Operator'siVlanual
®
2000 PSi
1.9 GPM
Model No. 500.752110
PRESSUREWASHER ,_
CUSTOMERHELPLINE
HOURS: Non. - Fri. 8 a.m. to 5 p.m. (CT)
WAReleG
Before usingthis product, readthis
manualand follow all SafetyRules
and Operating Instructions.
I_ I7ADVERTENCJA
Antes de utilizar el producto, lea este
manualy siga todas las Reglasde
Seguridade Instrucciones de Uso.
Sears, Roebuckand Co., RoffmanEstates,IL 60179 U.S.A.
Visit ourCraftsman website:www.craftsman.cnm
Part No. 202564GS Draft - (02/16/2007)
•Safety
•Assembly
•Operation
•Maintenance
•Parts
,, Espafiol, p. 32
3

WARRANTY.......................................... 2
SAFETYRULES...................................... 2-5
FEATURESANDCONTROLS.............................. 6
ASSEMBLY......................................... 7-9
OPERATION....................................... 10-13
SPECIFICATIONS..................................... 14
MAINTENANCE.................................... 15-19
STORAGE........................................... 20
TROUBLESHOOTING.................................. 21
REPLACEMENTPARTS.............................. 22-28
NOTES ............................................. 29
EMISSIONCONTROLWARRANTY..................... 30-31
ESPANOL......................................... 32-55
HOWTO ORDERPARTS........................ BACKPAGE
ONE-YEARFULLWARRAHTYONCRAFTSMAHPRESSUREWASHER
If this pressurewasher fails dueto a defectin material or workmanship within one year from the dateof purchase,return it to
any Searsstore, other Craftsman outlet, or SearsParts & RepairCenterin the UnitedStates or Canadafor free repair (or
replacementif repair proves impossible).
All warranty coverageapplies for only 90 days from dateof purchaseif this pressure washer is ever usedfor commercial or
rentalpurposes.
This warranty gives you specific legal rights, and you mayalso haveother rights which vary from stateto state.
Sears, Roebuck and Co., Hoffman Estates, IL 60178
Sears Canada Inc., Toronto, Ontario, Canada M5B 288
,_ Thisisthe safetyalert symbol.It isusedto alert youtopotentialpersonalinjuryhazards.Obeyall safetymessages
thatfollow thissymboltoavoid possibleinjuryor death.
_Read this manualcarefully and becomefamiliar
with yourpressurewasher. Knowits applications,
its limitations, and any hazardsinvolved.
Thesafety alert symbol (_.) is usedwith a signal word
(DANGER,CAUTION,WARNING),a pictorial and/or a safety
messageto alert you to hazards.BANGERindicatesa hazard
which, if not avoided, willresult in deathor serious injury.
WARNINGindicates a hazardwhich, if not avoided, could
result in deathor serious injury. CAUTIONindicatesa hazard
which, if not avoided, might result in minor or moderate
injury. NOTICEindicatesa situation that could result in
equipment damage. Follow safety messagesto avoid or
reducethe risk of injury or death.
Hazard Symbolsand Meaninos
ToxicFumes Kickback
2 5-
SlipperySurface Fall
Fire Explosion
ElectricalShock
FluidInjection
Operator'sManual
MovingParts FlyingObjects HotSurface
© SearsBrands, LLC

WARHJNG
Theengineexhaustfromthisproductcontains
chemicalsknowntotheState of California tocause
cancer,birthdefects,or otherreproductiveharm.
WARHJHG
Runningengine gives off carbon monoxide, an
odorless, colorless, poison gas.
Breathingcarbon monoxide can cause headache,
_ atigue, dizziness,vomiting, confusion, seizures,
nausea,fainting or death.
Some chemicals or detergents may be harmful if
inhaled or ingested, causing severe nausea,
fainting, or poisoning.
*OperatepressurewasherONLYoutdoors.
Keepexhaustgasfromenteringaconfinedareathrough
windows,doors,ventilationintakes,or otheropenings.
DONOTstartor runengineindoorsor in anenclosedarea,
evenif windowsanddoorsareopen.
Usea respiratoror maskwheneverthereisa chancethat
vaporsmaybeinhaled.
Readall instructionswith masksoyouarecertainthemaskwill
providethenecessaryprotectionagainstinhalingharmful
vapors.
WARHIHG
_¢ isk of electrocution.
Contactwith power source can causeelectric
shock or burn.
* NEVERspraynearpowersource.
WARHIHG
Fueland its vapors are extremely flammable and
explosive.
Fireor explosion cancause severe burns or
death.
WHENADDINGORDRAININGFUEL
*TurnpressurewasherOFFandletit coolatleast2 minutes
beforeremovingfuelcap.Loosencapslowlyto relievepressure
in tank.
Fillor drainfueltankoutdoors.
DONOToverfilltank.Allowspaceforfuelexpansion.
Iffuelspills,waituntilit evaporatesbeforestartingengine.
Keepfuelawayfromsparks,openflames,pilotlights,heat,and
otherignitionsources.
DONOTlighta cigaretteorsmoke.
WHENSTARTIN6EQUIPMENT
*Ensuresparkplug,muffler,fuelcap,andair cleanerarein
place.
. DONOTcrankenginewith sparkplugremoved.
WHENOPERATINGEQUIPMENT
*DONOTtip engineor equipmentat anglewhichcausesfuelto
spill.
. DONOTsprayflammableliquids.
WHENTRANSPORTINGORREPAIRINGEQUIPMENT
*Transport/repairwithfueltank EMPTYor withfuelshutoffvalve
OFF.
. Disconnectsparkplugwire.
WHENSTORINGFUELOREQUIPMENTWITH FUELIN TANK
*Storeawayfromfurnaces,stoves,waterheaters,clothes
dryers,or otherappliancesthathavepilotlightor otherignition
sourcebecausetheycanignitefuelvapors.

WARHJHG
Startercord kickback(rapid retraction) can result
in bodily injury. Kickbackwill pull handand arm
_,_.< toward engine faster than you can let go.
Brokenbones, fractures, bruises, or sprains
could result.
•NEVERpull starter cord without first relieving spray gun
pressure.
.When starting engine, pull cord slowly until resistanceis felt
and then pull rapidly to avoid kickback.
•After eachstarting attempt, where enginefails to run, always
point spray gun in safe direction and squeezespray gun trigger
to releasehigh pressure. Engagespray gun trigger lock.
•Firmly grasp spray gun with both handswhen using high
pressure spray to avoid injury when spray gun kicks back.
%
WARHIHG
Useof pressure washer cancreate puddles and
slippery surfaces.
Kickbackfrom spray gun cancause you to fall.
.Operatepressure washer from a stable surface.
•The cleaningarea should haveadequate slopes and drainageto
reducethe possibility of afall dueto slippery surfaces.
.Be extremelycareful if you must usethe pressure washer from
a ladder,scaffolding, or any other similar location.
•Firmly grasp spray gun with both hands when using high
pressure spray to avoid injury when spray gun kicks back.
WARHIHG
_ Contact with muffler result in serious
area can
burns.
_ Exhaustheat/gases can ignite combustibles,structures or damagefuel tank causing a fire.
•DO NOTtouch hot parts and AVOID hot exhaust gases.
.Allow equipmentto cool before touching.
•Keepat least 5feet (152 cm) of clearanceon all sides of
pressure washer including overhead.
•Codeof FederalRegulation (CFR)Title 36 Parks, Forests,and
Public Property require equipment powered by an internal
combustion engine to have aspark arrester, maintained in
effective working order, complying to USDAForestservice
standard 5100-1C or later revision. Inthe State of California a
spark arrester is required under section 4442 of the California
Public resources code. Other statesmay havesimilar laws.
WARHIHG
The high pressure stream of water that this
equipment produces can cut through skin and its
_ nderlying tissues, leading to serious injury and
)ossible amputation.
Spray gun traps high water pressure, even when
engine is stopped and water is disconnected,
which can cause injury.
•DONOTallow CHILDRENto operate pressure washer.
.NEVERrepair high pressure hose. Replaceit.
•NEVERrepair leaking connections with sealantof any kind.
Replaceo-ring or seal.
•NEVERconnect high pressure hoseto nozzle extension.
.Keephigh pressure hoseconnectedto pump and spray gun
while system is pressurized.
•ALWAYSpoint spray gun in safe direction and squeezespray
gun trigger, to releasehigh pressure, everytime you stop
engine. Engagetrigger lockwhen not in use.
•NEVERaim spray gun at people, animals, or plants.
.DONOTsecure spray gun in open position.
•DO NOTleavespray gun unattendedwhile machine is running.
.NEVERusea spray gun which does not have atrigger lock or
trigger guard in place and in working order.
.Always be certain spray gun, nozzlesand accessories are
correctly attached.
WARHIHG
_ Unintentionalsparking can result in fire or
_¢ electric shock.
WHENADJUSTINGORMAKINGREPAIRSTOYOUR
PRESSUREWASHER
.Disconnectthe sparkplug wire from the spark plugand place
the wire where it cannot contact spark plug.
WHENTESTINGFORENGINESPARK
.Use approved spark plug tester.
•DONOTcheck for sparkwith spark plug removed.

WARHJHG
Starter and other rotating parts canentangle
hands, hair, clothing, or accessories.
*NEVERoperate pressure washer without protective housing or
covers.
*DO NOTwear loose clothing, jewelry or anythingthat may be
caught in the starter or other rotating parts.
*Tie up long hair and remove jewelry.
WARNING
Risk of eye injury.
"_JSpraycan splash back or propel objects.
Always wear safetygoggles when using this equipment or in
vicinity of where equipment is in use.
Beforestarting the pressure washer, be sureyou are wearing
adequatesafety goggles.
NEVERsubstitute safety glasses for safetygoggles.
NOTICE
High pressure spray may damage fragile items including
lass.
DONOTpoint spray gun at glasswhen in jet spray mode.
NEVERaim spray gun at plants.
NOTICE
Improper treatment of pressure washer can damage it and
shorten its life.
If you have questions about intended use, ask dealer or contact
Sears.
NEVERoperate units with broken or missing parts, or without
protective housing or covers.
DONOT by-pass any safetydevice on this machine.
DONOTtamper with governed speed.
DONOToperate pressure washer above rated pressure.
DONOT modify pressure washer in any way.
Before starting pressure washer in cold weather, check all parts
of the equipment to besure ice has not formed there.
NEVERmove machine by pulling on hoses. Use handle
provided on unit.
Checkfuel system for leaksor signs of deterioration, such as
chafed or spongy hose,loose or missing clamps, or damaged
tank or cap. Correct all defects beforeoperating pressure
washer.
This equipment is designedto be usedwith Searsauthorized
parts ONLY.If equipment is used with parts that DO NOT
comply with minimum specifications, userassumes all risks
and liabilities.

KNOWYOURPRESSUREWASHER
_Head the Operator'sManual and safety rulesbefore operatingyourpressurewasher.
Comparethe illustrations with your pressurewasher to familiarizeyourself with the locations of various controls and
adjustments. Savethis manualfor future reference.
A- Recoil Starter -- Usedfor starting the engine manually.
B-Oil Fill/Dipstick -- Check,add and drain engine oil here.
C- Pump -- Developshigh pressure.
D-Automatic Cool DownSystem -- Cycleswater through
pump whenwater reaches125°-155°F. Warm water will
dischargefrom pump onto ground. This system prevents
internalpump damage.
E - HighPressureHose-- Connectone end to water pump
and the other end to spray gun.
F-Adjustable NozzleExtension-- Attachto spray gun to
useadjustable nozzle.Adjust for high or low pressure;
narrow or fan spray,
G-Spray,Gun-- Controlsthe application of water onto
cleaningsurface with trigger device,Includestrigger lock,
H-Warning/OperatingInstructions Tag -- Identifies
hazardsand proper procedureto start/stop pressure
washer.
J - Fuel Tank-- Filltank with regular unleadedfuel. Always
leaveroom for fuel expansion.
Items Net Shown:
Air Filter -- Protectsengine by filtering dust and debris out
of intake air.
Data Tag (near rear of baseplate) -- Provides model and
serial number of pressure washer. Pleasehavethese readily
availableif calling for assistance.
HighPressureOutlet-- Connectionfor high pressure hose.
PrimerBulb -- Preparesa cold enginefor starting.
Safety Goggles-- Always usethe enclosedsafety goggles
when running your pressure washer.
ThrottleLever-- Sets engine in starting mode for recoil
starter and stops a running engine.
Water Inlet -- Connectionfor garden hose.

Your pressure washer requires some assembly and is ready
for useonly after it has been properly servicedwith the
recommendedoil and fuel.
If you haveany problemswith the assemblyof your
pressurewasher, please call the pressurewasher heipline
at 1-800-222-3135.
Attach Handle
1. Placehandle (A) onto base(B). Makesure holes in
handlealign with holeson base.
UNPACKTHEPRESSUREWASHER
1. Removeeverything from carton exceptpressure washer.
2. Opencarton completely bycutting eachcorner from top
to bottom.
3. Removepressure washer from carton.
CARTONCONTENTS
Checkall contents, if any parts are missing or damaged,call
the pressure washer helpline at 1-800-222-3136.
• Main Unit
• Handle
• Wheel Kit
• High PressureHose
• Spray Gun
• Adjustable NozzleExtension
• Oil Bottle
• Parts Bag (which includes the following):
• Operator's Manual
• Owner's Registration Card
• SafetyGoggles
• MeshAccessory Bag
Becomefamiliar with eachpiecebefore assemblingthe
pressure washer, identify all contents with the illustration on
page 6. If any parts are missing or damaged,callthe
pressure washer helpline at 1-800-222-3136.
ASSEMBLINGPRESSUREWASHER
Your Craftsmanpressure washer will need assembly before
operation:
1. Fill out and send in registration card.
2. Attach handleto main unit.
3. Install wheel kit.
4. Add oil to engine crankcase.
5. Add fuel to fuel tank.
6. Connectpressure hoseto spray gun and pump.
7. Connectwater supply to pump.
8. Attach nozzleextensionto spray gun.
2. Insert carriagebolts (C)through holesfrom outside of
unit and attach a plastic knob (D) from inside of unit.
Tighten by hand.
Install WheelKit
Thewheel kit is designedto greatly improve the portability of
your pressure washer.
NOTE:Wheelkit is not intendedfor over-the-road use.
install the wheel kit as fellows:
1. Placethe bottom ofthe pressure washer frame on a flat,
evensurface.
2. Slidea wheel (A) overthe axle pin (B).
NOTE:Besure to install wheel with raisedhub inboard.
3. Slideaxle pin through hole (C)in frame.
4. Retainwheel on axle pin with retainingpin (D).
5. Repeatstep 2 through 4 to secure second wheel.

Add Engine Oil
1. Placepressure washer on a flat, ]eve]surface.
2. Cleanarea around oil fill and remove yellow oil fill
cap/dipstick.
NOTE:See Oil Recommendationsin Maintenancesection.
Verify provided oil bottle is the correct viscosity for current
ambient temperature.
3. Using oil funnel (optional), slowly pour contents of
provided oil bottle into oil fill opening.
NOTICE
Improper treatment of pressurewasher can damageit and
shorten its life.
DONOTattempttocrankor starttheenginebeforeit hasbeen
properlyservicedwith therecommendedoil.Thismayresultin
anenginefailure.
4. Replaceoil fill cap/dipstick and fully tighten.
Add FueJ
Fuel must meet these requirements:
*Clean,fresh, unleadedgasoline.
* A minimum of 87 octane/87 AKI (91 RON).Highaltitude
use,see HighAltitude.
, Gasolinewith up to 10% ethanol (gasohol) or up to 15%
MTBE(methyl tertiary butyl ether) is acceptable.
NOTICE
Avoid pressure washer damage.
Failureto follow Operator's Manualfor fuel
recommendations voids warranty.
DONOTuseunapprovedgasolinesuchasE85.
DONOTmixoil in gasoline.
DONOTmodifyengineto runon alternatefuels.
To protect the fuel system from gum formation, mix in a fuel
stabilizerwhen adding fuel. SeeStorage. All fuel is not the
same. If you experiencestarting or performanceproblems
after using fuel, switch to a different fuel provider or change
brands. This engine is certified to operateon gasoline. The
emission control system for this engine is EM (Engine
Modifications).
WARHIHG
,_ Fueland its flammable and
vapors are extremely
explosive.
Fireor explosion can causesevere burns or
death.
WHENADDINGFUEL
*TurnpressurewasherOFFandletit coolatleast2 minutes
beforeremovingfuelcap.Loosencapslowlyto relievepressure
in tank.
* Fillfueltankoutdoors.
*DONOToverfilltank.Allowspaceforfuelexpansion.
* Iffuelspills,waituntilit evaporatesbeforestartingengine.
Keepfuelawayfromsparks,openflames,pilotlights,heat,and
otherignitionsources.
DONOTlighta cigaretteorsmoke.
Cleanareaaround fuel fill cap, removecap.
Slowly add regular unleadedfuel (A) to fuel tank (B). Be
careful not to overfill. Allow about 1.5" (4 cm) (C) oftank
space for fuel expansion.
o
1.
2.
3. Install fuel cap and wait for anyspilled fuelto evaporate.
CAUTIOH! Alcohol-blendedfuels (calledgasohol, ethanol or
methanol) canattract moisture, which leadsto separationand
formation of acids during storage.Acidic gas candamagethe
fuel system ofan engine while in storage.
To avoid engine problems, the fuel system should be treated
with a fuel preserver or emptied beforestorage of 30 days or
longer. If adding a fuel preserver,fill the fuel tank with fresh
fuel. if only partially filled, air in the tank will promote fuel
deterioration during storage, if fuel preserver is not used,
drain the fuel tank, start the engine and let it run until the fuel
linesand carburetor are empty. Usefresh fuel next season.
SeeStoragefor additional information.
NEVERuseengine or carburetor cleaner products in the fuel
tank as permanent damagemay occur.
NighAJtitude
At altitudes over 5,000 feet (1524 meters), a minimum
85 octane /85 AKI (89 RON)gasoline is acceptable.To
remainemissions compliant, high altitude adjustment is
required. Operationwithout this adjustment will cause
decreasedperformance, increasedfuel consumption, and
increasedemissions. Seea qualified Searsdealerfor high
altitude adjustment information. Operationof the engine at
altitudes below 2,500 feet (762 meters)with the high altitude
kit is not recommended.

Connect Hose and Water Supply to Pump
NOTICE
IDONOTrun the pump without the water supply connected
_nd turned on. ______
I* Damageto equipmentresultingfrom failuretofollowthis
h instructionwillvoidwarranty.
NOTE:Removeand discard the shipping caps from the
pump's high pressure outlet and water inlet before attaching
hoses•
1. Uncoil high pressure hoseand attach one end of hoseto
baseof spray gun. Tighten by hand•
WARHIHG
The high pressure stream of water that this
_ quipment produces cancut through skin and its
underlyingtissues, leadingto serious injury and
_ossibleamputation•
NEVERconnecthighpressurehoseto nozzleextension.
• Keephighpressurehoseconnectedto pumpandspraygun
whilesystemispressurized•
• Alwaysbecertainspraygun,nozzlesandaccessoriesare
correctlyattached•
Attach other end of high pressure hoseto high pressure
outlet on pump. Tighten by hand.
Beforeconnectinggarden hoseto water inlet, inspect
inlet screen (A). Cleanscreenif it contains debris or have
it replacedif damaged•DONOTrunpressurewasher if
inletscreenis damagedor missing.
4. Runwater through garden hosefor 30 secondsto flush
it of debris•Turn off water•
IMPORTANT:DONOTsiphon standing water for the water
supply• Use ONLYcold water (less than IO0°F).
5. Connectgarden hose(not to exceed50 feet in length) to
water inlet• Tighten by hand•
NOTICE
Using a OneWay Valve(vacuum breakeror checkvalve) at
uj_&_j?_inlet cancause um or inlet connector duma e.
ThereMUSTbeatleasttenfeetof unrestrictedgardenhose
betweenthepressurewasherinletandanydevice,suchasa
vacuumbreakeror checkvalve•
Damageto equipmentresultingfrom failureto followthis
instructionwillvoidwarranty•
6. Turn ONwater, point gun in a safe direction and squeeze
trigger to purge pump system of air and impurities•
WARHIHG
Riskof eyeinjury•
• _ ISpray cansplash back or propel objects•
Alwayswearsafetygoggleswhenusingthis equipmentor in
vicinityof whereequipmentisin use.
Beforestartingthepressurewasher,besureyouarewearing
adequatesafetygoggles•
NEVERsubstitutesafetyglassesfor safetygoggles•
ChecMist Before Starting Engine
Reviewthe unit to ensureyou haveperformed all of the
following:
1. Besure to read SafetyRules and Operationsections
before usingthe pressure washer•
2. Makesure handle is in placeand secure•
3. Checkthat oil has beenaddedto proper level in engine
crankcase•
4. Add proper fuel to fuel tank•
5. Checkfor proper hoseconnections (high pressure and
water supply) and that thereare no kinks, cuts, or
damageto the high pressure hose•
6. Provideproper water supply (not to exceed IO0°F).

HOWTOUSEYOURPRESSUREWASHER
If you haveany problems operatingyour pressure washer,
pleasecallthe pressure washer helpline at 1-800-222-3136.
Pressure Washer Location
PressureWasherClearance
WARNING
_ Exhaustheat/gases can ignitecombustibles,
structures or damagefuel tank causing a fire.
•Keepatleast5ft. (152cm)clearanceonall sidesofpressure
washerincludingoverhead.
Placepressure washer outdoors in an areathat will not
accumulate deadlyexhaustgas. DONOTplacepressure
washer where exhaustgas (A) could accumulateand enter
inside or be drawn into a potentially occupied building.
Ensureexhaustgas is kept awayfrom any windows, doors,
ventilation intakes, or other openingsthat can allow exhaust
gasto collect in a confined area. Prevailingwinds and air
currents should be taken into considerationwhen positioning
_ressurewasher.
WARHIHG
Runningengine gives off carbon monoxide, an
;_ odorless, colorless, poison gas.
Breathingcarbon monoxide can causeheadache,
fatigue, dizziness,vomiting, confusion, seizures,
nausea,fainting or death.
. OperatepressurewasherONLYoutdoors.
•Keepexhaustgasfromenteringaconfinedareathrough
windows,doors,ventilationintakes,or otheropenings.
•DONOTstartor runengineindoorsor in anenclosedarea,
evenif windowsanddoorsareopen.
To Start Your Pressure Washer
To start your engine-powered pressurewasher for the first
time, follow these instructions step-by-step. This information
also applies wheneveryou start the engine after you havelet
the pressure washer sit idle for at least a day.
1. Placepressure washer outside near an water source
capableof supplying water at a flow rategreater than
2.9gallons per minute and no less than 20 PSIat
pressurewasher end of garden hose.
2. Checkthat high pressure hose istightly connectedto
spray gun and pump. SeeAssembyfor illustrations.
3. Makesure unit is in a levelposition.
4. Connectgarden hoseto water inlet on pressure washer
pump.
5. Turn ONwater, point gun in a safe direction and squeeze
trigger to purge pump system of air and impurities.
[NOTICE
DONOTrun the pump without the water supply connected
and turned on.
L amageto equipmentresultingfrom failureto followthis
instructionwillvoidwarranty.
6. Attach nozzleextension to spray gun. Tighten by hand.
7. Engagetrigger lock (A) on spray gun trigger.
10
