Craig CRT713 User manual

1
FCC INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.These limits are designed to provide
residential protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not Installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception. which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on the circuit different from that to which the
receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
The equipment may generate or use radio frequency energy. Changes or modifications to
this equipment may cause harmful interference unless the modifications are expressly
approved in the instruction manual. Modifications not authorized by the manufacturer may
void user’s authority to operate this device.
GENERAL WARNINGS:
1. Important Instructions:
zThis product is suitable for 14 years old and above. Please read the instruction
manual before you play with this product.
2. Make sure the unit always within the Radio Frequency
control range. Otherwise, the unit will out of control and may crash.
3. Safety Instructions:
zKeep away from the objects and crowds.
¾The unit is flying at high speed; keep it away from crowds, buildings, high voltage
wires, etc.
¾Do not operate this unit in bad weather.
zKeep away from water and rain.
The unit has electronic and mechanical parts which may be damaged by water.
zKeep away from the working unit.
The blades are turning in high speed, always keep away from it.

2
LOCATION OF CONTROLS:
Main Unit:
1. Blades
2. Battery Door
3. Power ON-OFF Switch
4. Connection Jack of Camera
5. Built-in Battery
6. DC IN Jack of Main Unit

3
Remote Control:
1. Power On-Off Button
2. Left Joystick
3. Right Joystick
4. H (High Speed ) Button
5. L (Low Speed) Button
6. Headless Button
7. Forward/Backward Trimmer
8. Left/Right Trimmer
9. 3D Rolling 1 Button
10. 3D Rolling 2 Button

4
Connect to any Computer or
USB Charger
(Computer and USB Charger
not included
)
PREPARATIONS:
Battery Recharging:
The unit has a built-in DC 3.7V Li-ion rechargeable battery, recharge it before first time
use or when it is consumed as follows:
1. Open the battery door by slide it out then lift up.
2. Take out the battery from the battery compartment. Connected the small jack from
the supplied USB Charging Cable to the connection plug of the battery.
3. Connected the full size USB Plug from the supplied USB Charging Cable to any
Computer or USB Charger having DC 5V output as the figure below:
4. During charging, the charging indicator on the full size USB Plug will illuminate.
When finished, it will turn off.
5. Disconnect the battery from the Computer or USB Charger.

5
6. Insert the connection plug from the battery to the DC IN Jack on the unit as the figure
below:
7. Replace the battery into the battery compartment then close the battery door.
Notes: Your battery will last longer if you follow these simple guidelines for charging for
and storing.
A. For normal charging, it need approx. 100 minutes.
B. Recharge and store the device within the temperature range of 5°C~35°C
(40°F~95°F).
C. Do not overcharge (longer than 24 hours). Excessive charging or discharging may
shorten the battery’s life.
D. Battery life naturally shortens slowly over time.

6
Install or replace the batteries of Remote Control:
If using the supplied Remote Control to control the unit. Install or replace (when the
batteries were consumed) the batteries as below:
1. Unsecure the screw from the battery door.
2. Open the battery door by slide it off then lift it up as the Fig. 1 below.
3. Install four (4) AA size batteries (not included ) into the battery compartment as the
polarity marking inside.( For longest playing time, Alkaline batteries are
recommended.)
4. Close the battery door as the Fig. 2 below and secure the screw on it.
BATTERY PRECAUTIONS:
Follow these precautions when using a battery in this device:
1. Using only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the
battery compartment. A reversed battery may cause damage to device.
3. Do not mix different types of batteries together (e.g. Carbon-zinc, Alkaline) or old
batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long
period of time, remove the batteries to prevent damage or injury from possible battery
leakage.
5. Do not try to recharge the battery after fully charged, it can overheat and rupture.
(Follow battery manufacturer's instructions.)
6. Do not dispose of battery in fire. Battery may explodes or leak.
7. Clean the battery contacts and also those of the device prior to battery installation.
Fig.1 Fig.2

8
OPERATION
Operation with Remote Control:
1. Recharge the built-in battery and connected it to the DC IN Jack on the unit as
previous procedure.
2. Slide the Power ON-OFF Switch on the bottom of unit to ON position to power on the
unit. The decorative lights will illuminate and blink.
3. Place the unit on a horizontal place.
4. Install the batteries to the Remote Control as the previous procedures. Press the
Power On-Off Button to turn on the Remote Control. The Power On Indicator will
illuminate.
5. Push the Left Joystick upward and then push it downward immediately to pairing the
Remote Control to the unit. Then:
A. Push the Left Joystick upward to rising.
B. Push the Left Joystick downward to reduce the height or landing.
C. Push the Left Joystick to left to turns the unit counterclockwise.
D. Push the Left Joystick to right to turns the unit clockwise.
E. Push the Right Joystick upward to fly to forward.
F. Push the Right Joystick downward to fly to backward.
G. Push the Right Joystick to left to fly to left.
H. Push the Right Joystick to right to fly to right.
I. Press the /Left/Right Trimmer repeatedly to fine tune the Joystick’s
control of Left/Right.
J. Press the /Forward/Backward Trimmer repeatedly to fine tune the
Joystick’s control of Forward/Backward.
K. Press 3D Rolling 1 Button to roll the unit in rolling mode 1.
L. Press 3D Rolling 2 Button to roll the unit in rolling mode 2.
M. Press the H/L (High/Low Speed) Button repeatedly to adjust the moving speed
as desired.
N. During flying, press the Headless Button to automatically identify the direction
where the Remote Control located. Then push the Right Joystick upward to fly
the unit to it. Press the button again to resume normal control.
6. To shut off the unit, push the Right Joystick to downward. Wait until the blade stop
running. Slide the Power ON-OFF Switch to OFF position to shut off the unit.
7. To shut off the Remote Control, press the Power On-Off Button again. The Power
On Indicator will not light.

12
The angle of camera can be adjust as below:
Replacement of Blades:
When the blade was damaged or deformed, replace it by the supplied same type (same
makings) spare blade with the supplied screwdriver as the figure below:
Note: Always replace the damaged blade by the same type (same makings) blade.
Otherwise, the motion of the unit will become abnormal.
Camera

13
TROUBLE SHOOTING:
SYMPTOM: POSSIBLE CAUSE POSSIBLE SOULTION
Remote Control not
functioning
The batteries consume. Replace by new batteries.
Batteries wrong installed.
Reinstall the batteries as the polarity marking
inside the battery compartment.
The unit not workable
The built-in battery had not
connected to the unit.
Connect the built-in battery to the unit as the
“PREPARATION” section point 6 on page 6.
The built-in battery consumes.
Recharge the built-in battery as the
“PREPARATION” section on page 5.
The unit had not paired to the
Remote Control.
Pair the unit to the Remote Control as
“OPERATION” section point 3-5 on page 8.
The blade still running
after landing
The unit had not shut off,
Push the Left Joystick on the Remote Control
to downward. Wait until the blades stop
turning. Unplug the battery from the unit by
disconnect the plug from battery to DC IN
Jack on the unit.
Control abnormal or
motion unstable
One (or more than one)
blade(s) deformed or
damaged.
Check and replace the deformed/damaged
blade(s) by new one.
The unit can not
moving straightly or
auto turning
Adjust the motion by:
Left/Right Trimmer and/or Forward/Backward
Trimmer.
