Craftsman 675 Series User manual

Sears Brands Management Corporation, Hoffman Estates, IL 60179, U.S.A.
Visit our website: www.craftsman.com
CAUTION: Before using
this product, read this
manual and follow all
safety rules and operating
instructions.
Operator’s Manual
675 Series
LOG SPLITTER
Model No. 247.77641
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• PARTS LIST
• Español
®
6 /11/ 2010
FORM NO. 769-05240A

22
PARTS LIST
68
63
76
2
1
25
22
10
13
20
71
33
55
44
45
15
84
19
64
17
61
41
41
69
58
57
56
34
65
41
44
67
62
72
59
66
48
23
51
29
30
27
59
77
50
72
18
61
11
12
3
4
6
5
74
75
7
8
9
44
65
70
41
41
39
43
38
35
14
52
53
73
26
28
37
23
32
23
31
24
40
36
42
16
48
49
23
21
47
46
54
78
60
79
81
83
79
80
82
29
A
A
Craftsman Log Splitter Model 247.77641

23
Ref.
No.
Part No. Description
1. 918-0769A Hydraulic Cylinder
2. 727-04166 Hydraulic Tube
3. 710-1018 Hex Cap Screw 1/2-20 x 2.75
4. 737-0192 90 Degree Solid Adapter
5. 918-0481A Control Valve
6. 737-0153 Return Elbow
7. 737-0238 Nipple Pipe 1/2-14
8. 710-1806 Hex Cap Screw 1/2-13 x 3.25
9. 719-0550A Wedge Assembly
10. 912-3058 Hex Lock Nut, 1/2-20
11. 712-0711 Hex Jam Nut 3/8-24
12. 710-0459A Hex Cap Screw 3/8-24 x 1.5
13. 781-0351 Adjustable Gib
14. 936-0116 Flat Washer.635 x.93 x.06
15. 712-3022 Hex Lock Nut 1/2-13
16. 681-04071A-0637 Beam Assembly
17. 710-3056 Hex Screw, 5/16-18 x 3.25
18. 710-0502A Hex Washer Screw 3/8-16 x 1.250
19. 781-04426-4044 Dislodger Bracket
20. 781-0790-0637 Back Plate
21. 737-04093 Inlet Filter
22. 727-0443 Return Hose 3/4” ID x 44” Lg.
23. 726-0132 Hose Clamp 5/8”
24. 737-0316 Filter Housing
25. 723-0405 Oil Filter
26. 734-0873 Hub Cap
27. 714-0162 Cotter Pin
28. 712-0359 Slotted Nut 3/4-16
29. 634-0186 Wheel Assembly
30. 936-0351 Flat Washer.760 ID x.500 OD
31. 737-0312 Adapter 3/4-14
32. 781-0526A Hose Guard
33. 737-0348A Vented Dipstick
34. 711-1587 Clevis Pin
35. 781-0690 Lock Rod
36. 914-0470 Cotter Pin
37. 726-0214 Push Cap
38. 732-0583 Compression Spring
39. 781-04180-0637 Log Tray Bracket
40. 710-04484 Hex Washer Screw, 5/16-18 x .750
41. 712-04065 Flange Lock Nut, 3/8-16
42. 781-04179-0637 Log Tray
43. 981-04040A-0637 Frame Assembly
44. 710-0521 Hex Bolt 3/8-16 x 3
Ref.
No.
Part No. Description
45. 719-0353 Coupling Shield
46. 914-0122 Square Key 3/16” x.75
47. 710-1842 Screw, 1/4-20 x .38
—718-04392 Coupling, .500
—718-04395 Coupling, .875
—735-04103 Spider Coupling
48. 712-04063 Flange Lock Nut, 5/16-18
49. 781-0097-0637 Rear Coupling Support Bracket
50. 781-1024A-0637 Fender Mounting Bracket
51. 727-04130 Hose
52. 918-04127 Gear Pump
53. 737-0329 45 Degree Elbow Fitting
54. 727-0502 High Pressure Hydraulic Hose
55. 781-0788-0637 Tongue Assembly
56. 747-1261 Latch Rod
57. 781-1045-0637 Latch
58. 932-3127 Compression Spring
59. 736-0371 Flat Washer
60. 781-0538A Hose Guard
61. 710-3085 Hex Cap Screw, 3/8-16 x 3.50
62. 936-0185 Flat Washer,.375 x.738 x.063
63. 747-04539 Hydraulic Valve Control
64. 681-04030 Hitch Coupling Assembly
65. 713-0433A Chain
66. 731-2496A Fender
67. 911- 0813 Clevis Pin
68. 720-04088 Grip
69. 732-0194 Spring Pin
70. 781-0789-0637 Jack Stand
71. 915-0120 Spiral Pin
72. 710-0650 TT Screw, 5/16-18 x 0.875”
73. 710-0602 TT Screw, 5/16-18 x 1.00
74. 711-04585 Clevis Pin
75. 913-04036 Valve Handle Link
76. 914-0111 Cotter Pin
77. 710-0376 Hex Screw, 5/16-18 x 1.00
78. 736-3010 Flat Washer, .407 x .812 x .135
79. 941-0987 Roller Bearing
80. 921-0168 Dust Seal
81. 734-0872 Tire, 16 x 4.8 x 8.0
82. 934-0255 Tubeless Air Valve
83. 634-0188 Rim Assembly
84. 710-04683 Hex Washer Screw, 3/8-16 x 1.000
Craftsman Log Splitter Model 247.77641

24
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
307
13
337
635
383
3
11
910
54
50
51
7
5
585
684 287
525
524
842
1
8
847
523
27
27
32
26
28
25
29
40
40
35
36
33
45
34
45
24
741
16
146
20
12
22
46
43
15
4
32A
718
868
2
871
870
869
1330 REPAIR MANUAL
1058 OPERATOR’S MANUAL
306
584

25
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
365
968
445
425
443
163
529
159
970
966
976
188
104
137
276 127
633
121 CARBURETOR OVERHAUL KIT
617
137
276
633
617
977 CARBURETOR
GASKET SET
163
163
134
81
613
300
222
125
134
133
109
633A
97
633
104
137
975
276
276
117
163
108
127
130
95 617
692
668
832
836
843
633A
633A
276
118

26
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
332
304
305
363
455
23
1036 EMISSIONS LABEL
55
456
58
60
459
689
597
608 65
592
190
670
957
972
1059
1211
1210
601
187
78
37
497
627 930
347
1005

27
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
334
851
333
202
209
356
562
505
227
616
404
615
358 ENGINE GASKET SET
12
320
51
585
7
163
524 668 842
48
617
1329 REPLACEMENT ENGINE

28
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
Ref.No. PartNo. Description
1. BS-697322 Cylinder Assembly
2. BS-399269 Bushing/Seal Kit
3. BS-299819S † Oil Seal (Magneto Side)
4. BS-493279 Engine Sump
5. BS-691160 Cylinder Head
7. BS-692249 † Cylinder Head Gasket
8. BS-695250 Breather Assembly
9. BS-699125 Breather Gasket
10. BS-691125 Screw (Breather Assembly)
11. BS-691781 Breather Tube
12. BS-692232 † Crankcase Gasket
13. BS-690912 Screw (Cylinder Head)
15. BS-691680 Oil Drain Plug
16. BS-691455 Crankshaft
20. BS-399781S † Oil Seal (PTO Side)
22. BS-691092 Screw (Engine Sump)
23. BS-691992 Flywheel
24. BS-222698S Flywheel Key
25. BS-791097 Piston Assembly (Standard)
—BS-791326 Piston Assembly (.020” Oversize)
26. BS-791098 Piston Ring Set(Standard)
—BS-791324 Piston Ring Set (.020” Oversize)
27. BS-691866 Piston Pin Lock
28. BS-499423 Piston pin
29. BS-499424 Connecting Rod
32. BS-691664 Screw (Connecting Rod)
32A. BS-695759 Screw (Connecting Rod)
33. BS-262651S Exhaust Valve
34. BS-262652S Intake Valve
35. BS-691270 Valve Spring (Intake)
36. BS-691270 Valve Spring (Exhaust)
37. BS-694086 Flywheel Guard
40. BS-692194 Valve Retainer
43. BS-691997 Governor/Oil Slinger
45. BS-690548 Valve Tappet
46. BS-691449 Camshaft
48. BS-792740 Short Block
50. BS-794305 Intake Manifold
51. BS-794306 † Intake Gasket
54. BS-691650 Screw (Intake Manifold)
55. BS-691421 Rewind Starter Housing
Ref.No. PartNo. Description
58. BS-697316 Starter Rope (Cut to Req’d Length)
60. BS-281434S Starter Rope Grip
65. BS-690837 Screw (Rewind Starter)
78. BS- 691108 Screw (Flywheel Guard)
81. BS-691740 Muffler Screw Lock
95. BS-691636 Screw (Throttle Valve)
97. BS-696565 Throttle Shaft
104. BS-691242 †† Float Hinge Pin
108. BS-691182 Choke Valve
109. BS-498593 Choke Shaft
117. BS-498981 Main Jet (Standard)
118. BS-498978 Main Jet (High Altitude)
121. BS-498260 Carburetor Overhaul Kit
125. BS-792253 Carburetor
127. BS-694468 †† Welch Plug
130. BS-696564 Throttle Valve
133. BS-398187 Carburetor Float
134. BS-398188 †† Needle/Seat Valve
137. BS-693981 ††* Float Bowl Gasket
163. BS-795629 †*†† Air Cleaner Gasket
187. BS-791891 Fuel Line (Cut to Required Length)
188. BS-693399 Screw (Control Bracket)
190. BS-690940 Screw (Fuel Tank)
202. BS-691829 Mechanical Governor Link
209. BS-691291 Governor Spring
222. BS-692982 Control Bracket
227. BS-690783 Governor Control Lever
240. BS-298090S Fuel Filter
276. BS-271716 ††* Sealing Washer
287. BS-690940 Screw (Dipstick Tube)
300. BS-692038 Muffler
304. BS-493294 Blower Housing
305. BS-691108 Screw (Blower Housing)
306. BS-690450 Cylinder Shield
307. BS-690345 Screw (Cylinder Shield)
332. 712-0318 Nut (Flywheel)
333. BS-695711 Magneto Armature
334. BS-691061 Screw (Armature Magneto)
337. 759-3338 Spark Plug
339. BS-794797 Tube/Connector Assembly

29
PARTS LIST
Briggs & Stratton Engine Model 126L02 For Craftsman Log Splitter Model 247.77641
Ref.No. PartNo. Description
347. BS-691396 Rocker Switch
356. BS-693010 Stop Wire
358. BS-794307 Engine Gasket Set
363. BS-19069 Flywheel Puller
365. BS-692524 Screw (Carburetor)
383. BS-89838S Spark Plug Wrench
404. BS-690272 Washer (Governor Crank)
425. BS-690670 Screw (Air Cleaner Cover)
443. BS-692523 Screw (Air Cleaner Primer Base)
445. BS-491588S Air Cleaner Cartridge Filter
455. BS-791960 Flywheel Cup
456. BS-692299 Pawl Friction Plate
459. BS-281505S Ratchet Pawl
497. BS-690664 Screw (Stopswitch)
505. BS-691251 Nut (Governor Control Lever)
523. BS-499621 Dipstick
524. BS-692296 † Dipstick Tube Seal
525. BS-495265 Dipstick Tube
529. BS-691923 Grommet
562. BS-92613 Bolt (Governor Control Lever)
564. BS-690351 Screw (Control Cover)
584. BS-697734 Breather Passage Cover
585. BS-691879 † Breather Passage Gasket
592. 712-0349 Nut (Rewind Starter)
597. BS-691696 Screw (Pawl Friction Plate)
601. BS-791850 Hose Clamp
604. BS-794794 Control Cover
608. BS-497680 Rewind Starter
613. BS-691340 Screw (Muffler)
615. BS-690340 Governor Shaft Retainer
616. BS-698801 Governor Crank
617. BS-270344S †*†† O-Ring Seal (Intake Manifold)
627. BS-792565 Stopswitch Bracket
633. BS-691321 ††* Choke/Throttle Shaft Seal
Ref.No. PartNo. Description
633A. BS-693867 ††* Choke/Throttle Shaft Seal
635. BS-66538S Spark Plug Boot
668. BS-493823 Spacer
670. BS-692294 Fuel Tank Spacer
684. BS-690345 Screw (Breather Passage Cover)
689. BS-691855 Friction Spring
692. BS-690579 Detent Spring
718. BS-690959 Locating Pin
741. BS-790345 Timing Gear
832. BS-499034 Muffler Guard
836. BS-690664 Screw (Muffler Guard)
842. BS-691031 † O-Ring Seal (Dipstick Tube)
843. BS-691895 Lever Sleeve
847. BS-692047 Dipstick/Tube Assembly
851. BS-493880S Spark Plug Terminal
868. BS-697338 Valve Seal
869. BS- 691155 Valve Seat (Intake)
870. BS-690380 Valve Seat (Exhaust)
871. BS-262001 Guide Bushing (Exhaust)
— BS-63709 Guide Bushing (Intake)
930. BS-691919 Rewind Guard
957. BS-794793 Fuel Tank Cap
966. BS-794798 Air Cleaner Primer Base
968. BS-692298 Air Cleaner Cover
972. BS-794792 Fuel Tank
975. BS-796611 Float Bowl
977. BS-498260 Carburetor Gasket Set
1005. BS-691346 Flywheel Fan
1036. BS-697457 Emission Label
1058. BS-MS3260 Owner’s Manual
1059. BS-692311 Screw/Washer Kit
1210. BS-498144 Pulley/Spring (Pulley) Assembly
1211. BS-498144 Pulley/Spring (Spring) Assembly
1330. 272147 Repair Manual
†Included in Engine Gasket Set, Key. No. 358
††Included in Carburetor Overhaul Kit, Key. No. 121
*Included in Carburetor Gasket Set, Key. No. 977

30
PARTS LIST
Craftsman Log Splitter Model 247.77641
Model Plate
KEEP HANDS and FEET AWAY
WARNING
CONTROL
VA LV E
REVERSE
NEUTRAL
FORWARD
LOG DISLODGER
S32061 AC
LUBRICATE BEAM BEFORE EACH
USE. REFER TO OPERATOR’S
MANUAL FOR DETAILS.
Retract wedge, lodged wood
will be automatically removed.
PERSON STABILIZING LOG ON SPLITTER
MUST BE SAME PERSON WHO OPERAT ES
CONTROL VA LVE.
KEEP HANDS AWAY FROM WEDGE AND
MOVING PA RTS.
HYDRAULIC FLUID
Maintain fluid level within
the ranges specified on the
dipstick. DO NOT OVERFILL!
Check when fluid is cold
and with unit level. Never
run below this level. Pump
will be ruined. Change
hydraulic fluid every 100
hours of use. Change
hydraulic filter every 50
hours of use. Use only a 10 micron hydraulic filter.
Order Part Number Hydraulic Filter 723-0405
HYDRAULIC FLUID
ONLY
DEXRON III or
10 WEIGHT AW
min.
max.
DIP
STICK
MOVING LOG SPLITTER BY HAND
TOWING LOG SPLITTER
WARNING -
TO AVOID INJURY AND/OR PROPERTY DAMAGE
777D14914
777S32061
777S33112
777I23022
777S32605
777X43902
Operation Of This Equipment May Create
Sparks That Can Start Fires Around Dry
Vegetation. A Spark Arrestor May Be
Required. The Operator Should Contact
Local Fire Agencies For Laws Or Regula-
tions To Fire Prevention Requirements.
WARNING
777S33200
27
VERTICAL / HORIZONTAL
LOG SPLITTER
SU
NOT
T
O
A
V
O
I
D
E
N
G
I
N
E
D
A
M
A
G
E
DO NOT
USE E85 OR FUEL
CONTAINING MORE
THAN 10% ETHANOL
777X43688
