Crate&Barrel SLOANE User manual

SLOANE GREY/MAHOGANY LEANING DESK
1 - left
upright
1 - right
upright
2 - shelves
TOOLS REQUIRED
allen wrench (included)
phillips head screwdriver
Drill and 1/4"drill bit
Made in Indonesia - r01 Page 1 of 4
Thank you for purchasing the Sloane Grey/Mahogany
Leaning Desk. This page lists all the contents included in the
box. Please take the time to identify the hardware as well as
the individual components to this product. As you unpack
and prepare for assembly, place the contents on a carpeted
or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
Missing hardware?
Please call 800.606.6387
for replacements.
HARDWARE
COMPONENTS
BOX 1
2 - large
bolts
6 - small
bolts
17 - small
screws
1 - top
crossbar
4 - medium
screws
2 - wall
fittings
1 - wall
strap
1 - plastic
anchor
4 - wood
dowels
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
1 Insert 4 wood dowels into top crossbar as
shown.
2 - connecting
plates
2 - desktop
brackets
(1 left, 1 right)
1 - desktop
1 - large
screw
COMPONENTS
BOX 2

Made in Indonesia - r01 Page 2 of 4
SLOANE GREY/MAHOGANY LEANING DESK
C
B
top
crossbar
left
upright
shelves
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
A
C
top
crossbar
right
upright
B
A
desktop
4 Attach 2 right/left desktop brackets to the bottom of
assembled unit as shown with 8 small screws per
bracket. Do not fully tighten each screw before all the 8
screws are attached. At this point, secure screws with a
screwdriver. Position unit upright.
Assembly is now complete.
2 A) Fit dowels of top crossbar
into right upright. Secure top
crossbar with 1 large bolt as
shown, using a phillips head
screwdriver.
B) Position right upright with 2
shelves (in descending depths)
and 1 desktop as shown. Place
the shortest depth shelf at the top
of the uprights, and desktop at
the bottom.
C) Insert 1 small bolt through
each shelf and desktop side.
Secure each screw with an allen
wrench.
3 A) Fit dowels of top crossbar into left upright. Secure
top crossbar with 1 large bolt as shown, using a phillips
head screwdriver.
B) Position left upright with 2 shelves and a desktop as
shown.
C) Insert 1 small bolt through each shelf and desktop side.
Secure each screw with an allen wrench. Position unit
upright.
rear
right desktop
bracket
front
NOTE: Do not fully
tighten the screws until
all 8 screws are inserted
into each bracket
A
large bolt

Made in Indonesia - r01 Page 3 of 4
SLOANE GREY/MAHOGANY LEANING DESK
SAFETY MOUNTING ASSEMBLY
For added safety and stability, it is recommended that the wall mounting
hardware be installed. For safe mounting, it is essential to use wall
anchors appropriate to your wall type (i.e. plaster, drywall, concrete, etc.).
Mount to wood studs whenever possible.
A) Attach 1 wall fitting to assembled unit as shown, using 1 small
screw.
B) Determine the final location of shelving unit. Mark position on the
wall, approximately 2" below the bracket mounted to the back of the unit.
C) Drill a hole in the wall stud. If the wall stud is not available, drill a hole
in the wall that is slightly smaller in diameter than the anchor. Gently tap
the plastic anchor until the flange of the anchor is flush with the wall.
D) Attach the wall fitting to the wall by inserting 1 large screw through
the wall fitting and into the plastic anchor in the wall.
E) Place the unit so the wall fitting on the back edge is aligned with the
wall fitting on wall.
F) Lace one end of the wall strap through both fittings, and into the
other end of the strap.
G) Pull the strap tightly until secure.
Mounting assembly is now complete.
NOTE:
If you are unsure about your
wall type or what mounting
method you should use,
consult a qualified
professional or your local
hardware store.
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
CLEANING AND CARE
Clean surfaces with a dry or
damp soft cloth. Do not use
abrasive cleaners.
A
wall fitting &
small screw
C
F
wall strap
plastic
anchor
D
large screw

Made in Indonesia - r01 Page 4 of 4
SLOANE GREY/MAHOGANY LEANING DESK
MULTIPLE LEANING SHELVES/DESK ASSEMBLY
If you purchased multiple leaning items, it is suggested that every two or
more item be secured together. As shown, connect every 2 units with 2
connecting plates. Attach each plate with 2 medium screws using a
screwdriver. Repeat steps for each additional leaning unit item.
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com

SLOANE GREY/MAHOGANY LEANING BOOKCASE
1 - left
upright
1 - right
upright
5 - shelves
TOOLS REQUIRED
allen wrench (included)
phillips head screwdriver
Drill and 1/4"drill bit
Made in Indonesia - r01 Page 1 of 4
Thank you for purchasing the Sloane Grey/Mahogany
Leaning Bookcase. This page lists all the contents included
in the box. Please take the time to identify the hardware as
well as the individual components to this product. As you
unpack and prepare for assembly, place the contents on a
carpeted or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
Missing hardware?
Please call 800.606.6387
for replacements.
HARDWARE
COMPONENTS
BOX 1
COMPONENTS
BOX 2
4 - large
bolts
10 - small
bolts
1 - small
screw
1 - bottom
crossbar
1 - top
crossbar
1 - large
screw
2 - wall
fittings
1 - wall
strap
1 - plastic
anchor
8 - wood
dowels
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
1 Insert 8 wood dowels into top and bottom
crossbars as shown.
2 - connecting
plates
top crossbar
bottom crossbar
BOTTOM
NOTE: Bottom crossbar
is indicated as shown.
4 - medium
screws

Made in Indonesia - r01 Page 2 of 4
SLOANE GREY/MAHOGANY LEANING BOOKCASE
CLEANING AND CARE
Clean surfaces with a dry or damp soft cloth.
Do not use abrasive cleaners.
2 A) Fit dowels of crossbars
into right upright as shown.
Make sure top and bottom
crossbars are assembled in the
appropriate location. Secure
each crossbar with 1 large bolt
as shown, using a phillips head
screwdriver.
B) Position right upright with 5
shelves (in descending depths)
as shown. Place the shortest
depth shelf at the top of the
uprights, and longest depth shelf
at the bottom.
C) Insert 1 small bolt through
each shelf side, and secure each
screw with an allen wrench.
C
B
top
crossbar
bottom
crossbar
left
upright
shelves
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com
A
C
top
crossbar
bottom
crossbar
right
upright
3 A) Fit dowels of crossbars into
left upright. Secure each crossbar
with 1 large bolt as shown, using a
phillips head screwdriver.
B) Position left upright with 5
shelves as shown.
C) Insert 1 small bolt through each
shelf side, and secure each screw
with an allen wrench. Position unit
upright.
Assembly is now complete.
B
A
A
large bolt

Made in Indonesia- r01 Page 3 of 4
SLOANE GREY/MAHOGANY LEANING BOOKCASE
A
wall fitting &
small screw
SAFETY MOUNTING ASSEMBLY
For added safety and stability, it is recommended that the wall mounting
hardware be installed. For safe mounting, it is essential to use wall
anchors appropriate to your wall type (i.e. plaster, drywall, concrete, etc.).
Mount to wood studs whenever possible.
A) Attach 1 wall fitting to assembled unit as shown, using 1 small
screw.
B) Determine the final location of shelving unit. Mark position on the
wall, approximately 2" below the bracket mounted to the back of the unit.
C) Drill a hole in the wall stud. If the wall stud is not available, drill a hole
in the wall that is slightly smaller in diameter than the anchor. Gently tap
the plastic anchor until the flange of the anchor is flush with the wall.
D) Attach the wall fitting to the wall by inserting 1 large screw through
the wall fitting and into the plastic anchor in the wall.
E) Place the unit so the wall fitting on the back edge is aligned with the
wall fitting on wall.
F) Lace one end of the wall strap through both fittings, and into the
other end of the strap.
G) Pull the strap tightly until secure.
Mounting assembly is now complete.
NOTE:
If you are unsure about your
wall type or what mounting
method you should use,
consult a qualified
professional or your local
hardware store.
C
F
wall strap
plastic
anchor
D
large screw
Customer Service 800.967.6696 |Latest instructions available at www.crateandbarrel.com

Made in Indonesia - r01 Page 4 of 4
SLOANE GREY/MAHOGANY LEANING BOOKCASE
MULTIPLE LEANING SHELVES/DESK ASSEMBLY
If you purchased multiple leaning items, it is suggested that every two or
more item be secured together. As shown, connect every 2 units with 2
connecting plates. Attach each plate with 2 medium screws using a
screwdriver. Repeat steps for each additional leaning unit item.
