LevelOne
WAB-6120
150Mbps Wireless Outdoor PoE Access Point
Quick Installation Guide

Hardware Installation
1. Grab the cover and pull it back harder to take it out
2. Plug Cat.5/5e/6 cable into the RJ-45 port.
3. Slide the cover back
4. plug the power cord into the DC port of the PoE injector

5. Put what in the Step.3 and Step.4 together by plugging the other side of the Cat.5/5e/6 cable in the
Step.3 into the PoE port of the PoE injector in the Step.4. When you finish the Step.5, the complete set
will be like the following picture.

Configuration
Check Your Network Settings to login web UI
Please make sure your PC can get IP address automatically, so the router can communicate with
your PC during configuration.
Select “Control Panel” > “Network Connections”.
Right click the “Local Area Connection” and choose “Properties”.
Select the TCP/IP protocol for your network card.
Click on the Properties button. You should then see the following screen and make sure you
have selected “Obtain IP address automatically”
Open your WEB browser (Internet Explorer is recommended).
Then enter: http://192.168.1.1
User name: admin
Password: admin

AP Mode
1. Choose Wireless > Basic Settings for the wireless basic settings
Click save.
Choose Security to change the security settings.
Click Save.

Now, you can see SSID “LevelOne” in the list.
Congratulations!
The AP mode is now successfully configured.
