Cortex CU-GSM User manual

CU-GSM central unit
v.2.0
User manual
Riga, Latvia
2012

General information
CU-GSM central unit is a one-channel receiver, that collects information via GSM channel
using voice channel and SMS-messages and transmits it to the WinSC software. entral unit
receives information via voice channel in Contact ID protocol (RT4-5gt device) and via SMS
messages in Contact ID, Silent knight (4x2), aradox and Magellan protocols (RT4-5gc
device).
1. GSM-antenna
2. SIM holder
3. Jumper block for power supply selection
4. Power socket
5. USB-socket
6. Receiver indicator
7. GSM mode indicator
© Korteks 2012
Liksnas street 7, Riga, Latvia, Phone nr./fax: [phone]
E-mail: [email protected], http://www.cortex.lv
2

owering and activating
In order to work properly a SIM-card must be inserted in the central unit. SIM must be
activated, PIN request must be turned on and SIM PIN must be set as "0000".
SIM must be inserted before central unit is turned on.
entral unit can be powered in two different ways:
1. Using power supply that provides 10-15V voltage and 250 мА current. Power supply is
connected to the power socket (5). To use this option jumper on the power selection
block (4) must connect central pin and ADAPT pin (Default option).
2. USB-port is used as a power supply. To use this option jumper on the power selection
block (4) must connect central pin and USB pin.
Attention! It is strictly recommended to use the first option to power the device.
After powering up, GSM indicator (8) will start to flash. First 10-15 seconds it will flash
constantly (flash and pause approximately 1 second each). During this time Receiver indicator
should flash two times. This will mean that SIM is initialized successfully and all the settings are
loaded. After that GSM indicator should start flashing once every three seconds. If that didn't
happen than the probable troubles are following:
−SIM-card is not activated
−PIN request is turned off
−PIN is different from "0000" карточки отличается от «0000»
−entral unit is out of GSM coverage of the current mobile operator
Connecting to WinSC software
When first connected to the computer, CU-GSM requires a MM232R driver to be installed.
After installing the driver, CU-GSM should be recognized by the operating system as USB
serial port and can be connected to the WinSC software.
To do so, open receiver settings window - Service/Receiver settings. In that window you
must specify channel number and corresponding OM-port in the Slot field. In the Receiver
Type field you have to select U-GSM. After that, press ort settings button and set the OM-
port preferences. They must be the following:
Baud rate 9600
Data bits 8
arity None
Stop bits 1
Flow control None
Time of heartbeat test 01:30
© Korteks 2012
Liksnas street 7, Riga, Latvia, Phone nr./fax: [phone]
E-mail: [email protected], http://www.cortex.lv
3

Central unit indication
GSM-indicator (green LED). After powering on, for 10-15 seconds it will flash once per
second. After Initializing and while working properly it will flash once every 3 seconds.
Receiver indicator (red LED). When initializing it will double-flash once. After initialization
it will flash every time information is received.
Sound signal – short single beep is formed if U-GSM didn't receive an answer to it's test
message from the software. Long sound signal is formed if U-GSM failed to transmit received
message to the software.
Central unit events
entral unit events are described in the system events editor window - Service/System events
Editor
All messages look the following way:
Account Event code Event description
0000 Т50 SIM error
0000 R50 SIM initialization successful
0000 Т40 Blank call. No data received
0000 Т10 Faulty data received
0000 А20 No GSM coverage
0000 R30 GSM coverage restored
0000 T60 heck sum error
0000 Т70 SMS sending failure
0000 R70 SMS sent successfully
0000 T80 Incorrect SMS text
