Cradlepoint MBR95 User manual

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
`
Preface
CradlePoint reserves the right to revise this publication and to make changes in the content thereof without obligation to
notify any person or organization of any revisions or changes.
Manual Revisions
Revision
Date
Description
Author
1.0
July 19, 2011
Initial release for Firmware version 3.2.4
Jeremy Cramer
1.1
Feb. 21, 2012
Updated release for Firmware version 3.4.1
Jeremy Cramer
1.2
July 31, 2012
Updated release for Firmware version 3.6.3
Jeremy Cramer
Trademarks
CradlePoint and the CradlePoint logo are registered trademarks of CradlePoint, Inc. in the United States and other
countries. All other company or product names mentioned herein are trademarks or registered trademarks of their
respective companies.
Copyright © 2012 by CradlePoint, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written consent by
CradlePoint, Inc.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
`
Table of Contents
1INTRODUCTION ................................................................ 3
1.1 PACKAGE CONTENTS ............................................................. 3
1.2 SYSTEM REQUIREMENTS......................................................... 3
1.3 MBR95 OVERVIEW .............................................................. 3
2HARDWARE OVERVIEW .................................................... 5
2.1 PORTS,BUTTONS,AND SWITCHES............................................ 6
2.2 LEDS.................................................................................. 7
3QUICK START .................................................................. 10
3.1 BASIC SETUP ...................................................................... 10
3.2 CONNECT TO A COMPUTER OR OTHER DEVICE .......................... 11
3.3 COMMON PROBLEMS .......................................................... 14
4WEB INTERFACE -- ESSENTIALS........................................ 18
4.1 ADMINISTRATOR LOGIN ....................................................... 19
4.2 GETTING STARTED –FIRST TIME SETUP................................... 21
4.3 QUICK LINKS ...................................................................... 26
4.4 BASIC MODE VS.ADVANCED MODE ....................................... 27
4.5 NETWORK SETTINGS VS.INTERNET ......................................... 28
5STATUS........................................................................... 29
5.1 CLIENT LIST........................................................................ 30
5.2 DASHBOARD ...................................................................... 32
5.3 GPS................................................................................. 35
5.4 INTERNET CONNECTIONS ...................................................... 36
5.5 STATISTICS (ADVANCED MODE ONLY)..................................... 47
5.6 SYSTEM LOGS..................................................................... 50
6NETWORK SETTINGS ....................................................... 51
6.1 CONTENT FILTERING............................................................ 52
6.2 DHCP SERVER (ADVANCED MODE ONLY) ............................... 55
6.3 DNS (ADVANCED MODE ONLY)............................................. 56
6.4 FIREWALL (ADVANCED MODE ONLY) ...................................... 59
6.5 MAC FILTER...................................................................... 64
6.6 ROUTING (ADVANCED MODE ONLY)....................................... 65
6.7 WIFI /LOCAL NETWORKS .................................................... 66
7INTERNET........................................................................81
7.1 CONNECTION MANAGER ...................................................... 82
7.2 DATA USAGE (ADVANCED MODE ONLY).................................. 97
7.3 WIFI AS WAN (ADVANCED MODE ONLY) ............................. 102
8SYSTEM SETTINGS ......................................................... 105
8.1 ADMINISTRATION ............................................................. 106
8.2 DEVICE ALERTS (ADVANCED MODE ONLY)............................. 114
8.3 SYSTEM CONTROL............................................................. 116
8.4 SYSTEM SOFTWARE ........................................................... 117
9GLOSSARY..................................................................... 118
10 APPENDIX ................................................................... 132
10.1 REGULATORY INFORMATION ............................................. 132

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 2
10.2 WARRANTY INFORMATION ............................................... 132
10.3 SPECIFICATIONS .............................................................. 133

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 3
1 INTRODUCTION
1.1 Package Contents
Wireless 4G/3G Router (MBR95)
AC power adapter (12V, 1.5A) WARNING: using a power adapter other than the one provided may damage the
MBR95 and will void the warranty
CAT5 Ethernet Cable (5 feet)
Setup Guide
1.2 System Requirements
Ethernet-based, Cable/DSL/Satellite modem; Broadband USB Data Modem with Active Subscription; and/or
WiFi as WAN.
Windows 2000/XP/7, Mac OS X, or Linux Computer with WiFi Adapter (802.11n Recommended)
Internet Explorer v6.0 or higher, Firefox v2.0 or higher, Safari v1.0 or higher.
1.3 MBR95 Overview
Create a WiFi hotspot anywhere you have broadband signal
Create secure instant networks anywhere you receive mobile broadband signal. The most powerful feature of the
MBR95 is its ability to use USB Mobile Broadband Data Modems to create instant secure networks, plus traditional
wired networking options like Cable, DSL, or Satellite.
HOW DOES IT WORK?
Connect this router to a 4G/3G MOBILE MODEM and get more from your data plan. Most WiFi enabled devices
don’t support USB 4G/3G Data Modems. When you connect the modem to the MBR95, you can securely share
your data plan with up to 32 people or devices.
Or, connect this router to your existing DSL / CABLE / SATELLITE MODEM and add 600 feet of WiFi to your
network.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 4
CradlePoint routers are built to work with most popular 4G/3G USB Modems from: AT&T, Bell Canada, Clearwire,
Cricket, Rogers, Sprint, T-Mobile, Telus, US Cellular, Verizon Wireless, & Virgin Mobile, as well as most Cable,
DSL, and Satellite providers.
ENHANCED WIFI
600+ feet of WiFi Range
Wireless “N” WiFi (802.11n, legacy 802.11b/g, 2x2 MIMO Internal Antenna system)
Enhanced performance around walls and other obstructions
Maximum security with both Private and Guest networks
ADDITIONAL FEATURES
2x2 MIMO Internal Antenna Subsystem, dual SSIDs
Plug-and-Play support for over 120 broadband data modems including LTE, WiMAX and HSPA+, allowing for
maximum flexibility
Simple to install, configure and maintain

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 5
2 HARDWAREOVERVIEW

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 6
2.1 Ports, Buttons, and Switches

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 7
2.2 LEDs
Power: The MBR95 must be powered using an approved 12V DC power source.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 8
Green = Powered on.
No Light = Not receiving power. Check that the unit is connected to an outlet.
Amber = Attention. Check router status page.
Active Ethernet Port Connections –1-4 LAN: Indicates a connected device on the 1-4 LAN ports on the MBR95.
Blue = Connected to an active 10/100 Ethernet interface.
Blinking Blue = Traffic.
No Light = Not connected, the connection is not configured correctly, the router is not configured correctly, or the
router may not be turned on.
WPS: WiFi Protected Setup. When you press the WPS button for five seconds, it allows you to use WPS for your WiFi
security.
Blinking Blue = WPS setting is in progress.
Solid Blue = WPS is active.
Wireless Broadcast: Indicates activity on the WiFi broadcast for the 2.4 GHz band.
Blue = 2.4 GHz WiFi is on and operating normally.
Red = Error with 2.4 GHz connection.
No Light = WiFi is off.
Cable, DSL, or Satellite Modem –WAN: Indicates information about a data source connected to the WAN Ethernet port
(blue port).
Blue = Connected to an active 10/100 Ethernet interface.
Blinking Blue = Traffic.
No Light = Not connected, the connection is not configured correctly, or the switch or router are not configured
correctly or turned on.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 9
Mobile Broadband Modem (USB) –WAN:Indicates the status of a USB modem connected to the MBR95.
Blue = Modem has established an active 4G connection.
Blinking Blue: Modem is connecting to 4G.
Green = Modem has established an active 3G connection.
Blinking Green = Modem is connecting to 3G.
Amber = Modem is not active.
Blinking Amber = Data connection error. No modem connection possible.
Blinking Red = Modem is in the process of resetting.
4G/3G Modem Signal Strength: Blue LED bars indicate the active modem’s signal strength. Press WPS button to turn
on/off.
4 Solid Bars = strongest signal
1 Blinking Bar = weakest signal

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 10
3 QUICKSTART
3.1 Basic Setup
1) Connect the Router to a Modem or Data Source: Your router requires an Internet source. Insert a supported USB
modem; connect a Cable, DSL, or Satellite modem to the Blue Ethernet WAN port; or connect to an available WiFi
source.
For Failover/Failback functionality, you will need at least two of these sources (for example: an Ethernet source and a
USB modem).1
2) Connect to a Power Source: Connect the 12v DC power adapter to the router and a power source. Flip the power
switch to the ON position; this should illuminate the green Power Status LED.
1Data Modem Not Included. This Product Requires an Activated Data Modem or Phone with Data Plan for Full Functionality. See your Cellular/3G/4G Service Provider for Details
on Coverage and Data Plan Options

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 11
3.2 Connect to a Computer or other Device
3.2.1 Wireless Network Connection
1) Find the network. On a WiFi-enabled computer or device,
open the window or dropdown menu that allows you to access
wireless networks. The MBR95 network will appear on the list:
select this network.
2) Log in. You will need to input the Default Password when
prompted. The Default Password is provided on the product
label found on the bottom of your router (this password is the
last eight digits of the router’s MAC address, which can be found
on the product box or on the product label).
NOTE: If more than one MBR95 wireless router is visible, you can find the correct unit by checking for its SSID (service set identifier; the unique
name of the local network). The SSID can be found on the bottom of the router in the form MBR95-xxx, where “xxx” is the last 3 digits of the
router’s MAC address.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 12
3.2.2 Accessing the Administration Pages
For most users, the MBR95 Router can be
used immediately without any special
configuration changes. If you would like to
change your network name or password or
configure any of the advanced features of the
MBR95, you will need to log in to the
administration pages:
Access your router’s Administrator
Login screen by opening a web
browser window and typing “cp/”(your
router’s default hostname) or the IP
address “192.168.0.1”into the address
bar.
Enter your Default Password. This
password can be found on the bottom of the MBR95. Then click the LOGIN button.
When you log in for the first time, you will be automatically directed to the First Time Setup Wizard. Follow the
instructions given with the Wizard or see Getting Started –First Time Setup for more information about using the
First Time Setup Wizard.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 13
3.2.3 Connect to the Internet
If you used the First Time Setup Wizard, you might have
changed the “WiFi Network Name” or the “Security Mode”
password. If so, you will need to reconnect to the MBR95
network.
Find the network. Look for your new personalized
network name (or the default SSID of the form “MBR95-
xxx”).
Log in using your new personalized WiFi security
password (or the Default Password found the bottom of
the router).
Your network should now be up and running, and users who
have the security password can access the network on WiFi-enabled devices.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 14
3.3 Common Problems
This section contains a list of some of the most common issues faced by users of the MBR95.
Please visit CradlePoint Knowledgebase at http://knowledgebase.cradlepoint.com/ for more help and answers to your
other questions.
3.3.1 Your USB Modem Does Not Work With the Router
If your USB data modem is not working with the router, check the list of supported devices at
http://www.cradlepoint.com/modems to ensure you are using a supported device and carrier. The device you are
using must be supported on the carrier network providing your cellular service or it’s considered an unsupported
device, even if it is supported on another carrier’s network.
Sometimes a USB data modem needs to be updated or have other configurations set correctly in order to make a
connection through the router. If your USB Modem has not been updated recently, it is recommended that you do
so if it is having trouble connecting to the MBR95. Insert your USB data modem into your PC and access the
Internet using the software provided by your cellular carrier. Follow the directions provided to complete the update.
Once you have updated your USB data modem, reconnect the cellular device to your CradlePoint router and
connect to the Internet.
If you are using a 4G WiMAX modem you need to set the WiMAX Realm. This can be done on the administration
pages. Log in using the hostname “cp/”or IP address “http://192.168.0.1”in your browser. On page 3 of the First
Time Setup Wizard (go to Getting Started → First Time Setup), you can set the WiMAX Realm. Be sure to click
Apply on page 4 to save the change.
Some wireless carriers provide more than one Access Point Name (APN) that a modem can connect to. If you wish
to specify the APN, this can be done on the administration pages. Log in using the hostname “cp/”or IP address
“http://192.168.0.1”in your browser. Go to Internet → Connection Manager. In the WAN Interfaces section,
select your modem and click “Edit.” Select the SIM/APN Settings tab. There is an Access Point Name field: Set
the APN and click Submit. Some APN examples are isp.cingular, ecp.tmobile.com, and vpn.com. The modem
must be removed and reinserted (or the router must be rebooted) for this change to take effect.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 15
If the above issues have been resolved and you can connect to the router but you cannot get Internet through it
using your modem, you may need to upgrade the router firmware. Use your computer (you may need to plug your
modem directly into your computer if you don’t have another way to access the Internet) to download the latest
firmware for the router (go to http://www.cradlepoint.com/support/mbr95 and scroll over firmware at the bottom of
the page). Then log in to the router administration pages and manually upload the firmware. Go to System
Settings → System Software and click on “Manual Firmware Upload”.
If you are still unable to access the Internet after following the above directions, contact CradlePoint Technical
Support for further assistance.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 16
3.3.2 You are Connected to the Router but Cannot Connect to the Internet
The status LEDs of your router will give you an indication whether or not a proper connection is being made. See the LED
STATUS definitions below:
If the USB data modem LEDs are not illuminated, your modem is not connected and online. You may need to update
firmware. Refer to the previous section, “Your USB Modem Does Not Work With The Router.”
If you are still not online after updating, call CradlePoint Technical Support for further assistance.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 17
3.3.3 Your MBR95 router gets an IP conflict when you plug it into your Cable or DSL modem.
If your Cable or DSL modem is not working with the router, check that there is not an IP conflict. Go to Internet →
Connection Manager and find the Ethernet connection under WAN Interfaces. If it says “IP conflict” you will need
to change the IP address of the MBR95 router from “192.168.0.1”. A suggested IP address is “192.168.10.1”.
Change the IP address by going to Network Settings→ WiFi / Local Networks. Find the IP address under “IP
Settings” and type the alternate IP address. Click Submit to save the settings.
NOTE: To access the router administration pages after changing the IP address you will need to go to the new IP address in your Internet browser
instead of “http://192.168.0.1”. You may continue to use “cp/” to access the router administration pages after this change.
If you are still unable to access the Internet after following the above directions, contact CradlePoint Technical Support for
further assistance.

CRADLEPOINT MBR95 | USER MANUAL Firmware ver. 3.6.3
© 2011CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 18
4 WEBINTERFACE-- ESSENTIALS
The MBR95 has a Web interface for configuration and administration of all features. The interface is organized with a
button for toggling between Basic Mode and Advanced Mode and 5 tabs at the top of the screen:
Getting Started
Status
Network Settings
Internet
System Settings
Click on any of the 5 tabs to open a dropdown menu with further options for the administration of the MBR95.
