Cosco Scenera Next User manual

i ii
SCENERA NEXT
CONVERTIBLE CAR SEAT
Rear Facing: 5-40 lb and 19-40 in.
(2.3-18 kg and 48-101.6 cm)
Forward Facing: 22-40 lb and 29-43 in.
and at least 1 year old
(10.1-18 kg and 73.6-110 cm)
KEEP INSTRUCTIONS FOR FUTURE USE.
Read all instructions before using this child
restraint.
Failure to follow the warnings on the labels
and in the instruction manual can result in
serious injury or death to your child.
FUNSMARTSIMPLE
©2016 Dorel Juvenile.All Rights Reserved.
To see installation videos, scan the QR
Code or visit www.coscokids.com.
LOWER
ANCHOR
BELT
Page 28
TETHER
Page 47
CUP
HOLDER
Page 24
4358-7084A 2.7.17

WARNING:Verify your child’s weight and height
(do not guess) before choosing the child restraint’s
placement.
See page 3 to adjust
internal harness system
See page 3 to adjust
internal harness system
Choosing Rear or Forward Facing
Your child’s height, weight,and age determine how your child restraint should be
placed in the vehicle.Please talk to your doctor about the best option for your child.
+
+
Lower Anchor Belt
Install Page 37
Vehicle Belt Install
Page 42
Lower Anchor Belt
Install Page 48
Vehicle Belt Install
Page 52
REAR FACING
5-40 lb (2.3-18 kg)
19-40 in. (48-101.6 cm)
Children up to 1 year of age must ride rear facing.
The American Academy of Pediatrics recommends
that children remain rear facing until they are at
least 2 years old.
In this child restraint, your child can remain rear facing
up to 40 lb (18 kg) and up to 40 in. (101.6 cm).
FORWARD FACING
22-40 lb (10.1-18 kg)
29-43 in. (73.6-110 cm)
At least 1 year old
The American Academy of Pediatrics recommends
that children remain in a five-point harness until
they outgrow their forward-facing harnessed child
restraint.
This typically occurs around age 4, but some children
outgrow them sooner and others not until later.

Table of Contents
Getting Started................ 1
Parts of the Child Restraint..............1
Prepare Child Restraint to Fit Your
Child..............................................3
How Does Your Child Fit?................4
Changing Position of Buckle............6
Changing Position of Shoulder Harness
Strap..............................................8
Harness System Adjustments for Smaller
Infants............................................10
Securing Child in Child Restraint......15
General Use ..................... 18
Removing Harness System..............18
Removing Seat Pad for Cleaning......20
Installing Harness System................21
Accessories on Select Models.........24
Safety Information ........... 25
Child Restraint Use .........................25
Vehicle Seating Position..................26
Installation in Vehicle ......................26
Vehicle Information.......... 28
Choosing Lower Anchor
or Vehicle Belts...............................28
Knowing Your Vehicle Belts.............31
Aircraft Information.........................35
Rear Facing ...................... 36
Lower Anchor Belt Installation....37
Vehicle Belt Installation..........42
Forward Facing................ 46
Tether Use ............................47
Lower Anchor Belt Installation....48
Vehicle Belt Installation.........52
Important Information ..... 55
Using a Locking Clip.......................55
Dorel Juvenile Group Information......57
Registration and Safety Notices.......58
Troubleshooting..............................59
Replacement Parts Order Form........60
Warranty........................................62

1 2
Parts of the Child Restraint
PQ
R
S
L
KM
O
N
A. Shoulder Harness Slots
B. Harness Strap
C. Chest Clip
D. Buckle
E. Cup Holder Attachment
(under pad)
F. Hip Harness Slots
G. Harness Release Lever
(under flap)
H. Harness Adjustment Strap
I. Cup Holder (see page 24)
J. Lower Anchor Belt (see page 28)
Side ViewFront View Back View
A
B
C
D
E E
F
G
HJ
I
K. Lower Anchor Belt
Attachment for Storage
(under side of shell)
L. Rear-Facing Belt Path
M. Forward-Facing Belt Path
N. Rear-Facing Level Line
O. Shell (child restraint)
P. Tether (see page 47)
Q. Instruction Manual Storage
R. Tether Attachment for Storage
S. Splitter Plate
H

3 4
4. Place Child in
Child Restraint to
Determine Proper
Harness Fit
The child’s bottom
and back should
be flat against the
child restraint. See pages 4-5 for fit
guidelines.
How Does Your Child Fit?Prepare Child Restraint to Fit Your Child
4
1. Fully Loosen
Harness Strap
Push down on harness
release lever (under
flap on front of seat
pad) while pulling out
on harness strap as
shown.
3. Release Chest Clip
Press on chest clip
release button and pull
apart. Place harness
strap out of the way.
2. Unbuckle Harness
Press in towards the
top of the red button.
Pull buckle tongues
out.
REAR FACING
Buckle Position
Start in the 1st slot and
adjust outward as your
child grows.
Buckle should be used
in the slot closest to
your child.The buckle should be not
underneath or behind your child.
1st or 2nd slot MUST be used.
Harness Strap
Position
Harness strap MUST
be at or slightly below
shoulders.Always
choose the shoulder
harness slot closest to your child’s
shoulder height.
If the lowest shoulder harness slots are
above the child’s shoulders, do not use
this child restraint.
To change the buckle position, see pages 6-7.
To change harness strap position, see pages 8-9.
To make adjustments for smaller infants, see pages 10-14.
Use the guidelines below to determine if the buckle and harness strap are in the right
place for your child.
1
2
continued on next page

5 6
Changing Position of Buckle
FORWARD FACING
Buckle Position
Start in the 1st slot
and adjust outward as
your child grows.
Buckle should be
used in the slot clos-
est to your child.The buckle should not
be underneath or behind your child.
Any slot can be used.
Harness Strap
Position
Harness strap MUST
be at or slightly
above shoulders.
Always choose the
shoulder harness slot closest to your
child’s shoulder height.
If the highest shoulder harness slots
are below the child’s shoulders, do not
use this child restraint.
1
2
3
1. Turn Seat Over
Locate buckle’s
metal retainer on
bottom of shell.
2. Rotate Metal
Retainer and Push
It Up Through Shell
and Pad
3. From Top of Seat,
Pull Buckle Out of
Shell
4. Insert Buckle’s
Metal Retainer into
Slot Closest to Child
Buckle MUST face
out.
You MUST use the 1st
or 2nd buckle slots when child restraint
is used rear facing. Any slot can be used
when forward facing.
1
2
3
continued on next page
To change the buckle position, see pages 6-7.
To change harness strap position, see pages 8-9.

7 8
Changing Position of Shoulder Harness Strap
5. Pull Metal
Retainer
Completely
Through Pad and
Shell
6. Check Buckle
Pull up on buckle
to make sure it is
secured.
The buckle MUST
not pull out.
WARNING: Failure to place
buckle’s metal retainer completely
through pad and shell can result in
serious injury or death.
1. Fully Loosen
Harness Strap
Push down on
harness release lever
(under flap on front of
seat pad) while pulling
out on harness strap
as shown.
2. From Back,
Remove Harness
Strap Loops From
Splitter Plate
3. Pull Harness
Strap Out of
Shoulder Harness
Slots
continued on next page
If you will be using
the lowest shoulder
harness slots, see
pages 10-14.
Otherwise, continue
on to step 4.

9 10
5. Attach Harness
Strap Loops to
Splitter Plate
Sewn ends of the
harness strap loops
MUST face towards
you.
DO NOT twist harness strap or harness
adjustment strap. Make sure the harness
strap loops are fitted COMPLETELY ON
both sides of the splitter plate.
sewn
end
WARNINGS: Make sure the
harness height is correct for your
child’s size. Do not use this child
restraint rear facing
unless the top of your
child’s head is at least
1 in. (2.5 cm) below
the top of the child
restraint.
Do not use this child
restraint forward facing
if the tops of your
child’s ears are above
the top of the child
restraint.
Failure to follow these steps can
result in serious injury or death.
4. Rethread
Harness Strap into
Correct Shoulder
Harness Slots For
Your Child
See pages 4-5 for
fit guidelines.
When using the lowest shoulder harness slots, you MUST make these
adjustments.
2. With Buckle in
the 1st Slot As
Shown, Turn the
Seat Over
If you need to move
the buckle to the 1st
slot, see page 6.
3. From Bottom of
Seat, Pull Metal
Retainer Towards
You and Push It
Up into Middle
Slot As Shown
4. From Top of
Seat, Lay the Metal
Retainer Flat
Against the Shell
As Shown
Harness System Adjustments for Smaller Infants
continued on next page
1. Pull Up Front of
Seat Pad

11 12
Choosing Rear or Forward Facing
7. From Back,
Remove Harness
Strap Loops From
Splitter Plate
8. Pull Harness
Straps Out of
ShoulderHarness
Slots
6. Fully Loosen
Harness Strap
Push down on
harness release
lever (under flap on
front of seat pad)
while pulling out on
harness strap as
shown. continued on next page
9. Unthread Chest
Clip
10. Unthread
Buckle
Do not unbuckle the
buckle.
11. Turn Seat Over
and Pull Harness
Strap Down and
Out of Hip Harness
Slot
5. Check Buckle
Pull up on buckle
to make sure it is
secured.
The buckle MUST
not pull out.
12. Weave Harness
Strap In and Out of
Shell as Shown
Harness strap goes
behind buckle strap.
front of seat
bottom of seat

13 14
Choosing Rear or Forward Facing
15. Thread Buckle
and Chest Clip
Harness strap end
goes through the
back of buckle
tongues and through
the chest clip front to
back as shown.
13. Thread
Harness Strap Up
Through Slot in
Seat Pad
17. Attach Harness
Strap Loops to
Splitter Plate
Sewn ends of the
harness strap loops
MUST face towards
you.
DO NOT twist
harness strap or
harness adjustment
strap. Make sure
the harness strap
loops are fitted
COMPLETELY ON
both sides of the
splitter plate.
16. Thread Harness
Strap Into Lowest
Shoulder Harness
Slots
18. Replace Seat
Pad Around Front
of Shell
WARNINGS: Harness system
must be installed correctly.
Failure to follow these warnings
can result in serious injury or
death.
sewn
end
14. Make Harness
Strap Even
Sewn ends of
harness strap loops
MUST face each
other.

15 16
Securing Child in Child Restraint
1. Place Child in
Child Restraint
The child’s bottom
and back should be
flat against the child
restraint.
Position harness strap over child’s
shoulders and upper thighs.
2. Buckle Harness
Push buckle tongues
into buckle until you
hear a “click.”
Pull up on harness
strap to make sure
buckle is locked.
3. Close Chest Clip
Insert right half
of chest clip into
left half and snap
together.
4. Tighten Harness
Pull on harness
adjustment strap
to tighten harness
snugly.
continued on next page
5. Position Chest
Clip
The chest clip must
be placed at mid-
chest (even with
armpits) and away
from the child’s neck.
6. Check Harness
Tightness
Try to pinch the
harness at the
shoulders vertically
between index finger
and thumb as shown.
If your fingers slip off, the harness is
tight enough.
If you can pinch the harness strap,
tighten more. The harness strap should
be snug throughout its length.
A snug strap should not allow any slack.
It lies in a relatively straight line without
sagging. It does not press on the child’s
flesh or push the child’s body into an
unnatural position.

17 18
WARNINGS: Failure to fasten
and tighten the harness system
correctly may allow the child to
be ejected from the child restraint
in a crash or sudden stop causing
serious injury or death.
Do not mistake comfort for safety.
Harness system must be snugly
adjusted.
DO NOT put snow-
suits or bulky
garments on your
child when
placing them in the
child restraint.
Bulky clothing can
prevent the harness straps from
being tightened properly.
To Remove Child From Child Restraint
1.Loosen Harness Strap
2.Unbuckle Harness 3.Release Chest Clip 4.Remove Child
2. From Back,
Remove Harness
Strap Loops From
Splitter Plate
4. Unthread Chest
Clip
3. Pull Harness
Strap Out of
Shoulder Harness
Slots
1. Fully Loosen
Harness Strap
Push down on
harness release
lever (under flap on
front of seat pad)
while pulling out on
harness strap as
shown.
Only remove the harness system to clean the seat pad.
Removing Harness System
continued on next page

19 20
6. Pull Harness
Strap Out of Seat
7. Turn Seat Over
Locate buckle’s metal
retainer on bottom of
shell.
8. Rotate Metal
Retainer and Push
It Up Through Shell
and Pad
9. From Top of
Seat, Pull Buckle
Out of Shell
5. Unthread Buckle
Do not unbuckle the
buckle. Remove Pad
Pull pad off the
bottom of child
restraint and
remove pad.
You must remove the harness system to remove the pad from the
shell. See pages 18-19. Cleaning Pad
Machine wash separately with cold water
on a gentle cycle. Do not use bleach.
Tumble dry separately for 10-12 minutes
on low heat. Remove immediately.
Cleaning Harness Strap
Spot clean using warm sudsy water and
damp cloth.
Replacing Pad
Starting from bottom of child restraint,
slip pad on shell. Pull harness adjustment
strap through pad. Wrap pad around the
top of shell. Install harness system, see
pages 21-23.
WARNINGS: Do not use child
restraint without the seat pad.
Failure to do this can result in
serious injury or death.
Removing Seat Pad for Cleaning

21 22
Installing Harness System
1. Insert Buckle’s
Metal Retainer into
Slot Closest to Child
Buckle MUST face out.
You MUST use the 1st
or 2nd buckle slots
when child restraint is
used rear facing. Any slot can be used
when forward facing.
3. Check Buckle
Pull up on buckle
to make sure it is
secured.
The buckle MUST not
pull out.
2. Pull Metal
Retainer
Completely
Through Pad
and Shell
1
2
3
continued on next page
If you will be
using the lowest
shoulder harness
slots, see pages
10-14.
Otherwise, continue
on to step 1.
7. Thread Buckle
and Chest Clip
Harness strap ends
go through the back
of buckle tongues
and through the chest
clip front to back as
shown.
6. Make Harness
Strap Even
Sewn ends of
harness strap loops
MUST face each
other.
5. Pull Harness
Strap Across
Bottom of Shell
Harness strap MUST
lie in front of harness
adjustment strap as
shown. Push harness
strap up through
other hip harness
slot.
4. Rethread Harness
Strap
With sewn end of
harness strap loop
facing the buckle,
thread harness strap
down through hip
harness slot.

23 24
9. Attach Harness
Strap Loops to
Splitter Plate
Sewn ends of the
harness strap loops
MUST face towards
you.
WARNINGS: Failure
to place harness adjust-
ment strap behind the
harness strap as shown
can result in serious
injury or death.
Harness system must be installed
correctly.
Failure to follow these warnings can
result in serious injury or death.
8. Thread Harness
Strap Into Correct
Shoulder Harness
Slots For Your Child
See pages 4-5 for
fit guidelines.
sewn
end
DO NOT twist harness
strap or harness
adjustment strap.
Make sure the harness
strap loops are fitted
COMPLETELY ON
both sides of the
splitter plate.
Accessories on Select Models
Cup Holder
The cup holder can be
attached to either side of
the shell.
Pull pad off corner of
shell. Align symbol on cup
holder with symbol on
shell.
Hook bottom of cup holder
under edge of shell. Snap
top of cup holder over
edge of shell.
Replace pad.
The cupholder is
dishwasher safe.
Head Pillow
To remove,
from the back
of the head
pillow gently
pull the fabric
tabs out from the shoulder
harness slots.
To attach, slide the fabric tabs
into shoulder harness slots.

25 26
Never take your child out of the child
restraint while the vehicle is moving.
Never leave child unattended.
Placing your child in a hot child
restraint may result in burns.
Do not use a child restraint with dam-
aged or missing parts.
Do not use cut,frayed or damaged
harnesses.
Do not substitute parts or try to modi-
fy the child restraint in any way.
Do not lubricate buckles and fasten-
ers.
Do not use any child restraint acces-
sory except those approved by Dorel
Juvenile Group.
Never allow any child to play with this
child restraint; it is not a toy.
Do not remove or cover up any of the
warning labels or other labels on the
child restraint.
Read all instructions for additional
warnings.
On the side of the child restraint there
is a date of manufacture label. Do not
use this child restraint more than 8
years after the date of manufacture.
Child Restraint Use
Check the vehicle belt or lower an-
chor belt before each use. Use only if
the belt can be tightened properly and
locked securely in place.
This child restraint should be securely
belted in the vehicle even when not
in use. In a crash or sudden stop, an
unsecured child restraint could injure
occupants.
Do not use a child restraint that has
been in a crash.You must get a new
child restraint.
Installation in Vehicle
Never install a rear-facing
child restraint in the front
seat of a vehicle equipped
with an active passenger
side frontal airbag.
Always check vehicle owner’s
manual for child restraint use
with side airbags.
Check the vehicle owner’s manual for
more information about air bag/child
restraint use.
Use the child restraint
only on vehicle seats
that face forward.
Do not use on seats
that face the sides or
rear of the vehicle.
Use the center seating position if
possible.
For vehicles without a back seat,refer
to your vehicle owner’s manual.
Vehicle Seating Position
continued on next page

27 28
If you are not sure where to place the
child restraint in your vehicle, consult
your vehicle owner’s manual,contact
Dorel Juvenile Group Care Department
(see page 57),or visit your local Child
Passenger Inspection Station.Go to
http://www.safercar.gov/cpsApp/cps/
index.htm to find your closest station.
Children are
safer when
properly
restrained in
rear seating positions than in the
front seating positions.
According to National Highway
Traffic SafetyAdministration
information, children in rear
seating positions are statistically
safer,whether you have air bags,
advanced air bags,or no air bags
at all.
To avoid your child being seriously
burned, take the following precau-
tions:
1. Park in the shade or where sun does
not directly hit the child restraint.
2. Cover the child restraint with a sheet
or blanket when not in use.
3. Check for hot seat and buckles
before placing child in child restraint.
To help protect your vehicle seat’s
upholstery from damage, use a single
layer towel underneath and behind
child restraint.
Choosing Lower Anchor or Vehicle Belts
The LATCH System
The lower anchors of LATCH
(LowerAnchors andTethers
for CHildren) is a universal
system for installing child re-
straints without using vehicle
seat belts.
The lower anchor system
can ONLY be used in vehicles
that have the lower anchor
bars installed and designated
LATCH seating positions.
Most vehicles manufactured after September 2002 are equipped with lower anchor
bars.Check your vehicle owner’s manual to see which seating positions may be
equipped with the LATCH system.
Lower
Anchor
Bars
Seat Bight
Your vehicle’s features may be considerably
different than those pictured here.
continued on next page

29 30
When installing this child restraint with vehicle
belts, the lower anchor hooks and belt MUST be
properly stored.
Storing Lower Anchor Belt:
When used rear facing, thread lower anchor
belt through forward-facing belt path as shown.
Then attach hooks to attachments near rear-facing
belt path as shown. Gently pull free end of belt to
remove slack.
When used forward facing, thread lower anchor
belt through rear-facing belt path. Then attach
hooks to attachments near rear-facing belt path as
shown. Gently pull free end of belt to remove slack.
LowerAnchor
Hooks
Adjuster Vehicle Belts
If lower anchors are not an
option, you must use the
vehicle seat belt system to
install the child restraint.
There are some vehicle belts
that will not work with a
child restraint or will require
special attention.
Check your vehicle owner’s
manual for specific
instructions.
WARNINGS: When used correctly the lower anchor belt or vehicle
belts are equally safe. Do not use both the lower anchor belt and
vehicle belt at the same time.
Your vehicle’s features may be considerably
different than those pictured here.

31 32
Knowing Your Vehicle Belts
continued on next page
1.You MUST Review
Your Vehicle Owner’s
Manual
Your vehicle owner’s
manual will let you
know what vehicle
belts and seating positions child restraints
can be installed in.
2. Determine How
the Child Restraint
Will Be Locked Into
Place
The vehicle belt MUST
NOT loosen after
tightening.
This means there needs to be a way to
lock the vehicle belt.
The ways this can be done are:
• By using the seat belt’s retractor; or
• By using the seat belt’s latch plate.
Not all vehicle belts and seating positions will work with child restraints.
Please follow the following steps to understand how to lock a child restraint
with a vehicle belt.
3. Check the
Retractor
Retractors pull seat
belts into stored
positions and lock
the belt to hold pas-
sengers in place.
A retractor is most likely how you will be
locking a child restraint into place.
See the following“Types of Retractors”
section for some common types of
vehicle belt retractors that will work with
this child restraint.
Switchable Retractor
(most vehicles have this type)
This retractor can be switched to a lock-
ing mode.You MUST have the retractor in
the locking mode to use the seat belt with
this child restraint.
Switching to locking mode: Slowly pull
the shoulder belt all the way out,then let
it go back in an inch or two.
As it goes back in,you will most likely
hear a ratcheting sound.
Gently pull the belt to see if it has locked.
You will not be able to pull any more belt
out if the lock has engaged.
Types of Retractors

33 34
This retractor always locks.
It will automatically lock after slowly pull-
ing the seat belt out at least halfway and
letting the belt go back into the retractor
an inch or two.
If the retractor does not lock,it is most
likely an Emergency Locking Retractor.
These retractors only lock during a sud-
den stop or collision.
Automatic Locking
Retractor
Emergency Locking
Retractor See Step 4
“Check the
Latch Plates”
Locking Latch
Plate
4. Check the Latch
Plates
Latch plates are the part
of the seat belt that goes
into the
buckle.
Hold the lap belt with one
hand and with your other
hand grasp the tongue
of the latch plate (the
part that goes inside the
buckle).Pull the latch
plate straight out in line
with the lap belt.
Emergency Locking
Retractor Lap Only Belt
Inflatable Seat Belts
Never UseWith This Child
Restraint
You will need to determine if your seat
belt’s latch plate can lock the belt. See
Step 4,“Check the Latch Plates.”
If the latch plate does not slide up and
down the vehicle belt,it is a locking
latch plate.
If the latch plate slides
up and down the vehi-
cle belt,it is a sliding
latch plate.
Sliding latch plates
easily slip between
the lap and shoulder
portions of the belt.
If you have an Emer-
gency Locking Retrac-
tor with a Sliding Latch
Plate,you MUST use
a locking clip to install
the child restraint.See
pages 55-56.
Emergency
Locking
Retractor
with a Sliding
Latch Plate
