COZY VFT201 and User manual

INSTALLATION AND
OPERATION INSTRUCTIONS
P/N 88900 /REV. 02/04
MODEL NUMBERS IMANUAL MODELS
NATURAL GAS I VFM63, VFM103, VFM203, VFM303
PROPANE GAS I VFM64, VFM104, VFM204, VFM304
IARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any
phone in your building.
•Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire
department.
INSTALLATION AND SERVICE MUST BE
PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE
GAS SUPPLIER.
Vent-Free Gas Heat
I HERMOSTAT MODELS I
VFT101, VFT201, VFT301
VFT102, VFT202, VFT302
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this
manual for future reference.
INSTALLER MUST SHOW
HOMEOWNER PROPER
LIGHTING AND OPERATION
OF HEATER. HAVE THEM
COMPLETE AND RETURN
THE WARRANTY CARD.
This is an unvented gas fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. See Pg. 4 & 5.
This unit is not approved for installation in greenhouses, or environments involving dusty, wet,
corrosive, or explosive conditions. Such conditions will invalidate the warranty and may create
unsafe conditions.
This appliance may be installed in an afiennarket, permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.

WARNING: hnproper installation, adjustment, alteration, service or maintenance can canse property
damage, personal injury or loss of life. Refer to the owner's information manual provided with this
appliance. Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
THIS HEATER SHOULD NOT BE INSTALLED ABOVE 7,000 FT. ELEVATION.
HEATERS INSTALLED ABOVE 4,500 FT. MAY EXPERIENCE NUISANCE PILOT
OUTAGE AND THIS CONDITION MAY BE AGGRAVATED BY IMPROPER PRESSURE
AND INCORRECT SIZING RELATIVE TO FREE AIR OR CONFINED SPACE.
INTRODUCTION............................ 2, 3
SPECIFICATIONS........................... 3
SAFETY INSTRUCTIONS ................. 3,4
FRESH AIR FOR COMBUSTION VENTI-
LATION &AIR DISTRIBUTION ....... 4, 5
INSTALLATION............................. 5
CLEARANCES............................... 6
TOOLS &ADDITIONAL SUPPLIES ..... 6
GASRO[YGH-IN.............................. 6
WALLMOUNT............................... 9
FREE STANDING............................ 9
CONTENT
GAS CONNECTION.................................. 10
LIGHTING INSTRUCTIONS .............................. 11 14
PROPER OPERATION....................................... 15
MAINTENANCE .............................................. 16
BLOWER INSTRUCTIONS ................................ 17
TROUBLE SHOOTING GUIDE............................ 22
ILLUSTRATED PARTS BREAKDOWN ............... 18,20
PARTSLIST................................................... 19,21
WARRANIT .................................................. 24
L.P GASWARNING SHEET .............................. 23
INTRODUCTION
Read these installation and operating instructions carefully before you install or attempt to use this vent free
room heater. If you do not understand any part of these instructions, consult local authorities, a qualified
installer, service agency, or the gas supplier. FAILURE TO READ OR UNDERSTAND THESE
INSTRUCTIONS CAN RESULT IN MALFUNCTION, INEFFICIENT OPERATION,
PROPERTY DAMAGE, SERIOUS INJURY OR DEATH.
These installation instructions are a general guide and do not supersede applicable local codes and
ordinances. Before planning or beginning the installation besure itcomplies with allphases ofthe local
heating code. Or, in the absence of local codes, with the latest edition of the National Fuel Gas Code,
ANSI.Z223.1/NFPA54. A copy of which is available from the American Gas Association, 1515Wilson
Blvd., Arlington, Virginia22209.
The design of this appliance was certified to comply with the latest edition of ANSI Z21.11.2, also available
from the American Gas Association.
Page 2

INTRODUCTION- CONT'D.
For your protection this heater is equipped with an Oxygen Depletion Sensor (ODS) pilot system. Never operate heater if
ODS has been damaged or tampered with as this could expose you to Carbon Monoxide (a colorless, odorless gas) that
could result in injury or death. Early simls of Carbon Monoxide poisoning resemble intluenza, with headaches, dizziness,
or nausea. If you develop these symptoms GET FRESH AIR AT ONCE. Turn off heater and call a qualified selaTicelnanto
check heater. Some people are more affected by Carbon Monoxide than others: Including pre_lant women, persons with
a heart or lung disease, anemia, those under the influence of alcohol, and those at high altitudes.
OPERATION
Infrared heaters "heat like the sun" with ahnost instantaneous, safe, clean burning "waves" of intiared heat. Like the sun,
they must "see" the object to be heated. Make sure they are installed away tiom furniture or any other object which
might block the intiared "waves". The Cozy thennostatically controlled units offer the additional benefit of automatically
cycling the heating to maintain just the right room temperature. Ventfree gas room heaters are designed strictly t\_r
"supplemental" room heat use and should never be installed as "sole source heating".
ROOM HEATER SPECIFICATIONS
Your room heater comes packed in a single carton. Before installation, check the rating plate to veril_ that the Model
Number is correct and that the room heater is equipped for the type gas you intend to use.
MODELN[_IBER
NATURAL GAS V_163 VFM303
PROPANE GAS VFM64 VFM304
TYPECONTROL MAN. MAN.
HEIGHT 22-1/2" 22-1/2"
WIDTH 11-1/2" 26-13/16"
DEPTH 7" 7"
INPUT (BTUiHR.) 5.500 LO /10,000
MEDi20,000
HI /30.000
NO YES YES
NO YES YES
YES NO NO
YES NO NO
YES YES YES
16 LB. 35 LB. 35 LB.
Gas Supply Line Size
Optional CVF Blower
Optional Floor Stand
Bathroom Installation
Bedroom Installation
Piezo Ignitor
Shipping Weight
MANUAL MODELS
VFM103 VFM203
VFM104 VFM204
MAN. MAN.
22-1/2" 22-1/2'
14-9/16" 20-11/16"
7" 7"
10,000 LO /10.000
HI /20.000
NO YES
YES YES
NO NO
YES NO
YES YES
22 LB. 30 LB.
VFT101 VFT201
VFT102 VFT202
T-STAT T-STAT
BULB BULB
22-1/2" 22-12"
14-9/16" 20-1116"
7" 7"
10.000 20,000
NO YES
YES YES
NO NO
YES NO
YES YES
22 LB. 30 LB.
THERMOSTAT MODELS
VFT301
VFT302
T-STAT
BULB
22-1/2"
26-13/16"
7 _'
30.000
As applicable:
1. An unvented room hetaer having an input rating of more than
or bathrooln; or
2. An unvented room heater having an input rating of more than
10,000 Btu per hour shall not be installed in a bedroom
6,000 Btu per hour shall not be installed in a bathroom.
SAFETY INSTRUCTIONS
1) Keep burner and control compartment clean.
2) Due to high temperatures, the heater should be located out of traffic and away from furniture and draperies.
3) Children and adults should be alerted to the hazard of high surface temperature and should stay away to avoid burns
or clothing imfition.
4) Young children should be carefully supel-vised then they are in the same room with this heater.
53 Do not place clothin_ or other flammable material on or near the heater.
6) Any safety screen or guard removed for sel-vicing must be replaced prior to operating the heater.
Page 3

SAFETY INSTRUCTIONS - CONTINUED
7) Installation and repair should be done by a qualified service person. The heater should be inspected before use
and at least annually by a professional service person. More liequent cleaning may be required due to excessive
lint lioln carpeting, bedding, material, etc. It is imperative that control compartlnents, burners, and circulatin_ air
passageways of the heater be kept clean.
8) "WARNING: Any changes to this heater or its controls can be dangerous'.
9) Do not use this heater if any part has been under water, hnmediately call a qualified service person to inspect the
heater and to replace any part of the control system and any _as control which has been under water.
10) Due to high surface and radiated telnperamres, keep children, clothing, and furniture away.
11) Do not install this heater in a recreational vehicle.
12) Never use a match, candle, flame or other source ofianition to check for _as leaks. Use only soapy water or
liquid detergent.
13) Before cleaning or servicing, turn off the gas and allow heater to cool.
14) Do not put objects around the heater that will obstruct the flow of combustion and ventilation air.
15) When installing the heater allow adequate accessibility clearances for servicing and proper operation.
16) Keep appliance area clear and free fioln combustible materials, gasoline and other flammable vapors and liquids.
17) Do not install in a residential or commercial garage.
18) WARNING: Do not use a blower or other accessory not approved for use with this heater.
19) "WARNING: Failure to keep the primary air opening(s) of the burner(s) clean may result in sooting and property
damage."
20) "WARNING: Do not allow fans to blow directly into the appliance. Avoid any drafts that alter burner flame
patterns."
21) This appliance is intended for supplemental heating.
FRESH AIR FOR COMBUSTION, VENTILATION AND HEAT DISTRIBUTION
With todays eneigy efficient homes, it is possible to make your home so air tight that it can result in stale air, dry rot, mold
development and host of other related problems. Gas burning appliances need fresh air for combustion as well as for
good distribution of heated air throughout the home. The l\_llowing mlide provides good general rules for classifying and
properly ventilating most homes.
"The National Fuel Gas Code ANSI Z223.1/NFPA54 defines a confined space as a space whose volume is less than 50
cubic feet per 1,000 Btu per hour (4.81n3per Kw) of the ag_egate input rating ofatt appliances installed in that space and
an unconfined space as a space whose volume is equal to or greater than 50 cubic feet per 1,000 Btu per hour (4.8m 3per
Kw) of the aggregate input rating ofalt appliances installed in that space. Rooms comlnunicating directly with the space
in which the appliance is installed, through openings not furnished with doors, are considered a part of the unconfined
space."
"This heater shall not be installed in a confined space or unusually tight construction unless provisions for adequate
combustion and ventilation air are made. Use the l\_llowing example to determine if the heater is being installed in a
confined or unconfined space."
STEP 1. First find the cubic feet of area to be heated lenath x width x heiaht. NOTE: Include aW adjoining rooms that
cannot be separated by closing a door or that have a air exchange _itte that cannot be closed between rooms.
EXAMPLE: Area size 25 ft. x 15 ft. x 7-1/2 ft. 2,812.5 cubic feet.
STEP2. Divide area cubic feet by 50. EXAMPLE: 2,812.5 50 56.25. Multiplythisnumberby 1,000 for total Btu input
room can support. EXAMPLE: 56.25 x 1,000 56,250 Bin.
STEP3. List all gas burning appliances in this area and total the combined Btu input. EXAMPLE:
Cozy vent fiee heater. ......................... 20,000 Bm
Gaswater heater................................ 58,000 Bm
Gas range (all burners & oven on) ........... 28,000 Bm
106,000Btu
Page 4

FRESH AIR FOR COMBUSTION, VENTILATION AND HEAT DISTRIBUTION - CONTD.
STEP 4. Compare the total Btu the area can support (from Step 2) to the total Btu in the area the heater wilt be installed
(fioln Step 3). If the total froln Step 2 is larger this is considered an unconfined space, ifBtu total froln Step 3 is larger this
is considered a confined space and provisions must be made t\_radditional combustion and ventilation air. EXAMPLE:
Btu area can support is 56,250, total Btu in area is 106,000 this would be a confined space.
NOTE: A third construction class is one with unusually tight construction, defined as, construction where: (A) Walls
and ceilings exposed to the outside atmosphere have a continuous water vapor retarder with a rating of 1per (6x 10-11 Kg
per pa-sec-m 2)or less with openings gasketed or sealed, and, (B) Weatherstripping has been added on openabte windows
and doors, and, (C) Caulking or sealants are applied to areas such as joints around window and door frames, between
sole plates and floors, between wall ceiling joints, between walt panels, at penetration for plumbing, electrical, and gas
lines, and at other openings.
"WARNING: If the area in which the heater may be operated is smaller than that defined as an unconfined space, or if the
building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods
described in the National Fuel Gas Code, ANSI Z223.1/NFPA54, Section 5.3 or applicable local codes." Examples would
be to provide two permanent openings either to an adjoining room, or to the outside. See the National Fuel Gas Code t\_r
details. See Fibre 9 & Figure 10 below.
ater
ater
iiii illllllltll r
I
Equipment located in confined
spaces; all air fioln inside the
building. See 5.3.3(a).
Opening
Opening
-- _Chimney or gas vent
Alternate
air inlet --
jVentilation louvers
_d of attic)
4,,.A===_
I [ HIHII I I [ I ]IIIHH
[[' I I q'] [' I ] ]'' I 'T ]
[_ Ventilation lomers foi
1reheated cia,al space
"-Outlet Air
!Inlet Air
Equipment located in confined spaces; all air from
outdoors - inlet air from ventilated crawl space and
outlet air to ventilated attic. See 5.3.3(b).
FIGURE 9 FIGURE 10
INSTALLATION
Installation and service must be performed by a qualified installel; service agency or the gas supplier.
LOCATION
1) For most efficient performance, locate heater as centrally as possible in the area to be heated.
2) Do not install heater in a closet, alcove or small hallway where the heater could be isolated from the space to be
heated and adequate combustion air by closing a door.
Page 5

INSTALLATION - CONTINUED
3) Protect heater from wind, high traffic areas, and drafts (such as doorways, locations that get direct air from a ceiling
fan, etc.) as this will cause nuisance pilot outage.
4) Alhnodels may be walhnounted. Model No. VFM 10, VFT10, VFM20, VFT20, VFM30 & VFT301nay be fiee
standing by adding optional VF-FSK floor stand kit. These floor mounted units must also have an approved, fire
resistant floor base (available fiom factory) and must be hard piped.
5) If optional blower is to be added, locate heater so there is safe access to an electrical outlet.
CLEARANCES
1) Maintain adequate accessibility clearances for
servicing and proper operation.
2) Minimum clearances as viewed from front of
heater. 3" clearance below heater shall be
measured fioln top surface of carpeting, tile,
etc.
3) IfVF-FSK Free Standing Kit is used and the
heater is installed directly on carpeting, tile, or
other combustible material other than wood
flooring, the appliance shall be installed on a
metal or wood panel extending the full width
and depth of the appliance, such as a stove
board.
TOOLS AND ADDITIONAL SUPPLIES
REQUIRED
1) Pipe wrenches (2).
2) Phillip head screwdriver or screwgun.
3) Pressure test gauge.
4) An A.G.A. certified manual shut offvatve
with 1/8" NPT pressure tap.
5) Union connector for type of piping used
(check local codes).
6) Pipe sealant certified for use with L.E gas.
7) Components to assemble a drip leg.
8) Level.
9) Drill (if anchors are required).
ROUGH-IN GAS SUPPLY
1) Determine location of heater. (See
"Operation", "Fresh Air", and "Safety
Instructions" for details.
2) Install at least a V_,"diameter gas supply line.
(Gas supply can enter through bottom or
back of heater). See Figure 1.
T
36"
_' ',,_ //_
m 8':-->
CLEARANCES
3"
J
I
--- ---
1-5/8" -J _-- 13-1/16"
FIGURE 1
8"_
Page 6

SEE FOLLOWING CHARTS FROM NFPN54, ANSI Z223.1 TO DETEILMINE PROPER GAS SUPPLY LINE SIZE REQUIRED TO SUPPOI{I' TOTAL BTU REQUIRE-
IMENTS.
NATURAL GAS
Maximum Capacity of Pipe in Cubic Feet of Gas per Hour for Gas Pressures of 0.5 psig or Less and a Pressure Drop of 0.5 Inch Water Colun-m.
(Based on a 0.60 Specific Gravi UGas)
--a
Nominal LENGTH OF PIPE, FEET
Iron Pipe Internal
Size, Diametm;
Inches Inches 10 20 30 40 50 60 70 80 90 100 125 150 175 200
V4 0.364 43 29 24 20 18 16 15 14 13 12 11 10 9 8
3/8 0.493 95 65 52 45 40 36 33 31 29 27 24 22 20 19
V2 0.622 175 120 97 82 73 66 61 57 53 50 44 40 37 35
3¢_ 0.824 3(10 250 200 170 151 138 125 118 110 103 93 84 77 72
1 1.049 680 465 375 320 285 2(:0 240 220 205 195 175 160 145 135
1-1/4 1.38 1400 950 770 6(_) 5_ 530 490 4(-l) 430 400 360 325 300 280
1-1/2" 1.61 2100 1460 1180 990 900 810 750 690 650 620 550 500 400 430
2 2.067 3950 2750 2200 1900 1680 1520 1400 1300 1220 1150 1020 950 850 800
2-1/2 2.469 6300 4350 3520 3C_)0 2650 2400 2250 2050 1950 1850 1650 15(X) 1370 1280
3 3.068 11000 7.7 6250 5300 4750 43(X) 39(X) 37(X) 3450 3250 2950 2650 2450 2280
4 4.026 23(X)0 158(X) 128(X) 10900 9.7 8800 8100 7500 7200 6700 6000 5500 5000 46(X)
*Pipe and Tubing Selection
Total piping length -84 |Yet (use table 4 @ 90 fYet)
From a to b, demand 200,000 - 38,000 65,000 35.000
: 338,000 Bl'Uihr. use 1" pipe.
From b to c, demand 38,000 65.000 - 35,000
138,000 BTUihr; use _;" pipe or 7/8" tubing.
From c to d, demand : 65,000 35,000
100.000 BTUibr; use }g' pipe or }g' tubing.
From d to e, demand 35,000 BTU/hr; use %" pipe or 5/8" tubing.
From b to E demand : 200,000 BFUihr; use /" pipe.
From c to g, demand 38.000 BTUihr; use I,)" pipe or 5/8" tubing.
From d to h, demand 65,000 BTU/hr; use %" pipe or _A" tubing.
Example 2.
Determine the sizes of piping or robing required lbr the two-stage L.P.
(;as installation shown.
26 5 8
/qrst Stage Feet
Re_ulatol Furnace
200.000
Second Stage
Regulator
Total first stage piping length = 26 feet; first stage regulator setting is 10 PSIG (use Table 1or 3,
@ 30 lk'et) From aa to a, demand 338,000 BTU hr; use _=" pipe, _2"
robing, or 'A" T plastic pipe.
*lnlbrmation li'om - REGO PRODUCTS
"I.P GAS SI'RVICI'MAN'S MANUAl2'
) ) ) )
SEE FOI_I_OWINGPAGEFOIl III ESIZING CIIARI S FOR 1ROIANE GAS.
Total second stage piping length = 58 feet (use table 4, @
60 feet).
From a to b. demand 338,000 BlUihr; use I" pipe.
From b to c, demand 138,000 BTUihr; use _;*" pipe or 7/8"
tubing.
From c to d. demand 100,000 BlUihr; use !_" pipe or 2_"
tubing.
From d to e, demand 35,000 BTUihr; use !2" pipe or '2"
tubing.
From b to f demand 200,000 BTU/hr; use _a" pipe.
From c to g, demand 38,000 BTUihr; use !2" pipe or 5/8"
tubinm

TABLE 1 -first stage pipe sizing
10 PSIG Inlet with a 1 PSIG Pressure Drop
Maximum capacity of pipe or robing, in thousands ofBTU/hr, of L.P. Gas
PROPANE GAS
Size of Pipe LENGTH OF PIPE OR TUBING. FEET*
Or Copper
Tubing, Inches 10 20 30 40 50 60 70 80 90 100
Copper
Tubing
(OD
Pipe
Size
3/8 558 383 309 265 235 213 196 182 171 161
½ 1387 870 700 599 531 481 443 412 386 365
5/8 2360 1622 1303 1115 988 896 824 767 719 679
¾ 3993 2475 2205 1887 1672 1515 1394 1297 1217 1149
½ 3339 2295 1843 1577 1398 1267 1165 1084 1017 961
¾ 6982 4799 3854 3298 2923 2649 2437 2267 2127 2009
1 13153 9040 7259 6213 5507 4989 4590 4270 4007 3785
1-1/4 27004 18560 14904 12756 11306 10244 9424 8767 8226 7770
1-1/2 40461 27809 22331 19113 16939 15348 14120 13136 12325 11642
277924 53556 43008 36809 32623 29559 27194 25299 23737 22422
Copper
Tubing
(O.D.)
Pipe
Size
12s IS0 17s ?00 ?2s ?sO ?Ts _00 _s0 400
3/8 142 130 118 111 104 90 89 89 82 76
½ 323 293 269 251 235 222 211 201 185 172
5/8 601 546 502 467 438 414 393 375 345 321
¾ 1018 923 843 790 740 700 664 634 584 543
½ 852 772 710 660 619 585 556 530 488 454
¾ 1780 1613 1484 1381 1296 1224 1162 1109 1020 949
1 3354 3039 2796 2601 2441 2305 2190 2089 1922 1788
1-1/4 6887 6240 5741 5340 5011 4733 4495 4289 3945 3670
1-1/2 10318 9349 8601 8002 7508 7092 6735 6426 5911 5499
219871 18005 16564 15410 14459 13658 12971 12375 11385 10591
*Total length
away).
Notes: 1)
2)
of piping fronl outlet of first stage regulator to inlet of second stage regulator (or to inlet of second stage regulator furthest
To allow 2 PSIG pressure drop, multiply total gas demand by .707, and use capacities fronl table.
For different first stage pressures, multiply total gas demand by the i\311owing factors, and use capacities from table.
First State Pressure PSIG Multiply by
20 .844
21 .912 Data Calculated per NFPA #54 & 58.
TABLE 4 - Second, Single, or Integral Twin Stage Pipe Sizing
11 Inches Water Column Inlet with a V2Inch Water Column Drop
Maximum capacity of pipe oi tubing in thousands ofBTU/hr of LP-Gas PROPANE GAS
Size of Pipe
Or Copper
Tubing, Inches
3/8
Copper 1/2
Tubing 5/8
(OD.)
Pipe
Size
Copper
Tubing
(OD.)
Pipe
Size
3/4
7/8
1/2
3/4
1
1-1/4
1-1/2
2
3/8
1/2
5/8
3/4
7/8
1/2
3/4
1
1-1/4
1-1/2
2
LENGTH OF PIPE OR TUBING. FEET*
10 20 30 40 50 60 70 80
49 34 27 23 20 19
110 76 61 52 46 42 38 36
206 141 114 97 86 78 71 67
348 239 192 164 146 132 120 113
536 368 296 253 224 203 185 174
291 200 161 137 122 110 102 94
608 418 336 287 255 231 212 198
1146 788 632 541 480 435 400 372
2353 1617 1299 1111 985 892 821 764
3525 2423 1946 1665 1476 1337 1230 1144
6789 4666 3747 3207 2842 2575 2369 2204
90
33
62
105
161
87
185
349
717
1074
2068
125 150 175 200 225 250 275 300 350
74 67 62 58 54 51 48 46 43
155 141 129 120 113 107 101 97 89
292 265 244 227 213 201 191 182 167
600 544 500 465 437 412 392 374 344
899 815 749 697 654 618 587 560 515
1731 1569 1443 1343 1260 1190 1130 1078 992
*Total length of piping
100
32
59
100
154
84
175
33O
677
1014
1954
4OO
40
83
156
320
479
923
from outlet of regulator to appliance furthest away. Data Calculated per NFPA #54 & 58.
Page 8

INSTALLING HEATER WALL MOUNT
(VFM20, VFT20, VFM30, VFT30)
WALL MOUNT (VFM6, VFM10, VFT10)
STEP 1. Remove walt mounting bracket froln back of
heater.
STEP2. Locate wall stud.
STEP 3. Attach wall mounting bracket to wall stud
with top at desired heigllt, using (2) screws provided.
Make sure top of bracket is level. See Fimlre 2.
STEP 4. Hang top of heater on wall mounting bracket.
STEP5. Remove bottom flont panel.
STEP 6. Secure back of heater to wall, utilizing
anchors (if necessary) or wood screws. See Figure 3.
WALL STUD
o O O
O O
--IWALL
MOUN_ING
BRACKET
FIGURE 2
J
/
HOLES FOR MOUNTING BACK OF
HEATER TO WALL
FIGURE 3
Page 9
STEP 1. Relnove wall mounting bracket fiom back of
heater.
STEP 2. Locate two studs.
STEP 3. Attach wall mounting bracket to wall studs with
top at desired height using (2) wood screws provided.
Make sure top of bracket is level. See Figure 4.
STEP 4. Hang top of heater over wall mounting bracket.
STEP 5. Remove bottom front panel.
STEP 6. Secure back of heater to wall, utilizing anchors (if
necessary) or wood screws. See Figure 3.
0 o 0
© ° ©
FIGURE 4
INSTALLING VF-FSK FLOOR BASE KIT
STEP 1. Remove floor base fiom carton.
STEP 2. AIiN1 screw holes in base to holes in heater
bottom.
STEP 3. Make sure that cut-out in top of floor base aliNls
with cut-out in bottom of heater and the other cut-out in
bottom of heater and the other cut-out in base if facing
towards back of unit (see illustration below).
STEP4. Attach floor base to bottom of heater using four
#8 screws (provided).
NOTE: Floor bases are t\_ruse on VFM 10, VFT 10, VFM-
20, VFT-20, VFM30 and VFT30 only. The VFM6 Series has
no base and is not approved for use with one.
HEATER
¢lake sure this cut-out
faces back of heater.

STEP1.
NOTE:
GAS CONNECTION
Make the gas connection between the manual shut off valve and regulator located inside
heater cabinet. Hold regulator when tightening connection to prevent dmnage to regulator
and internal robing. See Figure 5 for completed installation.
All piping and connection must be checked for leaks by the installer. If connections are not
exposed, apressure test must be ran. The appliance and its individual shut offvalve must
be disconnected from the gas supply piping system during any pressure testing at pressures
in excess of ½ psig (3.5 kPa). The appliance must be isolated from the gas supply piping
system by closing its individual manual shut offvalve during any pressure testing of the gas
supply piping system at test pressures equal to or less than 1/2psig (3.5kPa).
Outside Re_. InternalReaulator
Supplied _ _lied)
_" M_Union
\ {_- Drip Leg
1/8" NPT Plug
FIGURE 5
Manual
Cut off
Valve
Pressure rl
GASPIPINGWITHVF-FSKKIT
FIGURE 5A
Page 10

VFM63, VFM103 -NATURAL GAS VFM64, VFM104 -L.P. GAS
FOR YOUR SAFETY READ BEFORE LIGHT
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTL_ A
FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, |
PERSONAL INJURY OR LOSS OF LIFE. 1
A. This appliance has a pilot which must be lighted by
hand. When lighting the pilot, follow these
instructions exactly.
B. BEFORE LIGHTING smell all around the appliance
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch, do not use aW
phone in your building.
• hnmediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
C. Use only your hand to push in or turn the gas control
knob. Never use tools. If the knob will not push in or
turn by hand, don't try to repair it, call a qualified
service technician. Force or attempted repair may
result in a fire or explosion.
D. Do not use this appliance if any part has been under
water, hnmediately call a qualified service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
STOP! Read the safety information above on this
label.
2. Depress gas control knob slightly and turn
cloc_vise _ to "OFF".
3. Turn offalt electric power to the appliance.
INSTRUCTIONS
I,t.
BGas
Control
Knob
NOTE: Knob can not be tamed from "PILOT" to
"OFF" unless knob is depressed slightly. Do not tbrce.
4. Wait five (5) minutes to clear out any gas. Then smell
t\_rgas, including near the floor. If you smell gas,
STOP! Follow "B" in the safety information above
on this label. If you don't smell gas, go to the next
step.
5. Locate pilot in the cut-out below the burner.
6. Locate piezo iNlitor button on top of heater.
7. Turn gas control knob counterclockwise _ to
"PILOT".
8. Depress gas control knob and hold in. hnmediately
begin alternately pushing and releasing piezo
ignitor button, observing pilot, until pilot is lit.
Continue to hold the control knob in t\_rabout one
(1) minute after the pilot is lit. Release the gas
control knob and it will pop back up. Pilot should
remain lit. If pilot goes out, repeat steps 2 thru 7.
• If knob does not pop up when released, STOP and
immediately call your service technician or gas
supplier.
• If the pilot will not stay lit after several tries, turn the
gas control knob to "OFF" and call your service
technician or gas supplier.
9. Turn gas control knob counterclockwise_ to
"ON".
Depress
TURN OFF GAS TO APPLIAN
knob slightly and turn clockwise :"
Page 11

VFM203 - NATURAL GAS VFM204 -L.P. GAS
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A
FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PER-
SONAL INJURY OR LOSS OF LIFE.
A. This appliance has a pilot which must be lighted by
hand. When lighting the pilot, t\_ltow these instruc-
tions exactly.
B. BEFORE LIGHTING smell all around the appliance
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch, do not use any
phone in your building.
• hnlnediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
C. Use only your hand to push in or mm the gas
control knob. Never use tools. If the knob will not
push in or turn by hand, don't try to repair it, call a
qualified sela:ice technician. Force or attempted
repair may result in a fire or explosion.
D. Do not use this appliance if any part has been
under water. Ilnmediately call a qualified service
technician to inspect the appliance and to replace
any part of the control system and any gas control
which has been under water.
1.
2.
3.
LIGHTING INSTRUCTIONS
STOP! Read the safety information above on this
label.
Depress gas control knob slightly and turn cloclcvvise
to "OFF".
Turn offatl electric power to the appliance.
DGas
Control
Knob
NOTE: Knob can not be turned tiom "PILOT" to "OFF" unless
knob is depressed slightly. Do not force.
4. Wait five (5) minutes to clear out any gas. Then smell
for gas, including near the floor. If you smell gas,
STOP! Follow "B" in the safety information above
on this label. If you don't smell gas, go to the next
step.
5. Locate pilot in the cut-out below the burner.
6. Locate piezo ignitor button on top of heater.
7. Turn gas control knob countercloc_vise ld-'xto
"PILOT".
8. Depress gas control knob and hold in. Ilnmediatet
begin alternately pushing and releasing piezo
ignitor button, observing pilot, until pilot is lit.
Continue to hold the control knob in tbr about
one (1)minute after the pilot is lit. Release the
gas control knob and it will pop back up. Pilot
should remain lit. If pilot goes out, repeat step_
2thru 7.
• If knob does not pop up when released, STOP and
immediately call your sela:ice technician or gas
supplier.
• If the pilot will not stay lit after several tries, turn
the gas control knob to "OFF" and call your
service technician or gas supplier.
9. Turn on all electric power to the appliance.
10. Turn gas control knob countercloc_vise N"Nto
desired "LO" or "HI'" setting.
TURN OFF GAS TO APPLIAN
Depress gas control knob slightly and turn cloclcvvise fNto "OFF".
Turn offall electric power to the appliance if service is to be perforlned.
Page 12

VFM303 - NATURAL GAS VFM304 - L.P. GAS
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
A. This appliance has a pilot which must be lighted by • If you cannot reach your gas supplier, call the fire
hand. When lighting the pilot, tSllow these instruc- department.
tions exactly. C. Use only your hand to push in or turn the gas control
BEFORE LIGHTING smell all around the appliance knob. Never use tools. If the knob will not push in or
area for gas. Be sure to smell next to the floor turn by hand, don't try to repair it, call a qualified
because some gas is heavier than air and will settle service technician. Force or attempted repair may
on the floor, result in a tire or explosion.
WHAT TO DO IF YOU SMELL GAS: D. Do not use this appliance if any part has been under
Do not try to light any appliance, water. Imlnediately call a qualified service technician
Do not touch any electric switch, do not use any to inspect the appliance and to replace any part of the
phone in your building, control system and any gas control which has been
Ilnmediately call your gas supplier tiom a under water.
neighbor's phone. Follow the gas supplier's
instructions.
g.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this
label.
2. Depress gas control knob slightly and turn
cloc_vise _ to "OFF".
3. Turn offalt electric power to the appliance.
/Gas
Control
Knob
NOTE: Knob can not be turned from "PILOT" to "OFF"
mless knob is depressed slightly. Do not force.
4. Wait five (5) minutes to clear out any gas. Then
smell for gas, including near the floor. If you smell
gas, STOP! Follow "B" in the safety information
above on this label. If you don't smell gas, go to
the next step.
5. Locate pilot in the cut-out below the burner.
6. Locate piezo ignitor button on top of heater.
7. Turn gas control knob counterclockwise _ to
"PILOT".
8. Depress gas control knob and hold in. hnmediately
begin alternately pushing and releasing piezo
ignitor button, observing pilot, until pilot is lit.
Continue to hold the control knob in for about one
(1) minute after the pilot is lit. Release the gas
control knob and it will pop back up. Pilot should
remain lit. If pilot goes out, repeat steps 2 thru 7.
" If knob does not pop up when released, STOP and
immediately call your service technician or gas
supplier.
• If the pilot will not stay lit after several tries, mm the
gas control knob to "OFF" and call your service
technician or gas supplier.
9. Turn on all electric power to the appliance.
10. Turn gas control knob counterclockwise _ to
desired temperature setting.
TO TURN OFF GAS TO APPLIANCE
Depress gas control knob slightly and turn cloclcwise _ to "OFF".
Turn off atl electric power to the appliance if service is to be performed.
Page 13

VFT101, VFT201, VFT301 - NAT. GAS /VFT102, VFT202, VFT302 - L.P.
FOR YOUR SAFETY RF_Ak_ BEFORE LIGHTING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A
FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PER-
SONAL INJURY OR LOSS OF LIFE.
A. This appliance has a pilot which 1Tlustbe lighted by
hand. When lighting the pilot, follow these instruc-
tions exactly.
B. BEFORE LIGHTING smell all around the appliance
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch, do not use any
phone in your building.
• hnlnediately call your gas supplier l_oln a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
C. Use only your hand to push in or turn the gas
control knob. Never use tools. If the knob will
not push in or turn by hand, don't try to repair it,
call a qualified selaTicetechnician. Force or
attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been
underwater. Ilnmediately call a qualified selMce
technician to inspect the appliance and to replace
any part of the control system and any gas
control which has been under water.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety inforlnation above on this
label.
2. Depress gas control knob slightly and mm clockwise
€'N to "OFF".
3. Turn offalt electric power to the appliance.
/
Gas
Control
Knob
NOTE: Knob can not be turned fiom "PILOT" to "OFF" unless
knob is depressed slightly. Do not force.
4. Wait five (5) minutes to clear out any gas. Then smell
f\_rgas, including near the floor. If you smell gas,
STOP! Follow "B" in the safety information above
on this label. If you don't smell gas, go to the next
step.
5. Locate pilot in the cut-out below the burner.
6. Locate piezo ignitor button on top of heater.
7. Turn gas control knob counterctoclcwise K"Nto
"PILOT".
8. Depress gas control knob and hold in.
hmnediately begin alternately pushing and
releasing piezo ignitor button, obsmMng pilot,
until pilot is lit. Continue to hold the control
knob in for about one (1) minute after the pilot
is lit. Release the gas control knob and it will
pop back up. Pilot should remain lit. If pilot
goes out, repeat steps 2 thru 7.
• If knob does not pop up when released, STOP
and immediately call your service technician or
gas supplier.
• If the pilot will not stay lit after several tries, turn
the gas control knob to "OFF" and call your
serMce technician or gas supplier.
9. Turn on all electric power to the appliance.
10. Turn gas control knob counterclockwise _ to
desired temperature setting.
TURN OFF GAS TO APPLIAN
Depress gas control knob slightly and turn cloclcwise _ to "OFF".
Turn off atl electric power to the appliance if selaqce is to be performed.
Page 14

PROPER OPERATION
ODS /PILOT FLAME
The pilot pressure has been pre-set at the factory and with proper supply pressure will provide asafe,
reliable ignition source. See Figure 6.
(DRRE(T INCORRECT -
LOW PRESSURE INCORRECT - OXYGEN LEVEL DROPPING
BURNER FLAME
All orificing and pressure setting was done at the factory and, with proper supply pressure, wilt provide a safe, efficient
source of heat. However, if any questions about lnanifold pressure, have a qualified selwiceman check with a manometer,
Natural Gas will be 5", L.R Gas will be 10" w.c. A proper burner flame (See Figure 7)will produce a reddish-orange flow on
the surface of the ceramic burner plaques. If the burner flame has blue streamers or the flame is floating offthe surface of
the plaques, turn heater offand call a qualified selwice person. Do not operate heater if all plaques are not glowing.
NOTE: There wilt be approximately ¼" space on the sides and top of the burner that will not glow.
VFM20: When turned to the "LO" setting the two middle plaques wilt light and glow. When valve is turned to "HI" then
_-_,:i:t }! :P::' L _?
i: , :L _.
N_:','i::?A
_. :_
,: 17:[
CORRECT FLAME
FIGURE 7
INCORRECT FLAME
all four plaques will be lit.
_o,_, !
VFMIO /CORRECT FLAME
"LO"
_- 5:' )_5]'°'_,r
VFM20 /CORRECT FLAME
_ _I-II _
Page 15

The entire heater should be checked and cleaned by a qualified service person before the start of each
heating season. More frequent cleaning may berequired due to excessive lint conditions from carpeting,
bedding material, etc.
CABINET
To clean the cabinet and hearth and j arab assemblies of your heater, turn off and allow to cool, then wipe
with a soft damp cloth. This will remove any dust. Never use metal polish, furniture wax, or any type of
cleaning solution as this could cause odors when the heater is turned back on.
MAIN BURNER
Burners may be cleaned by using a low pressure air hose, or soft brush. Be careful not to damage the
ceramic plaque.
ODS/PILOT
STEP 1. Remove bottom front panel.
STEP 2. Disconnect pilot line from pilot.
STEP 3. Use a low pressure air hose to blow through pilot and through ODS opening in side of pilot.
WARNING: Never insert anything into any of the openings in the pilot as this could damage the Oxygen
Depletion System and expose the homeowner to Carbon Monoxide poisoning.
/i g#,
,_" "\,x/,/_'
;TEP 3 - PILOT CLEANING
WARNING: After any servicing or cleaning make sure heater is completely re-assembled and check for
gas leaks.
Page 16

BLOWER INSTRUCTIONS
INSTALLING THE VFB BLOWER
STEP 1. Remove blower asselnbly tiom shipping carton.
STEP 2. Insert blower assembly into upper back of heater (See Figure 8).
STEP3. Secure blower to heater using three #8 screws (provided) through holes pre-punched in heater back.
STEP 4. Locate mounting holes t\_rswitchbox (See Fimlre 8).
STEP 5. Secure switchbox to heater using two #8 screws (provided).
STEP6. Plug power cord into 115 volt three-prong _ounded receptacle.
CAUTION: Always unplug power cord bel\)re servicing or cleaning heater. This appliance is equipped with a three-
prong (_ounding) plug tbr your protection against shock hazard and should be plugged directly into a
properly _ounded three-prong receptacle.
Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper
and dangerous operation. Verify proper operation after servicing.
/
FIGURE 8
•Blower Assembly
Blower
Motor
Black
White
Ifany ofthe originalwire supplied
with the appliance must be re-
placed, itmust bereplaced with a
wire of at least a 105°Ctempera-
turerating.
Z-g = -*
WIR1NG DIAGRAM /VFB BLOWER
Page 17

MANUAL MODELS
NAT. GAS L.P. GAS
VFM63 VFM64
VFM103 VFM104
VFM203 VFM204
VFM303 VFM304
VENT FREE INFRA-RED HEATER
MANUAL CONTROL
PARTS LIST
Prices and specifications subject to change
without notice. All prices are F.O.B. factory.
Blower
Parts
VFM103,
VFM104
©
VFM63,
VFM64
_ VFM203, VFM204
Page 18
VFM303, VFM304
"MED"
"LO"

REPLACEMENT PARTSLIST. TO ORDER REPLACEMENT PARTSYOU MUST GIVE MODEL NUMBER, SERIAL
NUMBER, TYPE OF GAS USED, PARTDESCRIPTION AND PARTNUMBER.
MODELNUMBERSNATURAL VFM63 VFM 103 VFM203 VFM303
MODELNUMBERSPROPANE VFM64 VFM 104 VFM204 VFM304
REF, PART LIST PART LIST PART LIST PART LIST
PART DESCRIPTION NO, NO, PRICE NO, PRICE NO, PRICE NO. PRICE
Valve, CPMM-21400/17 1 88290 $40,60 88290 $40,60 88291 $42,00 88177 $41,30
ODS/Pilot (NAT. GAS) 2 88169 $41,90 88169 $41,90 88169 $41,90 88169 $41,90
ODS/Pilot (LP. GAS) 2 88168 $36,20 88168 $36,20 88168 $36,20 88168 $36,20
Manifold 3 88147 $10,10 88148 $20,10 N/A N/A N/A N/A
Manifold "LO" 3a N/A N/A N/A N/A 88155 $18,40 88157 $18,80
Manifold "HI" 3b N/A N/A N/A N/A 88156 $17,90 88159 $18,80
Manifold "MEDIUM" 3c N/A N/A N/A N/A N/A N/A 88158 $18,80
Burner Orifice (NAT. GAS) 5 88021 $3,40 88021 $3,40 88021 $3,40 88021 $3,40
Burner Orifice (LP. GAS) 5 88020 $3,40 88020 $3,40 88020 $3,40 88020 $3,40
Gas Regulator (NAT. GAS) 6 88035 $17,50 88035 $17,50 88031 $17,50 88031 $17,50
Gas Regulator (LP. GAS) 6 88036 $17,50 88036 $17,50 88032 $17,50 88032 $17,50
Burner Assembly 7 88150 $42,20 88151 $79,70 88152 $145,50 88153 $197,40
Gas Supply Tube 9 88045 $2,80 88066 $4,20 88066 $4,20 88049 $4,70
Control Rod 10 88019 $11,70 88019 $11,70 88019 $11,70 88019 $11,70
Control Knob 11 88075 $4,00 88075 $4,00 88008 $5,90 88010 $6,60
Wall Mounting Bracket 12 35220 $7,00 35220 $7,00 35960 $8,60 35960 $8,60
Piezo 13 80016 $5,70 80016 $5,70 80016 $5,70 80016 $5,70
Electrode Wire 30" 14 88070 $2,80 88070 $2,80 88070 $2,80 88070 $2,80
Pilot Tubing Assy,24"Nat,&L,F 15 88013 $4,70 88013 $4,70 88013 $4,70 88013 $4,70
Control Rod Grommet 16 88018 $1,10 88018 $1,10 88018 $1,10 88018 $1,10
Casing Back 17 35165 $16,90 35425 $19,30 35925 $20,00 36425 $25,90
Casing Left Side 18 35060 $13,10 35060 $13,10 35060 $13,10 35060 $13,10
Casing Right Side 19 35070 $13,10 35070 $13,10 35070 $13,10 35070 $13,10
Top Front Panel 20 35045 $14,90 35340 $16,20 35870 $12,70 36340 $21,20
Bottom Front Panel 21 35080 $10,10 35360 $10,70 35860 $12,40 36360 $13,80
Bezel Assembly 22 35100 $43,40 35380 $46,80 35880 $51,70 36380 $58,30
Wire Guard 23 88100 $21,40 88101 $23,00 88105 $26,60 88104 $33,40
Heat Shield 24 35200 $2,60 35460 $2,90 35940 $4,00 36440 $4,60
Valve Support Bracket 25 35185 $2,90 N/A N/A 35185 $2,90 35185 $2,90
Regulator Support Bracket 26 35240 $5,00 35480 $4,00 35240 $5,00 35480 $4,00
Lighting Instruction Assembl 91370 $2,80 91370 $2,80 91371 $2,80 91380 $4,50
BLOWER PARTS VF-B
Blower/Motor Assembly 30 N/A N/A 88250 $58,60 88250 $58,60
Blower Housing 31 N/A N/A 37025 $13,00 37025 $13,00
Fan Switch 32 N/A N/A 88240 $5,90 88240 $5,90
Power Cord 33 N/A N/A 80202 $4,20 80202 $4,20
Junction Box N/A N/A 37075 $6,10 37075 $6,10
Junction Box Cover N/A N/A 37085 $7,80 37085 $7,80
* TWO REQUIRED
I Mr. Contractor, we only sell parts through our wholesalers, but the prices listed above are for your convenience.
|
For prompt parts service, contact the wholesaler fiom which you purchased your Cozy heater. NOTE: Parts & I
schematic drawings on current models are shown at _vw.cozyheaters.com
MARCH 2005
Page 19

THERMOSTAT MODELS
NAT. GAS L.P. GAS
VFT101 VFT102
VFT201 VFT202
VFT302 VFT302
VENT FREE INFRA-RED HEATER
THERMOSTAT CONTROL
PARTS LIST
Prices and specifications subject to change
without notice. All prices are F.O.B. factory.
Blower
Parts
®
Mr. Contractor, we only sell parts through
our wholesalers, but the prices listed are for
your convenience. For prompt parts
service, contact the wholesaler tiom which
you purchased your Cozy heater. NOTE:
Parts & schematic drawings on current
models are shown at _vw.cozyheaters.com.
©
©VFT101, VFT102
VFT201, VFT202
VFT301, VFT302
Page 20
