headset
BTSHS01
User Manual

BTSHS01 User Manual
1
1
Contents
1. Before Starting........................................................................................................... 2
2. Product Introduction............................................................................................... 3
2.1 Features................................................................................................ 3
2.2 Package Contents..............................................................................3
2.3 Hardware Description..................................................................... 4
2.4 Product Configuration.................................................................... 4
2.5 LED Description.................................................................................5
3. Charge Batteries.........................................................................................................6
4. Start Using.................................................................................................................... 7
4.1 Use with audio devices................................................................... 7
(1) Power On........................................................................ 7
(2) 3.5mm audio connector............................................ 7
(3) Pairing.............................................................................. 8
(4) Wearing Headset.......................................................... 8
(5) Adjusting Volume........................................................ 9
4.2 Use with mobile phone.................................................................10
(1) Bluetooth Headset/Switch on mobile phone..10
(2) Pairing............................................................................11
(3) Adjusting Volume......................................................12
(4) Start Headset Phone................................................12
4.3 Use with stereo adapter and phone.........................................13
4.4 Use with other Bluetooth Devices...........................................13
(1) Install BTUSB01...........................................................13
(2) Start the Bluetooth Software.................................13
(3) Find Bluetooth Devices.........................................13
(4) Start Pairing.................................................................14
(5) Start using Headset..................................................15
5. FAQ................................................................................................................................16
6. Specification............................................................................................................. 18
7. Compatible Mobile Phone List.......................................................................... 19

BTSHS01 User Manual
22
33
2
1. For the first time using, it takes 4 hours to fully charge the
batteries and 2 hours afterwards. After the batteries were
fully charged, talking time is up to 8 hours and the standby
time is up to 160 hours. For further information, please refer
to the Battery Charging chapter in this manual.
2. The product configurations are based on Bluetooth stereo
adapter and mobile phone. For other Bluetooth devices,
please refer to the brand manuals.
3. When pairing with mobile phone or other Bluetooth devices,
please select [CG-BTSHS01] for this headsets ID name and
enter the passkey [1234] (for mobile phone) to start the
Bluetooth connection.
4. ”The Bluetooth Qualification of this product could be
referred to Bluetooth Identifier B02152”.
Before starting
1

22
BTSHS01 User Manual
33
2Product Introduction
corega BTSHS01 is a Bluetooth 1.2 standard headset, with the included
Bluetooth audio adapter, it can be used on any audio device which has a
3.5mm audio output, such as personal stereo, TV, DVD player, MP3 player
and iPOD etc..
This headset is also compatible with Bluetooth mobile phones. It sup-
ports auto music/phone switching function, so you will not miss out any
phone call while you are listening music. The simple black-white design
of CG-BTSHS01, is ideal for not only people who want to enjoy the free-
dom of wireless, but also seek for high quality of stereo sound.
2.1 Features
• Bluetooth 1.2 Standard
• Compatible with any 3.5mm audio port devices
• Easy carrying foldable ear-hook design
• Noise suppression, echo elimination and duplex sound for clearer
quality calls
• Up to 8 hrs talk time and 160 hrs stand-by time
(* Various usage patterns may adversely affect battery performance)
• USB charger included, can recharge through computer USB port
• Up to 10m operating range
(* Environmental factors may adversely affect wireless signal range)
• Auto switching between phone / music mode
2.2 Package Contents
• Bluetooth Stereo Headset
• Bluetooth Stereo Adapter
• Charger
• USB Charger
• AV cable
• T-Connector
• Rubber Band
• Cloth bag
• Manual

BTSHS01 User Manual
4
5
2.3 Hardware Description
[Right] [Left]
Volume Button
Play/Pause/Answer
/Hang-up Button
Microphone
Pairing
Track Wheel Button
Charging Port
[Front view]
Power Switch/Pairing Button
Charging Port
2.4 Product Configuration
.
.
.
.
.
.
.
.
.
.
.
.
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
e
BTSHS01
Bluetooth Stereo Headset
Mobile Phones
Laptop with BTSAP01 Bluetooth Audio Adapter
MP3 Player with BTSAP01
Bluetooth Audio Adapter
CD Player with BTSAP01
Bluetooth Audio Adapter
DVD Player with BTSAP01 Bluetooth Audio Adapter

4
BTSHS01 User Manual
5
2.5 LED Description
X: OFF : BLINKING O: ON
LED LED1: RED LED2: BLUE
Power On X 
Standby X 
Pairing  
Pairing Successfully X 
Working X 
Incoming Call X 
Talking X 
Low Battery X X
Charging O X
Charged Done X X

BTSHS01 User Manual
6
7
For the first time using, it takes 4 hours to fully charge the batteries
and 2 hours afterwards. After the batteries were fully charged, talking
time is up to 8 hours and the standby time is up to 160 hours.
(* Various usage patterns may adversely affect battery performance)
The following figure is the Battery Charging instructions:
1. Connect the T-Connector to the power adapter
2. Connect the stereo headset to the T-Connector
3. Connect the stereo adapter to the T-Connector
4. Plug the power adapter into an electrical outlet.
When start charging, the RED LED is steady on. Until the batteries
are fully charged, RED LED is then off and power adapter should be
unplugged and removed from electrical outlet.
*Note: Alternatively, both devices can be charged through USB port by
using USB charger provided.
3Charging Batteries

6
BTSHS01 User Manual
7
The followings are pairing modes and sequences for the stereo headset:
4.1 Headset ---> Stereo adapter (Pairing --->)
4.2 Headset ---> Mobile phone
4.3 Headset ---> Stereo adapter then Headset ---> Mobile phone
4.4 Headset ---> Other Bluetooth devices
4.1 Use with audio devices
(1) Power On
Use the power switch to turn on the power.
*Note: Turn the switch to [OFF] to switch off the headset.
(2) 3.5mm audio connector
Plug the audio connector into the 3.5mm audio port of the audio
device.
*Note: To use headset with DVD, TV or Hi-Fi system etc., please use
the provided AV cable in the package.
4Start Using

BTSHS01 User Manual
8
9
(3) Pairing
a. When Power is On, press and hold the pairing track wheel on the
stereo headset until the blue and red LEDs flash alternatively.
b. When Power is Off, press and hold the control button on the stereo
adapter until the blue and red LEDs flash alternatively.
c. When both headset and stereo adapter’s Blue LEDs start to flash
three times, then the pairing is completed.
*Note:
1. If pairing is unsuccessful, the stereo adapter has to be switched off
then repeat the step a and b until the pairing is successful.
2. One headset can only be paired with one stereo adapter each time.
3. If either the headset or adapter is switch off and switch back on
again, there is no need to repairing. Please press once on the round
control button of headset or stereo adapter to back on bluetooth
connection status.
4. To turn off the stereo adapter, press and hold the round button
until RED LED is blinking.
(4) Wearing Headset
Hold both sides of the headset  Hook the headset from the back
of head  Gently adjust headset position

8
BTSHS01 User Manual
9
 
(5) Adjusting Volume
1. Adjusting Headset Volume
Press [Vol.+] to increase the volume, [Vol.-] to decrease the volume.
Vol+
Vol-
*Note: It is recommended to adjust headset volume once the pairing is
completed, since default volume may be slightly quiet.
2. Set volume mode
《Normal volume mode》
- When power is on, press and hold the control buttons on the stereo
adapter for 1.5 seconds to disconnect the stereo adapter from the
audio device. Then you will hear a ‘DoDo’ sound from the headset.
- Single clink on the control button will reconnect the stereo adapter
to the audio device ans set the stereo headset to normal volume
mode.
Single click1.5 secondes

BTSHS01 User Manual
10
11
《High volume mode》
- When power is on, press and hold the control buttons on the stereo
adapter for 1.5 seconds to disconnect the stereo adapter from the
audio device. Then you will hear a ‘DoDo’ sound from the headset.
- Double clink on the control button will reconnect the stereo adapter
to the audio device ans set the stereo headset to high volume mode.
Double click1.5 secondes
*Note:
- For iPOD, normal mode is preferred.
- For Sony PSP or Creative MP3 player and others, high volume mode
is preferred.
4.2 Use with mobile phone
Before start pairing, please have mobile phone manual in hand and
read through the pairing chapter. Moreover, please refer to the com-
patible mobile phone table in the last page to ensure your mobile
phone is compatible.
(1) Bluetooth Headset/Switch on Mobile Phone
a. Switch on your Bluetooth mobile phone
b. Use the power switch to turn on the headset power

10
BTSHS01 User Manual
11
(2) Pairing
a. Press and hold the pairing/track wheel button on the stereo head-
set until blue and red LEDs are flashing.
b. To properly perform pairing procedure on your mobile phone,
please refer to the manual of your mobile phone for its own pairing
instruction. This device name is set to be [CG-BTSHS01]. If you are
asked to enter pin-code during pairing, please enter [1234].
*Note:
1. If the pairing is unsuccessful, the BLUE LED is then flashing.
Please repeat the step a and b until the pairing is completed.
2. One headset can only be paired with one bluetooth mobile
phone each time.
3. If the headset is switch off and switch back on again, there is no
need to repairing. Please press once on the round control but-
ton of headset or reconnect bluetooth connection from mobile
phone to back on bluetooth connection status.

BTSHS01 User Manual
12
13
(3) Adjusting Volume
《Adjusting Headset Volume》
Press [Vol.+] to increase the volume, [Vol.-] to decrease the volume.
Vol+
Vol-
(4) Starts Headset phone
《Make a call》
- Dial out the number from your mobile phone.
- Voice is automatically transferred to the headset.
《Receive a call/End a call》
- When there is an incoming call, a ‘DoDo’ sound is appeared from
headset. Press the answer button to answer the call and the audio
channel will be switched to the mobile phone.
- When finish talking, press the answer button to end the call and the
audio channel will be switched back to the audio device.
*Note: Press the answer button after the DoDo sound

12
BTSHS01 User Manual
13
《Reject a call 》
- Press and hold the Vol- button of the headset for around 3 seconds.
(This function may not work on some Bluetooth mobile phones)
4.3 Use with stereo adapter and phone
The pairing sequence is:
1. Headset with Stereo Adapter
2. Headset with Bluetooth mobile phone
4.4 Use with other Bluetooth Devices
This headset can also connect with other Bluetooth devices, such as
USB Bluetooth dongle, Bluetooth PDA etc.. For the detail configuration,
please refer to the device manual.
In the following, we use corega BTUSB01 USB Bluetooth dongle for
configuration example:
(1) Install BTUSB01
Plug BTUSB01 in USB port and install BTUSB01 driver and Bluetooth
utility 4.0. (For the latest driver, please visit www.corega-asia.com)
(2) Start the Bluetooth Software
Double clicks [My Bluetooth Places] on the desktop
(3) Find Bluetooth Devices
Click [Find Bluetooth Devices], and switch on headset power. The
new detected device is then shown in the window in few seconds

BTSHS01 User Manual
14
15
(4) Start pairing
a. Double clicks on the icon, like the figure shown below
b. Press and hold the black track wheel button on the headset until
RED and BLUE LEDs are flashing alternatively. Double clicks on the
icon below:
c. Then a message box is pop up from right bottom corner, please
click on the message box.

14
BTSHS01 User Manual
15
d. When the password request box is shown, please enter the pass-
word [1234]. Then the pairing is completed.
*Note: If the pairing is unsuccessful, the BLUE LED is then flashing.
Please repeat the step 3 and 4 until the pairing is completed.
(5) Start using headset
《Adjusting Headset Volume》
Before start using the headset, please adjust the headset volume
first. For the detail, please refer to 4.1 (5).
* Addition feature: Forward/Backward music track
The Bluetooth stereo adapter provided doesn’t support this func-
tion. To use this function, the bluetooth dongles/devices have to
have or use:
1. A2DP and AVRCP profiles.
2. Window Media Player as default music player
*Note: This function is operatable in the corega BTUSB01 with the
latest driver (v.4.0). (Please visit www.corega-asia.com )

BTSHS01 User Manual
16
17
1. Can I change Bluetooth passkey?
No, the Bluetooth is written into the device when it manufactured and
cannot be changed.
2. Can I use stereo headset with audio device and mobile phone at same
time?
Yes, the stereo headset can be used with audio device and mobile phone
at same time. However, there could be some compatibility issues on
certain brands of models of mobile phones.
3. Can I use stereo headset while it is in charging mode?
No, the stereo headset cannot be used while it is in charging mode.
4. What is the operating range of the Headset?
The operating range of the Headset is up to 10 meters.
(* Environmental factors may adversely affect wireless signal range)
5. Do I need to pair the stereo headset with my mobile phone and
Bluetooth stereo adapter every time I use it?
You need to pair the stereo headset with your mobile phone and
Bluetooth stereo adapter when first time using it. You only need to
reconnect the stereo headset with your mobile phone and Bluetooth
stereo adapter afterward. (See *Note in 4.1 and 4.2)
6. How come the track control does not work with my MP3 player?
The Stereo Adapter in this package does not support this function,
but other Bluetooth devices (such as corega BTUSB01) have following
required components can activate the track control function.
1. Bluetooth devices and utilities support A2DP and AVRCP profiles
2. Use Windows Media Player as default music player
7. Can I use the Stereo headset with mobile phone to listen to music?
If your mobile phone is Bluetooth enabled and supports stereo feature
(A2DP), then you can use the stereo headset with your mobile phone
to listen to music. However, most of Bluetooth enabled phones do not
support such feature.
5FAQ

16
BTSHS01 User Manual
17
8. When my mobile phone was searching for the headset, why did sev-
eral Bluetooth devices appear on my mobile phone?
The headset will appear as “CG-BTSHS01” on your mobile phone after
having been found by your mobile phone.
9. Why doesn’t the headset work suddenly?
1) The headset may have run out of battery. When it is in low battery,
a red LED will start to flash.
2) When this happens, please restart your mobile phone. (It is not
necessary to perform Pairing again.)
10. How to use the rubber band in the package?
The main purpose of rubber band is for fastening with other devices,
such as MP3 hooker and Bluetooth devices. It can be used like the
figures shown below:
1. Fasten with Bluetooth stereo adapter
2. Fasten with MP3 hooker
*Note: If you have any further question, please contact our customer
service , ser[email protected]

BTSHS01 User Manual
18
19
Standard Bluetooth 1.2
Bluetooth Profile Headset:A2DP, HSP, HFP, AVRCP
Stereo Adapter:A2DP
Frequency 2.4GHz~2.4835GHz ISM Band
RF Output Power 0 dBm(typical)
Receiving Sensitivity -80 dBm(typical)
Cover Range
Up to 10M (open space)
* Environmental factors may adversely affect
wireless signal range
Spectrum FHSS (Frequency Hopping Spread Spectrum)
Security Pairing, 128bits Encryption Authentication
Usage Time
Talk time: 8 hours
Standby time: 160 hours
* Various usage patterns may adversely affect
battery performance
Power Class Class 2
Signal/Noise Distortion <-91 dB
Antenna Type Chip Antenna
Volume Range -24 dB ~21.5 dB
Power Requirements DC 5V± 5%
Battery Rechargeable 230mAh Li-Polymer Battery
Environment Requirements
Operating Temperature:-25~75˚C
Humidity:<90% (non- non-condensing)
Storage Tempterature:-30~95˚C
Humidity:<90% (non- non-condensing)
Physical Specifications
Dimension Headset 102(W) x 57.5(D) x 69.5(H) mm
Adapter 34.5(W) x 14.5(D) x 44(H) mm
Weight Headset 76.4 g (main unit)
Adapter 18.8 g (main unit)
6Specification
