Corinex PowerNet User manual

m
s
t
‰
d

Contents
This Owner’s Manual, as well as the software described in it, is furnished under
license and may be used or copied only in accordance with the terms of the license.
The content of this manual is furnished for informational use only, it is subject to
change without notice, and it does not represent a commitment on the part of
Corinex Global Corp.
Corinex Global Corp. assumes no responsibility or liability for any errors or inaccuracies
that may appear in this book.
It is our policy to enhance our products as new technologies, hardware components,
software and firmware become available; therefore, the information contained in this
document is subject to change without notice.
Some features, functions, and operations described in this manual may not be
included and sold in certain countries due to government regulations or marketing
policies.
The use of the product or its features described in this document may be restricted or
regulated by law in some countries. If you are unsure which restrictions or regulations
apply, you should consult your regional Corinex office or the authorized reseller.
Published by:
Corinex Global Corp.
33076 – 1583 Marine Drive
West Vancouver, B.C., V7V 1HO
Canada
Tel: [phone]
Fax: [phone]
Corinex is a registered trademark of Corinex Global Corp.
Microsoft, MS−DOS, MS, Windows, Windows NT are either registered trademarks or
trademarks of Microsoft Corporation in the U.S.A. and/or other countries.
1.1 Overview
1
Corinex PowerNet USB Adapter• Owner‘s Manual
All products or company names mentioned herein may be the trademarks of their
respective owners.
Copyright (c) 2001−2002 by Corinex Global Corp.
Source document: Corinex Povernet USB Adapter_Owner's Manual.doc

Contents
Contents
1Introduction.................................................................................3
1.1 Overview...................................................................................... 3
1.2 About this Manual....................................................................... 3
2Installation Guide ........................................................................4
2.1 What this Package Contains......................................................... 4
2.2 System Requirements................................................................... 4
2.3 Installing the USB Adapter software ............................................5
3User‘s Guide...............................................................................10
3.1 PowerNet Setup Tool User Guide...............................................10
3.2 Corinex PowerNet USB Adapter .................................................13
3.3 FAQ .................................................................................... 14
3.4 USB Adapter Specifications........................................................ 15
4Troubleshooting Guide..............................................................17
1.1 Overview
2
Corinex PowerNet USB Adapter• Owner‘s Manual

1Introduction
1Introduction
1.1
1
Overview
Corinex PowerNet USB Adapter is network interface adapter, using
110/220 powerline as a medium for communication. After successful
installation, indoor PowerNet network behaves as traditional LAN for
computers. The Corinex PowerNet USB Adapter supports 14 Mbps−
network speed.
The product keeps network maintenance cost low and eliminates
usage barriers while there is no need for additional wiring.
The Product is a highly integrated and requires no glue logic or
external memory.
1.2 About this Manual
This Owner‘s Manual is intended to provide sufficient information to
help you understand successfully install the Corinex PowerNet USB
Adapter products to meet your networking needs.
1.1 Overview
3
Corinex PowerNet USB Adapter• Owner‘s Manual
With the information in this guide, you should be able to:
 Analyze your network needs…
 Plan the configuration of Corinex PowerNet USB Adapter
options…
 Install and configure your Corinex PowerNet USB Adapter
according to your plan…
 Verify and optimize your Corinex PowerNet USB Adapter
performance…

2Installation Guide
2Installation Guide 2
2.1 What this Package Contains
When you receive your Corinex PowerNet USB Adapter, check to be
sure that your package contains:
• Corinex PowerNet USB Adapter
• AC cord
• USB cable
• This manual
• Installation CD
2.2 System Requirements
• IBM compatible PC with one available USB port (Not hub)
• CD−ROM drive
• Windows 98/ME/2000/XP operating system
2.1 What this Package Contains
4
Corinex PowerNet USB Adapter• Owner‘s Manual

2Installation Guide
2.3 Installing the USB Adapter software
1. Insert the installation CD, it should automatically start. Do not
connect USB Adapter to PC before step 7! If the installation
program does not start automatically, start the application by
selecting „My Computer“, usually found on the desktop.
Navigate to the CD drive, and double click on the drive. The
following screen should be displayed:
2. Click „Yes“ to start installation. The following screen is the
welcome screen. Click „Next“ to continue.
2.3 Installing the USB Adapter software
5
Corinex PowerNet USB Adapter• Owner‘s Manual
3. The next screen will ask where PowerNet Setup Tool should be
installed. Click „Next“ to continue.

2Installation Guide
4. This screen will ask where Setup should place the program’s
shortcuts. Select Start Menu Folder or simply click „Next“.
2.3 Installing the USB Adapter software
6
Corinex PowerNet USB Adapter• Owner‘s Manual

2Installation Guide
5. The following screen will appear to inform that Setup is ready to
begin installing PowerNet Setup Tool on your computer. Click
„Install“.
6. The following screen will appear to inform that the USB driver
that is about to be installed does not have a Microsoft signature.
Accept this to continue. (this screen varies a little between
versions of Windows)
2.3 Installing the USB Adapter software
7
Corinex PowerNet USB Adapter• Owner‘s Manual

2Installation Guide
7. The next screen is the last step in the process, it is now time to
connect your Corinex PowerNet USB Adapter. Plug the supplied
AC cord into the USB Adapter and into an AC outlet. Plug the
supplied USB cable into the USB Adapter and to a USB port on
your PC. Another screen similar to the previous may appear.
Accept this to continue.
If the driver was not automatically installed, follow the
instructions in the driver installation wizard and select installation
from c:\program files\Corinex\PowerNet USB Adapter\USB drivers
2.3 Installing the USB Adapter software
8
Corinex PowerNet USB Adapter• Owner‘s Manual
8. The following screen appear in Windows 98/ME. Click “Yes” to
restart your system.

2Installation Guide
9. After restart (in Windows 20000/XP immediately, after step 7)
will be automatically run “PowerNet Setup Tool”. Refer to section
3.1 for details. This prevents anyone from intercepting your
transmitted data.
10. It is neccessary to configure network settings for your new
networking hardware. Refer to your operating system manual for
instructions to setup required parameters such as IP adddress
and subnet mask; or ask your system administrator for required
informations.
2.3 Installing the USB Adapter software
9
Corinex PowerNet USB Adapter• Owner‘s Manual
