Crane Barnes 3SE-DS Series User manual

A Crane Co. Company
BARNESBARNES®
INSTALLATION and OPERATION MANUAL
Submersible Sewage Ejector
IMPORTANT! Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
 changeproductwithoutpriorwrittennotication.
420 Third Street 83 West Drive, Brampton
Piqua, Ohio 45356 Ontario, Canada L6T 2J6
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.cranepumps.com Form No. 088743-Rev. S
Series: 3SE-DS, 3HP
1750RPM, 60Hz.
(Double Seal)

2
TABLE OF CONTENTS
SAFETY FIRST............................................................................................... 3
A. PUMP SPECIFICATIONS ................................................................................4 - 5
B. GENERAL INFORMATION ..............................................................................6
C. INSTALLATION ................................................................................................6 - 7
ELECTRICAL DATA .........................................................................................7
D. START-UP OPERATION..................................................................................8
E. PREVENTATIVE MAINTENANCE ...................................................................8
F. SERVICE and REPAIR ....................................................................................8 - 12
G. REPLACEMENT PARTS..................................................................................13
TROUBLE SHOOTING....................................................................................14
CROSS-SECTION 3SE-DS 3450RPM (Fig. 9)................................................15
EXPLODED VIEW 3SE-DS 3450RPM (Fig. 10)..............................................16
PARTS LIST 3SE-DS 3450RPM ......................................................................17 - 18
CROSS-SECTION 3SE-DS 1750RPM (Fig. 11) ..............................................19
EXPLODED VIEW 3SE-DS 1750RPM (Fig. 12)..............................................20
PARTS LIST 3SE-DS 1750RPM ......................................................................21 - 22
RETURNED GOODS POLICY.........................................................................23
WARRANTY ...................................................................................................24
START-UP REPORT........................................................................................25 - 26
WARRANTY REGISTRATION
SPECIAL TOOLS AND EQUIPMENT
INSULATION TESTER (MEGGER)
DIELECTRIC TESTER
SEAL TOOL KIT ( see parts list)
PRESSURE GAUGE KIT (see parts list)
Other brand and product names are trademarks or registered trademarks of their respective holders.
® Barnes is a registered trademark of Crane Pumps & Systems, Inc
1996, 1997, 1998, 1999, 2001, 2002, 3/06, 9/06, 2/07 Alteration Rights Reserved

3
Please Read This Before Installing Or Operating Pump.
This information is provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help recognize this information,
observe the following symbols:
IMPORTANT! Warns about hazards that can result
in personal injury or Indicates factors concerned with
assembly, installation, operation, or maintenance which
could result in damage to the machine or equipment if
ignored.
CAUTION ! Warns about hazards that can or will cause minor
personal injury or property damage if ignored. Used with symbols
below.
WARNING ! Warns about hazards that can or will cause serious
personal injury, death, or major property damage if ignored. Used
with symbols below.
Only qualied personnel should install, operate and repair
pump. Any wiring of pumps should be performed by a qualied
electrician.
WARNING ! - To reduce risk of electrical shock, pumps
and control panels must be properly grounded in
accordance with the National Electric Code (NEC) or the
Canadian Electrical Code (CEC) and all applicable state,
province, local codes and ordinances.
WARNING! - To reduce risk of electrical shock, always
disconnect the pump from the power source before
handling or servicing. Lock out power and tag.
WARNING! Operation against a closed
discharge valve will cause premature bearing
and seal failure on any pump, and on end
suction and self priming pump the heat build
may cause the generation of steam with resulting dangerous
pressures. It is recommended that a high case temperature
switch or pressure relief valve be installed on the pump body.
CAUTION ! Never operate a pump with a plug-in type
power cord without a ground fault circuit interrupter.
CAUTION! Pumps build up heat and pressure
during operation-allow time for pumps to cool
before handling or servicing.
WARNING! - DO NOT pump hazardous materials
(ammable, caustic, etc.) unless the pump is specically
designed and designated to handle them.
Do not block or restrict discharge hose, as discharge
hose may whip under pressure.
WARNING! - DO NOT wear loose clothing that may
become entangled in the impeller or other moving parts.
WARNING! - Keep clear of suction and discharge
openings. DO NOT insert ngers in pump with power
connected.
Always wear eye protection when working on pumps.
Make sure lifting handles are securely fastened each
time before lifting. DO NOT operate pump without
safety devices in place. Always replace safety devices
that have been removed during service or repair.
Secure the pump in its operating position so it can not
tip over, fall or slide.
DO NOT exceed manufacturers recommendation for
maximum performance, as this could cause the motor
to overheat.
DO NOT remove cord and strain relief. Do not connect
conduit to pump.
WARNING! Cable should be protected at all times to
avoid punctures, cut, bruises and abrasions - inspect
frequently. Never handle connected power cords with
wet hands.
WARNING! To reduce risk of electrical shock, all wiring
and junction connections should be made per the NEC
or CEC and applicable state or province and local
codes. Requirements may vary depending on usage
and location.
WARNING! Submersible Pumps are not approved for
use in swimming pools, recreational water installations,
decorative fountains or any installation where human
contact with the pumped uid is common.
WARNING! Products Returned Must Be Cleaned,
Sanitized, Or Decontaminated As Necessary Prior
To Shipment, To Insure That Employees Will Not Be
Exposed To Health Hazards In Handling Said Material.
All Applicable Laws And Regulations Shall Apply.
Bronze/brass and bronze/brass tted pumps may
contain lead levels higher than considered safe for
potable water systems. Lead is known to cause cancer
and birth defects or other reproductive harm. Various
government agencies have determined that leaded
copper alloys should not be used in potable water
applications. For non-leaded copper alloy materials of
construction, please contact factory.
IMPORTANT! - Crane Pumps & Systems, Inc. is not
responsible for losses, injury, or death resulting from a
failure to observe these safety precautions, misuse or
abuse of pumps or equipment.
SAFETY FIRST!
Hazardous uids can
cause re or explo-
sions, burnes or death
could result.
Extremely hot - Severe
burnes can occur on contact.
Biohazard can cause
serious personal injury.
Hazardous uids can Hazard-
ous pressure, eruptions or ex-
plosions could cause personal
injury or property damage.
Rotating machinery
Amputation or severe
laceration can result.
Hazardous voltage can
shock, burn or cause death.

4
inches
(mm)
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN
ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT
INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED
MEDIA IS A COMMON OCCURRENCE.
DISCHARGE.................. 3” NPT, Vertical
LIQUID TEMPERATURE . 104°F (40°C) Continuous
MOTOR HOUSING ........ Cast Iron ASTM A-48, Class 30
VOLUTE......................... Cast Iron ASTM A-48, Class 30
SEAL PLATE ................. Cast Iron ASTM A-48, Class 30
IMPELLER:
Design...........2 Vane, Open with Pump out vanes
on Back side. Dynamically
balanced, ISO G6.3
Material ........ Cast Iron ASTM A-48, Class 30
SHAFT............................ 416 Stainless Steel
SQUARE RINGS............ Buna-N
HARDWARE .................. 300 Series Stainless Steel
PAINT ............................. Air dry enamel, top coat
SEAL Design.......... Double Mechanical in oil lled
pressure equalized reservoir
Material ........ Rotating Faces - Carbon
Stationary Faces - Ceramic
Elastomer - Buna-N
Hardware - 300 series stainless steel
CORD ENTRY................ 30 Ft. (9.1m) Cord. Epoxy sealed
housing with secondary pressure
grommet for sealing and strain relief
SPEED ........................... 1750RPM, 60Hz (nominal)
UPPER BEARING:
Design.......... Single Row, Ball, Oil Lubricated
Load ............. Radial
LOWER BEARING:
Design.......... Single Row, Ball, Oil Lubricated
Load ............. Radial & Thrust
MOTOR: Design.......... NEMA L, Single phase,
NEMA B, Three Phase Torque Curve,
Oil Filled, Squirrel Cage Induction
Insulation...... Class B
SINGLE PHASE.............Permanent Split Capacitor (PSC)
Includes overload protection in
motor
THREE PHASE..............230/460, 60Hz is Dual voltage
motor. Requires overload protection
to be included in control panel
MOISTURE SENSOR .... Normally Open, Requires relay in
control Panel
TEMP SENSOR ............. Normally Closed, Requires relay in
control Panel
OPTIONAL EQUIPMENT.. Seal Material, Impeller Trims,
Additional Cord.
SECTION: A - PUMP SPECIFICATIONS:
1750RPM

5
SECTION B: GENERAL INFORMATION
B-1) To the Purchaser:
Congratulations! You are the owner of one of the nest pumps
on the market today. CP&S pumps are products engineered
and manufactured of high quality components. Over one
hundred years of pump building experience along with a
continuing quality assurance program combine to produce a
pump which will stand up to the toughest applications. This
manual will provide helpful information concerning installation,
maintenance, and proper service guidelines.
B-2) Receiving:
Upon receiving the pump, it should be inspected for damage
or shortages. If damage has occurred, le a claim immediately
with the company that delivered the pump. If the manual
is removed from the packaging, do not lose or misplace.
B-3) Storage:
Short Term- CP&S Pumps are manufactured for e󰀩cient
performance following short inoperative periods in storage.
For best results, pumps can be retained in storage, as factory
assembled, in a dry atmosphere with constant temperatures
for up to six (6) months. Long Term- Any length of time
exceeding six (6) months, but not more than twenty-four (24)
months. The unit should be stored in a temperature controlled
area, a roofed over walled enclosure that provides protection
from the elements (rain, snow, wind-blown dust, etc.), and
whose temperature can be maintained between +40 deg. F
and +120 deg. F. (4.4 - 49°C). Pump should be stored in its
original shipping container. On initial start up, rotate impeller
by hand to assure seal and impeller rotate freely. If it is
required that the pump be installed and tested before the long
term storage begins, such installation will be allowed provided:
1.) The pump is not installed under water for more than
one (1) month.
2.) Immediately upon satisfactory completion of the test,
the pump is removed, thoroughly dried, repacked in the
original shipping container, and placed in a temperature
controlled storage area.
B-4) Service Centers:
For the location of the nearest Barnes Service Center, check
your Barnes representative or Crane Pumps & Systems, Inc.,
Service Department in Piqua, Ohio, telephone [phone]
or Crane Pumps & Systems Canada, in Brampton, Ontario,
[phone].
SECTION C: INSTALLATION
C-1) Location:
These pumping units are self-contained and are
recommended for use in a sump, lift station or basin. The
sump, lift station or basin shall be vented in accordance
with local plumbing codes. This pump is designed to pump
sewage, e󰀪uent, or other nonexplosive or noncorrosive
wastewater. and shall NOT be installed in locations classied
as hazardous in accordance with the National Electrical Code
(NEC), ANSI/NFPA 70 or The Canadian Electrical Code.
Never install the pump in a trench, ditch or hole with a dirt
bottom; the legs will sink into the dirt and the suction will
become plugged.
C-1.1) Submergence:
It is recommended that the pump be operated in the
submerged condition and the sump liquid level should never
be less than dimension “A” in Fig. 1.
C-2) Discharge:
Discharge piping should be as short as possible. Both a
check valve and a shut-o󰀨 valve are recommended for each
pump being used. The check valve is used to prevent back-
ow into the sump. Excessive backow can cause ooding
and/or damage to the pump. The shut-o󰀨 valve is used to
stop system ow during pump or check valve servicing.
Barnes Pumps supplies a breakaway tting discharge system
designed to allow the submersible wastewater pump to be
installed or removed without requiring personnel to enter the
wet well.
Place the Break Away Fitting (BAF) in position. Temporarily
secure the guide rails in the upper mounting brackets and
locate the base on the bottom of the wet well. Level the base
with grout and/or shims. Install the intermediate support
brackets, if required. Make sure the rails are in a true vertical
position so the pump will clear the access opening and
will slide freely down the rails into place on the discharge
stationary tting. Once the rails are in proper alignment, bolt
the base into the oor of the station and connect the discharge
pipe to the elbow.
Connect the movable portion and other supplied ttings of the
BAF onto the pump and lower into wet well. See the Break
Away Fitting manual for more information.
C-3) Liquid Level Controls:
The level controls are to be supported by a mounting bracket
that is attached to the sump wall, cover or junction box. Cord
grips are used to hold the cords in place on the mounting
bracket. The control level can be changed by loosening
the grip and adjusting the cord length as per the plans and
specications. Be certain that the level controls cannot hang up
or foul in it’s swing and that the pump is completely submerged
when the level control is in the “O󰀨” mode.
FIGURE 1
Recommended Submergence Level
Minimum Submergence Level
Bottom of Feet
A = 10”

6
C-4) Electrical Connections:
C-4.1) Power & Control Cords:
The cord assembly mounted to the pump must not be modied
in any way except for shortening to a specic application.
Any splice between the pump and the control panel must be
made in accordance with all applicable electric codes. It is
recommended that a junction box, if used, be mounted outside
the sump or be of at least Nema 4 (EEMAC-4) construction if
located within the wet well. DO NOT USE THE POWER OR
CONTROL CORDS TO LIFT PUMP. NOTE: THE WHITE
WIRE IS NOT A NEUTRAL OR GROUND LEAD. THE
BLACK, WHITE AND RED LEADS ARE POWER CARRYING
CONDUCTORS. THE GREEN LEAD IS FOR CONNECTION
TO GROUND.
C-4.2) Overload Protection :
C-4.2-1) Three Phase - The normally closed (N/C) thermal
sensor is embedded in the motor windings and will detect
excessive heat in the event an overload condition occurs. The
thermal sensor will trip when the windings become too hot and
will automatically reset itself when the pump motor cools to a
safe temperature. It is recommended that the thermal sensor
be connected in series to an alarm device to alert the operator
of an overload condition, and/or the motor starter coil to stop
the pump. In the event of an overload, the source of this
condition should be determined and rectied immediately. DO
NOT LET THE PUMP CYCLE OR RUN IF AN OVERLOAD
CONDITION OCCURS !
C-4.2-2) Single Phase - The type of in-winding overload
protector used is referred to as an inherent overheating
protector and operates on the combined e󰀨ect of temperature
and current. This means that the overload protector will trip out
and shut the pump o󰀨 if the windings become too hot, or the
load current passing through them becomes too high. It will
then automatically reset and start the pump up after the motor
cools to a safe temperature. In the event of an overload, the
source of this condition should be determined and rectied
immediately. DO NOT LET THE PUMP CYCLE OR RUN IF
AN OVERLOAD CONDITION OCCURS !
NOTE: Single phase pumps can be orederd with an optional
Thermal Sensor as well as the standard in winding overload
protection.
C-4.3) Moisture Sensors:
A normally open (N/O) detector is installed in the pump
seal chamber which will detect any moisture present. It is
recommended that this detector be connected in series to an
alarm device or the motor starter coil to alert the operator that
a moisture detect has occurred. In the event of a moisture
detect, check the individual moisture sensor probe leads
for continuity, (∞ resistance = no moisture ) and the junction
box/control box for moisture content. The above situations
may induce a false signal in the moisture detecting circuit. If
none of the above test prove conclusive, the pump(s) should
be pulled and the source of the failure identied and repaired.
IF A MOISTURE DETECT HAS OCCURRED SCHEDULE
MAINTENANCE AS SOON AS POSSIBLE.
If current through the temperature sensor exceeds the values
listed, an intermediate control circuit relay must be used to
reduce the current or the sensor will not work properly.
TEMPERATURE SENSOR ELECTRICAL RATINGS
Volts Continuous
Amperes
Inrush
Amperes
110-120 3.00 30.0
220-240 1.50 15.0
440-480 0.75 7.5
600 0.60 6.0
C-4.4) Wire Size:
Consult a qualied electrician for proper wire size if additional
power cable length is required. See table for electrical
information.
MODEL NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
WINDING
RESISTANCE
MAIN - START
3SE3024L 3.0 230/1 60 1750 A 28.0 59.0 10/3 SOW 0.690 (17.5) 0.84 - 4.0
3SE3034L 3.0 230/3 60 1750 D 19.0 56.0 10/4 SOW 0.750 (19.1) 1.40
3SE3044L 3.0 460/3 60 1750 D 9.0 28.0 10/4 SOW 0.750 (19.1) 6.30
3SE3054L 3.0 575/3 60 1750 E 8.3 23.0 10/4 SOW 0.750 (19.1) 9.90
Winding Resistance ± 5%. Pump rated for operation at ± 10% voltage at motor.
Moisture & Temperature sensor cord for all models is 18/5 SOW, 0.476 O.D.
OPTIONAL - Temperature sensor cord for 3 phase models is 14/2 SOW, 0.530 (13.5mm) O.D.

7
SECTION: D START-UP OPERATION
D-1) Check Voltage and Phase:
Before operating pump, compare the voltage and phase
information stamped on the pump identication plate to the
available power.
D-2) Check Pump Rotation:
Before putting pump into service for the rst time, the motor
rotation must be checked. Improper motor rotation can
result in poor pump performance and can damage the motor
and/or pump. To check the rotation, suspend the pump
freely, momentarily apply power and observe the “kickback”.
“Kickback” should always be in a counter-clockwise direction
as viewed from the top of the pump motor housing.
D-2.1) Incorrect Rotation for Three-Phase Pumps:
In the event that the rotation is incorrect for a three-phase
installation, interchange any two power cable leads at the
control box. DO NOT change leads in the cable housing in the
motor. Recheck the “kickback” rotation again by momentarily
applying power.
D-2.2) Incorrect Rotation for Single-Phase Pumps:
In the unlikely event that the rotation is incorrect for a single
phase pump, contact a Barnes Service Center.
D-3) Start-Up Report:
Included at the end of this manual is a start-up report sheet,
this sheet is to be completed as applicable. Return one copy
to Barnes and store the second in the control panel or with
the pump manual if no control panel is used. It is important to
record this data at initial start-up since it will be useful to refer
to should servicing the pump be required in the future.
D-3.1) Identication Plate:
Record the numbers from the pump identication plate on both
START-UP REPORTS provided at the end of the manual for
future reference.
D-3.2) Insulation Test:
Before the pump is put into service, an insulation (megger)
test should be performed on the motor. The resistance values
(ohms) as well as the voltage (volts) and current (amps) should
be recorded on the start-up report.
D-3.3) Pump-Down Test:
After the pump has been properly wired and lowered into the
basin, sump or lift station, it is advisable to check the system
by lling with liquid and allowing the pump to operate through
its pumping cycle. The time needed to empty the system, or
pump-down time along with the volume of water, should be
recorded on the start-up report.
SECTION E: PREVENTATIVE MAINTENANCE
As the motor is oil lled, no lubrication or other maintenance
is required, and generally Barnes Pumps will give very
reliable service and can be expected to operate for years on
normal sewage pumping without failing. However as with any
mechanical piece of equipment a preventive maintenance
program is recommended and suggested to include the
following checks:
1) Inspect motor and seal chambers for oil level and
contamination and repair as required per section F-1.
2) Inspect impeller and body for excessive build-up or
clogging and repair as required per section F-2.
3) Inspect motor and bearings and replace as required per
section F-3.
4) Inspect seal and diaphragm for wear or leakage and repair
as required per section F-4.
SECTION F: SERVICE AND REPAIR
NOTE: All item numbers in ( ) refer to Figures 9 & 10,
3450RPM and Figures 11 & 12 , 1750RPM.
F-1) Lubrication:
Anytime the pump is removed from operation the cooling oil
in the motor housing (2) and seal chamber, must be checked
visually for oil level and contamination.
F-1.1) Checking Oil:
Motor Housing - To check oil, set unit upright. Remove cap
screws (6) and lockwashers (4), lift conduit box assembly (9)
from motor housing (2) but DO NOT disconnect conduit box
wiring from motor leads. With a ashlight, visually inspect the
oil in the motor housing (2) to make sure it is clean, clear and
that oil level is above all internal componentry.
Seal Chamber - Place pump on its side with the square
head pipe cap (22) downward, remove pipe cap (22) and
drain oil from the seal chamber. If the oil is found to contain
considerable water or other contamination or little oil drains
out, the shaft seal (38) and diaphragm (31) should be
inspected and replaced if required.
F-1.2) Testing Oil:
1. Place pump on it’s side, remove cap screws (6) and
lockwashers (4), lift conduit box assembly (9) from
motor housing (2) and drain oil into a clean, dry container.
In separate container drain seal chamber by removing
pipe cap (22).
2. Check oil for contamination using an oil tester with a
range to 30 Kilovolts breakdown.
3. If oil is found to be clean and uncontaminated (measure
above 15 KV. breakdown), rell the motor housing and
seal chamber as per section F-1.3.
4. If oil is found to be dirty or contaminated (or measures
below 15 KV. breakdown), the the pump must be carefully
inspected for leaks at the shaft seal (38), conduit box
assembly (9), diaphragm (31), O-rings (10) and (36),
pipe cap (22) and pipe plug (5) before relling with oil.
To locate the leak, perform a pressure test as per
section F-1.4.
After leak is repaired, rell with new oil as per section
F-1.3.
F-1.3) Replacing Oil:
Motor Housing - Drain all oil from motor housing and
dispose of properly. Rell with (see parts list for amount) new
cooling oil as per Table 1. An air space must remain in the top
of the motor housing to compensate for oil expansion (see
Fig. 9 or 11). Set unit upright and ll only until the motor, as
viewed through the conduit box opening, is just covered and
no more. Reassemble the O-ring (10), conduit box assembly
(9), cap screws (6) and lockwashers (4), apply Locktite (47)
to each cap screw (6) thread before installing. Torque cap
screws (6) to 17.5 ft, lb.
Seal Chamber - Rell chamber completely full with new
cooling oil per Table 1 or reuse the uncontaminated oil.
Important!-DONOToverlloil.
Overllingofmotorhousingwithoilcan
create excessive and dangerous hydraulic
pressure which can destroy the pump
andcreateahazard.Overllingoilvoids
warranty.

8
F-1.4) Pressure Test:
Motor Housing - Before checking the pump for leaks around
the shaft seal, square rings, and cord inlet, the oil level should
be full as described in section F-1.3. Remove pipe plug
(5) and lifting handle (7) from motor housing (2).Apply pipe
sealant to pressure gauge assembly and tighten into pipe
plug hole (see Fig. 2). Pressurize motor housing to 10 P.S.I.
Use a soap solution around the sealed areas and inspect
joints for “air bubbles”. If, after ve minutes, the pressure is
still holding constant, and no “bubbles” are observed, slowly
bleed the pressure and remove the gauge assembly. Replace
the pipe plug using a sealant. If the pressure does not hold,
then the leak must be located.
Seal Chamber - Remove pipe cap (22) and pipe plug (21)
from Bearing Bracket (20) and check that seal chamber is
full of oil. Apply pipe sealant to pressure gauge assembly
and tighten into hole in bearing bracket (20). Pressurize seal
chamber to 10 PSI and check for leaks as outlined above.
Caution ! - Pressure builds up extremely
fast, increase pressure by “tapping” air
nozzle. Too much pressure will damage
seal. DO NOT exceed 10 P.S.I. in motor
housing & 10 P.S.I. in seal chamber.
TABLE 1 - COOLING OIL - Dielectric
SUPPLIER GRADE
BP Enerpar SE100
Conoco Pale Para󰀩n 22
Mobile D.T.E. Oil Light
G & G Oil Circulating 22
Imperial Oil Voltesso-35
Shell Canada Transformer-10
Texaco Diala-Oil-AX
Woco Premium 100
F-2) Impeller and Volute Service:
F-2.1) Disassembly and Inspection:
To clean out volute (25), disconnect power, remove hex nuts
(19), lockwashers (18) and socket head cap screws (42),
vertically lift motor and seal assembly from body (25). Clean
out body if necessary. Clean and examine impeller (27) for
pitting or wear, replace if required. Inspect Square Ring (36)
and replace if cut or damaged.
If impeller (27) requires replacing, remove cap screw (33)
and washer (34). The impeller is keyed onto the shaft with a
square key (32) and to remove, pull impeller straight o󰀨 the
shaft using a wheel puller, if required. Before reinstalling,
check the motor shaft and impeller bore for damage.
F-2.2) Reassembly:
To install impeller (27), apply a thin lm of oil to motor shaft
and slide impeller straight onto shaft, keeping keyways lined
up. Drive key (32) into keyway. Locate washer (34), apply
Loctite (46) to shaft threads, thread hex nut (33) to shaft and
torque to 35 ft. lbs. Rotate impeller to check for binding.
Position square ring (36) on volute ange and install impeller
and motor housing over studs and onto volute (25). Apply
thread locking compound to threads of each stud (23) and
socket head cap screw (42). Thread nut (19) onto stud (23)
and thread socket head cap screw (42) into volute (25),
torque to 24 ft. lbs. Check for free rotation of motor and
impeller.
F-3) Motor and Bearing Service
F-3.1) Disassembly and Inspection:
To examine or replace the motor (1) and bearing (39),
disassemble pump, volute and impeller (as outlined in
paragraph F-2.1) and disassemble seal plate and shaft seal
(as outlined in paragraph F-4.1). Drain oil from motor as
outlined in paragraph F-1.3.
Position unit upright, using blocks to avoid resting unit on
shaft. After removal of cable and box assembly (9) from motor
housing (2), remove cable lead wires from motor lead wires
and moisture and temperature sensors wires (if equipped)
from control cable by unscrewing connectors (11) and (16).
The wiring connections should be noted to insure correct
connections when reassembling. Vertically lift the outside
motor housing (2) from bearing bracket (20) with lifting strap
(7). Inspect square ring (36) for damage or cuts. Remove the
upper motor bolts and lift upper end bell from motor (1).
Vertically lift stator. Inspect winding for shorts and resistance.
To test the temperature sensor (if equipped), check for
continuity between the black and white wires. If found to be
defective contact a motor service station or Barnes Pumps
service department. Remove retaining ring (28) from bearing
bracket (20) and pull motor rotor and lower bearing (39)
vertically from bearing bracket (20). Examine bearing (39)
and replace if required. If replacement is required, remove
retaining ring (29) from motor shaft and remove bearing (39)
from motor shaft using a wheel puller. Check rotor for wear.
If rotor or the stator windings are defective, the complete
motor must be replaced. Check motor capacitor (3) on single
phase units and replace if defective. While disassembled,
check moisture sensor wires (15) (if equipped), that they are
secured to electrodes (17) with screws (13).
REMOVE HANDLE
REMOVE PIPE
PLUG
PRESSURE GAUGE
ASSEMBLY
10 PSI 
AIR
10 PSI
AIR 
FIGURE 2

9
Important ! - ALL parts must be clean before
reassembly.
F-3.2) Reassembly:
Bearing - When replacing bearing, be careful not to damage
the rotor or shaft threads. Clean the shaft thoroughly.
Insert retaining ring (29) onto motor shaft. Apply adhesive
compound to the shaft and press bearing (39) on the motor
shaft, position squarely onto the shaft applying force to the
inner race of the bearing only, until bearing seats against
retaining ring (29).
Motor - Slide lower bearing (39) and motor rotor squarely into
the bearing bracket (20) until bearing seats on the bottom.
Insert retaining ring (28) into bearing bracket (20).
Position motor housing and stator into pilot, aligning holes
in bearing bracket (20). Apply thread locking compound on
motor bolts and tighten. Torque motor bolts to 17 ft. lbs. Place
all motor leads above the motor. Position square ring (36) on
bearing bracket (20) and lower housing (2) over motor and
into pilot. Make wire connections per paragraph F-3.3.
F-3.3) Wiring Connections:
Check power cable (9A) and control cable (9E) (if used), on
conduit box (9),for cracks or damage and replace complete
conduit box assembly (9) if required (see Fig. 4). Bring motor
wires through wire opening in top of housing (2), position
square ring (10) in conduit housing (9) and reconnect motor
leads to power cable and moisture and temperature sensor
leads to control cable (if equipped) using connectors (11) and
(16) as show in Fig. 3.
CONNECTORS
CONNECTORS
CONNECTORS
CONNECTORS
FIGURE 3
SINGLE PHASE, 230 VOLT AC
Power Cable (9a) Motor Lead Number
Green (Ground) Green
Black 1
White 2
Flag Terminal Capacitor
Flag Terminal Capacitor
THREE PHASE, 200/230 VOLT AC
Power Cable (9a) Motor Lead Number
Green (Ground) Green
Black 1 & 7
Red 2 & 8
White 3 & 9
4, 5 & 6 Together
THREE PHASE, 460/575 VOLT AC
Power Cable (9a) Motor Lead Number
Green (Ground) Green
Black 1
Red 2
White 3
4 & 7 Together
5 & 8 Together
6 & 9 Together

10
MOISTURE AND TEMPERATURE SENSORS
Control Cable (9D) Lead Number
Black P1 (Temperature Sensor)
White P2 (Temperature Sensor)
Red W1 (Moisture Sensor)
Orange W2 (Moisture Sensor)
Green Ground
F-3.4) Conduit Box and Cable Assembly:
Rell with cooling oil as outlined in paragraph F-1.3. Position
conduit box (9) and square ring (10) over opening. Place
lockwashers (4) on cap screws (6), apply Loctite (47) to cap
screws (6) threads and torque to 16 ft lbs. Remove gland nuts
(9B) and (9F), friction rings (9C) and (9G), and grommets
(9D) and (9H) from conduit box (9) inspect and replace if
required.(see Fig. 4)
Insert one friction ring (9C), grommet (9D), one friction ring
(9C) and gland nut (9B) into conduit box for power cable (9A).
For control cable (9E) (if used), insert grommet (9H), friction
ring (9G) and gland nut (9F). Torque gland nuts (9B) and (9F)
to 15 ft. lbs to prevent water leakage.
F-4) Shaft Seal and Diaphragm Service:
Important ! - Handle seal parts with extreme care.
DO NOT scratch or mar lapped surfaces.
F-4.1) Disassembly and Inspection:
Diaphragm - To examine or replace the diaphragm (31)
or shaft seal (38), remove impeller (27) as outlined in
paragraph F-2.1. Drain oil from seal chamber as outlined in
paragraph F-1.3. Remove cap screws (8) and lifting strap
(7). Set unit upside down on blocks to avoid damaging cords.
Remove socket head cap screws (35) and lift seal plate (24)
vertically, being cautious to avoid seal damage, together with
diaphragm (31), clamp (37) and outboard stationary member
(38A) of shaft seal (38), from bearing bracket (20). Examine
diaphragm (31), if it is ruptured, cracked or damaged, replace
by removing screws (6), lockwashers (4) and diaphragm
clamp (37), Also, clean out vent holes in seal plate (24).
Check moisture sensor probes (17) (if equipped) for damage.
Replace by disconnecting wires (15) by removing screws
(13). Then remove probe (17) from bearing bracket (20). Pipe
plugs (30) replace sensor probes (17) when pump is supplied
without moisture sensors.
Seal - To expose shaft seal (38) for examination, complete
above procedure and slide o󰀨 outboard rotating member
(38B). See Fig. 5. Remove inboard rotating member (38D),
from shaft. Examine all seal parts and especially contact
faces. Inspect seal for signs of wear such as uneven wear
pattern on stationary members, chips and scratches on either
seal face. DO NOT interchange seal components, replace the
entire shaft seal (38).
F-4.2) Reassembly:
Diaphragm- At reassembly, make sure the bulge and molded-
in part number of diaphragm (31) is facing the seal plate
(24). With diaphragm (31) in place, lay diaphragm clamp (37)
in place on seal plate (24) and insert the four cap screws
(6) and lockwashers (4) and tighten. Apply pipe thread
compound to moisture sensor probe (17), if equipped (or pipe
plugs 30), and insert in bearing bracket (20). Attach wires (15)
with screws (13).
FIGURE 4
Gland Nut (9B)
Power Cord (9A)
Friction Ring (9C)
Grommet (9D)
Friction Ring (9C)
Gland Nut (9F)
Control Cord (9E)
Friction Ring (9G)
Grommet (9H)
Friction Ring (9G)
Conduit Box & Cable
Assembly (9)

11
Seal - Clean and oil seal cavities in bearing bracket (20)
and seal plate (24). Lightly oil (DO NOT use grease) outer
surface of inboard stationary member (38E) and outboard
stationary member (38A). Press inboard stationary member
(38E) rmly into bearing bracket (20) and outboard stationary
(38A) into seal plate (24), using a seal pusher nothing but the
seal pusher is to come in contact with seal face (see Fig. 7).
Important ! - DO NOT hammer on the seal pusher-
it will damage the seal face.
Make sure the stationary members are in straight and that the
rubber ring is not out of it’s groove. Slide a bullet over motor
shaft. Lightly oil (DO NOT use grease) shaft, bullet and inner
surface of bellows on rotating member (38D) see Fig. 8. With
lapped surface facing bearing bracket (20), slide rotating
member (38D) over bullet and onto shaft, using seal pusher,
until lapped faces of (38D) and (38E) are together (see Fig.
6).
Important ! - It is extremely important to keep
seal faces clean during assembly. Dirt particles
lodged between these faces will cause the seal to
leak.
Make sure driving lugs in retainer are matched in rotating
member. Place spring (38C) over shaft and in place on
rotating member (38E), making sure it is seated in retainer
and not cocked or resting on bellows tail. Re-oil shaft and
lightly oil inner surface of outboard rotating member (38B)
With tail section toward bearing bracket (20), slide rotating
member (38B) over bullet onto shaft with seal pusher until
retainer engages spring (38C) and spring is compressed
slightly. Make sure spring (38C) is properly engaged in both
retainers. Insert O-ring (36) onto bearing bracket (20). Slide
seal plate (24) over shaft onto bearing bracket (20), being
careful not to damage outboard stationary member (38A) and
align holes for socket head cap screws (35). Thread socket
head cap screws (35) into bearing bracket (20) and tighten.
Assemble impeller and volute per paragraph F-2.2. Fill seal
chamber with oil as outlined in paragraph F-1.3.
FIGURE 7
Stationary Member (38A) &
(38E), Polished Face Out
Seal Plate (25) &
Bearing Bracket (20)
Seal Pusher
Rotating Member (38D)
Bullet
Motor & Seal Plate
Seal Pusher
Stationary
FIGURE 8
FIGURE 5 FIGURE 6

12
SECTION: G REPLACEMENT PARTS
G-1 ORDERING REPLACEMENT PARTS:
When ordering replacement parts, ALWAYS furnish the
following information:
1. Pump serial number and date code. (Paragraph G-4)
2. Pump model number. (Paragraph G-3)
3. Pump part number. (Paragraph G-2)
4. Part description.
5. Item part number.
6. Quantity required.
7. Shipping instructions.
8. Billing Instructions.
G-2 PART NUMBER:
The part number consists of a six (6) digit number, which
appears in the catalog. A one or two letter su󰀩x may follow this
number to designate the design conguration. This number is
used for ordering and obtaining information.
G-3 MODEL NUMBER:
This designation consists of numbers and letters which
represent the discharge size, series, horsepower, motor phase
and voltage, speed and pump design. This number is used for
ordering and obtaining information.
G-4 SERIAL NUMBER:
The serial number block will consist of a six digit number,
which is specic to each pump and may be preceded by
a alpha character, which indicates the plant location. This
number will also be su󰀩xed with a four digit number, which
indicates the date the unit was built (Date Code). EXAMPLE:
A012345 0490.
Reference the six digit portion (Serial Number) of this number
when referring to the product.

13
TROUBLE SHOOTING
CAUTION ! Always disconnect the pump from the electrical power source before handling.
If the system fails to operate properly, carefully read instructions and perform maintenance recommendations.
If operating problems persist, the following chart may be of assistance in identifying and correcting them:
MATCH “CAUSE” NUMBER WITH CORRELATING “CORRECTION” NUMBER.
NOTE: Not all problems and corrections will apply to each pump model.
PROBLEM CAUSE CORRECTION
Pump will not run 1. Poor electrical connection, blown fuse,
tripped breaker or other interruption of power,
improper power supply.
2. Motor or switch inoperative (to isolate
cause, go to manual operation of pump).
2a. Float movement restricted.
2b. Switch will not activate pump or is defective.
2c. Defective motor
3. Insu󰀩cient liquid level.
1. Check all electrical connections for
security. Have electrician measure current
in motor leads, if current is within ±20%
of locked rotor Amps, impeller is probably
locked. If current is 0, overload may be
tripped. Remove power, allow pump to cool,
then recheck current.
2a. Reposition pump or clean basin as
required to provide adequate clearance for
oat.
2b. Disconnect level control. Set ohmmeter
for a low range, such as 100 ohms full scale
and connect to level control leads. Actuate
level control manually and check to see that
ohmmeter shows zero ohms for closed switch
and full scale for open switch. (Float Switch).
2c. Check winding insulation (Megger Test)
and winding resistance. If check is outside
of range, dry and recheck. If still defective,
replace per service instructions.
3. Make sure liquid level is at least equal to
suggested turn-on point.
4. Recheck all sizing calculations to
determine proper pump size.
5. Check discharge line for restrictions,
including ice if line passes through or into
cold areas.
6. Remove and examine check valve for
proper installation and freedom of operation.
7. Open valve.
8. Check impeller for freedom of operation,
security and condition. Clean impeller and
inlet of any obstruction.
9. Loosen union slightly to allow trapped air
to escape.Verify that turn-o󰀨 level of switch
is set so that the suction is always ooded.
Clean vent hole.
10. Check rotation. If power supply is three
phase, reverse any two of three power supply
leads to ensure proper impeller rotation..
11. Repair xtures as required to eliminate
leakage.
12. Check pump temperature limits & uid
temperature.
13. Replace portion of discharge pipe with
exible connector.
14. Turn to automatic position.
15. Check for leaks around basin inlet and
outlets.
Pump will not turn o󰀨 2a. Float movement restricted.
2b. Switch will not activate pump or is defective.
4. Excessive inow or pump not properly sized
for application.
9. Pump may be airlocked
14. H-O-A switch on panel is in “HAND” position
Pump hums but does not run 1. Incorrect voltage
8. Impeller jammed or loose on shaft, worn or
damaged, impeller cavity or inlet plugged.
Pump delivers insu󰀩cient capacity 1. Incorrect voltage.
4. Excessive inow or pump not properly sized
for application.
5. Discharge restricted.
6. Check valve stuck closed or installed backwards.
7. Shut-o󰀨 valve closed.
8. Impeller jammed or loose on shaft, worn or
damaged, impeller cavity or inlet plugged.
9. Pump may be airlocked.
10. Pump running backwards
Pump cycles too frequently or runs
periodically when xtures are not in use
6. Check valve stuck closed or installed
backwards.
11. Fixtures are leaking.
15. Ground water entering basin.
Pump shuts o󰀨 and turns on indepen-
dent of switch, (trips thermal overload
protector). CAUTION! Pump may start
unexpectedly. Disconnect power supply.
1. Incorrect voltage.
4. Excessive inow or pump not properly sized
for application.
8. Impeller jammed, loose on shaft, worn or
damaged, impeller cavity or inlet plugged.
12. Excessive water temperature.
(internal protection only)
Pump operates noisily or vibrates
excessively
2c. Worn bearings, motor shaft bent.
5. Debris in impeller cavity or broken impeller
10. Pump running backwards
13. Piping attachments to buiding structure too
rigid or too loose.

14
3SE-DS 1750RPM
FIGURE 11

15
FIGURE 12
3SE-DS 1750RPM

16
PARTS LIST - 1750RPM
Seal Repair Kits
Double Seal........P/N - 130178 (†) 10, 31, 36, 38
Service Kits
Double Seal........P/N - 130174 (♦) 10, 11, 16, 28, 29, 30, 31, 32, 33, 36, 38, 39
Seal Tool Kit...............P/N-085736
Pressure Gauge Kit...P/N-085343
ITEM QTY PART NO. DESCRIPTION
1 1 088758 Motor 3SE3024DS
088763 3SE3034DS, 44DS
088766 3SE3054DS
2 1 053154 Motor Housing
3 1 036391 Capacitor 370V 45MFD
4 8 20-13-1 Lockwasher 1/4” Stainless
5 1 003204 Pipe Plug
6 8 1-7-1 Cap Screw 1/4-20 x 1” Lg Stainless
7 1 036754 Lifting Strap
8 2 1-65-1 Cap Screw 1/2-13 x 7/8” Lg Stainless
9 1 See Table 3 Conduit Box & Cable Assembly
9a 1 ----- Power Cable (Not Sold Separately)
9b 1 051447 Gland Nut 1 Phase
051447 Gland Nut 3 Phase
9c 2 066071 Friction Ring 1 Phase
051450 Friction Ring 3 Phase
9d 1 051452 Grommet 3 Phase
9e 1 ----- Control Cable (Not Sold Separately)
9f 1 051448 Gland Nut
9g 1 021531 Friction Ring
9h 1 066871 Grommet
9j 1 030169 Ground Screw 10-32 x 1/2 Lg Stainless
10 1 017026 †♦ Square Ring
11 4 074449 Wire Connector
12 1-1/2 Gal. 029034 Oil- Motor Housing
1-1/4 Qts 029034 Oil - Seal Cavity
13 2 038156 Machine Screw #6-32 x 3/8” Lg Zinc Plt Steel
14 1 033459 Bracket
15 2 051487 Moisture Sensor Wire
16 6 052990 ♦Wire Connector
17 2 066843 Moisture Sensor
18 4 20-14-1 Lockwasher 3/8” Stainless
19 4 15-23-1 Hex Nut 3/8-16 Stainless
20 1 065892 Bearing Bracket
21 1 003276 Pipe Nipple .375” NPT
22 1 036842 Pipe Cap
23 4 066103 Stud 3/8-16 x 3-7/8” Lg Stainless
24 1 065893 Seal Plate
25 1 062640 Volute
26 1 034322 Terminal Boot
27 1 088534 Impeller, Cast Iron, 7.50” Dia., (STD)
088534TA 7.38” Dia.
088534TB 7.25” Dia.
088534TC 7.12” Dia.
088534TD 7.00” Dia.
088534TE 6.88” Dia.
088534TF 6.75” Dia.
088534TG 6.62” Dia.
088534TH 6.50” Dia.
088534TJ 6.38” Dia.
088534TK 6.25” Dia.
088534TL 6.12” Dia.
088534TM 6.00” Dia.
088534TN 5.88” Dia.
088534TP 5.75” Dia.
088534TQ 5.62” Dia.
28 1 066130 ♦Retaining Ring
(*) Included with item number 9.

17
29 1 057882 ♦Retaining Ring
30 2 003217 ♦Pipe Plug (Replaces Item 18)
31 1 022873 †♦ Diaphragm
32 1 059186 ♦Shaft Key 3/16 Sq x 1” Lg Stainless
33 1 038132 ♦Hex Nut 5/8-18 Stainless
35 2 11-32-1 Soc. Hd. Cap Screw 1/4-20 x 1” Lg Stainless
36 2 033730 †♦ O-Ring
37 1 022879 Diaphragm Clamp Ring
38 1 064434 †♦ Shaft Seal (Both Ends) Carbon/Ceramic/Buna-N (STD)
071796 (Pump End) Tungsten/Tungsten/Buna-N
071796D (Both Ends) Tungsten/Tungsten/Buna-N
39 1 053746 ♦Ball Bearing
40 1 051621 Temperature Sensor
41 2 039111 Temperature Sensor Wire
42 2 066192 Soc. Hd. Cap Screw 1/4-20 x 2-1/4” Lg Stainless
45 2 039934 Cap Plug
46 A/R ----- Loctite, RC609
47 A/R ----- Loctite, 242
48 2 2-12008 Cable Tie, 7.31” Lg
49 A/R ----- Primer
50 A/R ----- Adhesive, Loctite, PST567
TABLE 2 - POWER & SENSOR CORD SETS
MODELS/
LENGTH
ITEM #9
1 PHASE
ITEM #9
3 PHASE
ITEM #9
NO SENSOR
30 Ft. (STD) 074439XC 074440XC 074441XC
40 Ft. 074439XE 074440XE 074441XE
50 Ft. 074439XF 074440XF 074441XF
75 Ft. 074439XJ 074440XJ 074441XJ
100 Ft. 074439XL 074440XL 074441XL
125 Ft. 074439XP 074440XP 074441XP
150 Ft. 074439XS 074440XS 074441XS
175 Ft. 074439XV 074440XV 074441XV
200 Ft. 074439XY 074440XY 074441XY

18
IMPORTANT!
WARRANTY REGISTRATION
Your product is covered by a warranty:
www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf
If you have a claim under the provisions of the warranty, contact your local
Crane Pumps & Systems, Inc. Distributor.
RETURNED GOODS
RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”.
CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR.
Products Returned Must Be Cleaned, Sanitized,
Or Decontaminated As Necessary Prior To Shipment,
To Insure That Employees Will Not Be Exposed To Health
Hazards In Handling Said Material. All Applicable Laws
And Regulations Shall Apply.
IMPORTANT!
WARRANTY REGISTRATION
Your product is covered by the enclosed Warranty.
If you have a claim under the provision of the warranty, contact your local
Crane Pumps & Systems, Inc. Distributor.
