Cornelius Nordic CCM0830 1 Guide

Nordic
Model CCM0830 1, 1030 1
Service Parts Manual
(Includes 50Hz. Units)
IMI CORNELIUS INC.
www.cornelius.com
Publication Number: 631806064
Revision Date: October 1, 2008
Revision: A
Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.
CCM0830 1-CCM1030 1 Service Parts Manual Manual Number 631806064

SERVICE PARTS MANUAL
22 INCH WIDE ICE SERIES CUBERS
MODEL-ICE0320, ICE0520
Includes 50Hz. Units
ICE-O-Matic
11100 East 45th Ave
Denver, Colorado 80239
Part Number 9081297-01 PD04/02 Rev1/05

CCM Series Service Parts Table Of Contents
This parts list contains the service parts available for the CCM Series icemakers listed below:
CCM0830*21 Air, Water and Remote
CCM0830*51 Air, Water and Remote
CCM1030*21 Air, Water and Remote
CCM1030*51 Air, Water and Remote
Check the model number on the data plate and refer to the correct listing for the specific component.
Check carefully that the correct part is identified and ordered.
Table of Contents Page 1
Cabinet Assembly Page 2 - 3
Evaporator/Water System Page 4 - 5
Air Cooled Page 6 - 7
Water Cooled Page 8 - 9
Remote Page 10 - 11
Control Box Page 12 - 13
Specific Compressor Components Page 13
Harvest Assist Assembly Page 14 - 15
Remote Condenser Page 16 - 17
Telephone Number
800-238-3600 All Departments
E-Mail: [email protected]
Website: www.cornelius.com
The CCM Series Service Manual is available separately, Part Number 631806061
Note: Model Number Suffix Indicates Machine Voltage As Follows
1=115/60/1
2=208-230/60/1
3=208-230/60/3
5=230/50/1
Engineering Revision Level =1
Page 1

CCM Series Service Parts Cabinet Assembly
Page 2

CCM Service Parts Exterior Panels
Item
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1 620204811 620204811 620204811 620204811 Front Panel
2 620204774 620204774 620204774 620204774 Front Panel Screws
3 620204457 620204457 620204457 620204457 Plastic Nut
4 620204930 620204930 620204930 620204930 Right Hand Side Panel-
A
ir Cooled Only
5 620204884 620204884 620204884 620204884 Right Hand Side Panel-Water and Remote Only
6 620204776 620204776 620204776 620204776 Side Panel Screws
7 620204809 620204809 620204809 620204809 Top Panel, Air Cooled
620204810 620204810 620204810 620204810 Top Panel, Water Cooled and Remote
8 620204444 620204444 620204444 620204444 Top Panel Screws
9 620204337 620204337 620204337 620204337 Rear Brace
10 620204885 620204885 620204885 620204885 Left Hand Side Panel
11 620204382 620204382 620204382 620204382 Rear Panel
12 620204441 620204441 620204441 620204441 Rear Panel Screws
13 620204349 620204349 620204349 620204349 Control Box Top Cover
14 620204347 620204347 620204347 620204347 Control Box Side Cover
15 620204929 N/
A
620204929 N/
A
Machine Compartment Cover
Model Number
Page 3

CCM Series Service Parts Evaporator/Water System
Page 4

CCM Series Service Parts Evaporator/Water System
Item Model Number
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204873 620204873 620204873 620204873 Evaporator Full Cube
1620204874 620204874 620204874 620204874 Evaporator Half Cube
2620204294 620204294 620204294 620204294 Water Distribution Tube
3620204453 620204453 620204453 620204453 Thumb Screw
4620204429 620204429 620204429 620204429 Rubber Washer
5N/A N/A N/A N/A Curtain Stopper
6620204494 620204494 620204494 620204494 Evaporator Mounting Panel Right Side
7620204486 620204486 620204486 620204486 Evaporator Water Return
8620204495 620204495 620204495 620204495 Evaporator Mounting Panel Left Side
9620204869 620204869 620204869 620204869 Evaporator Spillway
10 620204493 620204493 620204493 620204493 Evaporator Splash Curtain
11 620204521 620204521 620204521 620204521 Water Return Trough
12 620204443 620204443 620204443 620204443 Water Return Trough Screw
13 620204564 620204564 620204564 620204564 Float
14 620204563 620204563 620204563 620204563 Caplug (Float Deflector)
15 620204638 620204638 620204638 620204638 Water Pump
16 620204420 620204420 620204420 620204420 Clamp
17 620204420 620204420 620204420 620204420 Clamp
18 620204508 620204508 620204508 620204508 Water Pump Tube
19 620204404 620204404 620204404 620204404 Water Float Tubing (26 Inches required)
20 620204533 620204533 620204533 620204533 Water Inlet Fitting
21 620204530 620204530 620204530 620204530 Drop Adapter
22 620204466 620204466 620204466 620204466 Purge Valve
23 620204420 620204420 620204420 620204420 Clamp
24 620204928 620204928 620204928 620204928 Purge Drain Hose
25 620204419 620204419 620204419 620204419 Clamp
26 620204813 620204813 620204813 620204813 Purge Drain Fitting
Page 5

CCM Series Service Parts Air Cooled
Page 6

CCM Series Service Parts Air Cooled
Item Model Number
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204688 620204686 620204685 620204687 Compressor Kit
2620204612 620204612 620204612 620204612 Hot Gas Valve Body
3620204614 620204614 620204614 620204614 Hot Gas Valve Coil
4620204476 620204476 620204476 620204476 Low Pressure Control
5620204603 620204603 620204603 620204603 Filter Drier
6620204534 620204534 620204534 620204534 Service Valve Core
7620204535 620204535 620204535 620204535 Service Valve Cap
8620204596 620204596 620204596 620204596 Condenser
9620204478 620204478 620204478 620204478 Fan Control
10 620204882 620204882 620204882 620204882 Expansion Valve
11 620204924 620204924 620204924 620204924 Insulation-Danfoss Expansion Valve
12 620204814 620204814 620204814 620204814 Fan Shroud
13 620204577 620204574 620204577 620204812 Fan Blade
14 620204636 620204641 620204636 620204641 Fan Motor
15 620204286 620204335 620204286 620204335 Fan Motor Bracket
16 620204480 620204480 620204480 620204480 High Temperature Safety Control
17 620204926 620204926 620204926 620204926 Insulation Panel Bottom
18 620204927 620204927 620204927 620204927 Insulation Panel Top Divider
19 620204458 620204458 620204458 620204458 Insulation Clip
Note: The CCM0830 series has 1 fan motor, the CCM1030 series has 2 fan motors.
Page 7

CCM Series Service Parts Water Cooled
Page 8

CCM Series Service Parts Water Cooled
Item Model Number
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204688 620204686 620204685 620204687 Compressor
2620204883 620204883 620204883 620204883 Hot Gas Valve Body
3620204614 620204614 620204614 620204614 Hot Gas Valve Coil
4620204476 620204476 620204476 620204476 Low Pressure Control
5620204602 620204602 620204602 620204602 Filter Drier
6620204534 620204534 620204534 620204534 Service Valve Core
7620204535 620204535 620204535 620204535 Service Valve Cap
8620204587 620204587 620204587 620204587 Condenser
9620204465 620204465 620204465 620204465 Water Valve
10 620204474 620204474 620204474 620204474 High Pressure Control
11 620204882 620204882 620204882 620204882 Expansion Valve
12 620204924 620204924 620204924 620204924 Insulation-Danfoss Expansion Valve
13 620204480 620204480 620204480 620204480 High Temperature Safety Control
14 620204925 620204925 620204925 620204925 Receiver
15 620204926 620204926 620204926 620204926 Insulation Panel Bottom
16 620204927 620204927 620204927 620204927 Insulation Panel Top Divider
17 620204458 620204458 620204458 620204458 Insulation Clip
Page 9

CCM Series Service Parts Remote
Page 10

CCM Series Service Parts Remote
Item Model Number
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204688 620204686 620204685 620204815 Compressor
2620204612 620204612 620204612 620204612 Hot Gas Valve Body
3620204614 620204614 620204614 620204614 Hot Gas Valve Coil
4620204476 620204476 620204476 620204476 Low Pressure Control
5620204603 620204603 620204603 620204603 Filter Drier
6620204534 620204534 620204534 620204534 Service Valve Core
7620204535 620204535 620204535 620204535 Service Valve Cap
8620204606 620204606 620204606 620204606 Receiver
9620204474 620204474 620204474 620204474 High Pressure Control
10 620204882 620204882 620204882 620204882 Expansion Valve
11 620204924 620204924 620204924 620204924 Insulation Danfoss Expansion Valve
12 620204480 620204480 620204480 620204480 High Temperature Safety Control
13 620204475 620204475 620204475 620204475 Pump Down Control
14 620204612 620204612 620204612 620204612 Liquid Line Solenoid Body
15 620204614 620204614 620204614 620204614 Liquid Line Solenoid Coil
16 620204856 620204856 620204856 620204856 Valve-Shut Off
17 620204526 620204526 620204526 620204526 Remote Fitting 3/8 Male
18 620204527 620204527 620204527 620204527 Remote Fitting 1/2 Male
19 620204623 620204623 620204623 620204623 Check Valve
20 620204926 620204926 620204926 620204926 Insulation Panel Bottom
21 620204927 620204927 620204927 620204927 Insulation Panel Top Divider
22 620204458 620204458 620204458 620204458 Insulation Clip
Page 11

CCM Series Service Parts Control Box
14
Page 12

CCM Series Service Parts Control Box
Item Model Number
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204553 620204553 620204553 620204553 Purge Switch
2620204557 620204557 620204557 620204557 ON-OFF-WASH Switch
3620204548 620204548 620204548 620204548 Relay Socket
4620204551 620204551 620204551 620204551 Relay
5620204559 620204559 620204559 620204559 Water Pump Cord
6620204545 620204545 620204545 620204545 Contactor
7See Below See Below See Below See Below Compressor Start Relay
8See Below See Below See Below See Below Start Capacitor
9See Below See Below See Below See Below Run Capacitor
10 620204555 620204555 620204555 620204555 Timer
11 620204476 620204476 620204476 620204476 Low Pressure Timer Initiate
12 620204310 620204310 620204310 620204310 Curtain Switch Assembly
13 620204552 620204552 620204552 620204552 Curtain Switch
14 N/
A
N/
A
N/
A
N/
A
Bin Thermostat
Compressor Components
Model Number
CCM0830 2 A &
W
620204686 Compressor
620204649 Start Capacitor
620204672 Run Capacitor
620204678 Rela
y
CCM0830 2 R AND CCM1030 2 A &
W
620204687 Compressor
620204649 Start Capacitor
620204672 Run Capacitor
620204678 Rela
y
CCM0830 5 A W &
R
620204688 Compressor
620204654 Start Capacitor
620204672 Run Capacitor
620204675 Rela
y
CCM1030 2 R 620204815 Compressor
620204651 Start Capacitor
620204670 Run Capacitor
620204676 Rela
y
CCM1030 5 A W &
R
620204685 Compressor
620204649 Start Capacitor
620204670 Run Capacitor
620204678 Rela
y
A = Air Coole
d
W= Water Cooled
R= Remote
Page 13

CCM Series Service Parts Harvest Assist Assembly
Page 14

CCM Series Service Parts
Item
No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description
1620204366 620204366 620204366 620204366 Bracket, Probe Motor
2620204631 620204631 620204631 620204631 Gear Motor
3620204569 620204569 620204569 620204569 Clutch Assembly 180 Degree
4620204483 620204483 620204483 620204483 Snap Bushing
5620204481 620204481 620204481 620204481 Snap Bushing
6620204439 620204439 620204439 620204439 #6-32 x 1/2 Fillister Head Screw
7620204484 620204484 620204484 620204484 Connecting Rod
8620204424 620204424 620204424 620204424 Probe, Single Length
9620204427 620204427 620204427 620204427 Plain Flat Washer
10 620204451 620204451 620204451 620204451 Shoulder Screw
11 620204516 620204516 620204516 620204516 Spacer, Cam Switch
12 620204556 620204556 620204556 620204556 Cam Switch
13 620204407 620204407 620204407 620204407 Insulator, Switch
14 620204434 620204434 620204434 620204434 Pan Head Machine Screw
15 620204452 620204452 620204452 620204452 Speed Nut Plate
620204312 620204312 620204312 620204312 Complete Assembly
Model Number
Page 15

CCM Series Service Parts Remote Condenser
Page 16

CCM Series Service Parts RC Condenser
CCM0830R 1 CCM1448R1 CCM1848R1
CCM0530R CCM0630R CCM1030R 1 CCM1530R1 CCM2148R1
Item RC05001 RC06002 RC08002 RC14002C RC21002C Description
1 620204581 620204581 620204581 620204581 620204843 Fan Guard
2 620204369 620204369 620204369 620204369 620204838 Top Panel
3 620204436 620204436 620204436 620204436 620204436 ¼-20 x 1/2 Screw
4 620204580 620204580 620204580 620204580 620204844 Fan Blade
5 620204647 620204646 620204646 620204646 620204846 Fan Motor
6 620204425 620204425 620204425 620204425 620204425 ¼-20 x ¾ Cap Screw
7 620204426 620204426 620204426 620204426 620204426 Flat Washer
8 620204448 620204448 620204448 620204448 620204448 Flanged Lock Nut
9 620204436 620204436 620204436 620204436 620204436 ¼-20 x 1/2 Screw
10 620204371 620204371 620204371 620204371 620204371 Rear Panel
11 620204373 620204373 620204373 620204373 620204840 Brace
12 620204374 620204374 620204374 620204374 620204374 Leg
13 620204375 620204375 620204375 620204375 620204841 Leg Brace
14 N/A N/A N/A N/A N/A T-Nut-Shipping Only
15 620204373 620204373 620204373 620204373 620204840 Brace
16 620204377 620204377 N/A N/A N/A Cover Panel
17 602204372 602204372 602204372 602204372 620204839 Center Panel
18 620204370 620204370 620204370 620204370 620204370 Front Panel
19 620204379 620204379 620204379 620204379 620204842 Motor Brace
20 620204378 620204378 620204378 620204378 620204378 Motor Brace Support
21 620204376 620204376 620204376 620204376 620204376 Junction Box Cover
22 620204625 620204625 620204625 620204625 620204625 Mixing Valve
23 620204600 620204600 620204600 620204837 620204845 Condenser
24 620204626 620204626 620204626 620204626 620204626 Filter
25 620204527 620204527 620204527 620204527 620204527 1/2 Coupling
26 620204526 620204526 620204526 620204526 620204526 3/8 Coupling
27 620204627 620204627 620204627 620204627 620204627 Filte
r
Page 17
