COZY VC201A-H and User manual

Gas-Fired Vented
Room Heater
INSTALLATIONAND
OPERATINGINSTRUCTIONS
P/N 80900-H - REV. 01/05
Thisapplianceisequippedwith asafetycontrolsystemdesignedtoprotectagainst
improperventingofcombustionproducts.
THIS UNIT IS NOT TO BE INSTALLED IN MOBILE HOMES.
WARNING: Iftheinformation inthis manualis not
followed exactly, a fire or explosion may result
causingproperty damage,personal injuryor lossof
life.
-Donotstoreoruse gasoline or other flammable vapors
andliquids inthevicinityof thisoranyotherappliance.
- WHAT TODO IFYOUSMELL GAS:
•Donottryto light any appliance.
•Donottouchanyelectricalswitch;do not use any phone
inyourbuilding.
•Immediatelycallyourgassupplierfromaneighbor’s
phone. Followthegas supplier’s instructions.
•Ifyoucannotreachyour gas supplier,callthefire
department.
-INSTALLATIONANDSERVICE MUST BE
PERFORMEDBYAQUALIFIEDINSTALLER,
SERVICE AGENCY ORTHE GAS SUPPLIER.
WARNING: Operationofthis heaterwhen notconnected toaproperlyinstalled andmaintained
ventingsystem ortampering withthe vent safetyshut-off systemcan resultin CarbonMonoxide
(CO)poisoningand possibledeath.
RADIANTFRONT
CLOSED FRONT
This unit is not approved for installation in mobile homes, greenhouses, or environments involving
dusty, wet, corrosive, or explosive conditions. Such conditions will invalidate the warranty and may
create unsafe conditions.
Thecoatingselectedtoprovidelongerlife
tothe heat exchangermaysmoke slightly
uponinitialfiring. Provideadequateventi-
lationifthisoccurs.
NATURALGAS VC201A-H VC351A-H VC501A-H VC701A-H VCR351A-H VCR501A-H VCR701A-H
PROPANEGAS VC202A-H VC352A-H VC502A-H VC702A-H VCR352A-H VCR502A-H VCR702A-H
R
R

SPECIFICATIONS………………………. 2
INTRODUCTION……………………….. 3
VENTING………………………………... 3 ,4
GASSUPPLY……………………………. 5
LOCATION&SPECIALPRECAUTIONS 5
COMBUSTION&VENTILATIONAIR.... 6
CLEARANCES………………………….. 7
DRAFTDIVERTER…………………….. 7
DOORKNOB…………………………… 7
PILOTADJUSTMENT…………………. 8
RADIANTS&GLASSPANELS……….. 8
BURNERORIFICE&ORIFICECHART.......... 8
PROPERBURNERFLAME.............…………. 9
MAINTENANCE…………………………....... 9
LIGHTINGINSTRUCTIONS……………........ 10
TROUBLESHOOTINGCHART………… 11,12
BLOWERINSTRUCTIONS……………… 13
TSKWALLSTATKIT................................ 14
PARTSDRAWING……………………….. 15
PARTSPRICELIST………………………. 16
WARRANTY……………………………… 18
READCAREFULLY BEFOREINSTALLING UNIT
These installation instructions are a general guide and do not supersede applicable local codes and ordinances. Before
planning or making the installation be sure it complies with all phases of the local heating code. (Or, in the absence of
local codes, with the latest edition of National Fuel Gas Code, ANSI.Z223.1, or CAN1-B149).
The appliance, when installed, must be electrically grounded in accordance with local codes, or in the absence of local
codes, with the latest edition of National Electrical Code ANSI/NFPA 70, or Canadian Electrical Code CSA-C22.1.
All of the ANSI and NFPA standards referred to in these installation instructions are the ones that were applicable at
thetime the designof this appliancewas certified. The ANSIstandards are availablefrom the AmericanGas Association,
1515 Wilson Blvd., Arlington, VA. 22209.
The NFPA standards are available from the national Fire Protection Association, 60 Batterymarch Street, Boston,
Massachusetts 02110.
Canadian standards are available from International Approval Services, 178 Rexdale Boulevard, Etobicoke, Ontario,
Canada M9W 1R3.
The design of this appliance was certified to comply with ANSI Z21.11.1 vented room heaters and CAN1-2.1-M86.
Installer must leave these instructions with the consumer, have them complete, and return the warranty card.
ROOMHEATERSPECIFICATIONS
Your room heater comes packed in a single carton. Before installation, check the rating plate to verify that the Model Number is
correct and that the room heater is equipped for the type gas you intend to use.
TABLEOF CONTENTS
TYPE CONTROL GAS MODEL NUMBERS
CLOSEDFRONT THERMOSTAT BULB NATURAL VC201A-H VC351A-H VC501A-H VC701A-H
CLOSEDFRONT THERMOSTATBULB L.P. VC202A-H VC352A-H VC502A-H VC702A-H
RADIANTFRONT THERMOSTATBULB NATURAL N/A VCR351A-H VCR501A-H VCR701A-H
RADIANTFRONT THERMOSTATBULB L.P. N/A VCR352A-H VCR502A-H VCR702A-H
HEIGHT 20” 26” 26” 30”
WIDTH 24” 30” 30” 36”
DEPTH 15-1/4” 15-1/4” 19-1/4” 19-1/4”
INPUT(BTU/HR.) 20,000 35,000 50,000 70,000
GASINLET/OUTLETSIZE 1/2X3/8” 1/2X3/8” 1/2X3/8” 1/2X3/8”
VENTSIZE 3” 4” 4” 5”
CENTEROFVENTTOFLOOR 16-1/2” 21-1/2” 21-1/2” 25-1/2”
NUMBEROFRADIANTS(“VCR”SERIES) N/A 5 5 5
NUMBEROFRADIANTGLASS(“VCR”SERIES) N/A 2 2 2
APPROX.SHIPPINGWEIGHT(“VC”SERIES) 55 LBS. 84 LBS. 112 LBS. 138LBS.
APPROX.SHIPPINGWEIGHT(“VCR”SERIES) N/A 96 LBS. 124 LBS. 150LBS.
*OPTIONALBLOWERMODEL N/A CHB-3 CHB-3 CHB-3
*Blowers also available factory mounted on 50M Btu units. All 70M Btu units come with blower mounted only.
SPECIFICATIONS
Page 2

INTRODUCTION
THISIS AGAS-FIRED,GRAVITYVENTEDROOM HEATERTHATWILL OPERATESAFELYAND PROVIDEANEFFICIENT
SOURCEOFHEAT WHENINSTALLED,OPERATED AND MAINTAINEDASRECOMMENDEDINTHESE INSTALLATION
ANDOPERATINGINSTRUCTIONS. READ THESEINSTRCTIONSTHOROUGHLY BEFOREINSTALLING,SERVICING,OR
USING THIS APPLIANCE. IF YOU DO NOT UNDERSTAND ANY PART OF THESE INSTRUCTIONS, CONSULT LOCAL
AUTHORITIES,OTHERQUALIFIEDINSTALLERS,SERVICEAGENCIES,THEGASSUPPLIER,ORTHEMANUFACTURER.
VENTING
This heater must be connected to a properly installed and maintained venting system. This heater is equipped with a vent safety
shut-off device. Pilot outage will occur if the heater is not connected to a vent system. Pilot outage may occur due to restriction or
blockage in the vent or if connected to a masonry chimney having an area greater than the vent size shown on Page 2.
This appliance should be vented through a properly sized listed type B vent that has been constructed in accordance with the
National Building Code. If a horizontal section of vent is used, it must slope upwards a minimum of ¼ inch per foot of length.
This heater must not be connected to a vent system being used for wood or coal burning appliances. The use of more than one
appliance per vent system will most likely cause the vent safety shut-off device to shut off the heater due to the cooling of vent
temperatures through the draft diverter of the second appliance. In some situations, the vent safety shut-off may shut down the
heater if a too large, unlined, masonry chimney is used. Due to low vent temperatures associated with more efficient heaters it may
take too long to get the vent action going in a chimney before the shut-off device will shut down the heater. If this is the case, we
recommend lining the chimney with the proper size type B vent pipe or type B chimney liner.
WARNING: Do not bypass the vent safety shutoff switch. To do so could expose the consumer to
property damage, personal injury or possible death.
The switch, when activated, will extinguish the pilot flame. If the homeowner experiences this problem, the vent system must be
checked and corrected. NOTE: An existing vent that has worked for years may not be adequate for todays design because of
higher efficiency requirements resulting in lower stack temperatures. The following is a list of possible causes and corrective
actions.
POSSIBLECAUSES CORRECTIVE ACTION
1. Blockage in vent pipe 1.A) Check vent pipe for blockage, such as bird nest, wasp nest, twigs, leaves, etc.
1.B) Check that the vent cap is properly installed, not shoved too far down on the vent
pipe.
2. Burner is over firin 2.A) Check the manifold pressure.
2.B) Check the rate, NOTE: This appliance was orificed for elevations up to 2,000 feet.
When installed at higher elevations refer to orifice chart in main burner orifice
section of instructions for proper orifice size and re-orifice accordingly.
3. Improper vent system 3. Correct vent system.
A) Vent too short A) The vent should not terminate less than 5 feet above the drafthood connection. A
gas vent extending through an exterior wall shall not terminate adjacent to the
wall or below eaves or parapets. Also, the top of the vent must be at least 2 foot
above any obstacles within a 10 foot radius, including the roof. See Figure A.
B) Restriction in vent B) All type “B” vent shall extend in a generally vertical direction with offsets not
system caused by exceeding 45 degrees, except that a vent system having not more than one 60
offsets degree offset may be allowed. Any angle greater than 45 degrees from the vertical
is considered horizontal. The total horizontal run of a vent plus the horizontal vent
connector shall be not greater than 75 percent of the vertical height of the vent.
Any offsets used should be as far above the drafthood as possible to allow a
venting action to begin before any restriction is encountered.
C) Incorrect vent pipe C) Use listed “B” type vent pipe. Do not use transite or any other type of ceramic
pipe for venting. Do not use single wall pipe.
4. Loose connections on the 4. Check the connection on both the switch and the gas valve. Tighten if necessary.
Page 3
vent safety wiring harness

VENTING
10’ or Less
2’Min.
3’Min.
Ridge
Chimney
More than
10’ 10’
2’Min. 3’Min.
Ridge
Chimney
Height above any
roof surface
withon10’
horizontally
FIGUREA FIGUREA
Seal around collar
& flashings
Maintain
1”Clearance Support
Laterals
Termination of vent must be
securely guyed or braced if
it extends more than five (5)
feet above roof. See
Termination
diagram
above
Firestop Support
Assembly
VerticalVent
Elbow
Listed
Appl.
Terminate vent
at least 5 ft.
above draft hood
CONNECTINGTHEVENT INTO
AN EXISTING CHIMNEY
SAFE (See “Venting”)
NOTE: Thismay result
intheventsafetyswitch
shuttingdownthepilot
dependingonsize and
drawofchimney.
FIGURE7A
1/4
UNSAFE
FIGURE7B
RECOMMENDED
Usepropersize“B”
pipeorchimneyliner
insidechimney.
FIGURE7C
Page 4

GASSUPPLY
Thisventedroomheatermustbeconnectedtoagassupply
capableof supplying the appliances fullrated capacity.
Providea1/8inch N.P.T. pluggedtapping,accessiblefor
testgaugeconnection, immediately upstream ofthegas
supplyconnectiontothe appliance. The minimum inlet
pressure in the gas supply pipe should be 4.5” w.c. for
Natural Gas and 11.0” w.c. for Propane Gas, “for the
purposeofinputadjustment”. Themaximuminletpressure
inthe gassupply pipe shouldnever exceed14” w.c.for
either Natural or Propane Gas. The gas supply piping
shouldbesizedinaccordancewithANSIZ223.1National
FuelGas Code. Thenormalmanifoldpressureshouldbe
3.5” w.c. for Natural Gas and 10.0” w.c. for Propane
Gas.
If the outlet pressure of the gas valve must be adjusted,
thisshouldbedonebyaqualifiedservicemanusingproper
toolsandinstruments.
Checkallconnectionswithsoapywaterfor possible gas
leaks. Neveruseamatch,candleorotherignitionsource.
Itis recommendedthatpipecompoundwhich isresistant
to the action of liquefied petroleum gases be used. Do
notuseTeflon tape or Teflonimpregnatedcompound.
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping during any
pressuretestingofthatsystematthetestpressureinexcess
of½psig.
Theappliancemustbeisolatedfromthegassupplypiping
byclosing itsindividualmanualshutoffvalve duringany
pressure testing of the gas supply piping system at test
pressuresequal to or lessthan ½ psig.
LOCATIONANDSPEICAL
PRECAUTIONS
Dueto high temperaturesthe appliance shouldbe
locatedout of trafficand away fromfurniture and
draperies.
Childrenandadultsshouldbealertedtothehazards
ofhigh surface temperatureand should stayaway
toavoidburnsorclothingignition.
Youngchildrenshouldbecarefullysupervisedwhen
theyarein the same room astheappliance.
Clothingor otherflammablematerialshouldnotbe
placedon or near theappliance.
Any safety screen, guard, or casing top removed
forservicinga room heatermustbe replaced prior
tooperatingtheappliance.
Do not use this heater if any part has been under
water. Immediatelycallaqualifiedservicetechnician
toinspect theheater and toreplace anypart of the
controlsystemandanygascontrolwhichhasbeen
underwater.
For purpose of identifying the sides of the heater.
Whenyouarefacingthefrontoftheheatertheright
sidehas the access doorand the leftsideis solid.
Ifheaterisinstalledinaresidentialgarage,allburners
and pilot must be above 18”. Locate or protect
heatersoitcannotbedamagedbyamovingvehicle.
Page 5

COMBUSTIONAND VENTILATIONAIR
When installed, this gas appliance must be provided with fresh air for
combustion, ventilation, and dilution of hot flue gases. The minimum required
volume of the area where the appliance is installed should be 50 cubic feet per
1,000btu/hr.
If installed in an area of the home that is considered an unconfined space, the
natural infiltration of air around windows and doors will be adequate. If the
area is considered a confined space (less than 50 cubic feet per thousand btu),
fresh air can be supplied by providing two permanent openings into adjoining
rooms. Each opening shall have a minimum free area of one square inch per
1,000 btu per hour of the total input rating of all gas appliances in the confined
space, but not less than 100 square inches. One of the openings shall be within
12 inches of the ceiling and one within 12 inches of the floor. See Figure A.
If the home is of unusually tight construction (new and remodeled homes), free
air must be supplied through opening(s) to the outdoors. This can be
accomplished by providing 2 permanent openings, one commencing within 12
inches of the ceiling and one within 12 inches of the floor. These openings
shall communicate directly with the outdoors, or spaces that communicate
freely with the outdoors, such as a ventilated attic and crawl space through
galvanized or equivalent corrosion-resistant ducts. Exception: unobstructed
stud and joist spaces are acceptable ducts provided that not more than one fire
block is removed. Special provisions must be taken to insure that these stud
and joist spaces cannot be blocked with insulation or other objects. Each of
these openings using vertical ducts shall have a minimum free area of one
square inch per 4,000 btu/hr of total input rating of all gas appliances. See
FigureB and C. If horizontal ducts areused,the minimum free area shall beone
square inch per 2,000 btu/hr of total input rating of all gas appliances.
Fresh make-up air can also be provided through a duct to one permanent
openingcommencingwithin 12 inches of the ceiling. The minimumfreeareaof
this opening shall be one square inch per 3,000 btu/hr of the total input rating
of all gas appliances but not less than the sum of the areas of all vent connectors
in the space. See Figure D.
When calculating the amount of fresh air needed you must include make-up air
requirements for the operation of exhaust fans, kitchen ventilation systems,
clothes dryers, and fireplaces.
Additional information can be found in the latest edition of ANSI Z223.1
(NationalFuel Gas Code).
ALLCOMBUSTIONAIRFROM
ADJACENTINDOORSPACES
THROUGHINDOORCOMBUSTION
AIROPENINGS
UL Listed Vent Cap
UL Listed Gas Vent
Opening
Opening
ALL COMBUSTION AIR FROM
OUTDOORS. INLET AIR FROM
VENTILATED CRAWL SPACE AND
OUTLET AIR TO VENTILATED ATTIC
UL Listed Vent Cap
UL Listed Gas Vent
Ventilation Louvers
(each end of attic)
Outlet Air
Inlet Air
Ventilation
louvers for unheated
crawl space
ALL COMBUSTION AIR FROM OUTDOORS
THROUGH VENTILATED ATTIC ALL COMBUSTION AIR FROM OUTDOORS
THROUGH SINGLE COMBUSTION AIR OPENING
UL Listed Vent Cap
UL Listed Gas Vent
Ventilation Louvers
(each end of attic)
Outlet Air
Inlet Air Duct (Ends 1 Ft.
[300 mm] above floor)
UL Listed Vent Cap
UL Listed Gas Vent
Opening
Alternate
opening
location
FIGUREA
FIGUREC
FIGUREB
FIGURED
Page 6
Inlet
Grille
Inlet
Grille

CLEARANCES
If the area where the appliance is to be installed contains
carpeting, tile, or combustible materials, other than wood
flooring, the appliance shall be installed on a metal plate
(stoveboard), a wood panel, or other non-combustible
materials. The use of ceramic or quarry tile is acceptable
and provides an appealing surface that is easily cleaned.
This material is to extend 2 inches from each side and 12
inches from the front. It is advisable to extend this to the
wall behind the appliance.
Clearances to combustibles are as follows:
•From jacket to adjacent side walls, 2” on the 20/35, and
6” on the 50/70. Maintain adequate clearance on right
side for accessibility.
•From rear surface vertical vent pipe to rear walls – 6”.
•From rear of unit to rear wall, 13” on 20/35, and 14” on
the50/70.
•From top of heater to ceiling, 34” on the 20/35, and 31”
on the 50/70.
•Fromtop of heater toany overhanging projections such
as a mantle or window sill is 22” on the 20/35, and 19
inchesonthe50/70models, with a maximum horizontal
extension of 18 inches.
The clearances around the air opening into the combustion
chamber must be maintained, and the burner must be kept
clean.
Do not permit dust or dirt to accumulate here. The other
clearances previously mentioned must be maintained.
There must be adequate room provided and maintained
around the heater for accessibility and for the flow of
combustion and ventilation air.
Projection
Projection
CLEARANCES - VC20, VC35, VCR35
CLEARANCES - VC50 & VC70,
VCR50 & VCR70
Page 7
Projection
Projection
DRAFTDIVERTER
The draft diverter must be installed in the same atmospheric
pressurezoneasthecombustionairsupplyforthe main burner.
DOOR KNOB
Remove from the inside of the casing door and assemble to
the outside of the door. VC201 and VC202 have finger holes
in the door in lieu of knob.
WIRINGDIAGRAM
TEMPERATURE
CONTROL
BLOCKEDFLUE
SWITCH PILOT
GENERATOR
18 IN.
45.72CM
Ceiling
Wall
Floor
34 IN.
86.36CM 22 IN.
55.88CM
6 IN.
15.2CM
13IN.
33CM
20/35
Ceiling
Wall
Floor
18 IN.
45.72CM
6 IN.
15.2CM
14IN.
35.6CM
31IN.
78.7CM
19 IN.
48.3CM
50/70

PILOTADJUSTMENT
The pilot flame can be observed by opening the pilot lighting
hole cover. The pilot flame should surround the top 3/8 to ½
inch of the thermocouple (see Figure 2). If the flame needs
adjusting,firstlocatethepilot adjustment screw cap and remove.
Adjustment screw is underneath (see Figure 1). To increase the
flame, turn the pilot adjustment screw counterclockwise .
To decrease the flame, turn the screw clockwise . NOTE:
The pilot is unregulated. If incoming line pressure is more than
7” w.c. Natural Gas or 11” w.c. for L.P. Gas, the pilot flame size
should be decreased.
PILOTFLAME
ADJUST-
MENT
Pilotflame
should
envelop
3/8 to 1/2
inch on the
tip of the
generator.
FIGURE2
RADIANTSAND GLASSPANELS
FORALLVCRMODELS
(See Figure 9 – Replacement Parts Section)
INSTALLGLASSANDRADIANTSASFOLLOWS:
STEP1. Remove threescrews from under topof opening in
bezelframe assembly.
STEP2. Pull top of bezel down and lay aside.
STEP3. Remove glass from bottom pad in shipping carton.
STEP4. Remove carton containing radiants from cavity of
combustion chamber.
STEP5. Remove radiants from carton and install by tilting
backwards and lifting at the same time into opening. Place
the radiants on the burner radiants supports. The radiants
must be straight. Never operate heater if any radiant is
tilted to front or rear. Continued
STEP6. Install glass panels by inserting top edge into upper
retainer and lower into bottom support, and slide glass into
position. Do not allow a crack between the two glass panels.
Never operate heater with either glass missing or cracked.
STEP7. Re-install bezel byplacingbezeltabsover lower front
and swing bezel into position and secure with three screws.
MAIN BURNER ORIFICE
This appliance was shipped from the factory with an orifice
sized to give the correct gas input using the gas for which the
heater was equipped. There may be local conditions, such as
variation in gas pressure or BTU content of the gas, which
may be cause for a change in the orifice. The gas company
supplying the fuel or the installing contractor should check
the gas input rate.
If the rate exceeds the “BTUH INPUT” on the rating plate by
5%, the orifice should be replaced with a smaller orifice by a
qualified technician to reduce the input to the rating plate
value.
The input rate may need to be adjusted for elevation. See the
following charts to determine the correct orifice size for your
Model Number and elevation. These orifice sizes are based
on a heating value of 1020 for Natural Gas and 2500 for L.P.
Gas.
CAUTION: Aselevationincreases, derating is necessary for
the safe and proper operation of this heater. Do not increase
the Btu input rate by increasing the orifice size or gas
pressure. Allowforelevation derating when sizing gas heating
equipment.
SPECIFICELEVATIONS
Model 0 to 2,000- 4,000 - 6,000 - 8,000’
No. 2,000’ 4,000’ 6,000’ 8,000’ 10,000’
VC201 45 47 48 49 50
VC351 35 37 38 40 42
VC501 30 31 31 32 35
VC701 25 27 28 29 30
VCR351 35 37 38 40 42
VCR501 30 31 31 32 35
VCR701 25 27 28 29 30
ORDERKIT#49820 45-1HIGHALTITUDEKIT
SPECIFICELEVATIONS
Model 0 to 2,000- 4,000 - 6,000 - 8,000’
No. 2,000’ 4,000’ 6,000’ 8,000’ 10,000’
VC202 1.3mm 55 56 56 57
VC352 1.65mm 53 53 54 54
VC502 47 49 49 50 51
VC702 41 42 43 44 46
VCR352 1.65mm 53 53 54 54
VCR502 47 49 49 50 51
VCR702 41 42 43 44 46
ORDERKIT#49820 45-1HIGHALTITUDEKIT
NATURALGAS
L.P.GAS
Page 8
3/8 TO
1/2 INCH
PilotAdj. Screw
FIGURE1

CAUTION: There may be momentary and spasmodic
orangeflashes intheflame. Thisiscausedbytheburning
ofair borne dustparticles and isnot to beconfused with
theyellowtippingwhichisastableorpermanentsituation
whenthereisinsufficientprimaryair.
MAINTENANCE
CLEANING: To clean the front casing of your heater, it is
onlynecessary to use a soft cloth. Lightdustcan be removed
in this way. To obtain a polish or gloss, use a little light
machineoil on the cloth. Do not usemetalpolish or cleaning
solution. The burner ports should be kept free from lint and
dust.
CLEANINGOF COMBUSTIONCHAMBER
The combustion chamber of your console heater should
never need to be cleaned if proper burner adjustment and
gas pressures are maintained. However, if an unusual
circumstance should occur, the following procedure should
be followed in cleaning your combustion chamber.
1. Turn off gas supply to heater at manual valve in
supply line to heater.
2. Disconnect heater at ground joint union ahead of
main gas valve.
3. Remove main control and orifice assembly.
4. Remove burner.
5. Remove combustion chamber.
6. Using a scraper, scrape inside of a primary
combustion chamber. This should be area of
heaviest accumulation of carbon.
7. Remove plug bottom located in bottom rear of
second combustion chamber. Using a bottlebrush,
clean inside of this chamber. Shake residue out the
clean-out hole.
8. Clean the rear chamber by using bottlebrush
through the vent tube openings.
9. Replace combustion chamber, burner and control.
Checkallgaspipingforleaksbeforelighting heater.
Repair service should be performed by qualified persons.
The heater should be inspected before initial use. An annual
cleaning of control compartment and safety performance
check should be made by a qualified service person. More
frequent cleaning may be required when exposed to the
excessive lint conditions due to carpeting and bedding
material, etc. It is imperative that the control compartment,
burners, and circulating air passageways of the heater be
kept clean. Any safety screen, casing top, or guard removed
for servicing the heater must be replaced prior to operating
heater.
If the venting system is not maintained in proper operating
condition, the vent safety shutoff will not allow heater to
operate. Periodic examination of the entire venting system
as a routine part of the safety performance check is
recommended on an annual basis.
Itis advised that the pilot andmainburner flames be checked
at least twice during the heating season for any changes in
flame characteristics. See Figure 2 and Figure 3.
Page 9
FIGURE3
INNER MANTLE 1/4”
OUTER MANTLE 3 - 5”
PROPERBURNERFLAME
3” TO
5”
1/4”
SERVICERECORD
THIS IS A GAS-FIRED APPLIANCE, KEEP THE AREA CLEAR OF GASOLINE AND OTHER FLAMMABLE
VAPORS AND LIQUIDS. ALL COMBUSTIBLE MATERIAL MUST BE KEPT CLEAR OF THIS AREA.
HAVE A QUALIFIED SERVICEMAN CHECK THE BURNER PERIODICALLY. REMOVE AND CLEAN
IF NECESSARY.

10. Close pilot lighting hole cover and casing
door.
11. Turn gas control knob counterclockwise
to “ON”.
12. Turn temperature control knob to desired setting.
MODELS: VC201A-H,VC202A-H,VC351A-H,VC352A-H, VC501A-H,VC502A-H,VC701A-H,
VC702A-H,VCR351A-H,VCR352A-H, VCR501A-H,VCR502A-H, VCR701A-H,VCR702A-H
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: Ifyou donot follow theseinstructions exactly,a fireorexplosion may result
causingproperty damage,personalinjury orloss oflife.
A. This appliance has apilotwhich must be lighted byhand.
When lighting the pilot, follow these instructions ex-
actly.
B. BEFORELIGHTINGsmellallaround theappliancearea
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHATTODOIFYOUSMELLGAS:
•Do not try to light any appliance.
•Do not touch any electric switch; do not use any phone
in your building.
•Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
•Ifyoucannot reach your gas supplier, call thefiredepartment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand,don’t try to repair it, callaqualified service technician.
Force or attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system
and any gas control which has been under water.
LIGHTING INSTRUCTIONS
1. STOP! Read the information on the safety label.
2. Turn temperature control knob to “OFF” or it’s
lowest position.
3. Depress and turn gas control knob clockwise
to “OFF” position.
4. Wait five (5) minutes to clear out any gas. Then
smell for gas, including near the floor. If you smell
gas, STOP! Follow “B” in the information on the
safety label. If you don’t smell gas, go to the next
step.
5. Open casing door and pilot lighting hole cover.
6. Findpilot. (Follow metalpilottubefrom gascontrol).
7. Locate red piezo ignitor button on top of heater.
8. Turn gas control knob counterclockwise to
“PILOT”.
9. Push in gas control knob and hold in. Immediately
begin a series of pushing and releasing the red
piezo ignitor button, while observing the pilot.
Continue to spark until pilot is lit. Continue to
hold the gas control knob in for about one (1)
minuteafterthepilot is lit. Release the gas control
knob and it will pop back up. Pilot should remain
lit. If pilot goes out, repeat steps 3 thru 9.
• If knob does not pop up when released, STOP
andimmediately call your service technician
or gas supplier.
•If the pilot will not stay lit after several tries,
turn the gas control knob to “OFF” and call
your service technician or gas supplier.
TO TURN OFF GAS TO APPLIANCE
1. Turn the temperature control knob to it’s lowest setting.
2. Push in gas control knob slightly and turn clockwise to “OFF”. Do not force.
Page 10
Pilot is located on
end of combustion
chamber above
burner.
Gas Control Knob
NOTE: Knob can
not be turned from
“PILOT”to“OFF”
unless knob is
pushed in slightly.
Do not force.
