Cosmic Byte CosmoBuds X100 User manual

User Manual
TRUE WIRELESS GAMING EARBUDS
CosmoBuds
X100

40 HOURS
PLAYBACK TIME
FUTURISTIC
MECHANICAL
DESIGN
38 MS
ULTRA-LOW
LATENCY
EASY TOUCH
CONTROL
BATTERY DISPLAY
HIGH DEFINITION
AUDIO
BLUETOOTH
5.3
GOD MODE
MUSIC MODE
TM
INSTANT
PAIRING
IPX5
SWEAT &
WATERPROOF
TOUCH
CONTROLS
VOICE
ASSISTANT
ENC
MICROPHONE
IPX5

SPECIFICATIONS
V5.3
38 ms under game mode
10mm
20Hz-20Khz
98dB
Up to 7 hours per charge
(at 70% volume)
Up to 1O hours per charge
(at 50% volume)
up to 7 hours
100 days
10m
40 mAh
400 mAh
About 1.5 hours
Type-C
15 min = 100 min playtime
Bluetooth Version
Low latency
Driver size
Frequency Response
SNR
Music playtime
Talk time
Standby time
Transmission Range
Battery Earbuds
Charging case
Charging time
Charging interface
Fast Charging

CHARGING CABLE
CHARGING CASE
USER MANUAL
User Manual
TRUE WIRELESS GAMING EARBUDS
CosmoBuds
X100
EARTIPS X 3 PAIRS
TOUCH BUTTON
LED INDICATOR
PACKAGE CONTENTS

CHARGING

HOW TO CHARGE THE COSMOBUDS X100
CHARGING CASE
During use if the LED light on the TWS ashes with voice reminder
"Battery Level Low", it indicates that the TWS battery level is low.
To charge place the earbuds into the charging case.
The LED on the earbuds will turn on indicating that the earbuds are charging.
Once the earbuds are charged the LED on it will turn o.
To charge the case plug it to a 5V/1A charger using the included Type C Cable.
Once the indicator on the charging case Displays 100% charge you can discon-
nect the charger.
5V / 40 MA (EARBUDS)
5V / 400 MA (CHARGING CASE)

PAIRING

A) FIRST TIME USER- SMART POWER ON
a. Once you remove the earbuds from the charging case, they will
automatically enter pairing mode.
b. Visit your mobile Bluetooth settings, New Device and connect to
“CosmoBuds X100”
c. The CosmoBuds X100 will automatically pair with your mobile and is ready
for use.
B) MANUAL PAIRING- MANUAL POWER ON
a. Long pinch the touch buttons on both the earbuds simultaneously until the
LED lights on the earbuds start to ash.
b. The earbuds will connect to each other and enter pairing mode.
c. Visit your mobile Bluetooth settings, New Device and connect to
“CosmoBuds X100”
d. The CosmoBuds X100 will automatically pair with your mobile and is ready
for use.
The CosmoBuds X100 feature instant on and pairing feature. Once you have con-
nected the Earbuds to your device it will automatically connect to your mobile
device as soon as you remove it from the case.
NOTE:
Pairing mode lasts for 5 minutes. If the pairing time is missed, then you will need
to reconnect the earbuds and follow the above-mentioned procedure.
X100 remembers previously connected devices; once switched on, the earbuds
automatically reconnect to the previously connected device.
PAIRING THE X100 TO YOUR BLUETOOTH
DEVICE
INSTANT ON AND PAIR (IOP™)

Simply place the X100 into the charging case in correct orientation, they will
switch o automatically and enter charging mode.
Long pinch the touch button on either earbud for ve seconds to manually switch
o the X100.
Please note that both the earbuds can be used in mono mode.
Step 1: Use either of the two options; Smart Power On or Manual Power On for
switching on the desired earbud
Step 2: The selected earbud will automatically enter the connection mode.
Step 3: Turn on Bluetooth on your phone/media device and search for ‘Cosmo
Buds X100’ to connect.
NOTE:
To switch to Stereo mode, simply take out the other earbud from the case. It will
automatically power on and pair with the previously selected earbud, enabling
Stereo usage.
A) FIRST TIME USER- SMART POWER ON
a. Once you remove the earbuds from the charging case, they will
automatically enter pairing mode.
b. Visit your mobile Bluetooth settings, New Device and connect to
“CosmoBuds X100”
c. The CosmoBuds X100 will automatically pair with your mobile and is ready
for use.
B) MANUAL PAIRING- MANUAL POWER ON
a. Long pinch the touch buttons on both the earbuds simultaneously until the
LED lights on the earbuds start to ash.
b. The earbuds will connect to each other and enter pairing mode.
c. Visit your mobile Bluetooth settings, New Device and connect to
“CosmoBuds X100”
d. The CosmoBuds X100 will automatically pair with your mobile and is ready
for use.
USING SINGLE EARBUD ONLY
SMART POWER OFF
MANUAL POWER OFF

Please note that both the earbuds can be used in mono mode.
Step 1: Use either of the two options; Smart Power On or Manual Power On for
switching on the desired earbud
Step 2: The selected earbud will automatically enter the connection mode.
Step 3: Turn on Bluetooth on your phone/media device and search for ‘Cosmo
Buds X100’ to connect.
NOTE:
To switch to Stereo mode, simply take out the other earbud from the case. It will
automatically power on and pair with the previously selected earbud, enabling
Stereo usage.
TOUCH
FUNCTIONS

Triple Pinch the right earbud to switch between Game Mode and Music Mode
GOD Mode enables 38ms low latency sound and enables accurate sound posi-
tioning.
Music Mode enables the integrated music engine for High Fidelity Audio and
Bass.
MUSIC PLAYBACK MODE
CALLING MODE
PREVIOUS TRACK:
DOUBLE PINCH THE LEFT EARBUDS.
NEXT TRACK:
DOUBLE PINCH THE RIGHT EARBUDS.
PAUSE/RESUME PLAYING:
SINGLE PINCH ON EITHER EARBUD.
ANSWER INCOMING CALL:
SINGLE PINCH ON EITHER EARBUD.
REJECT INCOMING CALL:
LONG PINCH FOR 2 SECONDS.
HANG UP CALL:
SINGLE PINCH ON EITHER EARBUD.
GOD MODE/MUSIC MODE

VOICE
ASSISTANT

Triple Pinch the left earbud to activate your phone's default smart
voice assistant.
NOTE:
VOLUME CANNOT BE CONTROLLED VIA EARBUDS AND CAN ONLY
BE ADJUSTED VIA PHONE/MEDIA DEVICE
TRIPLE PINCH

TROUBLESHOOTING

FACTORY RESETTING
THE COSMOBUDS X100
Step 1: Unpair the CosmoBuds X100 from all your mobile devices before perfor-
ming reset. Go to Bluetooth Settings and “Forget the Device”
Step 2: Remove both the earbuds from the charging case.
Step 3: Long Pinch both the earbuds simultaneously for 5-6 seconds. The LED
light on both earbuds will blink 3 times and turn o.
Step 4: Place the earbuds back in the charging case and wait for 5 seconds.
Step 5: CosmoBuds X100 is now ready for use.
Perform the Factory Reset in case you face any diculty while operating
your X100 Earbuds
LONG PINCH
BOTH EARBUDS
SCAN QR CODE FOR
TROUBLESHOOT VIDEO

TOUBLESHOOT AUDIO
ONLY FROM ONE EARBUD
If you are unable to hear sound from any one earbud, perform the pairing steps
mentioned below
SCAN QR CODE FOR
TROUBLESHOOT VIDEO
DOUBLE PINCH
BOTH EARBUDS
SIMULTANEOUSLY
Step 1: Forget the earbuds in Bluetooth settings of your mobile device.
Step 2: Remove the earbuds from the charging case, the running led on both ear-
buds will be on.
Step 3: Double pinch both the earbuds top touch area simultaneously and wait for
5 seconds for the LED to turn o and turn on any one earbud.
Step 4: Now pair the earbuds with your mobile device. Once connected both LED
on the earbuds will turn o.
Step 5: Earbuds are ready for use.
Steps to Pair the Earbuds

POTENTIAL PROBLEM
Potential Problem Solution
•IF ONE EARBUD IS NOT WORKING Perform “TOUBLESHOOT AUDIO
ONLY FROM ONE EARBUD” steps
•IF EARBUDS ARE UNABLE TO
CONNECT
Perform the “FACTORY RESETTING
THE COSMOBUDS X100” &
“TOUBLESHOOT AUDIO ONLY
FROM ONE EARBUD” both steps
•IF EARBUDS DISCONNECT DURING
PHONE CALL
Charge the earbuds or perform
“FACTORY RESETTING THE
COSMOBUDS X100”
•IF THERE ARE OTHER ISSUES WITH
USAGE
Place the earbuds back into the
charging case and try using them
again or perform “FACTORY
RESETTING THE COSMOBUDS X100”

WARNING
• Please follow the instructions to operate.
• Please charge the ear-buds with input power below 5V/1A in order to protect
the battery.
• Please don’t use the ear-buds in extreme temperatures.
• Please don’t use the product near water.
• Please keep the product away from heat sources, as the heat may damage it.
• Don’t jam the ports such as charger port, LED port, etc.
• It is recommended to utilize the product below the maximum volume
in order to protect hearing and extend the ear-buds’ service life.
• Never disassemble or modify the device to avoid any permanent
damage or danger.
• Do not use the device during a thunderstorm to avoid irregular
function or risk of electric shock.
• Don’t use harsh chemicals to clean the device.
Advisable:
The earbuds start at a 100% volume and it may need to be reduced when the earbuds
are switched on at rst. This can be done by using the volume control on the phone/
media device.

REMOVE
VOLUME LIMIT

iOS
1. Go to Settings > Music
2. Move the slider of Sound Check to the left to turn it o.
HOW TO REMOVE VOLUME LIMIT ON
ANDROID AND IOS TO INCREASE THE VOLUME
THIS WILL REMOVE THE IOS VOLUME LIMIT SO THAT
EARBUDS CAN PLAY AT FULL VOLUME.
