HR90-2009 2
CS400-AC Hardware Replacement Procedures

About the CS400-AC Hardware Replacement Procedures
The CS400-AC Hardware Replacement Procedures lists and shows GreenBlade, Subrack, processor/DIMM, and
drive parts for the system. This manual includes procedures for replacing components in GB522 blades and
expansion blades. It also includes procedures for replacing parts in the subrack. Cray personnel or customers
who perform these replacement procedures must first complete Cray CCS hardware training and observe ESD
precautions when servicing this equipment.
Document Versions
HR90-2009: April 2016.
ESD Precautions
Observe electrostatic discharge (ESD) precautions during the entire removal and installation process. Required
apparel includes an ESD smock, ESD shoes, and an ESD wrist strap.
CAUTION:
●ESD Precautions
● Observe all ESD precautions. Failure to do so can result in equipment damage.
ESD Smock
Wear a Cray approved static-dissipative smock when you service or handle an ESD-sensitive device. Completely
button the smock and wear it as the outermost layer of clothing. You must have a portion of the smock’s sleeves
in direct contact with the skin of your arms. Skin contact is essential for a dissipative path-to-earth ground through
your wrist strap. Tuck hair that exceeds shoulder length inside the back of the smock.
ESD Shoes
Wear approved static-dissipative shoes or approved dissipative heel straps on both shoes when you service or
handle an ESD-sensitive device. When sensitive equipment is exposed to static discharge, ESD shoes provide a
backup to the wrist straps and grounding cords and help prevent an excessive charge from building up on you
when you contact the conductive flooring. Use dissipative footwear in addition to, not as an alternative to, a wrist
strap.
ESD Wrist-strap
Wear a Cray approved wrist strap when you service or handle an ESD-sensitive device to eliminate possible ESD
damage to equipment. Connect the wrist strap cord directly to earth ground.
Feedback
Visit the Cray Publications Portal at https://pubs.cray.com and use the "Contact us" link in the upper-right
corner to make comments online. Your comments and suggestions are important to us. We will respond to them
within 24 hours.
About the CS400-AC Hardware Replacement Procedures
HR90-2009 3
CS400-AC Hardware Replacement Procedures

CCS Parts Repair and Replacement
Cray Cluster Supercomputer (CCS) Support is available to customers of Cray CS300, CS400, and CS-Storm
systems. Four service tiers are available to CCS customers: Depot, Depot Rapid Exchange, Premium and
Premium Plus.
CCS customers should initiate a request for support by creating a case in the CrayPort portal. For Premium and
Premium Plus customers, support outside of local business hours can also be initiated by calling the after-hour
support numbers.
This section provides information on the following service related topics:
● Requesting Part Repair or Replacement
● Spare Part Numbers
Requesting Part Repair or Replacement
Cray Cluster Supercomputer (CCS) customers and field support personnel must run appropriate diagnostics and
perform troubleshooting before requesting part repair or replacement. These prerequisites are for replacement or
repair of defective/suspect parts covered under a Cray Service Level Agreement (SLA). To streamline the return
process, these prerequisites are being aligned with those of Cray’s vendors. Cray Service will assist customers
with troubleshooting and collaborate with vendors as needed. Cray remains the sole authority in granting a Return
Materials Authorization (RMA). Cray may grant an RMA without diagnostic results for specific sites due to their
security policies, or by authorization from a Cray executive, or for certain "Critical" cases as defined in the Cray
Cluster Supercomputer Support Operations Handbook.
Troubleshooting Procedures and Requirements
Cray Service provides detailed troubleshooting requirements and procedures to diagnose and identify faulty
hardware. These procedures are unique to specific part categories. Diagnostic utilities may be used to generate
log files or output that must be sent to Cray Service when requested before an RMA request is processed. As a
minimum, customers must demonstrate that the fault follows the suspect part. Cray will not repair or replace any
returned part that does not comply with these troubleshooting requirements and procedures.
Return Materials Authorization Number
After an RMA is approved, Cray Service issues a unique RMA number for that part. A single RMA number is
generated for each batch of identical parts. Orders containing different parts are issued different RMA numbers.
For example, a replacement of 3 GPUs will share the same RMA number, but a replacement of 1 GPU and 1
HCA will be issued two RMA numbers. Cray will not repair or replace any returned part without an RMA number.
Parts received by Cray without an RMA number will be returned as is.
Packaging and Shipping RMA Parts
All parts returned to Cray must be individually tagged and identified with the RMA number. They must be properly
packaged to prevent shipping and ESD damage. If possible, customers should save and reuse Cray shipping
boxes (in good condition) when returning parts. If this is not possible, customers should provide enough
CCS Parts Repair and Replacement
HR90-2009 4
CS400-AC Hardware Replacement Procedures

packaging (antistatic bags and ESD foam) so there is at least 2 inches of threedimensional clearance between
the part and the shipping box. Cray will not be responsible for any damage as a result of poor customer
packaging and may return the damaged part as is, without repair or replacement. Customers may consolidate
multiple RMA requests in a single CrayPort case. Similarly, customers may consolidate multiple RMAs in a single
box, provided it meets Cray packaging recommendations.
Customers must print the CrayPort case number visibly and legibly on the exterior of the box or on the shipping
address label.
CS400-AC Part Numbers
Part Number Description
GreenBlade\Subrack
101129600 SR5110 subrack, 5U 10X node. Includes L/R angle brackets and cable management bar
000-01601A SR8204 subrack, 8U 4X node. Includes L/R angle brackets and cable management bar
101129800 SR8116 subrack, 8U 16X node. Includes L/R angle brackets and cable management bar
101117701 Chassis, GB522XA, PCIe3 X16 Slot 1, KP
101210400 Chassis, GB522N expansion blade, up to 2X K20/X/K40
101210500 Chassis, GB522N expansion blade, up to 2X K80
101195200 Chassis, GB822XA, 6X 2.5" HDD bay
002-00372B Fan module assembly, air cooled systems, (for SR5110/SR8204/SR8116 subracks)
23101-0295-01 Fan module replacement dual fans: 12V, 3000 rpm with cable assembly
22302-0270-01 Fan module: fan interface board (FIB) for 2 fans
002-00374C iSCB module (SR5110/SR8204/SR8116 subracks)
22302-0313-01 iSCB module PCBA - Ext Board, GB2 IO, 10/100, RJ45, reset/LED
22309-0005-04 iSCB module PCBA - CPU, GB2 IMX253, 16 node mgr, hot-swap (plugs to midplane)
002-00316A Cable management bar assembly, GB2 (SR5110/SR8204/SR8116 subracks)
150-00143B Power supply, GreenBlade 1630W, 1U, 277V input, 133A/12V 6A/5Vsb (SR5110/SR8204/
SR8116)
101139200 Riser card, 1U PCIe-3 x16, S2600KP/TP Slot 1
101243300 Subrack support angle assembly, left side, 25.945 +-0.75" (SR5110/SR8204/SR8116)
101243400 Subrack support angle assembly, right side, 25.945 +-0.75" (SR5110/SR8204/SR8116)
GPUs and Coprocessors
101219400 Cable Assembly, Twin-Ax, Slot 2, PCIEX16 GB522N/M
51010-3218-00 PCIe Cable Bracket, GB522MN (Used with twin-ax cable assy)
56000-0030-01 Gasket EMI, GreenBlade Expansion
22302-0412-00 GPU Node IFB, 4U MIC CoProcessor GB522M, 2 GPU Hot-Swap, KP
CCS Parts Repair and Replacement
HR90-2009 5
CS400-AC Hardware Replacement Procedures

Part Number Description
22302-0412-10 GPU Node IFB, 4U K20/40 GB522N, 2 GPU Hot-Swap, KP
22302-0412-20 GPU Node IFB, 4U K80 GB522N, 2 GPU Hot-Swap, KP
22302-0402-02 GPU Bridge Board/Riser, GB522 Expansion Blade, (MIC/PHI, K20/K40, K80)
22303-0082-01 GPU Front PCBA/LED/push button switch assembly (MIC/PHI, K20/K40, K80 expansion
blades)
101210300 Chassis, GB522M Expansion Blade, with cover/cables/brackets, up to 2X MIC/PHI (not incl.)
101210400 Chassis, GB522N Expansion Blade, with cover/cables/brackets, up to 2X K20/K40 (not incl.)
101210500 Chassis, GB522N Expansion Blade, with cover/cables/brackets, up to 2X K80 (not incl.)
100972402 GPU Card, TESLA ATLAS K40 12GB 235W Passive
101142501 GPU Card, STELLA DUO K80 24GB 300W Passive
130-00149A MIC Card, XEON PHI 7120P Passive 61C 1.25GHZ 16GB 300W
Rackmount Servers (2U)
101137200 Chassis, 2828X, 2U S2600WT2 dual Xeon 8X 2.5" HDD, up to 2X 1100W (Intel: 936032,
R2208WT2YS)
101125300 Chassis, 2828X, 2U S2600WTT dual Xeon 8X 3.5" HDD, up to 2X 1100W (Intel: 936035,
R2308WTTYS)
101142900 Power supply, 1100W, 80+ platinum (2828X)
150-00145A Power supply, 1600W, 80+ platinum (2820XT)
190-00137A Rail kit, 1U/2U, full extension & tool-less, 609.6-762MM 800MM MAX (2828X)
100993600 RMM4 lite remote management module, KVM
Motherboards, DIMMs and Processors
101123200 Intel Kennedy Pass motherboard, dual Xeon Haswell, 8X DIMM, FDR IB (Connect-IB) on-
board
101132800 Intel Kennedy Pass motherboard, dual Xeon Haswell, 8X DIMM, (No InfiniBand on-board)
101123800 Intel Taylor Pass motherboard, dual Xeon Haswell, 16X DIMM, QSFP FDR IB
101132900 Intel Taylor Pass motherboard, dual Xeon Haswell, 16X DIMM, (No InfiniBand on-board)
101181500 Heatsink, 1U Passive, Std - 91.5 x 91.5, 47 fins, AL base, heatpiped/copper fins
101181600 Heatsink, 1U Passive, Wide - 91.5 x 110, 57 fins AL base, heatpiped/copper fins
167-00509A Battery backup, RAID smart lithium-ion 1500 mAh
100944700 DIMM, 8GB DDR4-2133 Reg dual rank 2RX8
100961800 DIMM, 16GB DDR4-2133 Reg dual rank ECC 1.2V 1GX4
100961801 DIMM FRU,16GB DDR4-2133 REG DUAL RANK ECC 1.2V 1GX4 (HYNIX)
100961802 DIMM FRU,16GB DDR4-2133 REG DUAL RANK ECC 1.2V 1GX4 (SAMSUNG)
101107700 DIMM, 32GB DDR4-2133 Reg dual rank ECC 1.2V 1GX4
CCS Parts Repair and Replacement
HR90-2009 6
CS400-AC Hardware Replacement Procedures

Part Number Description
101159100 IC, processor, E5-2660 V3, 2.6 GHz 10C Haswell 105W
101169900 IC, processor, E5-2620 V3, 2.4 GHz 6C Haswell 85W
101187200 IC, processor, E5-2683 V3, 2.40 GHz 14C Haswell 120W
101245301 IC, processor, E5-2699 V3, 2.3 GHz 18C Haswell 145W, SR1XD
101278300 IC, processor, E5-2667 V3, 3.2 GHz 8C Haswell 135W
101078600 IC, processor, E5-2670 V3, 2.3 GHz 12C Haswell 120W, M1
101078700 IC, processor, E5-2680 V3, 2.5 GHz 12C Haswell 120W, M1
101078900 IC, processor, E5-2690 V3, 2.6 GHz 12C Haswell 135W, M1
101079000 IC, processor, E5-2695 V3, 2.3 GHz 14C Haswell 120W, C1
101079100 IC, processor, E5-2650 V3, 2.3 GHz 10C Haswell 105W, M1
101120400 IC, processor, E5-2698 V3, 2.3 GHz 10C Haswell 135W, 40M , C1
Disk Drives
101030500 Disk drive, SATA 600 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101032700 Disk drive, SATA 480 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101178400 Disk drive, SATA 120 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101178500 Disk drive, SATA 160 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101178600 Disk drive, SATA 240 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101178700 Disk drive, SATA 300 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101125800 Disk drive, SAS 300GB 10K 6 2.5" 6Gb/s 64MB, Savvio
101178800 Disk drive, SATA 800 GB SSD, 2.5" 6 Gb/s, 20nm, Intel S3500
101179000 Disk drive, SATA 100 GB SSD, 2.5" 6 Gb/s, 25nm, Intel S3700
101179900 Disk drive, SATA 200 GB SSD, 2.5" 6 Gb/s, 25nm, Intel S3700
101180400 Disk drive, SATA 800 GB SSD, 2.5" 6 Gb/s, 25nm, Intel S3700
101180700 Disk drive, MSATA 120 GB SSD, 2.5" 6 Gb/s, 25nm, Intel 525
101180800 Disk drive, MSATA 180 GB SSD, 2.5" 6 Gb/s, 25nm, Intel 525
101180900 Disk drive, MSATA 240 GB SSD, 2.5" 6 Gb/s, 25nm, Intel 525
101181000 Disk drive, MSATA 60 GB SSD, 2.5" 6 Gb/s, 25nm, Intel 525
101181100 Disk drive, 400 GB SSD, 1/2 Height PCIe 2.0, 25nm, Intel 910
101181200 Disk drive, 800 GB SSD, 1/2 Height PCIe 2.0, 25nm, Intel 910
101205700 Disk drive, SATA 180 GB SSD, 2.5" 6 Gb/s, 20nm, R540/W490, Intel Pro 2500
101206400 Disk drive, SATA 120 GB SSD, 2.5" 6 Gb/s, 20nm, R540/W490, Intel Pro 2500
101206600 Disk drive, SATA 240 GB SSD, 2.5" 6 Gb/s, 20nm, R540/W490, Intel Pro 2500
101206700 Disk drive, SATA 480 GB SSD, 2.5" 6 Gb/s, 20nm, R540/W490, Intel Pro 2500
CCS Parts Repair and Replacement
HR90-2009 7
CS400-AC Hardware Replacement Procedures

Part Number Description
101238200 Disk drive, SATA 2 TB SSD, 2.5" 6 Gb/s, 7200 RPM, 128 MB Cache, Seagate Enterprise
160-00184B Disk drive, SATA 500 GB SSD, 2.5" 6 Gb/s, 7200 RPM, 32 MB Cache, Seagate Constellation
160-00185C Disk drive, SATA 250 GB SSD, 2.5" 6 Gb/s, 7200 RPM, 64 MB Cache, Seagate Constellation
160-00228A Disk drive, SATA 1 TB SSD, 2.5" 6 Gb/s, 7200 RPM, 64 MB Cache, Seagate Constellation
160-00258A Disk drive, SATA3 400 GB SSD, 2.5" 6 Gb/s, Read-500Mb/s, Write-460Mb/s, Intel
PCIe Cards
100629400 PCIe, Gen2 dual port 1GBE [GB822x] RJ45, 10/100/1GE, Intel 82576, (2.5 Gbps) includes
bracket
100882500 PCIe3.0, x8, 40 GbE, HBA, dual-port, ConnectX-3, QSFP (MCX314A-BCBT)
101082500 PCIe3.0, x8, HCA, Connect-IB, single-port QSFP FDR, 56 Gb/s (MCB191A-FCAT)
101196800 PCIe3.0, x8, 40 GbE, HBA, single-port QSFP (MCX313A-BCBT)
101203000 PCIe3.0, 800 GB SSD, 1/2 height, 20 nm, R2800/W1900, P3700
101264800 PCIe3.0, 1.6 TB SSD, 1/2 height, 20 nm MLC, HHHL, P3700
101267000 PCIe3.0, 2.0 TB SSD, 1/2 height, 20 nm MLC, HHHL, P3700
101267100 PCIe3.0, 400 GB SSD, 1/2 height, 20 nm MLC, HHHL, P3700
101267200 PCIe3.0, 2.0 TB SSD, 1/2 height, 20 nm MLC, HHHL, P3600
101267300 PCIe3.0, 1.6 TB SSD, 1/2 height, 20 nm MLC, HHHL, P3600
101268500 PCIe3.0 x16, HCA ConnectX-4 VPI single-port QSFP, EDR 100 Gb/s InfiniBand
101278400 PCIe3.0 x16, HCA ConnectX-4 VPI dual-port QSFP, EDR 100 Gb/s InfiniBand
101290000 PCIe3.0 x16, HCA ConnectX-4 single-port QSFP, EDR 100 Gb/s InfiniBand
101290100 PCIe3.0 x16, HCA ConnectX-4 dual-port QSFP, EDR 100 Gb/s InfiniBand
131-00153A PCIe, x8, RAID SAS 8P Ctrl 0/1/5/6/10/50/60
132-00110B PCIe2.0 x8, Intel True Scale Fabric InfiniBand, single-port, QSFP, QLE7300
132-00125A PCIe2.0 x8, Intel True Scale Fabric InfiniBand, dual-port, QSFP, QLE7300
132-00128A PCIe2.0 x8, Ethernet X520-DA2, dual-port, 10GB SFP+, low profile, full height
132-00137B PCIe3.0 x8, HCA ConnectX-3 VPI single-port QSFP, 40Gb/s QDR IB, 10GbE
132-00138B PCIe3.0 x8, HCA ConnectX-3 VPI dual-port QSFP, 40Gb/s QDR IB, 10GbE
132-00145A PCIe3.0 x8, HCA ConnectX-3 VPI single-port QSFP, 40Gb/s FDR IB, 40GbE
132-00150A PCIe3.0 x8, HCA ConnectX-3 EN dual-port SFP+, 10Gb/s, 40GbE
132-00157A PCIe3.0 x4, HCA ConnectX-3 EN single-port SFP+, 10Gb/s, 10GbE
132-00159A PCIe3.0 x16, HCA Connect-IB dual-port 56Gb/s FDR
Power Cords
085-00370B Power cord, LS14 to LS26, 10A-250/277V, 1.2 m (4 ft)
CCS Parts Repair and Replacement
HR90-2009 8
CS400-AC Hardware Replacement Procedures

Part Number Description
085-00374A Power cord, LS14 to LS26, 10A-250/277V, 1.5 m (5 ft)
085-00382A Power cord, LS25 to LS26, 250/277V, 1.2 m (4 ft)
085-00383A Power cord, LS25 to LS26, 250/277V, 1.5 m (5 ft)
085-00218A Power cord, C14 to C13, 17AWG, 10A-250V, 1.5 m (5 ft)
085-00251A Power cord, C14 to C13, 17AWG, 10A-250V, 1.2 m (4 ft)
085-00361A Power cord, C14 to C13, 17AWG, 10A-250V, 1.8 m (6 ft)
085-00360A Power cord, C14 to C13, 17AWG, 10A-250V, 3.0 m (10 ft)
085-00294A Power cord, C14 to C19, 14AWG, 15A-250V, 1.8 m (6 ft)
085-00384A Power cord, C14 to C19, 14AWG, 13A-250V, 3.0 m (10 ft)
085-00273A Power cord, C20 to C13, 10A-250V, 1.8 m (6 ft)
085-00351A Power cord, C20 to C13, 15A-250V, 1.5 m (5 ft)
CCS Parts Repair and Replacement
HR90-2009 9
CS400-AC Hardware Replacement Procedures

Power Cords
The following power cords are used with CS400-AC systems.
C20 to C13, 250 V
1.8 m (6 ft) - 10 A
1.5 m (5 ft) - 15 A
C20 C13
C14 C19
C14 to C19, 250 V, 14 AWG
1.8 m (6 ft) - 15 A
3.0 m (10 ft) - 13 A
1.5 m (59 in.)
C14 to C13, 250 V, 10 A, 17 AWG
1.2 m (47 in.)
C14 C13
3.0 m (10 ft)
1.8 m (6 ft)
1.5 m (59 in.)
LS25 to LS26, 250-277 V
LS-25 LS-26
1.2 m (47 in.)
1.2 m (47 in.)
1.5 m (59 in.)
LS14 to LS26, 250-277 V, 10 A
LS-14 LS-26
Power Cords
HR90-2009 10
CS400-AC Hardware Replacement Procedures

PCI Card Brackets
A custom PCI mounting bracket is required to install most PCI expansion cards in a GreenBlade chassis. The
following custom Intel and Mellanox PCI brackets are available for popular expansion/add-on cards. If a bracket is
not listed for the card that you want to add, please contact your Cray sales representative.
PCI Card Brackets
HR90-2009 11
CS400-AC Hardware Replacement Procedures

Brkt: 004-01317A (51010-2749-00)
Mellanox ConnectX-3 10GbE: MCX311A-XCCT/XCAT
Brkt and Gasket Kit: 90301-0426-00
Brkt & Gasket Kit: 101224600
Brkt: 51010-3056-10
Mellanox Connect-IB FDR: MCB191A-FCAT,
MCB193A-FCAT
Brkt: 101304600
Mellanox ConnectX-4 VPI EDR: MCX455A-ECAT
Brkt: 004-01172C (51010-2396-02)
Brkt & Gasket Kit: 002-00399A
Mellanox ConnectX-3 VPI: MCX353A-QCBT/TCBT/FCBT
Brkt: 004-01318A (51010-2396-10)
Brkt & Gasket Kit: 002-00398A (90301-0411-00)
Mellanox ConnectX-3: MCX353A-QCBT
Brkt: 004-01222C (51010-2395-02)
Mellanox Connect-IB, ConnectX-2/3: MCB192A-FCAT,
MCB194A-FCAT, MCX354A-QCBT/TCBT/FCBT,
MHQH29C-XTR, MHRH29C-XTR
Brkt & Gasket Kit: 002-00397A (90301-0418-00)
Brkt: 101304400
Brkt & Gasket Kit: 101304500
Mellanox ConnectX-4: MCX456A-ECAT
Brkt & Gasket Kit: 002-00405A
Brkt: 004-01173C (51010-2346-02)
Mellanox ConnectX-2: MNPH29C/D-XTR,
MCX312B-XCCT, MCX312A-XCBT
PCI Card Brackets
HR90-2009 12
CS400-AC Hardware Replacement Procedures

GB522 Overview and Replacement Videos
The following list provides links to a series of GB522 videos. Most of these instructional videos are less than a
minute in length. For those videos that are longer, the length is indicated next to the title. These videos are
provided through unlisted links on YouTubeTM, so they will not show up in searches or other lists.
GB522 Overview Video
●GB522 Blade Overview (5:52)
GB522 Compute Blade Videos
●Remove and Install Blade
●Remove and Install Cover
●Replace Disk Drive
●Replace Motherboard (4:55)
●Remove CPU
●Install CPU
●Remove Bridge Board
●Install Bridge Board
GB522 Expansion Blade Videos
●Remove from Subrack
●Install in Subrack
●Remove Accelerator
●Install Accelerator
●Separate Expansion Blade and Compute Blade
●Join Expansion Blade and Compute Blade
GB522 Overview and Replacement Videos
HR90-2009 13
CS400-AC Hardware Replacement Procedures

GB522X Replacement Procedures
The following procedures are included in this section to prepare a GB522X chassis before replacing failing
components/assemblies. The replacement procedures in this CS400-AC Hardware Replacement Procedures
document begin with the GB522X chassis removed from the subrack and placed on an ESD safe work surface
with the cover removed. These preparation procedures are not repeated in each component/assembly
replacement procedure.
● GB522X Power Down
● GB522X Chassis Removal and Installation
● GB522X Cover Removal
● GB522X Cover Installation
● GB522X Exploded Views
● PCIe Card Installation
● HDD/SSD Replacement
NOTE: Short instructional videos for many of the GB522X replacement procedures are available. Refer to
this page for a complete list of all the videos: GB522 Overview and Replacement Videos on page 13.
GB522X Power Down
1. Power down the GB522X using ACE, IPMI, or iSCB commands.
2. Check that the power status LED on the front is off.
3. Disconnect all Ethernet, InfiniBand (IB), and other I/O cables from the rear of the blade.
GB522X Chassis Removal and Installation
First, power down the GB522X and disconnect all cables.
Removal
1. Lift up the ejector handle on the bottom of the GB522X. Refer to the following figure.
2. Pull the ejector handle to unseat the GB522X from the subrack midplane.
3. Remove the GB522X from subrack and place it on an ESD-safe work surface.
GB522X Replacement Procedures
HR90-2009 14
CS400-AC Hardware Replacement Procedures

GreenBlade
COM
Installation
1. Slide the GB522X into the subrack, and carefully push it in until it seats with the midplane connectors.
2. Power on the GB522X and verify that the blue LED lights to indicate power is applied to the blade.
3. Connect the cables to the GB522X, boot the operating system, and close the rear doors of the cabinet.
GB522X Cover Removal
1. Remove the screw that secures the cover to the chassis. Refer to the following figure.
2. Press down on the latch button and slide the cover toward the rear of the chassis.
3. Lift and remove the cover.
TOWARD
THE REAR
GB522X Replacement Procedures
HR90-2009 15
CS400-AC Hardware Replacement Procedures

GB522X Cover Installation
The top cover is a required component of the GB522X GreenBlade chassis. Do not attempt to insert a
GreenBlade chassis into a subrack without the top cover in place.
1. Tip the front of the cover down so the flange on the cover fits below the top of the front panel housing.
2. Lower the back of the cover. The cutouts on the side fit around the pins/rivets inside the chassis and the pins
on the underside of the cover fit into the recesses in the rear panel.
3. Slide the cover forward and secure it to the chassis with one screw.
TOWARD
THE REAR
TOWARD
THE REAR
GB522X Exploded Views
The following three exploded views of GB522X models show the internal components of each chassis. Refer to
these illustrations when replacing components and following procedures. These detailed exploded views show
screw locations, component placement, and the intended assembly of components. Detailed step-by-step
information describing the location of components and screws for component removal and replacement is not
provided in all the replacement procedures in this CS400-AC Hardware Replacement Procedures document.
Views of the GB522M/N expansion blades are provided in GB522M and GB522N Exploded Views on page 28.
GB522X Replacement Procedures
HR90-2009 16
CS400-AC Hardware Replacement Procedures

GB522X Replacement Procedures
HR90-2009 17
CS400-AC Hardware Replacement Procedures

(from SATA 0 on motherboard)
Bridge board assembly
(same as 1st generation)
Bridge board assembly
(same as 1st generation)
(between bridge PCB and bracket)
(CS-GB-522X [Second generation])
SATA-3 cable assembly
Disk high-mount bracket
HDD/SSD
SATA power cable (5-4 pin)
SATA-3 cable assembly
PCIe Card Installation
Prerequisites
● Refer to CS400-AC Part Numbers on page 5 for available PCIe add-on cards.
● Refer to PCI Card Brackets for a list of mounting brackets to be used with the available PCIe add-on cards.
About this task
This procedure describes how to install an add-on card into a GreenBlade chassis. Refer to the corresponding
step numbers in the following figures. To remove a PCIe card, follow the steps in reverse.
Procedure
1. If necessary, remove the blank PCI slot bracket from the front panel.
GB522X Replacement Procedures
HR90-2009 18
CS400-AC Hardware Replacement Procedures

2. Many PCIe cards require removal of the manufacturer's bracket before installing the card in a GreenBlade
chassis. Refer to the figure below.
3. Attach a mounting bracket and EMI gasket to the PCI card.
A custom Cray PCI mounting bracket is needed to install most PCI cards into a GreenBlade chassis. Cray
has custom brackets and EMI gaskets for supported add-on cards.
EMI gasket
Remove
manufacturer’s
bracket
4. Attach the slot 1 PCI riser card to the add-on card as shown.
5. Install the PCI card assembly into the chassis by inserting the riser card into the open PCI slot 1 connector.
GB522X Replacement Procedures
HR90-2009 19
CS400-AC Hardware Replacement Procedures

6. Secure the bracket to the front panel using two M3-0.50 x 4 mm screws. Check that the EMI gasket and
bracket are not obstructing any LEDs or light pipes.
HDD/SSD Replacement
The following procedures describe how to replace an internal HDD/SSD in the two GB522X chassis models.
● First generation
● Second generation (with high-mount drive bracket)
For many of the steps, refer to the corresponding number in the figure for each procedure.
GB522X SSD Replacement (High-Mount Bracket)
Removal
1. Remove the GreenBlade chassis from the subrack and place it on a stable ESD-safe work surface. Remove
the cover.
2. Disconnect the SATA power connector (5-4 pin) from the drive.
3. Disconnect the SATA signal (flexible-foil) connector from the drive.
4. Remove the four screws that attach the high-mount bracket to the base of the chassis. Two screws go
through the node IFB.
GB522X Replacement Procedures
HR90-2009 20
CS400-AC Hardware Replacement Procedures
