ARIS Linearis N+ User manual

Original declaration of
incorporation with manual for
ARIS Damper actuator
Linearis N+
LIN+1538EN01
Stellantriebe
incl. manual for
ARIS Microprocessor-Controller PMR-Nano

Inhaltsverzeichnis
Identication..............................................................................................................................................................................3
Nameplate .................................................................................................................................................................................3
Guidelines and standards............................................................................................................................................................4
Safety information......................................................................................................................................................................4
Warnings.................................................................................................................................................................................... 4
General safety advices................................................................................................................................................................ 4
Technical specication.................................................................................................................................................................5
Function and application areas (Intended use)............................................................................................................................. 5
Safe and accurate use.................................................................................................................................................................5
Dimensions.................................................................................................................................................................................6
Performance data.......................................................................................................................................................................7
Expected lifespan and intended disposal......................................................................................................................................7
Actuator setup for operation........................................................................................................................................................7
Transport and (temporary) storage..............................................................................................................................................7
Packaging..................................................................................................................................................................................8
Safe disposal of packaging.......................................................................................................................................................... 8
Installation and mounting...........................................................................................................................................................8
Initial operation..........................................................................................................................................................................9
Electrical connection....................................................................................................................................................................9
Wiring diagram ........................................................................................................................................................................10
Operation of the actuators ........................................................................................................................................................10
Set up rotation direction............................................................................................................................................................ 10
Set up limit switches (Self-adjusting switch cam).........................................................................................................................11
Optional modules and extra features......................................................................................................................................... 11
Potentiometer...........................................................................................................................................................................11
Potentiometer with approval acc. to DIN EN 12067-2 (TÜV-Poti).................................................................................................11
Additional limit switches (Self-adjusting switch cam)...................................................................................................................13
2-wire-current output 4-20 mA..................................................................................................................................................13
Mechanical position indicator.....................................................................................................................................................14
Service switch (230 V AC only)..................................................................................................................................................14
Heating resistant (230 V AC only)..............................................................................................................................................14
Single wire control (230 V AC only)...........................................................................................................................................15
Parallel relay (230 V AC only)................................................................................................................................................... 15
Power supply 24 V DC (Special edition)......................................................................................................................................16
Required customer information.................................................................................................................................................16
Extraordinary situations............................................................................................................................................................16
Troubleshooting and repair .......................................................................................................................................................17
Maintenance.............................................................................................................................................................................17
Service..................................................................................................................................................................................... 17
Accessories...............................................................................................................................................................................17
Spare parts...............................................................................................................................................................................17
ARIS Stellantriebe GmbH
Rotter Viehtrift 9 Tel.: [phone] [email protected]
53842 Troisdorf/Germany Fax: [phone] www.stellantriebe.de

3
Linearis N+
1. Identication
This manual is valid for:
Description: Electric actuator
Type: Linearis N+
Serial no.: 1539-xxxxx-01001 ff.
1.1 Nameplate
Serial number
Actuator type
Voltage/Frequency/Power consumption
Actuating time/Force
Ambient temperature/Protection class
Additional built-in parts
ARIS Stellantriebe GmbH
Rotter Viehtrift 9
D-53842 Troisdorf
www.stellantriebe.de
SNr: 1539-XXXXX-01001
Typ: Linearis N+
230V, 50(60)Hz 12VA
1,7 mm/s 600 N
UT -15°C/+60°C IP65
1ZW
Made in
Germany
Stellantriebe

4Linearis N+
1.2 Guidelines and standards
ARIS actuators are partly completed machinery according to directive 2006/42/EC. This is certied by a declaration of incorporati-
on (see page 30).
Further applicable EC directives: EMC Directive 2004/108/EC
Applied harmonized standards: LVD (electrical safety) DIN EN 61010-1:2011-07
MachDir DIN EN 12100:2011-03
EMC Directive 2004/108/EC DIN EN 61000-3-2
DIN EN 61000-3-3
DIN EN 61000-6-2
DIN EN 61000-6-3
DIN EN 55011:2001-04
DIN EN 61000-6-4:2011-09
Protection classes by housing (IP-Codes): Protection class test DIN EN 60529:1991
EMC consideration of the complete plant and system pertubations and their combating
have to be carried out by the plant builder or operator. The wiring of the actuator should
comply with DIN EN 60204-1.
2. Safety information
2.1 Warnings
Symbols: Installation and initial operation only by certied experts according to the manual.
Observe the signicance of the following symbol and note explanations. They are subdevided in security levels and classied
according to ISO 3864-2.
DANGER indicates a hazard with a high risk degree, which, if not avoided, causes death or
heavy injuries.
WARNING indicates a hazard with a medium risk degree, which, if not avoided, can cause
death or heavy injuries.
CAUTION indicates a hazard with a low risk degree, which, if not avoided, can cause slight
or moderate injuries.
Indicates general advices, useful hints and work recommendations, which don´t have
inuence on the safety and health of the staff.
2.2 General safety advices
The actuator components are conform to the state of the art and apply as generally safe at the time they are shipped.
This manual serves as basis to install and operate ARIS actuators safety conform. All persons working with or on ARIS actuators
must observe this manual and especially its safety advices.
DANGER
ADVICE
!
CAUTION
WARNING
HINWEIS
!

5
Linearis N+
• This manual has to be kept at the operating place at any time.
• Read the manual carefully prior to installation and initial operation.
Certain parts of active electric appliances are obligatory under voltage.
• Working on electric appliances or equipment is only allowed for electrically qualied persons or other instructed persons
under guidance and custody of an electrically qualied person according to the electro-technical regulations.
• Observe all safety and accident prevention regulations while installing, operating and testing any electrical appliances or
machinery.
• Prior to all installation or regular work on the actuator make sure to switch off all connected machinery/appliances.
3. Technical specication
3.1 Function and application areas (Intended use)
ARIS actuators are exclusively designed for industrial use. ARIS actuators are utilized for operating regulating and shut-off applian-
ces (valves, slide valves, etc.).
ARIS actuators may not be used for:
• Potentially explosive atmospheres
• Temperatures below -15 °C or over 60 °C (optional +80 °C)
• Underground environments
• Near open res
• Under water
• Operating elevators
3.2 Safe and accurate use
ARIS actuators are factory checked prior to delivery. The nal functional testing must be performed within the total system by
qualied technical personnel.
The ARIS company assumes no liability for possible manufacturing errors and resulting damages or subsequent damages after the
actuator has been tested, installed and declared functional correct. The ARIS company especially assumes no liability for possible
manufacturing errors and resulting damages or subsequent damages when the actuator was operated inappropriate, has not
sufciently been tested within the total system, or has not been put out of operation after a failure has determined during testing.
Installation and initial operation only by qualied experts.
• Valves, levers and connecting rods are moving during actuator operation;
• Check for proper function of all emergency equipment on your machinery;
• Check for proper function of the actuator and operated valves after completion of all installation work;
• Never work with or operate a faulty actuator.
ADVICE
!
WARNING
CAUTION

6Linearis N+
3.3 Dimensions Linearis N+
100
150
50
45 x
41
153
86
63 60
TensorCL
102
63
86 112 41
Nano+
80
125
91
13 65 a 35

13
c
½
Stroke b
13
6 40
50

16
e
7
10
Stroke
30
56
38Stroke
d
68
Stroke a b c d e
150 201 341 106 85 278
300 351 491 212 170 428

7
Linearis N+
3.4 Performance data
• Protection class: IP65 (optional IP 66, IP 67)
• Motor: 230V ±10%, 50/60Hz ±5%, 100% ED (Standard)
» Special voltage/-frequency see nameplate (Option)
» Insulation class E acc. DIN EN 60034-1
• Motor: 24 V DC (Option) ±20%, ED S3 50%
» Insulation class E acc. DIN EN 60034-1
• Connection: 3 cable glands M16x1.5 (Customer provided)
• Path cut-off: Changeover switch (Opener/Closer)
» Switching capacity max. 10(3)A, 250V AC
• Ambient temperature
» -15 °C up to +60 °C (optional -30 °C...+80 °C)
• Installation position: Arbitrary
• Potentiometer (Option)
» Recommended wiper current: 0,2 μA
» Capacity at +70 °C: 0,5 W
• Travel: 150 mm, 300 mm
3.5 Expected lifespan and intended disposal
ARIS actuators have an expected lifespan of several years, depending on their utilization and application. No longer usable actu-
ators must not be dismantled as a whole, but seperately recycled in parts divided by their materials. Non-recyclable components
must be disposed according to national disposal regulations.
4. Actuator setup for operation
4.1 Transport and (temporary) storage
Use the factory packaging for transport to the installation point. Replace a damaged original packaging by a new solid packaging.
Suspended load
Improper use of transportation (ground conveyer, overhead crane, tools, lifting means etc.) can cause crushes and other injuries.
Required behaviour:
• Use transportation properly;
• DO NOT step or stand under suspended loads;
• Actuators with attached valves: Attach lifting gear only on the valve and NEVER on the actuator;
• Do not use ARIS actuators as a climbing or support aid;
Damage by wrong storage
• Store in well-ventilated rooms;
• Protection against possible ground humidity (shelf storage).
WARNING
ADVICE
!

8Linearis N+
4.2 Packaging
ARIS actuators are protected by special cardboard packaging at delivery.
4.3 Safe disposal of packaging
Additionally necessary packaging is made by easily separable packaging materials and can be recycled individually:
• Wood
• Cardboard
• Paper
• Plastics
4.4 Installation and mounting
• Inspect the actuator for damages prior to installation;
• the screw-in depth of connecting thread holes must not exceed 9 mm;
• check leak tightness of cable glands and blank plugs prior to initial operation;
• tighten the cover screws evenly (max. 1.2 Nm);
• do not operate before limit switches have been adjusted;
• protect the actuator against climatic inuences (e.g. by a protective cover);
• do not expose the actuator to hard shocks (e.g. by dropping);
• do not attach ropes, hooks or the like to the actuator;
• permanent overload and blocking leads to actuator damages;
• spark suppressor capacitor can effect the rotation stability of the actuators and may cause damages;
• use only ARIS original spare parts.
Consider prior to attachment of couplings:
• Do not turn the thread spindle by force;
• the attachment to the valve or a solid underground is made by the pre-assembled brackets (bearing blocks).
Driver connection
1. The con rods (A) are connected to the valve by a bolt (B).
2. Lubricate moving parts (OKS 416 or similar).
3. Insert the bolt (B) into the bores of the con rods attach the cotter pin (C).
4. Finally bend the cotter pin ends apart.
Installation position: The actuators can be installed position independendly.
Protection classes IP65 (optional IP 66, IP 67)
For all actuators observe the following advices:
The initial operation of the actuator is only permitted with orderly closed cover and closed cable entries. Use only cable glands
which are appropriate for the respective protection class.
ADVICE
!
A
B
C

9
Linearis N+
• Cable entries
Ensure that all cable entries are closed properly during storage, installation and initial operation.
Use only cables which are suitable for the diameter of the cable entries.
• Cover assembly
During the cover assembly make sure that the cover ts correctly.
The cover must not show any damages on the joint surface.
Tighten cover screws evenly (max. 1.2 Nm).
• Housing/Cover
No additional bores are allowed in the housing and the cover.
4.5 Initial operation
4.5.1 Electrical connection
Hazardous voltage: Possible stroke!
• The initial operation must be carried out only by experts!
• De-energize the actuator before opening.
• Observe the appropriate regulations during electrical installation and initial
operation.
Connect the actuator as follows:
• Connect the ground wire of the electric supply to the appropriate protective earth terminal.
• Connect the neutral N to terminal 1.
• Follow the steps under „Set up rotation direction“ (S. 10) during connection of the actuator.
• Always refer to the wiring diagram located inside the actuator.
Check before you close the circuit for the rst time:
• Is the actuator undamaged on the outside?
• Is the mechanical connection correct?
• Has the electrical connection been made regularly?
• Check if current type, voltage and frequency match with the motor data (see nameplate on cover and inside the actuator).
• Insert suitable cable glands for the connection line.
• Observe the wiring diagram inside the cover.
• Use separate (shielded) wires for low voltages (e.g. potentiometer).
• Set up limit switches prior to initial operation (see page 11).
All elements, such as switches, potentiomer etc., are factory-wired.
Never change the internal wiring.
CAUTION
WARNING
ADVICE
!

10 Linearis N+

8
67
S1
11
910 5455
+–
Strom-
ausgang
S2
Standard Optionen
14
1213
S3
17
1516
S4
4.5.2 Wiring diagram
SL Limit switch, CCW
SR Limit switch, CW
S1 Auxiliary switch 1
S2 Auxiliary switch 2
R1 Potentiometer 1
All auxiliary switches must be operated within the same voltage range. Do not mix line
voltage with low voltage.
5. Operation of the actuators
5.1 Set up rotation direction
Due to the internal wiring, the rotation direction (viewing direction is through the actuator towards the shaft) and the limit switches
assign as follows:
1. With line voltage on terminal 1 and 2, the actuator shaft rotates counter-clockwise. Limitation of this rotation direction
with upper switch SL. When the switch is activated, line voltage is on terminal 4.
2. With line voltage on terminal 1 and 3, the actuator shaft rotates clockwise. Limitation of this rotation direction with lower
switch SR. When the switch is activated, line voltage is on terminal 5.
3. If the actuator runs counterrotating to the commands, change the external connection of terminal 2 and 3 .
Depending on the model, limit switches may be arranged different than drawn in the wiring
diagram (see wiring diagram inside the actuator).
ADVICE
!
ADVICE
!
Current
output
Options
M
+L +R 5T+ 4
SL SR
–
Steuerelektronik
+24V -24V
SL SR
24V DC
Option 24 V DC
see chapter 5.3.10
+L Limit switch, CCW
+R Limit switch, CW
T+ +24V DC
(Manual override see chapt. 5.3.9.1)
– -24V DC
4 Feedback left end position
5 Feedback right end position
