Cowon CX7 User manual

User Guide 1.0EN
CX7
COWON

2
COWON CX7
+ Package Contents
COWON
C
X
7
Quic
k
Guid
e
COWON CX7 Portable Charging Cradle Quick Guide
S M L Normal Type Hook Type
Ear Tips Silicone Covers USB Type-C Cable
*Actual package contents may differ from the above images.
*L-size eartips are attached to the earphones.

2 3
COWON CX7
+ Before you start _ Names of Parts and Functions
LED
LED
Multi-Function Button (L)
Power / Call / Pairing / Play /
Volume Down / Previous Track
Multi-Function Button (R)
Power / Call / Pairing / Play /
Volume Up / Next Track
Charging Port
USB Type-C Port
Microphone
Charging Port

4
COWON CX7
+ Before you start _ Precautions
*For charging please remove the protective fi
lm from the earphone charging terminal. *Do not let the silicone covers cover the earphone charging protrusions. *Make sure that the earphone is properly positioned in the fixing groove of the
charging cradle and check if the earphone
LED is on.

4 5
COWON CX7
+ Before you start _ Charging
Charge the Earphones Charge the Charging Cradle
*Put the earphones in the charging cradle to start charging them automatically.
*Charging : The white LED Indicator on your earphones turns on / Charging
Complete : The white LED Indicator on your earphones turns off
*Put the USB cable in the Micro USB Port and connect it to the power adapter
to start charging.
*Charging : Charging cradle LED Indicator blink white (0~25%=1time,
25~50%=2times, 50~75%=3times, 75~100%=4times) / Charging Complete
: Stays solid
*Please charge the charging cradle periodically. When the cradle battery is
discharged, the earphone units may turn-on instead of being charged, causing
the earphone to be discharged.
Charging Complete
LEDLED
Charging Complete
×1 ×2 ×3 ×4
LED

6
COWON CX7
+ Using the Product _ Auto Power On · Off
Manual Power On · Off
*Press the button on the earphone for 4 seconds to turn it on when the power is off. (The blue LED flashes three times)
*Press the button on the earphone for 4 seconds to turn it off when the power is on. (The white LED flashes three times)
ON OFF
When both earphones are removed from the charging cradle,
they will automatically turn on.
When inserting the earphones into the charging cradle,
the earphone will automatically get turned off.

6 7
COWON CX7
+ Using the Product _ Pairing & Connection
Remove (Power On) Turn on Bluetooth Connect
Description
When both earphones are removed at the
same time from the charging cradle, they
will automatically turn on. L and R units are
connect to each other. Enter pairing mode
following an “Pairing Mode” voice.
Turn on Bluetooth on your smartphone or
Bluetooth-capable device.
Select ‘CX7 Bluetooth’ from the list of detected
devices to pair and connect automatically.
Voice
Prompts Power On → Connected (In Dual Mode) → Pairing Mode Pairing Successful
L R
CX7 Bluetooth
1 2 3
*The CX7 supports: Dual mode (Stereo) to use the left and right earphones together and Single mode (Mono) to use them separately.
*Remove both the left and right earphones from the charging cradle for use in Dual Mode, or only remove one earphone for use in Single mode.
*Putting one earphone in the charging cradle while in Dual mode does not disconnect the other earphone in use.
*After the initial pairing, opening the charging cradle lid automatically connects the earphones to the most recently connected device.

8
COWON CX7
+ Using the Product _ Listening to Music · Calling · Volume Control
L R
×1
1) 1)
×2
2) 2)
×3
3) 3)
2sec
4) 4)
4sec
1) In Dual mode, the microphone of the earphone removed from the
cradle first will be enabled. Removing L and R earphones from the
cradle at the same time enables the “L” microphone.
In Single Mode, each earphone will output sound with both
microphones enabled for use.
2) Use the Volume Down function with the L earphone and Volume Up
function with the R earphone. (In Single mode, only the functions on
the earphone currently in use are available.)
3) Press and hold the multifunction button for 3 times to launch the
voice recognition feature of your smartphone or tablet. (Android
OS : Google Assistant / iOS : Siri / Window OS : Cortana - Except
during calls)
4) Use the L earphone to go to the previous track and the R earphone
to go to the next track. (In Single mode, only the functions on the
earphone currently in use are available.)
*By using the CX7 in Single Mode, you can alternate between charging the left
and right earphones for extended use. (Audio books, Podcasts, etc.)
*Since Single Mode uses only one earphone, you can stay aware of
environmental sounds and use the device more safely when walking or
bicycling.
*Keep the product and a mobile phone within 1 meter when pairing.
*If passkey input is required, enter a password or a PIN No.‘0000’.
*When the CX7 is off, press and hold the multifunction button for 6 seconds
to enter pairing mode.

8 9
COWON CX7
+ Specification
Bluetooth Version V5.0
Bluetooth Profiles HSP / HFP / A2DP / AVRCP
Standby Time Up to 150 hours
Music-Playing Time Single Mode : About 7 hours
Dual Mode : About 6 hours
Charging Time CX7 : About 1 hour *
Charging Cradle : About 1 hour
Battery CX7: 3.7V / 50mAh
Charging Cradle : 5V / 500mAh
Input DC 5V / 500mA
Operating Distance Up to 10m (Free space)
Weight CX7 : 5g x 2
Charging Cradle : 37g
*Number of available CX7 charges using charging cradle (500mAh) : 3~4
times (with fully charged charging cradle)*For iPhone, user ringtone will be applied.
+ Voice Prompts
Status Voice Prompts
Power On “Power On”
Power Off “Power Off”
Bluetooth Connection “Connected”
Pairing Mode “Pairing Mode”
Pairing Completed “Pairing Successful”
Disconnected “Disconnected”
Incoming call “Incoming Call” *
Call Ended “Call Ended“
Low Battery “Battery Low”

10
COWON CX7
+ Precautions _ Reset to Dual Mode (When the L and R unist are not connecting to each other)
Delete connected device
& Turn off Bluetooth Power Off Hold for 10 seconds
and release
Release when the LED
turns blue Connection
Delete the [CX7 Bluetooth]
device registered on your
smartphone or other
Bluetooth device and turn
off Bluetooth.
Remove the earphones from
the cradle and turn off both
L and R units.
Press and hold the
left and right buttons
simultaneously for 10
seconds. Then release them.
Insert the earphones into the
charging cradle and check if
the earphone LED is on. Then
remove the left and right
earphones from the charging
cradle at the same time. Once
reset, the L unit will enter
pairing mode, and its LED will
flash white and blue.
Turn on Bluetooth on
your smartphone or other
Bluetooth device and
select [CX7 Bluetooth]
from the detected devices
to complete pairing and
automatically connect.
*Refer to page 'Pairing & Connection' when connecting the product to a smart device for the first time.
*If the L and R units only connect in single mode during normal dual-mode operation, reset to dual mode by following the instructions below.
*If it fails to reset, start again from Step ②.
O ff
00:0400:04
OffOff
00:1000:10
L R
CX7 Bluetooth
1 2 3 4 5

10
