Corsair K70 PRO MINI User manual

K70 PRO MINI
RGB WIRELESS MECHANICAL GAMING KEYBOARD
PУССКИЙ
RU
ﺔﻴﺑﺮﻌﻟا
AR
日本語
JA
한국어
KO
繁體中文
TC
POLSKIPL
PORTUGUÊS (BRAZIL)BP
SVENSKASV
ITALIANOIT
ESPAÑOL (LATIN AMERICA)LA
ESPAÑOL (EURO)ES
PORTUGUÊS (EURO)PT
NORSKNO
SUOMIFI
FRANÇAIS (EURO)FR
DEUTSCHDE
DANSKDA
NEDERLANDSNL
ENGLISHEN
FRANÇAIS (CAN)CF

GETTING TO KNOW YOUR KEYBOARD
BEFORE FIRST USE
Charge the keyboard fully before first use by connecting the USB cable (F) to the keyboard
USB Type-C port (E) and to an available USB 3.0 or better Type-A port on a compatible
device including:
Windows®PC Apple Mac®Microsoft Xbox One*
Microsoft Xbox Series X|S*
PlayStation 4**
PlayStation 5**
*Keyboard is compatible out of the box, see corsair.com/xbox-support for details.
**See Connecting to Sony PlayStation section.
ENGLISH
Hold the ESC key while turning the power switch (D) to on, then release the ESC key after two
seconds. The keyboard will then power on normally and be reset to factory defaults.
FACTORY RESET
A SLIPSTREAM WIRELESS ADAPTER
B 360° LIGHTEDGE
C REMOVEABLE ACCENT PIECE
D POWER SWITCH
E USB TYPE-C PORT
F USB TYPE-C TO TYPE-A CABLE
GOPTIONAL CORSAIR LOGO ESC KEY
H OPTIONAL RADIANT SPACE BAR
I KEYSWITCH PULLER
J KEYCAP PULLER
ENGLISH
1
BA
A
D E
G
C
HF
I J

CHARGING & BATTERY LIFE
CONNECTING VIA SLIPSTREAM WIRELESS
*To complete pairing to a SLIPSTREAM wireless adapter, initiate adapter pairing in iCUE device settings.
1. Plug in the SLIPSTREAM wireless adapter (A) to an available
USB 2.0 or better Type-A port
2. Slide the keyboard power switch (D) to the on position
3. Switch to SLIPSTREAM wireless mode (see below)
4. After SLIPSTREAM connects automatically, the shortcut key
turns solid white for 3 seconds
SHORTCUT FUNCTION ON-KEY INDICATION STATUS
FN + (Press) Switch to SLIPSTREAM
wireless mode
Solid White (3 sec) Connected
Pulsing White Disconnected
FN + (Hold) Start SLIPSTREAM
adapter pairing* Rapidly Blinking White Pairing
The keyboard will indicate charging status when plugged into a compatible device via USB cable.
Upon powering on the keyboard or using the check battery life shortcut below, an indication
will play to denote current battery charge level.
INDICATOR INDICATION STATUS
Enter Key
Solid Green Fully Charged
Pulsing Green Charging
SHORTCUT FUNCTION ON-KEY INDICATION STATUS
FN + Check Battery
Charge Level
Solid Green Fully charged
Blinking Green High charge
Blinking Amber Medium charge
Blinking Red Low charge
Pulsing Red Critically low charge
Tips and tricks:
• If left on and idle, the keyboard will go to sleep to conserve battery (adjustable in iCUE).
• Reduce brightness or turn off backlighting to extend battery life (and increase charging speed).
• Charge as soon as possible when battery is critically low to maximize battery health
and longevity.
• Always plug into a USB 3.0 port or better to ensure adequate charging current.
ENGLISH
2

CONNECTING VIA BLUETOOTH WIRELESS
1. Initiate Bluetooth pairing on the host device such as a phone or tablet (Bluetooth 4.0 or higher)*
2. Start Bluetooth host pairing on the keyboard, up to three devices can be paired (see below)
3. Input the code from the Bluetooth device screen on the keyboard if requested
4. When pairing completes, the Bluetooth shortcut key turns solid blue for 3 seconds
*Bluetooth host device must support standard keyboard HID input.
SHORTCUT FUNCTION ON-KEY INDICATION STATUS
FN + (Press) Switch to Bluetooth host 1 mode
Solid Blue (3 sec) Connected
Pulsing Blue Disconnected
FN + (Hold) Start Bluetooth host 1 pairing* Rapidly Blinking Blue Pairing
FN + (Press) Switch to Bluetooth host 2 mode
Solid Blue (3 sec) Connected
Pulsing Blue Disconnected
FN + (Hold) Start Bluetooth host 2 pairing* Rapidly Blinking Blue Pairing
FN + (Press) Switch to Bluetooth host 3 mode
Solid Blue (3 sec) Connected
Pulsing Blue Disconnected
FN + (Hold) Start Bluetooth host 3 pairing* Rapidly Blinking Blue Pairing
CONNECTING VIA USB WIRED
1. Connect the keyboard via USB cable to a USB 3.0 Type-A port or better
2. The keyboard will automatically switch to USB wired mode
3. Go to iCUE device settings to select up to 8,000Hz hyper-polling with
CORSAIR AXON*
NOTE: Wireless modes can be switched to at any time by pressing a wireless shortcut. Pressing
the same shortcut again will switch back to USB wired mode.
*Up to 8,000Hz hyper-polling is supported on PC and Mac. Xbox and PlayStation consoles support up to
1,000Hz polling only.
ENGLISH
3

CONNECTING TO SONY PLAYSTATION
Download iCUE from corsair.com/downloads and install on a Windows PC or Apple Mac to
connect all of your CORSAIR iCUE compatible products together in a single interface, giving you
complete control of everything from lighting to powerful macros.
When iCUE is running the keyboard operates in software mode and is
controlled by iCUE.
SOFTWARE MODE
HARDWARE MODE
When iCUE is not running or the keyboard is connected to a device that does not support
iCUE, the keyboard operates in hardware mode which uses profiles and settings saved to the
onboard storage.
*The number of lighting effects layers per profile and total number of proflles that can be saved to onboard storage
will vary based on complexity.
With iCUE and AXON Hyper-Processing Technology, you can create as
many custom profiles as can fit onto the 8MB of onboard storage. Each
profile can store complex backlighting effects (up to 20 layers), actions &
macros, and settings.*
The keyboard also has a special mode to support Sony PlayStation 4 and 5 via SLIPSTREAM
wireless and USB wired modes that can be activated via shortcut.
NOTE: Available functions may be limited depending on gaming console support and application.
SHORTCUT FUNCTION ON-KEY INDICATION
FN + (Hold for 5 sec)
Switch to PlayStation mode Blinks White (5 sec) then Solid White
Switch back to standard mode Pulses White (6 sec)
ENGLISH
4

The keyswitches can be removed and replaced with any variety or combination of CHERRY MX
RGB mechanical keyswitches. Other third party mechanical keyswitches with 3-pin design may
be compatible, but are not guaranteed to work due to physical differences.
Note: Be sure to align the new keyswitch properly before insertion to prevent bent pins or damage.
SWAPPING KEYSWITCHES
3. Align the new keyswitch's pins and
base with the sockets and opening.
4. Carefully press the keyswitch in until it
clicks into place. If you feel any resistance,
remove and try again.
1. Push the keycap puller (J) over the
keycap, then lift to remove.
2. Position the tips of the keyswitch puller
(I) under the keyswitch top and bottom
tabs, then press in and lift to remove.
ENGLISHENGLISH
5

PROFILE & LOCK FUNCTIONS
With iCUE you can program Win Lock to not only disable the Windows
key, but other key combinations that could interrupt your game, as well
as create new profiles and assign unique colors.
HARDWARE LIGHTING
Basic hardware lighting effects can be controlled via the below shortcuts when iCUE is not
running or the keyboard is connected to a device that does not support iCUE.
*Functions supported on select effects.
SHORTCUT FUNCTION
FN + Adjusts backlighting brightness in 20% decrements
FN + (Press)
Cycle through basic lighting effects
Water Color > Spiral Rainbow > Rain > Rainbow Wave > Visor > Type Lighting (Per-key) >
Type Lighting (Ripple) > Color Shift > Color Pulse > Color Wave > Static Color (8 Colors)
FN + (Hold) Reset lighting effect to onboard default
FN + Change lighting effect direction*
FN + Change lighting effect speed*
With iCUE you can program vivid and dynamic custom multi-layered
lighting effects then save them to onboard storage.
SHORTCUT FUNCTION ON-KEY INDICATION
FN + Change Profile Changes color based on profile (3 sec)
FN + Win Lock Solid red (when on)
FN + SCRLK Scroll Lock TAB Solid red (when on)
CAPS Caps Lock CAPS Solid red (when on)
ENGLISH
6

STANDARD SHORTCUTS
Full-size Keyboard Keys
SHORTCUT KEY FUNCTION
FN + ESC See legend on keycap
for function
FN + SHIFT + ESC
FN + number keys F1 to F12
FN + Arrow Up
FN + Arrow Left
FN + Arrow Down
FN + Arrow Right
SHORTCUT KEY FUNCTION
FN + DEL Delete
FN + INS Insert
FN + HOME Home
FN + END End
FN + PG UP Page Up
FN + PG DN Page Down
FN + PRTSC Print Screen
FN + PAUSE Pause Break
Windows
SHORTCUT WINDOWS FUNCTION
CTRL + ALT + FN + Control + Alt + Delete
ALT + FN + 4 Alt + F4
CONTROL SHORTCUTS
Audio and Media
SHORTCUT MEDIA FUNCTION
FN + Last Track
FN + Play / Pause
FN + Next Track
SHORTCUT AUDIO FUNCTION
FN + Mute Audio
FN + Decrease Volume
FN + Increase Volume
Mouse Cursor
*Available cursor speed settings are 125, 250, 500, 1000, and 2000 DPI.
SHORTCUT MOUSE FUNCTION
FN + Move Cursor Up
FN + Move Cursor Left
FN + Move Cursor Down
FN + Move Cursor Right
SHORTCUT MOUSE FUNCTION
FN + Left Click
FN + Right Click
FN + Increase Cursor Speed*
FN + Decrease Cursor Speed*
ENGLISH
7

MACRO RECORDING
Macros can be recorded at any time via the below process. In hardware mode your macros are
recorded to onboard storage and in software mode your macros are recorded to the current
iCUE profile.
NOTE: Saving a macro to a key or existing shortcut will overwrite that function until cleared.
*Hardware lighting, special functions, wireless modes, and control shortcuts cannot be recorded.
**Function keys as well as macro recording and wireless shortcuts cannot be recorded over.
Macro Clearing
Process Hold FN +
(2 seconds) >Press
FN +
>
Press any key or
FN + key
combination to clear
Recording
On-Key Indication Pulses Red > Rapidly
Blinks Red Rapidly Blinks Red
Keys that can be recorded:*
• Standard keys
• Standard shortcuts
Macros can be recorded to:
• Any key**
• FN + key**
• FN + Menu (FN2) + key
Macro
Recording Process
Hold
FN +
(2 seconds)
>
Press keys to record
>Press
FN +
>
Press any key or FN +
key combination to save
Recording
On-Key Indication Pulses Red > Blinks Red > Rapidly
Blinks Red Hold FN + to cancel
(2 seconds)
With iCUE you can edit recorded macros and assign additional actions
to keys.
ENGLISH
8

BATTERY REMOVAL INFORMATION
This product uses a rechargeable battery and safety guidelines must be followed in the event that
the product is disabled for disposal and recycling. To safely remove the battery for disposal and
recycling, follow the numbered steps with the below diagrams.
CORSAIR MEMORY, Inc. encourages customers to recycle used electronic hardware and
rechargeable batteries in accordance with local laws and regulations.
FCC ID: 2AAFMRGP0127
FCC ID: 2AAFMRGP0119
IC: 10954A-RGP0127
IC: 10954A-RGP0119
9
1
3
5
4

© 2022 CORSAIR MEMORY, Inc. All rights reserved. CORSAIR and the sails logo are registered
trademarks of CORSAIR in the United States and/or other countries. All other trademarks are the
property of their respective owners. Product may vary slightly from those pictured.
49-002535 AA
