Cozum GP922 User manual

Sayfa 1/15
GP922
GP722
GAS TILTING PAN
INSTRUCTION MANUAL

Sayfa 2/15
CONTENTS
INSTALLATION INFORMATION
A. AIMS AND SCOPE
B. RESPONSIBLITIES
C. SIGNS
1. DEVICE SPECIFICATIONS
1.1. TECHNICAL SPECIFICATIONS
2. TRANSPORTATION AND INSTALLATION OF THE PRODUCT
3. SAFETY WARNINGS
4. COMING THINGS TOGETHER WITH THE PRODUCT
5. DEVICE DESCRIPTION/EXPLANATION
6. PLACING THE DEVICE AND PREPARING IT FOR START UP
7. PRE-INSPECTIONS TO BE PERFORMED FOR START UP
8. START UP
9. GAS CONTROL
10. GAS DIAGRAM
11. GAS EQUIPMENTS
12. CLEANING THE DEVICE
14. SAFE LIFE
15. CHANGE THE GAS ENJECTOR

Sayfa 3/15
A. AIMS AND SCOPE
Descriptions for safe use and maintenance of the product
B. RESPONSIBLITIES
Responsibilities of Product’s Owner: The product’s owner is responsible for applying of
safety rules stated in this Instruction Manual or getting them applied by delegating his
authorities and risks, which may arise due to not applying. The product’s owner is also
responsible for the periodical maintenance of the machine.
Responsibilities of the Manufacturers: The manufacturer is responsible for the risks due
to manufacturing and assembling faults, even though all requirements stated in this manual
have been fulfilled.
C. SIGNS
WARNING: This sign indicates that it must be complied with the instructions related
to the subject; otherwise, the risky conditions, in which there can occur some
damages and dangers
CAUTION: This sign indicates any risky conditions, which can cause damages in
material and injuring of people, provided that one does not pay attention and states
that one must be careful.
DANGER: This sign indicates high risky conditions in which people can be injured,
provided that one does not pay attention and the rules always to be complied with.
DANGER: This sign indicates high risky conditions in which the people can be injured
or can die due to electrical shock.
Equipotential connection terminal
(If necessary, it must be connected to other equipment to make equal the potential)

Sayfa 4/15
1. Device Specifications
1.1 Technical Specifications
GP922
S-SU ÇIKIŞI (WATER OUTLET)
W-SU GİRİŞİ (WATER İNLET)
G-GAZ BAĞLANTISI
(GAS CONNECTION)
S
W
WG
242
110
45
G
900
1000
990
150
700870
GP722
1050
G-GAZ BAĞLANTISI
(GAS CONNECTION)
W-SU GİRİŞİ (WATER İNLET)
S-SU ÇIKIŞI (WATER OUTLET)
W
W
S
700
800
500670
G
242
G
42

Sayfa 5/15
Heat input of one burner
Total heat input
Type Number of
nozzles G20-
20mbar
G20-
25mbar
G30-
30mbar
G30-
50mbar
G31-
37mbar
GP922 1 20
20
20
20
20
20
20
20
20
20
GP722 1 8,8 8,8 8,8 8,8 8,8
8,8 8,8 8,8 8,8 8,8
Nozzle Diamater
Type Nozzle diamter G20-
20mbar
G20-
25mbar
G30-
30mbar
G30-
50mbar
G31-
37mbar
GP922 Burner 3 3 2.0 2.0 1.50
Pilot Burner 0,35 0,35 0,25 0,25 0,25
GP722 Burner 2.00 2.00 1.40 1.20 1.40
Pilot Burner 0,35 0,35 0,25 0,25 0,25
Gas Type
Gas
Category
Gas supply
pressure mbar
Country of destination
I
2E
20
DE,LU,PL.RO
I
2E+
20/25
BE,FR
I
3B/P
50
AT,DE,HU
I
3+
28
-
30/37
BE,CH.CY,CZ,EE,ES,FR,GB,GR.IE,IT,LT,LV,PT,SI,SK
I I
2E3B/P
20/50
DE
I I
2E+3+
20/25,28
-
30/37
BE,FR
I
2H
20
AT,CH,CZ,DK,EE,ES,FI,GB,GR,IE,IT,LT,LV,NO,PT,SE,SI,S
K,RO,BG,TR
I
3B/P
28
-
30
C
Y,CZ,DK,EE,FI,GR,HU,IT,LT,LV,MT,NL,NO,SE,SI,SK,RO,
BG,TR
I I
2H3B/P
20,28
-
30
CZ,DK,EE,FI,GR,IT,LT,LV,NO,SE,SI,SK,RO,BG,TR

Sayfa 6/15
2.TRANSPORTATION AND INSTALLATION OF THE PRODUCT
During transportation, take necessary precautions against the risk of falling down
and being turned upside down for the product.
Place the product onto a flat and solid ground.
Do not install the product near the flammable and explosive materials and do not
keep any flammable and explosive material near the furnace, while it is working.
Keep surely a fire extinguisher near the furnace and check whether the periodical
checking of the fire extinguisher has been implemented or not.
2. SAFETY WARNINGS
It is deemed that the users have accepted to conform to the rules stated in instruction
manuals and their products will be out of guarantee scope, unless they conform these rules.
The users are responsible for every sort of abstract and tangible cases, which can arise in
case of not conforming to the rules stated instruction manual.
Do not put any living on the devices. Device must be used to the purpose.
The children and unauthorized people are not allowed to use the device.
While the device is working, do not open in any way the cover of the device with cover.
Be careful not to squeeze your hands while closing the covers.
The device and covers should not be treated as step or ladder in any case.
During cleaning, do not use scratching and abrading means.
All safety checking has been performed. All tests have been implemented related to the
product and the product is in active.
Use rubber gloves during cleaning and maintenance.
Do not remove the label of the devices and warning labels
Manufacturer firm is not responsible for the printing errors, which take place in the instruction
manual and device description catalogue, coming together with the device.
Manufacturer reserves the right to make changes related to the every kind of improvement, if
it is necessary.
The regulations of the device except for the control can only be performed by the unhorsed
services. Do not be involved in the device adjustments.

Sayfa 7/15
In case of needing to drive the device by a different gas, this transformation must be carried
out a certified specialist or an authorized service.
When determining any gas leakage, gas valve must be closed and burning must be ended up.
This appliance is only for professional use and that it shall be used by qualified people
If the fire stops continuously, authorized service must be called.
It is necessary to call an authorized service for installing the device, and if necessary, for
changing in order to use it with other gases.
The information about gas installation has been given in instruction manual.
Gas adjustments can only be changed by your authorized service. Do not be involved in the
adjustments.
Qualified installer should be called in to install the appliance and, if necessary, to convert it
for use with other gases, in keeping with currently installation regulations in country in whıch the
apliance is to be installled.
4. COMING THINGS TOGETHER WITH THE PRODUCT
A. Description Catalogue
B. User/Maintenance/Assembling Manual
C. Guarantee Document
5. DEVICE DESCRIPTION/EXPLANATION
The device have wholly manufactured regarding to hygienic standards.
The legs are in adjustable feature and manufactured by stainless steel material.
For the insulation purposes, glass- wool and stone–wool have been used. Thanks to this
application, wasting of energy can be able to prevent.
It can work by LPG or natural gas.
Burner has safety valve and thermocouple. If the fire puts off, gas flow stops.
6. PLACING THE DEVICE AND PREPARING IT FOR START UP
 While the devices are in operation, do not keep burning material (plastic bags, table napkin,
clothe etc.) near them.
 Read the instruction and maintenance manual absolutely.
 Open the packing of the device and remove all protective tapes.
 Opening the cover of the device, take out the instruction manual and guarantee document.

Sayfa 8/15
 Place on the ground the machine with adjustable leg in type by adjusting its legs, for fixed
the devices with fixed leg, by smoothing the ground.
 There must be sufficient ventilation in the area, where you operate the device.
 Place your device 10 cm away from the surfaces not heat resistant and the wall.
7. PRE-INSPECTIONS TO BE PERFORMED FOR START UP
 Be sure that appropriate gas is used.
 Be sure that there isn’t any leakage on the gas connection of the device.
 Read the instruction manual absolutely
8. START UP
On the figures in gas control section, the figures of control panels existing on the device
have been shown. According to these figures, check whether or not gas connection have
been made exactly and correctly, as mentioned earlier.
Because Control switches existing on the device are graded, we can provide any cooking in
power we desire. (FIGURE 2)
9. GAS CONTROL
SERİES 700-900
Figure 2
1- Gas Switch
Figure 2

Sayfa 9/15
IGNITION OF THE PILOT BURNER SERİES 600-700-900
Press the knob and turn it counterclokwise until it reach position .Wait 20 seconds all the air
expelled from the pipes then push piezoelectric button until the pilotflame alights.After 5 seconds
release the konb desired position.Repeat oparation if the pilotflame should go out.
IGNITION OF THE BURNER AND TEMPATURE REGULATİON SERİES 700- SERİES 900
Turn to knob numbered from 1 to 8 to the desired setting;the gas will fallow the main burners,which will
ignated.
A- Pinpoint Flame B- 100 C° 2- 130 C° 3-160 C° 4-190 C° 5-220 C° 6-250 C°
7- 270 C° C-300 C°

Sayfa 10/15
10. GAS DIAGRAM
SERİES 900
18
0
01
03
05
13
14
06
07
07-02
07-03
12
09
16
10
11
17
04
15-02
15-01
15-03
07-01

Sayfa 11/15
11. GAS EQUIPMENTS
SERİES 900- SERİES 700
NO PART NAME
DIMENTION/
STANDART
01 Collector Ø21x2 1000mm
02 Olive Ø 10 (İnlet)
03 Olive 3/8’’ (Outlet)
04 Nut M16x10
05 Gas valve Pel25st
06 Burner (series 900) 10 kW
06 Burner (series 700) 8,4 kW
07 Pilot Burner
07-01
Nut Ø 4
07-02
Olive Ø 4
07-03
Nozzle
09 Pipe Pilot burner pipe
10 Olive Ø4
11 Nut Ø4
12 Termocouple M9x1000
13 Pipe 3/8’’
14 Nozzle M8
15 Ünion ¼-3/8
16 Piezoelectric
17 Knob
18 label 2.5mm²x200mm

Sayfa 12/15
12. CLEANING THE DEVICE
Device must be cleaned every day after use, after being sure that it is completely cooled
down.
Cleaning must be made by a clean wet cloth by wiping the device. It is recommended that
stainless steel surfaces should be wiped by inox cleaners.
During cleaning, do not use sharp edged, cutting and drilling tools such as scraper, emery in
no way.
Cleaning must not be done by spraying the water onto the device in no way.
13. INTERVENTION AFTER FAILURE
FAILURES / CAUSES
 There is no cooking.
 Be sure that the gas connection to the device has been made and there is gas flow to the
device.
 Be sure that you have opened the right control valve.
 Be sure that you have fired up pilot fire.
14. SAFE LIFE
The safe life of the product is 10 years.

Sayfa 13/15
15. CHANGE THE GAS ENJECTOR
15.1 Main Burner
1) Remove the control panel by unscrew the secrews ‘2’.
2)Raplace the main burner nozzles 14 with disered gas type nozzle according to nozzle daimeter chart.
14

Sayfa 14/15
Primary air
a
-adjustment of the diffuser for gas types
G20-20 mbar:a=15 mm G20-25 mbar:a=7mm
G30-30 mbar:a=12 mm G30-50 mbar:a=12 mm
G31-37 mbar:a=12 mm
15.2 Pilot Burner
The pilot flame is the nozzle type with fixed air.The only adjustment required is replacement of the nozzle depending
on the type of gas.
01-03
01-02
01-01
- Lossen the taper nut (01-01) remove the taper (01-02) and pilot nozzle (01-03)
- Replace the pilot nozzle with desired gas type nozzle according to nozzle chart.
- After replacing the pilot nozzle place the taper and tighten the taper nut.

Sayfa 15/15
INFORMATIONS ABOUT THE FIRM
COZUM KITCHEN IND. & TRADE CO.
Head Office-Factory
10015 Sokak No.13 A.O.S.B. Izmir - TURKEY
Tel: [phone] Fax: [phone]
e-mail: [email protected]
Export Department-Showroom-Sales Center
Kısıklı Caddesi Haluk Türksoy Sokak No.21/1 Altunizade-Istanbul-TURKEY
Tel: [phone] pbx Fax:[phone]
e-mail: [email protected]
www.cozummutfak.com
