Coremorrow E53.C Series User manual

This document describes the following products:
■E53.C Open loop 1 channel Software
E53.C Series Piezo Controller
User Manual
Version: V1.0

Declaration!
This user manual is a integrated user manual of the E53.C series piezoelectric controller. Please
read this user manual carefully before using this controller. Follow the instructions in the manual
during use. If there is any problem, please contact us for technical support. If you do not follow
this manual or disassemble and modify the product yourself, the company will not be liable for any
consequences arising therefrom.
Please read the following to avoid personal injury and to prevent damage to this product or any
other product connected to it. In order to avoid possible hazards, this product can only be used
within the specied range.
Notice!
Do not touch any exposed ends of the product and its accessories.
There is high voltage inside. Do not open the case without permission.
Do not connect or disconnect input, output, or sensor cables with power on.
Please keep surface of E53.C clean and dry, don't operate in humid or static environment.
After use, output voltage should be cleared to zero before turning o󰀨 the controller switch, such as
switching the servo state to the open-loop state.
Danger!
The piezoelectric power amplier described in this manual is a high-voltage device capable of
outputting high currents, which can cause serious or even fatal damage if not used properly.
It is strongly recommended that you do not touch any parts that connect to the high voltage output.
Special Note: If you connect it with other products in addition to our company, please follow the
general accident prevention procedures.
Operating the high-voltage amplication requires training professional operators.
Cautious!
Warning!
If the voltage exceeds the PZT's tolerable range, it will cause permanent damage to the PZT.
Before adding voltage to the PZT poles, it must be ensured that the positive and negative poles
of the PZT are connected correctly and the operating voltage is within the allowable range of this
PZT.
E53.C housing should be installed on a horizontal surface in an area with a 3CM air ow area to
prevent internal convection in the vertical direction.
Insu󰀩cient airow can cause equipment to overheat or premature instrument damage.
DECLARATION

Contents
1.Security ………………………………………………………………………………………………………………………… 2
1.1 Introduction …………………………………………………………………………………………………………… 2
1.2 Safety Instructions ………………………………………………………………………………………………… 2
1.3 Notes ……………………………………………………………………………………………………………………… 2
2. Introduction ………………………………………………………………………………………………………………… 3
2.1 Features ………………………………………………………………………………………………………………… 3
2.2 Applicaitons …………………………………………………………………………………………………………… 3
2.3 Order information…………………………………………………………………………………………………… 3
3.Driving Principle …………………………………………………………………………………………………………… 4
4.Appearance ………………………………………………………………………………………………………………… 4
5.Power Calculation ………………………………………………………………………………………………………… 4
6.Panel Introduction………………………………………………………………………………………………………… 5
7.Notes and suggestions ………………………………………………………………………………………………… 6
8.Contact us …………………………………………………………………………………………………………………… 6

2
E53.C Series Piezo Controller User Manual
1.Security
1.1 Introduction
Please keep surface of E53.C clean and dry.
Do not operate in the humid or static environment.
E53.C is used to drive capacitive loads (such as piezo actuators).
E53.C should not be used in user manuals of other products of the same name.
Pay special attention that E53.C cannot be used to drive resistive or inductive loads.
E53.C could be used for static and dynamic operating applications.
1.2 Safety Instructions
E53.C is based on the national safety standard. Improper use may cause personal injury or
damage to the piezo controller. The operator is responsible for the correct installation and
operation of the piezo controller.
Please read the user manual in detail.
Please eliminate any faults and potential safety hazards caused by the faults.
If the protective ground wire is not connected or connected incorrectly, there will be a possibility
of leakage. If you touch the E53.C piezo controller, it may cause serious or even fatal injuries.
If the piezo controller housing is opened without permission, touching the live parts may cause
electric shock, resulting in serious or even fatal injury or damage to the piezo controller.
Only authorized professional technicians with corresponding qualifications could open the
piezo controller.
When opening E53.C series controller, please disconnect the power plug.
Please do not touch any internal parts when operating under bare conditions.
1.3 Notes
The contents in the user manual are all standard descriptions, and the customized
parameters are not explained in detail in this manual.
The latest user manual is available for download on CoreMorrow website.
When operating theE53.C, the user manual should be placed near the system for easy
reference in time. If the user manual is missing or damaged, please contact CoreMorrow
customer service department.
Please timely add all the information given in the manufacturer's user manual, such as

3
supplements or technical descriptions.
If your user manual is incomplete, it will miss a lot of important information, cause serious
or fatal injuries, and cause property damage. Please read and understand the content in the user
manual before installing and operating the E53.C.
Only professionals who are authorized to meet the technical requirements could install,
operate, maintain and clean the E53.C.
2. Introduction
2.1 Features
1 channel small size
24V（20~30V）1.5A 36W
Peak current 1A
Ave current 60mA
Unload bandwidth 10KHz
Output short circuit protection
2.2 Applicaitons
Driving piezo actuators
Driving piezo objective scanners
2.3 Order information
E53.C——Open loop Analog/software input control
Accept customized according to requirements：
① 12bit gain/-20 ～ 120V output voltage（default）
② 15bit gain/-20 ～ 150V output voltage

4
E53.C Series Piezo Controller User Manual
3.Driving Principle
Analog/Digital in
Communication
Interface
D/A
+
-
A/D
PZT
Power
amplifier
High voltage
output
Control unit
Communication
control
4.Appearance
5.Power Calculation
● Average output（Sine wave operation mode）
Pa ≈ Upp • Us • f• Cpiezo
Pa=Average output[W]
Upp=Peak and peak drive voltage [V]
Us=Drive voltage[V]（（Vs+）-（Vs-））
Cpiezo=Piezo actuator capacitance[F]
f=Operating frequency of the sine wave[Hz]

5
No. Function Description
①Power indicator Green, lights when power's on
②USB port MicroUSB port
③ RS-232/422 See interface pin definition
④Analog input Analog voltage input interface
⑤Piezo connector Driving piezo actuaotr
⑥Limit Over-current indicator RS-232/422 interface pin
definition
① ② ③ ④ ⑤ ⑥
6.Panel Introduction
No. Function Description
1Signal source control
switch
M：Signal source selection by communication
instruction
D：Digital circuit as signal source
A：Using an external analog signal as a signal
source
①

6
E53.C Series Piezo Controller User Manual
7.Notes and suggestions
E53.C cannot be used to drive inductive loads. If the inductive loads are driven, the product
may be damaged.
If there is no need, please do not twist the potentiometer easily.
