Craftsman 919.72755 User manual

D23122 Rev.0 1/16/01
Owner’s Manual
CAUTION: Read the Safety Guidelines
and All Instructions Carefully Before
Operating.
Sold by Sears Canada, Inc., Toronto, Ont. M5B 2B8
Permanently Lubricated
Tank Mounted
AIR COMPRESSOR
• Safety Guidelines
• Assembly
• Operation
• Maintenance
• Service and Adjustments
• Troubleshooting
• Repair Parts
• Français
Model No.
919.727550

2 - ENGD23122
TABLE OF CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . .2
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SAFETY GUIDELINES . . . . . . . . . . . . . . . . . . .3-6
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . .7
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Contents of Carton . . . . . . . . . . . . . . . . . . . . .7
Tools Required for Assembly . . . . . . . . . . . . . .7
Assemble Rubber Feet . . . . . . . . . . . . . . . . . .7
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO SET UP YOUR UNIT . . . . . . . . . . . .8
Location of Air Compressor . . . . . . . . . . .8
Grounding Instructions . . . . . . . . . . . . . . .8
Extension Cords . . . . . . . . . . . . . . . . . . . .8
Voltage and Circuit Protection . . . . . . . . .8
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Know Your Air Compressor . . . . . . . . . . . . . . .9
Description of Operation . . . . . . . . . . . . . . . . .9
FULL ONE YEAR WARRANTY ON AIR COMPRESSORS
If this air compressor fails due to a defect in material or workmanship within one year from the date of purchase,
RETURN IT TO THE NEAREST SEARS SERVICE CENTER THROUGHOUT CANADA AND SEARS WILL REPAIR IT,
FREE OF CHARGE.
If this air compressor is used for commercial or rental purposes, the warranty will apply for ninety days (90) from the
date of purchase.
This Craftsman Air Compressor warranty gives you specific legal rights and you may have other rights which vary
from province to province.
Sears Canada, Inc., Toronto, Ont. M5B 2B8
How to Use Your Unit . . . . . . . . . . . . . . . . . .10
How to Stop . . . . . . . . . . . . . . . . . . . . . .10
Before Starting . . . . . . . . . . . . . . . . . . . .10
Before Each Start-up . . . . . . . . . . . . . . .10
How to Start . . . . . . . . . . . . . . . . . . . . . . . . .10
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . .11
Customer Responsiblilities . . . . . . . . . . . . . .11
To Check Saety Valve . . . . . . . . . . . . . . . . . .11
To Drain Tank . . . . . . . . . . . . . . . . . . . . . . . .11
SERVICE AND ADJUSTMENTS . . . . . . . . . . . . .12
To Repalce or Clean Check Valve . . . . . . . . .12
To Replace Regulator . . . . . . . . . . . . . . . . . .12 .
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
TROUBLESHOOTING GUIDE . . . . . . . . . . . .14-15
REPAIR PARTS . . . . . . . . . . . . . . . . . . . . . . .16-19
FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . . . .20-35
HOW TO ORDER REPAIR PARTS . . . .back cover
Model No. 919.727550
Max. Developed HP 2
Displacement CFM 4.8
Bore 1-7/8
Stroke 1-1/4
Voltage - Single Phase 120
Minimum Branch Circuit Requirement 15 amps
Fuse Type Time Delay
Air Tank/Capacity 4
Approximate Cut-in Pressure 100
Approximate Cut-out Pressure 125
SCFM @ 40 psi 3.7
SCFM @ 90 psi 2.6
SPECIFICATIONS
WARRANTY

3 - ENG D23122
SAFETY GUIDELINES - DEFINITIONS
Indicates an imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous sit-
uation which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
Used without the safety alert sym-
bol indicates a potentially haz-
ardous situation which, if not avoided, may result in
property damage.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY
AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUC-
TIONS BEFORE USING THIS EQUIPMENT.
RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN HOW TO PREVENT IT
SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols
below. Please read the manual and pay attention to these sections.
ALWAYS OPERATE THE COMPRESSOR IN A WELL VEN-
TILATED AREA FREE OF COMBUSTIBLE MATERIALS,
GASOLINE OR SOLVENT VAPORS.
IF SPRAYING FLAMMABLE MATERIALS, LOCATE COM-
PRESSOR AT LEAST 20 FEET AWAY FROM SPRAY
AREA. AN ADDITIONAL LENGTH OF HOSE MAY BE
REQUIRED.
STORE FLAMMABLE MATERIALS IN A SECURE LOCA-
TION AWAY FROM COMPRESSOR.
NEVER PLACE OBJECTS AGAINST OR ON TOP OF
COMPRESSOR. OPERATE COMPRESSOR IN AN OPEN
AREA AT LEAST 12 INCHES AWAY FROM ANY WALL
OR OBSTRUCTION THAT WOULD RESTRICT THE FLOW
OF FRESH AIR TO THE VENTILATION OPENINGS.
OPERATE COMPRESSOR IN A CLEAN, DRY, WELL VENTI-
LATED AREA. DO NOT OPERATE UNIT INDOORS OR IN
ANY CONFINED AREA.
ALWAYS REMAIN IN ATTENDANCE WITH THE PROD-
UCT WHEN IT IS OPERATING.
ALWAYS DISCONNECT ELECTRICAL POWER BY MOV-
ING PRESSURE SWITCH LEVER TO THE OFF POSITION
AND DRAIN TANK DAILY OR AFTER EACH USE.
IT IS NORMAL FOR ELECTRICAL CONTACTS WITHIN
THE MOTOR AND PRESSURE SWITCH TO SPARK.
IF ELECTRICAL SPARKS FROM COMPRESSOR COME
INTO CONTACT WITH FLAMMABLE VAPORS, THEY
MAY IGNITE, CAUSING FIRE OR EXPLOSION.
RESTRICTING ANY OF THE COMPRESSOR VENTILA-
TION OPENINGS WILL CAUSE SERIOUS OVERHEATING
AND COULD CAUSE FIRE.
UNATTENDED OPERATION OF THIS PRODUCT COULD
RESULT IN PERSONAL INJURY OR PROPERTY DAM-
AGE. TO REDUCE THE RISK OF FIRE, DO NOT ALLOW
THE COMPRESSOR TO OPERATE UNATTENDED.

4 - ENGD23122
HAZARD
RISK OF BURSTING
DRAIN TANK DAILY OR AFTER EACH USE. IF TANK
DEVELOPS A LEAK, REPLACE IT IMMEDIATELY WITH A
NEW TANK OR REPLACE THE ENTIRE COMPRESSOR.
NEVER DRILL INTO, WELD, OR MAKE ANY MODIFICA-
TIONS TO THE TANK OR ITS ATTACHMENTS.
THE TANK IS DESIGNED TO WITHSTAND SPECIFIC OPER-
ATING PRESSURES. NEVER MAKE ADJUSTMENTS OR
PARTS SUBSTITUTIONS TO ALTER THE FACTORY SET
OPERATING PRESSURES.
FOR ESSENTIAL CONTROL OF AIR PRESSURE,YOU
MUST INSTALL A PRESSURE REGULATOR AND PRES-
SURE GAUGE TO THE AIR OUTLET (IF NOT EQUIPPED)
OF YOUR COMPRESSOR. FOLLOW THE EQUIPMENT
MANUFACTURERS RECOMMENDATION AND NEVER
EXCEED THE MAXIMUM ALLOWABLE PRESSURE RATING
OF ATTACHMENTS. NEVER USE COMPRESSOR TO
INFLATE SMALL LOW-PRESSURE OBJECTS SUCH AS
CHILDREN’S TOYS, FOOTBALLS, BASKETBALLS, ETC.
1. FAILURE TO PROPERLY DRAIN CONDENSED
WATER FROM THE TANK, CAUSING RUST AND
THINNING OF THE STEEL TANK.
2. MODIFICATIONS OR ATTEMPTED REPAIRS TO THE
TANK.
3. UNAUTHORIZED MODIFICATIONS TO THE
UNLOADER VALVE, SAFETY VALVE, OR ANY
OTHER COMPONENTS WHICH CONTROL TANK
PRESSURE.
4. EXCESSIVE VIBRATION CAN WEAKEN THE AIR
TANK AND CAUSE RUPTURE OR EXPLOSION.
ATTACHMENTS & ACCESSORIES:
EXCEEDING THE PRESSURE RATING OF AIR TOOLS,
SPRAY GUNS, AIR OPERATED ACCESSORIES, TIRES AND
OTHER INFLATABLES CAN CAUSE THEM TO EXPLODE
OR FLY APART, AND COULD RESULT IN SERIOUS INJURY.
WHAT CAN HAPPEN HOW TO PREVENT IT
AIR TANK: THE FOLLOWING CONDITIONS COULD LEAD TO A WEAKENING OF THE TANK, AND
RESULT IN A VIOLENT TANK EXPLOSION AND COULD CAUSE PROPERTY DAMAGE OR SERIOUS
INJURY.
RISK FROM FLYING OBJECTS
WHAT CAN HAPPEN HOW TO PREVENT IT
THE COMPRESSED AIR STREAM CAN CAUSE SOFT TIS-
SUE DAMAGE TO EXPOSED SKIN AND CAN PROPEL
DIRT, CHIPS, LOOSE PARTICLES AND SMALL OBJECTS
AT HIGH SPEED, RESULTING IN PROPERTY DAMAGE OR
PERSONAL INJURY.
ALWAYS WEAR ANSI Z87.1 APPROVED SAFETY GLASS-
ES WITH SIDE SHIELDS WHEN USING THE COMPRES-
SOR.
NEVER POINT ANY NOZZLE OR SPRAYER TOWARD
ANY PART OF THE BODY OR AT OTHER PEOPLE OR
ANIMALS.
ALWAYS TURN THE COMPRESSOR OFF AND BLEED
PRESSURE FROM THE AIR HOSE AND TANK BEFORE
ATTEMPTING MAINTENANCE, ATTACHING TOOLS OR
ACCESSORIES.

5 - ENG D23122
HAZARD
RISK TO BREATHING
AIR OBTAINED DIRECTLY FROM THE COMPRESSOR
SHOULD NEVER BE USED TO SUPPLY AIR FOR HUMAN
CONSUMPTION. IN ORDER TO USE AIR PRODUCED BY
THIS COMPRESSOR FOR BREATHING, SUITABLE FIL-
TERS AND IN-LINE SAFETY EQUIPMENT MUST BE
PROPERLY INSTALLED. IN-LINE FILTERS AND SAFETY
EQUIPMENT USED IN CONJUNCTION WITH THE COM-
PRESSOR MUST BE CAPABLE OF TREATING AIR TO ALL
APPLICABLE LOCAL AND FEDERAL CODES PRIOR TO
HUMAN CONSUMPTION.
WORK IN AN AREA WITH GOOD CROSS-VENTILATION.
READ AND FOLLOW THE SAFETY INSTRUCTIONS PRO-
VIDED ON THE LABEL OR SAFETY DATA SHEETS FOR
THE MATERIAL YOU ARE SPRAYING. USE A
NIOSH/MSHA APPROVED RESPIRATOR DESIGNED FOR
USE WITH YOUR SPECIFIC APPLICATION.
THE COMPRESSED AIR DIRECTLY FROM YOUR COM-
PRESSOR IS NOT SAFE FOR BREATHING. THE AIR
STREAM MAY CONTAIN CARBON MONOXIDE, TOXIC
VAPORS, OR SOLID PARTICLES FROM THE TANK.
BREATHING THESE CONTAMINANTS CAN CAUSE
SERIOUS INJURY OR DEATH.
SPRAYED MATERIALS SUCH AS PAINT, PAINT SOL-
VENTS, PAINT REMOVER, INSECTICIDES, WEED
KILLERS, CONTAIN HARMFUL VAPORS AND POISONS.
WHAT CAN HAPPEN HOW TO PREVENT IT
RISK OF ELECTRICAL SHOCK
NEVER OPERATE THE COMPRESSOR OUTDOORS WHEN
IT IS RAINING OR IN WET CONDITIONS.
NEVER OPERATE COMPRESSOR WITH PROTECTIVE
COVERS REMOVED OR DAMAGED.
ANY ELECTRICAL WIRING OR REPAIRS REQUIRED ON
THIS PRODUCT SHOULD BE PERFORMED BY AUTHO-
RIZED SERVICE CENTER PERSONNEL IN ACCORDANCE
WITH NATIONAL AND LOCAL ELECTRICAL CODES.
MAKE CERTAIN THAT THE ELECTRICAL CIRCUIT TO
WHICH THE COMPRESSOR IS CONNECTED PROVIDES
PROPER ELECTRICAL GROUNDING, CORRECT VOLT-
AGE AND ADEQUATE FUSE PROTECTION.
YOUR AIR COMPRESSOR IS POWERED BY ELECTRICI-
TY. LIKE ANY OTHER ELECTRICALLY POWERED DEVICE,
IF IT IS NOT USED PROPERLY IT MAY CAUSE ELECTRIC
SHOCK.
REPAIRS ATTEMPTED BY UNQUALIFIED PERSONNEL
CAN RESULT IN SERIOUS INJURY OR DEATH BY ELEC-
TROCUTION.
ELECTRICAL GROUNDING: FAILURE TO PROVIDE ADE-
QUATE GROUNDING TO THIS PRODUCT COULD
RESULT IN SERIOUS INJURY OR DEATH FROM ELEC-
TROCUTION. SEE GROUNDING INSTRUCTIONS.
WHAT CAN HAPPEN HOW TO PREVENT IT

6 - ENGD23122
HAZARD
RISK FROM MOVING PARTS
NEVER OPERATE THE COMPRESSOR WITH GUARDS
OR COVERS WHICH ARE DAMAGED OR REMOVED.
ANY REPAIRS REQUIRED ON THIS PRODUCT SHOULD
BE PERFORMED BY AUTHORIZED SERVICE CENTER
PERSONNEL.
MOVING PARTS SUCH AS THE PULLEY, FLYWHEEL AND
BELT CAN CAUSE SERIOUS INJURY IF THEY COME
INTO CONTACT WITH YOU OR YOUR CLOTHING.
ATTEMPTING TO OPERATE COMPRESSOR WITH DAM-
AGED OR MISSING PARTS OR ATTEMPTING TO REPAIR
COMPRESSOR WITH PROTECTIVE SHROUDS REMOVED
CAN EXPOSE YOU TO MOVING PARTS AND CAN
RESULT IN SERIOUS INJURY.
WHAT CAN HAPPEN HOW TO PREVENT IT
RISK OF FALLING
WHAT CAN HAPPEN HOW TO PREVENT IT
A PORTABLE COMPRESSOR CAN FALL FROM A TABLE,
WORKBENCH OR ROOF CAUSING DAMAGE TO THE
COMPRESSOR AND COULD RESULT IN SERIOUS
INJURY OR DEATH TO THE OPERATOR.
ALWAYS OPERATE COMPRESSOR IN A STABLE
SECURE POSITION TO PREVENT ACCIDENTAL MOVE-
MENT OF THE UNIT. NEVER OPERATE COMPRESSOR
ON A ROOF OR OTHER ELEVATED POSITION. USE
ADDITIONAL AIR HOSE TO REACH HIGH LOCATIONS.
RISK OF PROPERTY DAMAGE WHEN TRANSPORTING
COMPRESSOR
WHAT CAN HAPPEN HOW TO PREVENT IT
OIL CAN LEAK OR SPILL AND COULD RESULT IN FIRE
OR BREATHING HAZARD, SERIOUS INJURY OR DEATH
CAN RESULT. OIL LEAKS WILL DAMAGE CARPET, PAINT
OR OTHER SURFACES IN VEHICLES OR TRAILERS.
ALWAYS PLACE COMPRESSOR ON A PROTECTIVE MAT
WHEN TRANSPORTING TO PROTECT AGAINST DAMAGE
TO VEHICLE FROM LEAKS. REMOVE COMPRESSOR
FROM VEHICLE IMMEDIATELY UPON ARRIVAL AT YOUR
DESTINATION.
(Fire, Inhalation, Damage to Vehicle Surfaces)
RISK OF BURNS
WHAT CAN HAPPEN HOW TO PREVENT IT
TOUCHING EXPOSED METAL SUCH AS THE COMPRES-
SOR HEAD OR OUTLET TUBES, CAN RESULT IN
SERIOUS BURNS.
NEVER TOUCH ANY EXPOSED METAL PARTS ON
COMPRESSOR DURING OR IMMEDIATELY AFTER OPER-
ATION. COMPRESSOR WILL REMAIN HOT FOR SEVERAL
MINUTES AFTER OPERATION.
DO NOT REACH AROUND PROTECTIVE SHROUDS OR
ATTEMPT MAINTENANCE UNTIL UNIT HAS BEEN
ALLOWED TO COOL.
For units requiring oil in pump or gasoline engines

7 - ENG D23122
ASSEMBLY
Contents of Carton
1 - Air Compressor
4 - Rubber Feet
1 - 3/8” x 25’ Hose
1 - Brad Nailer
2 - 1/4” Quick Connect Body
2 - 1/4’ Quick Connect Plug
1 - Roll of Teflon Tape
Tools Required for Assembly
1 - 3/8” socket or nut driver
Assemble Rubber Feet
1. Carefully place unit on side opposite of controls.
Leg
Rubber Foot
Screw
GLOSSARY
Become familiar with these terms before operating the
unit.
CFM: Cubic feet per minute.
SCFM: Standard cubic feet per minute; a unit of
measure of air delivery.
PSIG: Pounds per square inch gauge; a unit of meas-
ure of pressure.
Code Certification: Products that bear one or more
of the following marks: UL, CUL, ETL, CETL, have
been evaluated by OSHA certified independent safety
laboratories and meet the applicable Underwriters
Laboratories Standards for Safety.
Cut-In Pressure: While the motor is off, air tank
pressure drops as you continue to use your accesso-
ry. When the tank pressure drops to a certain low
level the motor will restart automatically. The low
pressure at which the motor automatically restarts is
called “cut-in” pressure.
Cut-Out Pressure: When an air compressor is
turned on and begins to run, air pressure in the air
tank begins to build. It builds to a certain high pres-
sure before the motor automatically shuts off - pro-
tecting your air tank from pressure higher than its
capacity. The high pressure at which the motor shuts
off is called “cut-out” pressure.
Branch Circuit: Circuit carrying electricity from elec-
trical panel to outlet.
ACCESSORIES
Accessories
• In Line Filter
• Tire Air Chuck
• Quick Connector Sets
(various sizes)
• Air Pressure Regulators
• Oil Fog Lubricators
• Air Hose:
1/4", 5/16" OR 3/8" I.D.
in various lengths
Specialty Tools
• Air Brush
• Inflating/Blow Gun
• Grease Gun
• Caulk Gun
• Engine Cleaner
Carpentry Tools
• Finishing Nailer / Stapler
• Construction Nailer / Stapler
Socket Driving
• 3/8" Impact/Butterfly Wrench
• 3/8" Ratchet
• 1/4" Ratchet
Material Shaping
• 2.625" Hammer
• 1.625" Hammer
• Reciprocating Saw
• Nibbler
Spray Painting
• Multi-Purpose Spray Gun
• Automotive Spray Gun
This unit is capable of powering the following Accessories. The accessories are available through the current
Power and Hand Tool Catalog or full-line Sears stores.
2. Using a 3/8 inch socket or nut driver remove the
screws attaching the unit to the shipping pallet.
NOTE: These screws will be used to install the rub-
ber feet.
3. Attach the four rubber feet to the unit’s legs using
the four screws removed in step 2.
NOTE: Flat side of rubber feet goes against unit legs.

8 - ENGD23122
4. If these grounding instructions are not completely
understood, or if in doubt as to whether the com-
pressor is properly grounded, have the installation
checked by a qualified electrician.
IMPROPER GROUNDING
CAN RESULT IN ELEC-
TRICAL SHOCK.
Do not modify the plug provided. If it does
not fit the available outlet, a correct outlet
should be installed by a qualified electri-
cian.
Repairs to the cord set or plug MUST be
made by a qualified electrician.
Extension Cords
Use extra air hose instead of an extension cord to
avoid voltage drop and power loss to the motor, and
to prevent overheating.
If an extension cord must be used, be sure it is:
• a 3-wire extension cord that has a 3-blade
grounding plug, and a 3-slot receptacle that will
accept the plug on the product
• in good condition
• no longer than 50 feet
• 12 gauge (AWG) or larger. (Wire size increases as
gauge number decreases. 10 AWG and 8 AWG
may also be used. DO NOT USE 14 OR 16
AWG.)
Grounding Pin
Grounded
Outlets
Plug
Voltage and Circuit Protection
Refer to the Specification section for the voltage and
minimum branch circuit requirements.
Certain air compressors can be operated on a 15 amp
circuit if the following conditions are met.
1. Voltage supply through branch circuit is 15 amps.
2. Circuit is not used to supply any other electrical
needs (lights, appliances, etc.).
3. Extension cords comply with specifications.
4. Circuit is equipped with a 15 amp circuit breaker
or 15 amp time delay fuse. NOTE: If compressor
is connected to a circuit protected by fuses, use
only time delay fuses marked “D”.
If any of the above conditions cannot be met, or if
operation of the compressor repeatedly causes inter-
ruption of the power, it may be necessary to operate it
from a 20 amp circuit. It is not necessary to change
the cord set.
INSTALLATION
Location of the Air Compressor
Locate the air compressor in a clean, dry and well
ventilated area. The air compressor should be located
at least 12" away from the wall or other obstructions
that will interfere with the flow of air. The air compres-
sor pump and shroud are designed to allow for proper
cooling. The ventilation openings on the compressor
are necessary to maintain proper operating tempera-
ture. Do not place rags or other containers on or near
these openings.
HOW TO SET UP YOUR UNIT
GROUNDING INSTRUCTIONS
RISK OF ELECTRICAL
SHOCK. In the event of a
short circuit, grounding reduces the risk of
shock by providing an escape wire for the
electric current. This air compressor must be
properly grounded.
The portable air compressor is equipped with a cord
having a grounding wire with an appropriate ground-
ing plug (see following illustrations). The plug must be
used with an outlet that has been installed and
grounded in accordance with all local codes and ordi-
nances.
1. The cord set and plug with this unit contains a
grounding pin. This plug MUST be used with a
grounded outlet.
IMPORTANT: The outlet being used must be installed
and grounded in accordance with all local codes and
ordinances.
2. Make sure the outlet being used has the same
configuration as the grounded plug. DO NOT USE
AN ADAPTER. See illustration.
3. Inspect the plug and cord before each use. Do
not use if there are signs of damage.

9 - ENG D23122
OPERATION
Description of Operation
Become familiar with these controls before operating
the unit.
On/Auto/Off Switch: Turn this switch ON to provide
automatic power to the pressure switch and OFF to
remove power at the end of each use.
Pressure Switch: The pressure switch automatically
starts the motor when the air tank pressure drops
below the factory set “cut-in” pressure. It stops the
motor when the air tank pressure reaches the factory
set “cut-out” pressure.
Safety Valve: If the pressure switch does not shut off
the air compressor at its “cut-out” pressure setting,
the safety valve will protect against high pressure by
“popping out” at its factory set pressure (slightly high-
er than the pressure switch “cut-out” setting).
Outlet Pressure Gauge: The outlet pressure gauge
indicates the air pressure available at the outlet side
of the regulator. This pressure is controlled by the reg-
ulator and is always less than or equal to the tank
pressure.
Tank Pressure Gauge: The tank pressure gauge
indicates the reserve air pressure in the tank.
Regulator: Controls the air pressure shown on the
outlet pressure gauge. Pull the knob out and turn
clockwise to increase pressure and counterclockwise
to decrease pressure. When the desired pressure is
reached push knob in to lock in place.
Drain Valve: The drain
valve is located at the
base of the air tank and is
used to drain condensa-
tion at the end of each
use.
Cooling System (not shown): This compressor con-
tains an advanced design cooling system. At the heart
of this cooling system is an engineered fan. It is per-
fectly normal for this fan to blow air through the vent
holes in large amounts. You know that the cooling
system is working when air is being expelled.
Air Compressor Pump (not shown): Compresses air
into the air tank. Working air is not available until the
compressor has raised the air tank pressure above
that required at the air outlet.
Check Valve: When the
air compressor is operat-
ing, the check valve is
“open”, allowing com-
pressed air to enter the air
tank. When the air com-
pressor reaches “cut-out”
pressure, the check valve “closes”, allowing air pres-
sure to remain inside the air tank.
Know Your Air Compressor
READ THIS OWNER’S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustra-
tions with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual
for future reference.
Drain
Valve
Outlet
Pressure Gauge
Safety Valve
Pressure
Switch
Regulator
Tank
Pressure Gauge
On/Auto/Off
Switch
Check Valve

10 - ENGD23122
How to Start:
1. Turn the On/Auto/Off lever to “AUTO” and allow
tank pressure to build. Motor will stop when tank
pressure reaches “cut-out” pressure.
2. Pull the regulator knob out and turn clockwise to
increase pressure. When the desired pressure is
reached push knob in to lock in place. The com-
pressor is ready for use.
NOTE: Always operate the air compressor in well-
ventilated areas free of gasoline or other combustible
vapors. If the compressor is being used to operate a
sprayer DO NOT place near the spray area.
Before Starting
Break-in Procedure
Serious damage may result if the
following break-in instructions are
not closely followed.
This procedure is required before the air compressor
is put into service and when the check valve or a
complete compressor pump has been replaced.
1. Make sure the On/Auto/Off lever is in the "OFF"
position.
2.
Plug the power cord into the correct branch circuit
receptacle.
(Refer to Voltage and Circuit
Protection paragraph in the Installation section of
this manual.)
3. Open the drain valve fully (counter-clockwise) to
permit air to escape and prevent air pressure
build up in the air tank during the break-in period.
Regulator
On/Auto/
Off Lever
Drain Valve
How to Use Your Unit
How to Stop:
1. Set the On/Auto/Off lever to “OFF”.
Before Each Start-Up:
1. Place On/Auto/Off lever to “OFF” and close air
regulator.
2. Pull regulator knob out, turn counter-clockwise
until it stops. Push knob in to lock in place.
3. Attach hose and accessories. NOTE: The hose or
accessory will require a quick connect plug if the
air outlet is equipped with a quick connect sock-
et.
Too much air pressure
causes a hazardous risk of
bursting. Check the manufacturer’s maximum
pressure rating for air tools and accessories.
The regulator outlet pressure must never
exceed the maximum pressure rating.
4. Move the On/Auto/Off lever to "ON/AUTO" posi-
tion. The compressor will start.
5. Run the compressor for 15 minutes. Make sure
the drain valve is open and there is minimal air
pressure build-up in tank.
6. After 15 minutes, move the On/Auto/Off lever to
"OFF" position and close the drain valve (clock-
wise).
7. Move the On/Auto/Off lever to "ON/AUTO" posi-
tion. The air receiver will fill to “cut-out” pressure
and the motor will stop.
The compressor is now ready for use.

11 - ENG D23122
3. Remove the air tool or accessory.
4. Pull ring on safety valve allowing air to bleed from
the tank until tank pressure is approximately 20
psi. Release safety valve ring.
5. Drain water from air tank by opening drain valve
(counter-clockwise) on bottom of tank.
Water will condense in the
air tank. If not drained,
water will corrode and weaken the air tank
causing a risk of air tank rupture.
6. After the water has been drained, close the drain
valve (clockwise). The air compressor can now
be stored.
NOTE: If drain valve is plugged, release all air pressure.
The valve can then be removed, cleaned, then rein-
stalled.
MAINTENANCE
Customer Responsibilities
Daily or after
each use
Before each use
Check Safety Valve ●
Drain Tank ●
To Check Safety Valve
If the safety valve does
not work properly, over-
pressurization may occur, causing air tank
rupture or an explosion. Before starting com-
pressor, pull the ring on the safety valve to
make sure that the safety valve operates
freely. If the valve is stuck or does not operate
smoothly, it must be replaced with the same
type of valve.
To Drain Tank
1. Set the On/Auto/Off lever to “OFF”.
2. Pull the regulator knob out and turn clockwise to
set the outlet pressure to zero.
On/Auto/Off
Lever
Safety Valve Ring
Regulator
Drain Valve

12 - ENGD23122
SERVICE AND ADJUSTMENTS
Unit cycles automatically when power is on. When doing Maintenance, you may be exposed
to voltage sources, compressed air or moving parts. Personal injuries can occur. Before per-
forming any Maintenance or repair, unplug the compressor and bleed off all air pressure.
ALL MAINTENANCE AND REPAIR OPERATIONS NOT LISTED MUST BE PERFORMED BY
TRAINED SERVICE TECHNICIAN.
To Replace or Clean Check Valve
1. Release all air pressure from air tank. See “To
Drain Tank” in the Maintenance section.
2. Unplug outfit.
3. Remove the hose by removing the hose clamp.
NOTE: The hose clamp is not reusable. You must pur-
chase a new hose clamp, see the Parts List Manual or
purchase a standard hose clamp at a local hardware
store.
4. Unscrew the check valve (turn counter-clockwise)
using a socket wrench.
5. Make sure the valve disc moves freely inside the
check valve and the spring holds the disc in the
upper, closed position. The check valve may be
cleaned with a solvent, such as paint and varnish
remover.
6. Apply sealant to the check valve threads. Reinstall
the check valve (turn clockwise).
7. Replace hose and new hose clamp.
8. Perform the Break-in Procedure. See “Break-in
Procedure” in the Operation section.
Check
Valve
Hose Clamp
To Replace Regulator
1. Release all air pressure from air tank. See “To
Drain Tank” in the Maintenance section.
2. Unplug outfit.
3. Using an adjustable wrench remove the outlet
pressure gauge and hose adapter from the regula-
tor.
4. Remove the regulator.
5. Apply pipe sealant tape to the nipple on the
standpipe.
6. Assemble the regulator and orient as shown.
NOTE: Arrow indicates flow of air. Make sure it is
pointing in the direction of air flow.
7. Reapply pipe sealant to outlet pressure gauge
and hose adapter.
8. Reassemble outlet pressure gauge and hose
adapter. Orient outlet pressure gauge to read cor-
rectly. Tighten securely.
Regulator
Arrow
Before servicing:
Unplug or disconnect electrical supply to the
air compressor.
Bleed tank of pressure
Allow the air compressor to cool.
Nipple
Regulator
Outlet
Pressure
Gauge
Hose
Adapter
Regulator

13 - ENG D23122
STORAGE
Before you store the air compressor, make sure you
do the following:
1. Review the "Maintenance" section on the preced-
ing pages and perform scheduled maintenance as
necessary.
2. Set the On/Auto/Off lever to “OFF”.
3. Turn the regulator counterclockwise and set the
outlet pressure to zero.
4. Remove the air tool or accessory.
5. Pull ring on safety valve allowing air to bleed from
the tank until tank pressure is approximately 20
psi. Release safety valve ring.
6. Drain water from air tank by opening drain valve
on bottom of tank.
Water will condense in the
air tank. If not drained,
water will corrode and weaken the air tank
causing a risk of air tank rupture.
7. After the water has been drained, close the drain
or drain valve.
NOTE: If drain valve is plugged, release all air pres-
sure. The valve can then e removed, cleaned, then
reinstalled.
8. Protect the electrical cord and air hose from dam-
age (such as being stepped on or run over). Wind
them loosely around the compressor handle. (If so
equipped)
Store the air compressor in a clean and dry location.

14 - ENGD23122
TROUBLESHOOTING
Performing repairs may expose voltage sources, moving parts or compressed air sources,
moving parts or compressd air sources. Personal injury may occur. Prior to attempting any
repairs, unplug the air compressor and bleed off all air tank air pressure.
PROBLEM CAUSE CORRECTION
Pressure switch does not shut off
motor when compressor reaches
“cut-out” pressure.
Pressure switch “cut-out” too
high.
Move On/Auto/Off lever to the
“OFF” position, if the outfit does
not shut off contact a Trained
Service Technician.
Contact a Trained Service
Technician.
Excessive tank pressure - safety
valve pops off.
Tube fittings are not tight enough. Tighten fittings where air can be
heard escaping. Check fittings
with soapy water solution. DO
NOT OVERTIGHTEN.
Air leaks at fittings.
Air leaks at pressure switch
release valve.
Defective pressure switch release
valve.
Contact a Trained Service
Technician.
Air leaks in air tank or at air tank
welds.
Defective air tank. Air tank must be replaced. Do not
repair the leak.
Do not drill into, weld or otherwise
modify air tank or it will weaken.
The tank can rupture or explode.
Air leaks between head and valve
plate.
Leaking seal. Contact a Trained Service
Technician.
Pressure reading on the regulated
pressure gauge drops when an
accessory is used.
It is normal for “some” pressure
drop to occur.
If there is an excessive amount of
pressure drop when the accessory
is used, adjust the regulator follow-
ing the instructions on page 6.
NOTE: Adjust the regulated pres-
sure under flow conditions (while
accesory is being used).
Possible defect in safety valve. Operate safety valve manually by
pulling on ring. If valve still leaks,
it should be replaced.
Air leak from safety valve.

15 - ENG D23122
PROBLEM CAUSE CORRECTION
Defective check valve. Remove and clean, or replace.Knocking Noise.
Compressor is not supplying
enough air to operate accessories.
Prolonged excessive use of air.
Compressor is not large enough
for air requirement.
Hole in hose.
Check valve restricted.
Air leaks.
Decrease amount of air usage.
Check the accessory air require-
ment. If it is higher than the
SCFM or pressure supplied by
your air compressor, you need a
larger compressor.
Check and replace if required.
Remove and clean, or replace.
Tighten fittings.
Motor will not run. Fuse blown, circuit breaker
tripped.
Extension cord is wrong length or
gauge.
Loose electrical connections.
Faulty motor.
Check fuse box for blown fuse
and replace as necessary.
Reset circuit breaker. Do not use a
fuse or circuit breaker with higher
rating than that specified for your
particular branch circuit.
Check for proper fuse. You should
use a time delay fuse.
Check for low voltage problem.
Check the extension cord.
Disconnect the other electrical
appliances from circuit or
operate the compressor on its
own branch circuit.
Check the extension cord.
Check wiring connection inside
terminal box.
Have checked by a Trained
Service Technician.
Damaged regulator ReplaceRegulator knob has continuous air
leak.
Regulator will not shut off air out-
let.
Damaged regulator Replace

16 - ENGD23122
COMPRESSOR PARTS DIAGRAM/
DIAGRAMME DU COMPRESSEUR D’AIR
19
16
18
17
15 14
13
5
12 11
10
21
9
8
7
6
1
4
3
2
20

17 - ENG D23122
D23122
PARTS LIST/LISTE DES PIÈCES
Key No. Part No.
Cle No: Piéce No. Description/Description
1 Z-TA-4428-1 Air Receiver Réservoir d’air
2 AC-0430 Drain Valve Robinet de vidange
* 3 SSF-607 Screw (4 used - torque 10-20 in. lbs.) Vis (2 requises- torque 10-20 in. lbs.)
* 4 SST-5314-1 Recess Rubber Bumper (4 used) Recess Bumper (4 used)
* 5 CAC-1254 Pump Isolator (4 used) Isolateurs (4 requis)
6 SSP-480 Nipple, 1/4-18 NPT x 2.50 Mammelon ¼- 18 NPT x 2.50
7 SSW-7480 Bushing, Strain Relief Coussinet
8 TIA-4150 Safety Valve Soupape de sûreté
9 CAC-4296-1 Regulator Régulateur
10 H-2099 Adapter, 1/4 NPT x 1/4 NPSM Adaptateur, 1/4 NPT x 1/4 NPSM
11 Z-GA-369 Gauge, Regulated Pressure Manomètre, Régulateur
12 SS-1286 Nipple Close 1/4-18 NPT Mammelon ¼- 18 NPT
13 Z-GA-370 Gauge, Tank Pressure Manomètre, Réservoir d’air
14 SSW-7367 Bushing, Stain Relief Coussinet
15 Z-D22857 Pressure Switch Manostat
16 SSP-537 Fitting, 90ºElbow Hose Barb Acople arponado
17 AC-0547 Check Valve Soupape de retenue
18 CAC-1206-1 Hose Clamp Pince
* 19 SSF-621 Screw,1/4-14 x.625 Phillips Drive (2 used) Vis, 7/4-14 x.625 (2 requises)
20 LA-3092-1 Drain Tank Label Étiquette de vidange du réservoir

18 - ENGD23122D23122
PUMP DIAGRAM/
DIAGRAMME DE LA POMPE DU COMPRESSEUR
17
12
2
16
22
35
73
32
10
11
26
698
5
1
4
23
28
15

19 - ENG D23122
D23122
PARTS LIST/LISTE DES PIÈCES
NOT ILLUSTRATED/NON ILLUSTRÉ
D20363 Label Billboard Étiquette pour tableau d’affichage
LA-3157 Label Pressure Guide Étiquette guide de pression
* K-0387 Isolator Kit includes
* K-0387 Trousse d’isolateur
x KK-4929 Fastener Kit
x KK-4929 Trousse de fixations
●KK-4964 Connecting Rod Kit
●KK-4964 Trousse de la bielle de connexion
Key No. Part No.
Cle No: Piéce No. Description Description
1 CAC-1320 Shroud (right) Boîtier (droit)
2 D22008 Shroud (left) Boîtier (gauche)
3 AC-0187-1 Outlet Tube Tube de sortie
4 CAC-1196 Cylinder Head Tête de cylindre
* 5 CAC-1199 Head Gasket Garniture de tête
●6 ----------- Cylinder Sleeve Chemise de cylindre
7 CAC-1206-1 Hose Clamp Pince
8 CAC-4323 Valve Plate Assembly Montage de la plaque de la soupape
* 9 SSG-8169 "O" Ring Joint torique
x 10 SSF-3147 Screw 3/8-16 UNC THD hex socket Vis àtête plate et creuse àsix pans
3/8 –16 x 1.25
●11 ----------- Rod Assembly Assemblage de la bielle
12 CAC-1342 Timing Belt Courroie d’ajustement
15 CAC-4130-2 Endbell Assembly Assemblage àextrémitésphérique
x 16 SUDL-9-1 Screw 8 - 32 x .375/.344 Vis, de terre
17 CAC-1283 Switch Cover Commutateur cover
* 22 CAC-1213 Pump Isolator (5 used) Isolateur de pompe (5 requises)
x 23 SSF-995 Screw #10-24 x 7/8 Vis taraudeuse àgrosse
Hex Washer HD (4 used) tête àsix pans no (4 requises)
x 26 SSF-3156 Screws 10 -9 x .50 Plastite THD (5 used) Vis pour le boîtier (5 requises)
28 AC-0534-1 Power Cord Assembly Câblage
* 32 CAC-1212 Tube Seal Joint d’étanchéitédu boyau
35 H-7051 Hose Tuyau

20 - FRD23122
TABLE DES MATIÈRES
TABLEAU DES SPECIFICATIONS . . . . . . . . . . . . . . .20
GARANTIE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
MESURES DE SÉCURITÉ IMPORTANTES . . . . . .21-24
LEXIQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
ACCESSOIRES . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
ASSEMLAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Contenu de l’emballage en carton . . . . . . . . . . . . .25
Outils requis pour l’assemblage . . . . . . . . . . . . . .25
Assemblage des pattes en caoutchouc . . . . . . . . .25
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
MONTAGE DE L’APPAREIL . . . . . . . . . . . . . . . . . .26
Emplacement du compresseur d’air . . . . . . . .26
Directives de mise àla terre . . . . . . . . . . . . . .26
Rallonges . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Protection contre la surtension et
protection du circuit . . . . . . . . . . . . . . . . . . . .26
UTILISATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27-28
Familiarisez-vous avec votre compresseur d’air . . .27
GARANTIE COMPLÈTE D'UN AN SUR LES COMPRESSEURS D'AIR SEARS
Si ce compresseur fait défaut, au cours de l'année suivant la date d’achat, pour cause de défaut de matériau ou
main-d’oeuvre, le retourner àl’un des magasins Sears le plus proche qui le réparera gratuitement.
Si le compresseur est utiliséàdes fins commerciales ou de location, cette garantie se limite à90 jours àpartir de la
date d’achat.
Cette garantie est complémentaire àtoute autre garantie statutaire qui peut varier d'une province àl'autre.
SEARS CANADA INC, TORONTO ONT. M5B 2B8
Description du fonctionnement . . . . . . . . . . . . . . .27
Utilisation de l’appareil . . . . . . . . . . . . . . . . . . . . .28
Arrêt de l’appareil
Avant le démarrage . . . . . . . . . . . . . . . . . . . .28
Avant chaque mise en marche . . . . . . . . . . . .28
Mise en marche . . . . . . . . . . . . . . . . . . . . . . .28
ENTRETIEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Responsabilités du client . . . . . . . . . . . . . . . . . . .29
Vérification de la soupape de sûreté. . . . . . . . . . .29
Vidange du réservoir . . . . . . . . . . . . . . . . . . . . . . .29
ENTRETIEN ET RÉGLAGES . . . . . . . . . . . . . . . . . . . .30
Remplacement ou nettoyage de la
soupape de retenue . . . . . . . . . . . . . . . . . . . . . . .30 . .
Remplacement du régulateur . . . . . . . . . . . . . . . .30 . .
RANGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
DÉPANNAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32-33
DIAGRAMME & LISTE DES PIÈCES . . . . . . . . . . .16-19
HOW TO ORDER REPAIR PARTS . . . .Couverture arrière
TABLEAU DES SPÉCIFICATIONS
Modèle no : 919.727550
Alésage 1 7/8 po (4,76 cm)
Course du cylindre 1 1/4 po (3,175 cm)
Tension –phase unique 120
Exigence minimale du circuit de dérivation 15 a
Genre de fusible àretardement àélément double
Capacitédu réservoir d’air 4 gal. (É.-U.) ( 15,1 L)
Pression d’enclenchement approx. 100
Pression de coupe-circuit approx. 125
Pi3/min standard (SCFM) à40 psi (lb/po. ca.) 3,7
Pi3/min standard (SCFM) à90 psi (lb/po. ca.) 2,6
GARANTIE
