Costway 202392 User manual

PARTS LIST
A
Foam Handle
B
Net Set
C
Scorecard Holder
D
Handle Tube
E
Umbrella Holder Base
F
Umbrella Holder
G
Sliding Lock
H
Upper Bracket
I
Joint
J
Main Frame Tube
K
Right Weight Stabilizer
K1
Left Weight Stabilizer
L
Leg Bracket
M
Beverage Holder
N
Rear Wheel
O
Anti-Splay Wire
P
Lower Bracket
Q
Front Wheel
R
2 Holes Leg Frame
S
3 Holes Leg Frame
T
Seat Fixed Bar
U
Right Wheel Locking Mechanism
U1
Left Wheel Locking Mechanism
V
Footbrake
W
Seat
X
Basket
Warning:
For your own safety,please read and understand these warnings and keep
this user guide for future reference.
Always make sure the cart is fully extended and locked before use.
Always make sure the cart is folded and locked properly before lifting or
transporting.
Do not run while using this product.
Do not use accessories other than those designed for use with your carts.
Keep all packing materials away from children and recycle where possible or
where required by law.
Warning:Keep hands and fingers away from moving or sliding parts!
Always keep control of the buggy - Do not let it run down hills without full control.
MAINTENANCE
To clean, wipe cart with a soft,dry cloth. Car polish may be used to maintain
finish. Lubricate moving parts every 6 months.
202392

Fig.3
Button
M6*40mm
1
2
3
4
Fig.13
Fig.2
Press the button to release the
front wheel, then fold until the pin
inserts in the hole as Fig.8 and 9.
Move the slide lock
downside and lock to
upper bracket as Fig.2.
Lift the handle to level
position as Fig.1.
Fig.1
Fig.12
Fig.14
Adjustable handle
with 4 positions
height as Fig.13.
Press the red button
and adjust the slide
lock to required handle
height as Fig.12.
Fig.9
Fig.7
Fig.4
Fig.5
Fig.10
Press the button on the wheel
lock mechanism to assembly
rear wheel as Fig.3.
Fig.11 shows the
folded position.
Assembly the seat as Fig.6.
Fig.6
Fig.11
Move the slide lock
up to release the
handle as Fig.10.
Assembly front wheel set into the lower frame by 1pc M6*40mm screw
and nut as Fig.4,then rotate until the pin inserts in the hole as Fig.5.
Umbrella Holder
Assembly
To Put In Use:
Simply attach the umbrella
holder onto the cart in fig. 15.
Foot Brake
Mechanism
Slide Lock Mechanism
Folding Steps
Assembly Details
Pin
Hole
hole
button
Fig.15
Fig.8
Release the seat
as Fig.7.
Push on the brake pedal to
stop the rear wheel and pull
off to release as Fig.14.

Front Wheel Adjustment Mechanism
1.If during use, you find the cart
veers to the right or left please
see the instructions below to
correct this problem.(Fig.1)
2.If the cart veers to the left, face
the front wheel of the cart and use
the Allen wrench provided to screw
the right bolt counterclockwise or
the left bolt clockwise until the front
wheel is centered between the front
3.If the cart veers to the right, face the
front wheel of the cart and use the
Allen wrench provided to screw the left
bolt counterclockwise or the right bolt
clockwise until the front wheel is
centered between the front fork.(Fig.3)
Left
Right
Fig .1
Fig .2
Fig .3
Left
Left
Right
Right
