Costway TY327431 User manual

TY327431
If you're having difficulty, our friendly
customer team is always here to help.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Children's Ride-on Excavator
Kinder Elektroauto
Voiture Électrique pour Enfant
Coche Eléctrico para Niños
Auto Elettrica per Bambini
Spycharko-ładowarka - pojazd elektryczny dla dzieci
USA:[email protected]
AUS:[e-mail] FRA:[e-mail] DEU:[e-mail]
ITA:[e-mail] ESP:[e-mail]
POL:[e-mail]
GBR:[e-mail]
DEU office: FDS GmbH, Neuer Höltigbaum 36, 22143 Hamburg, Deutschland
ITA office: Milano
FRA office: Saint Vigor d'Ymonville
POL office: GdańskGBR office: IpswichAUS office: TruganinaUSA office: Fontana

Der Artikel muss unter der Aufsicht eines Erwachsenen montiert und benutzt
werden.
Lesen Sie jeden Schritt sorgfältig durch und befolgen Sie die richtige
Reihenfolge.
Entfernen Sie alle Verpackungen, separieren und zählen Sie alle Teile und
Hardware vor der Montage oder Verwendung.
Bitte stellen Sie sicher, dass alle Teile richtig montiert sind, eine falsche
Montage kann zu einer Gefahr führen.
Achten Sie bei der Montage auf einen sicheren Untergrund und stellen Sie
den Artikel immer auf eine ebene, feste und stabile Fläche.
Bitte verwenden Sie den Artikel vorsichtig, da es große Geschicklichkeit
erfordert, um Unfälle durch Stürze oder Zusammenstöße des Benutzers oder
anderer zu vermeiden.
Bitte tragen Sie während der Verwendung geeignete Schutzausrüstung, z.B.
Schutzhelm, Handschuhe, Knieschützer, Ellbogenschützer usw.
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can
lead to a danger.
We recommend that, where possible, all items are assembled near the area
in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Ensure a secure surface during installation, and place the product always on
a flat, steady and stable surface.
Please use this product with caution. The use of this product requires
superb skills to avoid accidents to the user or others due to a fall or
collision.
Please wear suitable protective equipment during use, e.g. protective
helmet, gloves, knee pads, elbow pads etc.
Attention! Use it with protective equipment.
Attention! Not use it in the traffic.
Attention! Children should use this product under the parental supervision.
Allgemeine Warnhinweise
Before You Start Bevor Sie beginnen
Achtung! Müssen Persönliche Schutzausrüstung tragen .
Achtung! Darf nicht im Straßenverkehr verwenden.
Warnung: Kinder sollten diesen Artikel unter elterlicher Aufsicht benutzen.
Bitte sorgfältig lesen und zum späteren Nachschlagen aufbewahren.
Please read all instructions carefully and keep it for future reference.
EN DE
General Warnings
Warnings Warnung
02 03

Le produit doit être installé et utilisé sous la surveillance d’un adulte.
Lisez attentivement chaque étape et suivez l’ordre correct.
Retirez tous les emballages, séparez et comptez toutes les pièces et le matériel.
Assurez-vous que toutes les pièces sont correctement installées, une installation
incorrecte peut entraîner un danger.
Nous recommandons que, dans la mesure du possible, tous les articles soient
assemblés à proximité de la zone dans laquelle ils seront utilisés, afin d’éviter de
déplacer inutilement le produit une fois assemblé.
Assurez-vous que la surface soit solide pendant l’assemblage et placez toujours le
produit sur une surface plane et stable.
Veuillez utiliser le produit avec précaution, car le produit nécessite une grande habileté,
évitez les accidents de l’utilisateur ou d’autres personnes, par chute ou collision.
Veuillez porter un équipement de protection approprié pendant l’utilisation, par exemple,
le casque de protection, les gants, les genouillères, les coudières, etc.
¡Atención! Utilícelo con equipo de protección.
¡Atención! No lo use en el tráfico.
¡Atención! Los niños deben utilizar este producto bajo la supervisión de sus padres.
Attention ! Utilisez ce produit avec un équipement de protection.
Attention ! Ne l’utilisez pas dans la circulation routière.
Attention ! Les enfants doivent utiliser ce produit sous la surveillance de leurs parents.
Avant de Commencer
Veuillez lire attentivement toutes les instructions et les conserver pour la référence ultérieure.
Antes de Empezar
Lea atentamente todas las instrucciones y consérvelas para futuras consultas.
FR ES
Avertissements Généraux Advertencias Generales
Avertissements Advertencias
El producto debe instalarse y usarse bajo la supervisión de un adulto.
Lea detenidamente cada paso y siga el orden correcto.
Quite todo el embalaje, separe y cuente todas las piezas y los accesorios.
Asegúrese de que todas las piezas estén instaladas correctamente, una
instalación incorrecta puede provocar un peligro.
Recomendamos que, siempre que sea posible, todos los elementos se
monten cerca de la zona en la que se van a utilizar, para evitar mover el
producto innecesariamente una vez montado.
Asegure una superficie segura durante el montaje, y coloque el producto
siempre sobre una superficie plana, firme y estable.
Por favor, utilice este producto con precaución. El uso de este producto
requiere una gran destreza para evitar accidentes al usuario o a otras
personas debido a una caída o colisión.
Por favor, utilice un equipo de protección adecuado durante el uso, por
ejemplo, casco protector, guantes, rodilleras, coderas, etc.
04 05

Produkt musi być zainstalowany i używany pod nadzorem osoby dorosłej.
Przeczytaj uważnie każdy krok i postępuj we właściwej kolejności.
Usuń opakowanie i upewnij się, że zestaw zawiera wszystkie części i elementy
montażowe.
Upewnij się, że wszystkie części są poprawnie połączone, nieprawidłowa instalacja
może prowadzić do wypadku.
Zalecamy, aby w miarę możliwości wszystkie elementy były montowane w pobliżu
miejsca, w którym będą używane, aby uniknąć niepotrzebnego przenoszenia produktu
po złożeniu.
Zapewnij bezpieczną przestrzeń roboczą podczas montażu i upewnij się, że produkt
znajduje się na płaskiej i stabilnej powierzchni.
Używaj produktu ostrożnie. Unikaj upadku lub kolizji.
Podczas użytkowania należy nosić odpowiedni sprzęt ochronny, np. kask ochronny,
rękawiczki, nakolanniki, ochraniacze na łokcie itp.
Il prodotto deve essere installato e utilizzato sotto la supervisione di un adulto.
Leggere attentamente ogni passo e seguire l'ordine corretto.
Rimuovere tutti gli imballaggi, separare e contare tutte le parti e tutti gli accessori.
Si prega di assicurarsi che tutte le parti siano installate correttamente, un'installazione
errata può portare a un pericolo.
Si consiglia, ove possibile, di montare tutti gli articoli vicino alla zona in cui verranno posti
in uso, per evitare di spostare inutilmente il prodotto una volta assemblato.
Garantire una superficie sicura durante il montaggio e posizionare il prodotto sempre su
una superficie piana, stabile.
L'uso di questo prodotto richiede abilità superbe per evitare incidenti all'utente o ad altri
a causa di una caduta o collisione.
Indossare dispositivi di protezione adeguati durante l'uso, come il casco protettivo, i
guanti, le ginocchiere, le gomitiere, ecc.
Attenzione! Utilizzare il prodotto con dispositivi di protezione.
Attenzione! Non usare il prodotto nel traffico.
Attenzione! I bambini devono usare questo prodotto sotto la supervisione dei genitori.
Prima di Iniziare Zanim Zaczniesz
Przeczytaj uważnie wszystkie instrukcje i zachowaj je na przyszłość.Si prega di leggere attentamente tutte le istruzioni e conservarle per riferimento futuro.
PLIT
Avvertenze Generali Ogólne ostrzeżenia
Uwaga! Używaj z ochraniaczami.
Uwaga! Nie używaj go w ruchu ulicznym.
Uwaga! Dzieci moga używać tego produktu jedynie pod nadzorem dorosłych.
Avvertenza Ostrzeżenia
06 07

Suitable age:
Load Capacity:
Speed:
Size of car:
Power way:
Charge time:
37~96 Months
Under 30 kg (66 lbs)
2.5-5 km/h (1.5-3 mph)
148 x 61 x 64 cm (58'' x 24'' x 25'')
Charging type
8 ~ 12 hours
Battery
Charger
6V7Ah*2
12V1000mA
Owner’s Manual
with Assembly Instructions
Styles and colours may vary.
Made in China.
The owner's manual contains important safety information as well as
assembly, use and maintenance instructions.
The Ride-on Car must be assembled by an adult who has read and
understood the instructions in this manual.
Keep the package away from children and dispose of properly before use.
Keep this manual for future reference.
This ride-on will provide your child with many miles of riding of enjoyment.
To assure you and your rider a safe ride, we ask you to please read this
manual carefully, and keep it for future reference.
Follow the recommendations in this manual, they are designed to help
master the operation of your ride-on car and improve the safety of its rider.
About Your New Ride-On
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Placed on the front axle
Placed on the front axle
PART
NO.
REMARKS
PART NAME
Q’ty
(pcs)
Placed on the steering wheel
Placed on the steering wheel
1pc labeled “L”, and the other one
labeld “R”
6 pcs on the front axle, 2 pcs on the
rear axle
2 pcs on the front axle, 2 pcs on the
rear axle
Parts List of vehicle body
Gear box
Rear driving wheel
Ø12 washer
Steering plate
Inner bushing
Front wheel
Outer bushing
Ø10 Locknut
Vehicle body
Steering column
Front axle
Rear axle
Seat
M5x40 machine screw
Steering wheel
Ø5 nut
Windshield
Rear exhaust
Charger
2
2
8
1
2
2
2
4
1
1
1
1
1
1
1
1
1
1
1
EN
08 09
SPECIFICATIONS:

112
2
34
5
6
7
89
10 11
NOTE: Some parts shown are assembled on both sides of vehicle
Ø4x16 screw
Hubcap
Split pin
Ø10 washer
Spanner
A
B
C
D
E
Assembly package
1 pcs for spare
1 pcs for spare
Parts Diagram of Vehicle Body
19
E
1
2
6
7
D
C
8
B
8
9
10
11
12
14 15
17
5
18
16
4
D
3
3
3
3
B
13
A
Parts Diagram of Bucket
1. Ø10 locknut *2 ( placed on the Ø12 rod )
2. Inner bushing *2 ( placed on the Ø12 rod )
3. Ø12 rod *1
4. Ø4x16 screw *2 ( placed in the assembly package )
5. Boom (right) *1
6. Boom (left) *1
7. Boom linkage *1
8. Bucket tip *2 ( placed on the booms )
9. Bucket cover *2 ( placed on the booms )
10. Lock tie *2 ( placed on the booms )
11. Bucket *1
12. Ø12 washer *2
Longest: Rear axle
Shorter: Front axle
Shortest: Ø12 rod
10 11

WARNING!WARNING!
Before You Begin Assembly
Attach the Rear Axle
FOR THE SAFETY OF YOUR CHILD, PLEASE READ ALL WARNINGS
AND ASSEMBLY/USE INSTRUCTIONS. KEEP THIS GUIDE FOR
FUTURE REFERENCE.
● ADULT ASSEMBLY REQUIRED. The product contains small parts,
which are for adult assembly only. Keep children away when assembling.
● Always remove protective material and poly bags and dispose before
assembly.
• Make sure that the power switch is turned “OFF” before assembling the
rideon.
• Before first time use, charge the battery for at least 4 to 6 hours.
• Assembly tools required:
Remove all the parts from the rear axle.
1. Insert the rear axle into the hole on the vehicle body.
Screwdriver
(not included) Long nose pliers (not included) Spanner
1
Attach the Rear Wheels
4
5
4
5
1
3
11
2
Rear driving wheel
Rear axle
Rear wheels are more bigger
than front wheels
1,2. Slide the gear box onto the rear axle (Left Side). “R” labeled gear box
should be fit to the “R” side of vehicle body; “L” labeled gear box should be fit
to “L” side of vehicle body. Plug the connector on motor to the connector on
the vehicle body.
3. Slide the rear driving wheel onto the rear axle, and keep the rear driving
wheel matching up with the gear box.
4. Slide the Ø12 washer onto the rear axle.
5. Tighten a Ø10 locknut to the end of the rear axle with a spanner.
6
89
10
11
7
Tools required: Spanner
6-11: Repeat for the other driving wheel.
Rear driving wheel
HINT: An extra spanner has been provided to hold the locknut on the other side of the
rear axle while tightening the locknut on the other side.
12 13

Attach the Steering Plate
1
23
4
1,2. Turn the steering plate until it can be fit to the vehicle body.
3. Turn the steering plate to line up the holes in the steering plate with the
holes in the vehicle body.
4. Fit the front axle to the vehicle body.
After assembling any wheel to the axles, please check the gap
between the screw thread and the collapsible (refer to the left
picture), if the gap is too big, please add two or three washers
inside the wheel, but after tightening the nut outside the wheel,
please turn the wheel by your finger to check if the wheel can
run smoothly, this is very important, because if the wheel can
run smoothly, it is ok, but if the nut presses the wheel and the wheel can’t run
smoothly, the motor will be broken easily! Then you need to decrease one or two
washers to make sure the wheel can run smoothly!
1
2
3
4
5
6
7
8
Attach the Front Wheels
Front wheel, more smaller
than Rear wheel.
Tools required: Spanner
Front axle
Remove all the parts from the front axle.
1. Slide a Ø12 washer onto the front axle.
2. Slide the inner bushing onto the front axle.
3. Slide a Ø12 washer onto the front axle.
4. Slide a outer bushing (ring end first) onto the front axle.
5. Slide the front wheel onto the front axle, and keep it matching up with the outer
bushing.
6. Slide a Ø12 washer onto the front axle.
7. Tighten a locknut to the end of the front axle with a spanner.
HINT: An extra spanner has been provided to hold the locknut on the other side
of the rear alxe while tightening the locknut on the other side.
8. “Snap” the hubcap to the wheel cover.
Repeat for the other front wheel.
GAP
14 15

4
4
Attach the Steering Column
1. Turn the vehicle body on its side, Slide a Ø12 washer onto the steering
column from the straight end. Insert the steering column through the groove
A on the steering plate, the hole in the vehicle body and out through the hole
on the dash.
2. Insert the bent end of steering column through the groove B on the front
axle linkage.
3. Fit a Ø10 washer onto the steering column.
4. Insert a split pin into the hole in the steering column, bend the ends of split
pin back using the long nose pliers.
● Turn the vehicle body over. Remove the M5x40 machine screw and Ø5 nut
from the steering wheel with a screwdriver.
1. Place the steering wheel over the steering column, protruding from the
middle of the steering wheel base.
2. Align the holes on each side of steering wheel with the holes at the end of
the steering column.
3. Fasten a nut on the opposite end of the screw to secure the steering
wheel to the steering column.
4. Insert the tabs on the windshield to the slots in the vehicle body, and push
until you hear it “click” into place.
4
5
3
4
1
2
Steering
column
Ø10
washer
groove A groove B groove A
Steering
plate
23
1
Attach the Steering Wheel
End of the steering column
16 17

1. Plug the red fuse connector into the terminal on battery.
Connect the Powr Supply
1
Fuse box
BATTERY
Attach Seat & Rear Exhaust
1
1
2
3
1. Fit the tabs at back of the seat to
the holes on the vehicle body.
2. Insert two Ø4x16 screws and
tighten with a screwdriver.
3. Insert the tabs on the rear
exhaust into the holes on the
vehicle body, and push until you
hear it “click” into place.
18 19

5
6
1. Fit the bucket into boom (right),
2. Fit the bucket cover to the bucket,
3. Fit the bucket lock (ring end) against to the bucket,
4. Turn the bucket until it lines up with the holes in the boom (right), the holes
in the bucket lock and the holes in the bucket.
5. Insert the bucket tip through the holes in the boom (right), the holes in the
bucket lock, the hole in the bucket and out the hole in the boom (right),
6. Bend the bucket lock (opening end), and fit it into the grooved area in the
bucket tip.
Repeat for the other boom.
4
3
1
2
Assemble the Bucket-1
to be continued... to be continued...
Bucket tip
Boom (right)
Bucket lock
(opening end)
Bucket
Assemble the Bucket-2
20 21

3
4
1
2
Battery
The follow steps are only for TYPE A.
1. Fit the both ends of boom linkage into the slots in each boom.
2. Insert the Ø4x16 screw through the hole on the boom and into the boom
linkage, tighten the screw. Repeat for the other side.
1. Insert the Ø12 rod through the hole on the boom (right).
2. Slide an inner bushing onto the Ø12 rod.
3. Align the holes on each side of vehicle body with the holes on boom (left).
Insert the Ø12 rod through the holes on vehicle body. Slide an inner bushing
onto the Ø12 rod, and continue pushing the Ø12 rod till it passes through
the hole on the boom (left).
4. Slide a Ø12 washer onto the Ø12 rod.
5. Tighten a Ø10 lock nut to the end of Ø12 rod with a spanner.
HINT: An extra spanner has been provided to hold the lock nut on the
other side of the Ø8 rod while tightening the lock nut on the other side.
3. Tighten a Ø10 lock nut to one end of the Ø12 rod.
4. Slide a Ø12 washer onto the Ø12 rod from other side.
to be continued...
Assemble the Bucket-3
3
4
5
12
Ø12 rod
Ø10 lock nut
Ø12 washer Inner bushing
Vehicle body
Boom (right)
Assemble the Bucket-4
22 23

Safety
WARNING!
WARNING!
PREVENT INJURIES AND DEATHS:
● NEVER LEAVE CHILD UNATTENDED. ADULT SUPERVISION IS
REQUIRED. Always keep child in view when child is in vehicle.
● This toy should be used with caution since skill is required to avoid falls or
collisions causing injury to the user or third parties.
● Protective equipment should be worn.
● Never use in roadways, near cars, on or near steep inclines or steps,
swimming pools or other bodies of water.
● Always wear shoes.
● Always sit on the seat.
● Not to be used in traffic.
● This toy is unsuitable for children under 36 months due to its maximum
speed; Maximum user weight is 30kg.
● This toy has no brake.
Rules for Safe Riding
● Keep Children within Safe Riding Areas:
● Never use in roadway, near motor vehicles, on lawn space, on or near
steep inclines or steps, swimming pools or other bodies of water;
● Use the ride-on excavator only on flat surfaces. Such as inside your house,
garden or playground.
● Never use in the dark. A child could encounter unexpected obstacles and
have an accident. Operate the vehicle only in the daytime or a well-lit area.
● It is prohibited to change the circuit or add other electric parts.
● Inspect wires and connections of the vehicle periodically.
Do not let any child touch the wheels or be near them when the car is moving.
● This vehicle has adjustable seat belts. Please instruct children how to tie
the safety belt before using to guarantee the security.
Use the vehicle on generally level
ground ONLY! DO NOT Use the vehicle on Lawn space!
ADVANCED USE - High Speed Drive
Make sure your child knows how to steer, how to start and stop the vehicle
and knows the rules for safe driving. The vehicle can be driven at a maximum
of 2.5~5 km/h.
1. Power Button: Turns the vehicle on and off.
2. Forward/Reverse Switch: Changes the direction that vehicle moves
from forward to reverse.
● To move the car forward, shift the lever up.
● To move the car backward, shift the lever down.
3. High/Low Speed Switch: The switch operates the vehicle to move in
low or high speed.
4. Foot Pedal: Applies power (speed) to the vehicle.
● To move the car, press the pedal down.
● To brake or slow down, release pressure from the pedal.
Use Your Ride-on
Always stop vehicle when
changing the speed or
direction to avoid damaging
the gears and motor.
IMPORTANT!
24 25

ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY!
WARNING!
This product has Charging Protection. When charging, all functions will be
cut off! Only an adult can charge and recharge the battery.
• The POWER SWITCH must be turned in OFF position when charging.
• Before the first use, you should charge the battery for 4-6 hours. Do not
recharge the battery for more than 10 hours to avoid overheating the charger.
• When the vehicle begins to run slowly, recharge the battery.
• After each use or once a month, minimum recharge time is 8 to 12 hours,
less than 20 hours at most.
• If your ride-on vehicle comes with a Digital Voltmeter (IF EQUIPPED), the
magnitude of the voltage will tell you how much powder is left in the battery
so that you can recharge the battery in time. Please make sure the vehicle is
stopped when charging.
1. Plug the charger port into the input socket. (the socket is beside the power
switch)
2. Plug the charger plug into a wall outlet. The battery will begin charging.
• PREVENT FIRE AND ELECTRIC SHOCK:
- Use the only rechargeable battery and charger supplied with your vehicle. NEVER
substitute the battery or the charger with another brand. Using another battery or
charger may cause a fire or explosion.
- Do not use the battery or charger for any other product. Overheating, fire or
explosion could occur.
- NEVER modify the electric circuit system. Tampering with the electric system may
cause a shock, fire or explosion or may permanently damage the system.
- Do not allow direct contact between battery terminals. Fire or explosion can occur.
- Do not allow any type of liquid on the battery or its components.
- Explosive gasses are created during charging. Do not charge near heat or
flammable materials. Charge the battery in a well-ventilated area ONLY.
- NEVER pick up the battery by the wires or charger. Damage can occur to the
battery and may cause a fire. Pick up the battery by the case ONLY.
- Charge the battery in a dry area ONLY.
• Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to cause cancer and reproductive harm. Wash hands after
handling.
• Do not open the battery. Battery contains lead acid and other materials that are
toxic and corrosive.
• Do not open the charger. Exposed wiring and circuitry inside case may cause
electric shock.
• Only adults may handle or charge the battery. NEVER allow child to handle or
charge the battery. Battery is heavy and contains lead acid (electrolyte).
• Do not drop the battery. Permanent damage to the battery could occur or cause
serious injury.
• Before charging the battery, check for wear or damage to the battery, charger, its
supply cord and the connectors. DO NOT charge the battery if any damage to parts
has occurred.
• Do not allow the battery to drain completely. Recharge the battery after each use or
once a month if not used regularly.
• Do not charge battery upside down.
• Always secure the battery with the bracket. Battery can fall out and injure a child if
vehicle tips over.
Charging
WARNING!WARNING!
Charging
BATTERY BATTERY STATE
MAGNITUDE OF VOLTAGE
≥ 13.2
13.1~12.6
≤ 12.5
The battery is full.
The vehicle can work normally.
The battery needs to be charge.
6V7Ahx2
26 27

The battery features a thermal fuse with a rest fuse that will automatically trip and cut
all power to the vehicle if the motor, electric system or battery is overloaded. The
fuse will reset and power will be restored after the unit is turned OFF for 20 seconds
and then turned ON again. If the thermal fuse trips repeatedly during normal use, the
vehicle may need repair. Contact our Customer Service Team please.
To avoid losing power, follow these guidelines:
● Do not overload the vehicle.
● Do not tow anything behind the vehicle.
● Do not drive up steep slopes.
● Do not drive into fixed objects, which may cause the wheels to spin, causing the
motor to overheat.
● Do not drive in very hot weather, components may overheat.
● Do not allow water or other liquids to come in contact with the battery or other
electric components.
● Do not tamper with the electric system. Doing so may create a short circuit,
causing the fuse to trip.
The battery will eventually lose the ability to hold a charge. Depending on the amount
of use, and varying conditions, the battery should operate for one to three years.
Follow these steps to replace and dispose of the battery:
1. Remove the car seat.
2. Disconnect the battery connectors.
3. Remove the battery bracket.
4. Remove the battery cover.
5. Carefully lift the battery.
● Depending on the condition of the battery (i.e.: leakage) you may want to wear
protective gloves before removal.
● Do not lift the battery by its connectors or cables.
6. Place the dead battery in a plastic bag.
Important! Recycle the dead battery responsibly. The battery contains lead acid
(electrolyte) and must be disposed of properly and legally. It is illegal in most areas to
incinerate lead acid batteries or dispose of them in landfills. Take it to a
state-approved lead acid battery recycler, such as local automotive battery retailer.
Do not throw the battery away with your regular household waste!
7. Replace the battery and reconnect the connectors.
8. Replace the metal battery bracket.
9. Replace the seat.
Battery Replacement & Fuse
Battery Replacement and Disposal Contact our customer service
team please.
Contact our customer service
team please.
Vehicle is being
used in harsh
conditions
Vehicle is
overloaded
Avoid using vehicle in harsh
conditions , see <Safety>.
Reduce weight on vehicle.
Maximum user weight is
50kg.
Battery is old Replace battery, Contact our
customer service team please.
Battery is old Replace battery, Contact our
customer service team please.
Replace battery, Contact our
customer service team please.
Recharge battery.
Reset fuse, see <Fuse>
Battery is under
charged
Electrical system is
damaged
Battery low on
power
Thermal fuse has
tripped
Battery connector or
wires are loose
Battery is dead
Check that the battery connectors
are firmly plugged
into each other when recharging
Battery low on
power Recharge battery, Contact our
customer service team please.
Vehicle runs
sluggishly
Vehicle
does not run
very long
Vehicle
does not run
Motor is damaged
Check that the battery connectors
are firmly plugged into each other. If
wires are loose around the motor,
Contact our customer service team
please.
Solution
Possible Cause
Problem
Troubleshooting Guide
28 29

• It is parents' responsibility to inspect the main parts of the vehicle before
use and regularly check for potential hazards, such as batteries, the charger,
cables or wires, plugs, screws. If there is any damage, do not use the
vehicle until it is repaired.
• Make sure the plastic parts of the vehicle are not cracked or broken.
• Occasionally use a lightweight oil to lubricate moving parts such as wheels.
• Park the vehicle indoors or cover it with a tarp to protect it from wet
weather.
• Keep the vehicle away from sources of heat, such as stoves and heaters.
Plastic parts may melt.
• Recharge the battery after each use. Only an adult can handle the battery.
Recharge the battery at least once a month when the vehicle is not being
used.
• Do not wash the vehicle with a hose. Do not wash the vehicle with soap
and water. Do not drive the vehicle in rainy or snowy weather. Water will
damage the motor, electric system and battery.
• Clean the vehicle with a soft, dry cloth. To restore shine to plastic parts,
use a non-wax furniture polish. Do not use car wax. Do not use abrasive
cleaners.
• Do not drive the vehicle in loose dirt, sand or fine gravel which could
damage the moving parts, motors or the electric system.
• When not using, all the electrical source should be turned off. Turn off the
power switch and disconnect the battery connection.
Our products are suitable for
ASTM F963; GB6675; EN71 and EN62115 standard.
Troubleshooting Guide
Contact our customer service
please.
Check that the battery connectors
are firmly plugged into each
other. If wires are loose around
the motor, Contact our customer
service team please.
Poor contact of
wires or Connectors
A dead spot means the electric
power is not being delivered to the
terminal connection and the vehicle
needs repair. Contact our custom-
er service team please.
“Dead Spot" on
motor
Vehicle
needs a
push
to go
forward
Completely stop the vehicle and
shift
Attempting to shift
while the vehicle is
in motion.
Motor or gears are
damaged
Battery connector or
adapter
connector is loose
Charger is not
plugged in
Charger is not
working
This is normal and
not a cause for
concern
Check that the battery
connectors are firmly plugged
into each other.
Check that the battery charger is
plugged into a
working wall outlet.
Difficult
shifting from
forward to
reverse or
vice- versa
Loud grinding or
clicking
noises coming
from motor or
gear box
Battery can not
be recharged
Charger gets a
little hot when
recharging
SolutionPossible CauseProblem
Contact our customer
service please.
Completely read through this manual and the troubleshooting guide table
before calling. If you still need help to resolve the problems. Contact our
customer service team please.
Troubleshooting Guide
30 31

Geeignetes Alter: 37-96 Monate
Belastbarkeit: Unter 30kg
Geschwindigkeit: 2.5 - 5 km/Std.
Größe des Elektroautos: 148×61×64 cm
Stromart: Aufladen
Aufladezeit: 8-12 Stunden
Akku
Ladegerät
6V7Ah*2
12V1000mA
Benutzerhandbuch
mit Montageanleitung
Stile und Farben können variieren.
Hergestellt in China.
Das Benutzerhandbuch enthält wichtige Sicherheitshinweise sowie Montage-,
Gebrauchs- und Wartungsanweisungen.
Das Elektroauto muss von einem Erwachsenen zusammengebaut werden,
der die Anweisungen in dieserAnleitung gelesen und verstanden hat.
Bewahren Sie die Verpackung außerhalb der Reichweite von Kindern auf und
entsorgen Sie sie vor dem Gebrauch ordnungsgemäß.
Bewahren Sie diese Anleitung zum späteren Nachschlagen auf.
Dieses Elektroauto wird Ihrem Kind viele Kilometer Fahrvergnügen bereiten.
Um Ihnen und Ihrem Kind eine sichere Fahrt zu ermöglichen, bitten wir Sie,
diese Anleitung sorgfältig durchzulesen und zum späteren Nachschlagen
aufzubewahren.
Befolgen Sie die Empfehlungen in dieser Anleitung, um die Sicherheit und
den Betrieb Ihres Elektroautos und seines Fahrers zu verbessern.
Über Ihr Elektroauto
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Auf der Vorderachse platziert
Wird an der Vorderachse angebracht
Nr
Anmerkungen
Teilename
Menge
Wird am Lenkrad angebracht
Wird am Lenkrad angebracht
1 St. mit der Bezeichnung "L" und das
andere mit der Bezeichnung "R".
6 Stück an der Vorderachse, 2 Stück an
der Hinterachs
2 St. an der Vorderachse, 2 Stück an der
Hinterachse
Teileliste der Karosserie
Getriebe
Hinteres Antriebsrad
Ø12 Unterlegscheibe
Lenkungsplatte
Innere Buchse
Vorderrad
Äußere Buchse
Ø10 Sicherungsmutter
Karosserie
Lenksäule
Vorderachse
Hinterachse
Sitz
M5x40 Maschinenschraube
Lenkrad
Ø5 Mutter
Windschutzscheibe
Hinterer Auspuff
Ladegerät
2
2
8
1
2
2
2
4
1
1
1
1
1
1
1
1
1
1
1
DE
32 33

112
2
34
5
6
7
89
10 11
HINWEIS: Einige der abgebildeten Teile sind auf beiden Seiten des
Elektroautos montiert.
Ø4x16 Schraube
Radkappe
Splint
Ø10 Unterlegscheibe
Schraubenschlüssel
A
B
C
D
E
Zubehörpaket
1 St. als Ersatz
1 St. als Ersat
Explosionsdarstellung der Karosserie
19
E
1
2
6
7
D
C
8
B
8
9
10
11
12
14 15
17
5
18
16
4
D
3
3
3
3
B
13
A
Explosionsdarstellung der Schaufel
1. Ø10 Sicherungsmutter *2 ( auf der Ø12 Stange platziert )
2. Innere Buchse *2 ( auf der Ø12 Stange platziert )
3. Ø12 Stange *1
4. Ø4x16 Schraube *2 ( in der Zubehörpackung )
5. Ausleger (rechts) *1
6. Ausleger (links) *1
7. Gestänge für Ausleger *1
8. Schaufelspitze *2 ( auf den Auslegern platziert )
9. Schaufelabdeckung *2 ( auf den Auslegern platziert )
10. Verschlussband *2 ( auf den Auslegern platziert )
11. Schaufel *1
12. Ø12 Unterlegscheibe *2
Lange Hinterachse
Kurze Vorderachse
Kurze Ø12 Stange
34 35

WARNING!WARNUNG!
Bevor Sie mit der Montage beginnen
Befestigen Sie die Hinterachse
LESEN SIE ZUR SICHERHEIT IHRES KINDES ALLE WARNHINWEISE
UND MONTAGE- UND GEBRAUCHSANWEISUNGEN. BEWAHREN SIE
DIESE ANLEITUNG ZUM SPÄTEREN NACHSCHLAGEN AUF.
● MONTAGE DURCH ERWACHSENE ERFORDERLICH. Das
Elektroauto enthält Kleinteile, die nur von Erwachsenen zusammengebaut
werden dürfen. Halten Sie Kinder beim Zusammenbau fern.
● Entfernen Sie immer das Schutzmaterial und die Polybeutel und
entsorgen Sie diese vor der Montage.
● Vergewissern Sie sich, dass der Netzschalter auf "OFF" steht, bevor Sie
das Elektroauto zusammenbauen.
● Laden Sie den Akku vor dem ersten Gebrauch mindestens 4 bis 6
Stunden lang auf.
● Erforderliches Montagewerkzeug:
Entfernen Sie alle Teile von der Hinterachse.
1. Setzen Sie die Hinterachse in das Loch in der Karosserie ein.
Schraubendreher
(nicht im Lieferumfang
enthalten)
Spitzzange
(nicht im Lieferumfang
enthalten)
Schraubenschlüssel
1
Befestigen Sie die Hinterräder
4
5
4
5
1
3
11
2
Hinteres Antriebsrad
Hinterachse
Die Hinterräder sind größer
als die Vorderräder
6
89
10
11
7
Benötigte Werkzeuge:
Schraubenschlüssel
6-11: Wiederholen Sie den Vorgang für das andere Antriebsrad.
Hinteres Antriebsrad
TIPP: Es wurde ein zusätzlicher Schraubenschlüssel bereitgestellt, um die
Gegenmutter auf der anderen Seite der Hinterachse zu halten, während die
Gegenmutter auf der anderen Seite angezogen wird.
1,2. Schieben Sie den Getriebekasten auf die Hinterachse (linke Seite). Das mit "R"
beschriftete Getriebe sollte auf der "R"-Seite der Karosserie angebracht werden; das
mit "L" beschriftete Getriebe sollte auf der "L"-Seite der Karosserie angebracht
werden. Verbinden Sie den Stecker am Motor mit dem Stecker an der Karosserie.
3. Schieben Sie das hintere Antriebsrad auf die Hinterachse, und achten Sie darauf,
dass das hintere Antriebsrad mit dem Getriebegehäuse übereinstimmt.
4. Schieben Sie die Ø10 Unterlegscheibe auf die Hinterachse.
5. Ziehen Sie eine Ø10 Sicherungsmutter mit einem Schraubenschlüssel am Ende
der Hinterachse fest.
36 37

Befestigen Sie die Lenkungsplatte
1
23
4
1,2. Drehen Sie die Lenkungsplatte, bis sie an der Karosserie befestigt
werden kann.
3. Drehen Sie die Lenkungsplatte so, dass die Löcher in der Lenkungsplatte
mit den Löchern in der Karosserie übereinstimmen.
4. Bringen Sie die Vorderachse an der Karosserie an.
Nach der Montage jedes Rades auf die Achsen, überprüfen Sie
bitte die Lücke zwischen dem Schraubengewinde und dem
klappbaren (siehe linkes Bild), wenn die Lücke zu groß ist, fügen
Sie bitte zwei oder drei Unterlegscheiben im Inneren des Rades,
aber nach dem Anziehen der Mutter außerhalb des Rades,
drehen Sie bitte das Rad mit dem Finger, um zu überprüfen, ob
das Rad reibungslos laufen kann, das ist sehr wichtig, denn
wenn das Rad reibungslos laufen kann, ist es ok, aber wenn die Mutter drückt das
Rad und das Rad kann nicht reibungslos laufen, wird der Motor leicht gebrochen
werden! Dann müssen Sie eine oder zwei Unterlegscheiben verringern, um
sicherzustellen, dass das Rad reibungslos laufen kann!
1
2
3
4
5
6
7
8
Befestigen Sie die Vorderräder
Die Hinterräder sind größer
als die Vorderräder
Erforderliches Werkzeug:
Schraubenschlüssel
Vorderachse
Entfernen Sie alle Teile von der Vorderachse.
1. Schieben Sie eine Ø12 Unterlegscheibe auf die Vorderachse
2. Schieben Sie die innere Buchse auf die Vorderachse.
3. Eine Ø12 Unterlegscheibe auf die Vorderachse schieben.
4. Eine äußere Buchse (Ringende zuerst) auf die Vorderachse schieben.
5. Schieben Sie das normale Rad auf die Vorderachse, und achten Sie darauf, dass
es mit der äußeren Buchse übereinstimmt.
6. Schieben Sie eine Ø12 Unterlegscheibe auf die Vorderachse.
7. Ziehen Sie eine Gegenmutter am Ende der Vorderachse mit einem
Schraubenschlüssel fest.
HINWEIS: Es ist ein zusätzlicher Schraubenschlüssel vorgesehen, um die
Gegenmutter auf der anderen Seite der Hinterachse zu halten, während die
Gegenmutter auf der anderen Seite festgezogen wird.
8. Lassen Sie die Radkappe an der Radabdeckung "einrasten".
Wiederholen Sie diesen Schritt für die andere Seite.
LÜCKE
38 39
