Creda HB48283 User manual

Instructions for Installation and Use
Fan Oven
&
Cordialle
To the Installer
Before installation fill in the product details on the back cover of
this booklet. The information can be found on the rating plate.
To the User
You must read the instructions prior to installing and using the
appliance and then retain them for future reference.
Note: Timer must be set to ‘Time of Day’ and ‘Manual’
before the oven can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.

For more information on our exciting product range ring
Creda Answer Centre 08701 546474
OR
Visit us on the NET at
http://www.creda.co.uk
General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB
Creda Answer Centre 08701 546474
Web http://www.creda.co.uk
It may be necessary from time to time to change the specification outlined in this booklet
without notice. Any change which is made will not affect your statutory rights.
Our site invites you to make use of our interactive cookbook and product selector.
Feel free to browse our product range to see what’s bubbling away at the
moment or to ask for help on our products and services

Introduction 4
CONTENTS
3
For Your Safety – Always 5
For Your Safety – Never 6
Features 7
Controls 8
Oven Timer Operation (Cordialle) 9
Know Your Timer 10
Electronic Clock & Automatic Oven Timer Operation
11-14
Grill Pan and Handle 15
Grilling 16
Guide To Grilling Successfully 17
Using the Oven as a Fan Oven 18-19
Using the Oven for Other Functions 20
Temperature Conversion Scale 21
Oven Temperature Charts 22-23
Cooking Results Not Satisfactory 24
Care & Cleaning 25-28
Installation 29-33
Something Wrong? 34
Service Back Cover

INTRODUCTION
Your new cooker is guaranteed* and will give lasting service. This guarantee is
only applicable if the appliance has been installed in accordance with the
installation instructions detailed in this booklet.
To help make best use of your cooking equipment,
please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not
be accepted for use in any other installation.
To help remove the 'new' smell, heat up the empty oven(s) to maximum for a
minimum of two to three hours keeping the oven doors closed. Ensure that the
room is well ventilated (e.g. open a window or use an extractor fan) and that
persons who may be sensitive to the odour avoid any fumes. It is suggested that
any pets be removed from the room until the smell has ceased.
This odour is due to any temporary finish on oven linings and elements and also
any moisture absorbed by the insulation.
Note: When the cooker is first used, an odour may be emitted - this will cease
after a short period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on
the rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or
repaired by any person other than the authorised employee or agent.
(d) Has been correctly installed.
4
This appliance conforms to the following EEC Directives:
Low Voltage Equipment
73/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC

FOR YOUR SAFETY
When used properly, your appliance is completely safe but as with any
electrical product there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR
APPLIANCE.
ALWAYS
●Always make sure you remove all packaging and literature from inside the
oven/grill compartment before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces
will get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of steam
or heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on
the oven.
●Always keep the oven/grill door closed when the appliance is not in use.
●Always keep the appliance clean as a build up of grease or fat from cooking
can cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent
the possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●Always during use the oven becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother
the flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT.
Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of
the extinguisher is likely to tip the pan over. Never use water to extinguish
oil or fat fires.
5

FOR YOUR SAFETY
NEVER
●Never leave children unsupervised where a cooking appliance is installed as
all cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this may cause the appliance
to overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the oven controls.
6
To minimise the risk of injury to children please dispose of your product carefully and
safely. Remove all doors and lids (where fitted). Remove the mains cable (where
fitted) by cutting off flush with the appliance and always ensure that no plug is left in a
condition where it could be connected to the electricity supply.
To help the environment Local Authority instructions should be followed for the
disposal of your product.
DISPOSAL OF YOUR PRODUCT

Oven
Indicator
Light
Credaplan Fan Oven
Minute Minder
Selector Fan oven/grill
Cordialle Select
Alarm
pm
Auto
Minute
Minder Alarm
Stop
Time
Cook
Period
Minute
Minder Go
Set
Selector Fan oven/grill
FEATURES
7
Cordialle
Fan Oven
Electronic Timer
Oven &
Grill
Selector
Oven & Grill
Temperature
control 120 min.
Minute Minder
Grill Element
Stayclean Liners
2 Oven Shelves
Oven Light
Meat/Grill pan
Oven Fan
Rating plate
Oven Door
●●●●●●

A gentle flow of air will be blown below the control panel when the
selector switch is used.
The oven light is operated when the Fan Oven is selected.
The oven has a “Slow Cook Setting” this can be used for slow cooking,
keeping food warm and warming plates for a short period.
To operate the minute minder, rotate the minute minder control fully
clockwise (until it can not be turned any further) and then anti-clock-
wise to the required minute minder setting (0-120 minutes). This will
ensure that the duration of the audible warning is as long as possible.
The minute minder will then count down to ‘0’ at which time it will emit
an audible warning for a short period. The minute minder may
continue to tick for a period after the warning has sounded.
CAUTION: The oven will continue to cook after the audible warning
has sounded, it must be turned off Manually.
To cancel the Minute Minder, turn the Minute Minder control knob anti-
clockwise to the ‘0’ position.
Cooling Fan
Oven Interior
Lights
Slow Cooking
Minute
Minder. Fan
oven only
CONTROL PANEL
CONTROL MARKINGS
Note: It is advisable to check that all oven controls have been switched off after
you have finished using the appliance.
8
Control
Knob Description
Oven & Grill Selector
Oven/Grill
Temperature Control
A
B
Function
Turning Selector clockwise allows use of fan
oven.
Turning Selector anti-clockwise allows use of
grill.
Oven Temperature scale (in degrees centigrade)
When cooking turn clockwise to the required
setting.
1 = Low Setting when grilling
6 = High Setting when grilling
70-
230
Fan
Oven
Grill
1-6
Credaplan Fan Oven
Minute Minder
Selector Fan oven/grill
Cordialle Select
Alarm
pm
Auto
Minute
Minder Alarm
Stop
Time
Cook
Period
Minute
Minder On
Set
Selector Fan oven/grill
●●●●●●
Oven & Grill Selector Oven & Grill Temperature Control Minute
Minder
AB
AB

OVEN TIMER OPERATION (Cordialle)
AUTOMATIC COOKING
The Oven can be controlled by the Automatic Timer (Cordialle Only).
HINTS ON AUTOMATIC COOKING
1. Select foods which will require the same cooking time and temperature.
2. To ensure food does not cool down and require reheating, set the end time so
the food is ready when you require it.
3. Always ensure that meat and poultry is defrosted before placing in the oven.
4. Whenever possible, take food out of the refrigerator and keep it as cool as
possible.
5. If cooking food that requires frying before placing in the oven for automatic
cooking, keep the delay time to a minimum.
6. Never place hot or warm food in the oven for delay start cooking as it could
cause the oven to be warm and produce harmful bacteria in the food.
7. We advise that dishes containing left-over cooked poultry or meat, e.g.
Shepherd's Pie, should not be cooked automatically if there is to be a delay
period.
8. Ensure that delay start times are kept to a minimum to prevent bacterial
growth in food.
9. Wine or beer may ferment and cream may curdle during the delay period so
it is best to add these ingredients just before serving.
10. Foods which discolour should be protected by coating in fat or tossing in
water to which lemon juice has been added, prior to placing food in the oven.
11. Dishes containing liquid should not be filled too full to prevent boiling over.
12. Food should be well sealed (but not airtight) in a container to prevent the loss
of liquid during cooking. Aluminium foil gives a good seal.
13. Always ensure that food is piping hot and cooked thoroughly before serving.
14. Only reheat food once.
9
Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the oven
can be used. (Cordialle Only)

10
KNOW YOUR TIMER
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure the correct time of day is always set, before using you cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00
HOURS AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the display
will return to normal brightness for a few seconds and then dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will remain
lit for the period set. At the end of the Minute Minder Period, the timer will
emit an audible tone for 2 minutes, the symbol will start to flash and will
continue to flash until the Minute Minder function is cancelled.
This “Cookpot” symbol will light up either:–
– When you press the Cook Period Button and set a length of time for an
Auto Cooking Programme. (It will go out again a few seconds after you
release the timer buttons).
– During the actual Cook Period.
“AUTO” will light up:–
– When the timer is first turned on it will flash. (It will go out when a time
of day is set.)
– When an Auto Cooking Programme has been set.
The “Auto” symbol will flash at the end of an Auto Cooking programme to
indicate that the programme has finished.
(When the “Auto” symbol is flashing, to return the oven to Manual
operation, turn the oven controls off, ensure that the correct time of day
is set, and press the “Manual” button twice – The “Auto” symbol will
go out.
Here you can set a time period of up to 23 hours 59 minutes, that will
count down. When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20
minutes later.
Cook Period is the actual length of time for which, the timer will switch
the oven(s) on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of
11:00. The timer will switch the oven(s) on at 9:00 and turn the oven(s) off
at 11:00. You will hear a audible tone at 11:00, to indicate that the Auto
Cooking Programme has finished.
Notes:
– When setting an Auto Cooking programme you will need to set the
oven controls(s) to the required temperature(s) when you set the timer.
_ If an Auto Cooking programme has been set the oven(s) will only
operate during the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return
the ovens(s) to Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
Minute
Minder Cook
Period End Time Manual
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
11
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and Auto symbol
will be flashing intermittently.
Step 4 Press & hold in both the “Minute Minder” & “Cook Period”
button together.
Step 5 With the “Minute Minder” & “Cook Period” buttons still held in,
press either the “+” or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set for
an Auto Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder Button, a symbol will light
up.
Step 3 With the “Minute Minder” button still held in, set the required
Minute Minder time using the “+” and “–” buttons.
Release all buttons and the timer display will revert back to the time of day.
Bell symbol will remain lit to signify that a Minute Minder period has been
set.
At the end of the set time a bleeping sound will be heard, and the
symbol will flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop and the
symbol will go out automatically.
Step 4 To cancel the bleeping sound within the two minutes press the
Minute Minder button.
A
U
T
O
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Bell Symbol
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Note 1 When the Minute Minder has been set, the time remaining can be
checked at any time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone
sounds by pressing and holding the Minute Minder button and then at
the same time pressing the “–” button until 0.00 appears in the display
window.

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
12
Step 3 Press and hold in the Cook Period button.
The display will read 0.00 with the cookpot ( ) symbol lit.
Step 4 With the Cook Period button still held in, set the required Cook
Period using the “+” and “–” buttons.
Release the buttons and the timer display will revert to the time of day with
the Auto symbol and Cookpot ( ) symbol lit.
Step 5 Press and hold in the “End Time” button.
The display will read the earliest possible end time for the Cook
Period that you have set above.
The Auto symbol and Cookpot ( ) symbol will be lit.
Step 6 With the End Time button still held in, use the “+” and “–” buttons
to set the “End Time” (i.e. The time you require the oven to switch
off).
Release all the buttons and the timer will revert back to the time of day.
The “Auto” symbol will remain lit to signify that an Auto Cooking
Programme has been set. The ( ) symbol will go out.
Step 7 Turn the oven control(s) to the required temperature, and if
necessary select the appropriate oven function.
Note: If your appliance has two ovens: When the timer has been set for
one oven it is possible to use the other oven only during the same
Automatic programme.
At the end of the Automatic Cook Period the Auto Symbol will flash and an
intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless
cancelled. The “Auto” symbol will continue to flash until the timer is
returned to Manual operation (see below).
Step 8 Press the Manual button to cancel the bleeping sound. (If 2 minutes
has not elapsed).
Step 9 Turn the oven control(s) to the OFF position.
Step 10 Press the manual button again to return the oven(s) to Manual
Operation. (The Auto symbol will go out)
AUTO COOKING PROGRAMMES
There are two Auto Cooking programmes that can be selected using your timer:–
(a) To set the timer to switch the oven(s) On and Off Automatically
(b) To set timer to switch on immediately and OFF automatically after a set cook period.
a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY
This allows you to cook at a specified time for a chosen period before the oven switches
off Automatically.
Step 1 Check that the correct time of day is set, if not follow instructions for setting the
time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Minute
Minder Cook Period End Time Manual
Cooktop Symbol
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
A
U
T
O
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
13
Step 4 Press & hold in the “Cook Period” button, the display will read 0.00
and the cookpot ( ) symbol will light up.
With the Cook Period button still held set the required Cook Period using
the “+” and “–” buttons. Example: 1hr 30 minutes (as shown).
Note: Cook Period is the length of time the food requires to cook.
Step 5 Release all buttons.
The timer display will revert to the time of day with the Auto symbol lit &
Cookpot symbol remaining lit.
At the end of the Cook Period the “Auto” symbol will flash and an
intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless
cancelled. The “Auto” symbol will continue to flash until the timer is
returned to Manual operation (see below).
Step 6 Press the manual button to cancel the bleeping.
(If 2 minutes has not elapsed)
Step 7 Turn the oven control(s) to the OFF position.
Step 8 Press the “Manual” button again to return the cooker to Manual
operation. (The Auto symbol will go out).
b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY
AFTER A SET COOK PERIOD
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time
of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Step 3 Turn the oven control(s) to the required temperature, and if necessary select the
appropriate oven function.
A
U
T
O
Minute
Minder Cook Period End Time Manual
Cookpot Symbol
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
A
U
T
O
Minute
Minder Cook Period End Time Manual
Note: Cookpot symbol disappears
Note 1 When cooking automatically the Cook Period can be checked at any
time by simply pressing the Cook Period button.
Note 2 When cooking automatically the End Time can be checked at any time
by simply pressing the End Time button.

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
14
OTHER NOTES ON TIMER OPERATION
1. When cooking Automatically the Cook Period can be checked at any time simply by
pressing the Cook Period button.
2. When cooking Automatically the End Time can be checked at any time by simply pressing
the End Time button.
3. Having set a Cook Period and End Time an electronic device stores the information. The
device within the timer will switch the oven(s) on and off at the required times.
4. When setting an Auto Cooking Programme and a mistake is made, to clear:–
(a) Press and hold in the “Cook Period” button.
(b) With the Cook Period button still held in, return the display to by pressing the
“–” button.
(c) Release the “Cook Period” & “–” buttons, and the display will revert to the time of day
and the “Auto” symbol will flash.
(d) Press & release the “Manual” button.
(e) Start the sequence again.
5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity
supply to the oven has been interrupted. Reset the timer to the correct time of day.
Food in the oven may, therefore, not have been cooked, before serving check food is
thoroughly heated and completely cooked.
6. To set each function always press and hold the required function button and at the
same time press “+” or “–” buttons.
Note: Between the hours of 22.00 & 06.00 the display dims to prevent glare.
However, if you should operate a button during this period, the timer will return to
normal brightness for a few seconds and then dim again.
A
U
T
O
TO CANCEL AN AUTO COOKING PROGRAMME BEFORE
THE COOK PERIOD HAS FINISHED.
Step 1 Turn the oven control(s) to the OFF position.
Step 2 Press and hold in the “Cook Period” button.
Step 3 With the “Cook Period” button still held in, return the display to
0.00 by pressing the “–” button.
Step 4 Release the “Cook Period” and “–” buttons and the display will
revert to the time of day and the “Auto” symbol will flash.
Step 5 Press the “Manual” button to return the oven(s) to “Manual”
operation. The “Auto” symbol will go out.
Minute
Minder Cook Period End Time Manual
A
U
T
O
Minute
Minder Cook Period End Time Manual
Note 1 When cooking automatically the Cook Period can be checked at any time by
simply pressing the Cook Period button.

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove screw & washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace screw & washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace screw &
washers.
GRILL PAN AND FOOD GRID
DOOR POSITION FOR GRILLING
GRILL PAN & HANDLE
15
Note: If a fixed handle is required, the grill pan is unable to be stored in the oven
with the door closed and cannot be used as a meat pan.
Note:Do not grill with the grill/oven door
closed.
Step 1 Step 2 Step 3 Step 4
GRILL PAN FOOD GRID
(a)
(b) (c)
(d)

GRILLING PROCEDURE
16
Note: DO NOTallow young children near to the appliance when the grill is in use
as the surfaces get extremely hot.
Credaplan Fan Oven
Minute Minder
Selector Fan oven/grill
Cordialle Select
Alarm
pm
Auto
Minute
Minder Alarm
Stop
Time
Cook
Period
Minute
Minder On
Set
Selector Fan oven/grill
●●●●●●
Oven & Grill Selector Oven & Grill Temperature Control
AB
AB
Step 1 Ensure oven timer is set to manual.
Ensure the oven shelf is in the correct position (see Guide to Grilling
Successfully).
Ensure door is in the grilling position (see grilling page)
Step 2 Turn knob (A) anti-clockwise to grill function
Step 3 Turn knob (B) clockwise to select the Grill Setting (1–6). (1=Low, 6=High).
NOTE: When using the grill, a gentle flow if air will be detected coming from
beneath the control panel.
Step 4 After use, turn both controls A & B to their off (0) position.
Notes: • Ensure oven timer is set to manual (Cordialle Only).
• Preheat the grill at setting 6 on the grill control for approximately 5 minutes.
• The grill pan must be placed on the correct shelf and positioned centrally under
the grill element.
• Leave the control at 6 for toast, and for fast cooking of foods.
• For thicker foods requiring longer cooking, turn the switch to a lower setting
after the initial sealing on both sides at 6. The thicker the food, the lower the
control should be set.
• If excessive smoke is emitted reduce the setting.
•Do not line the grill pan with aluminium foil as this increases the amount of fat
spitting.
• Ensure that the Grill Pan is cleaned after use. Excessive fat build-up in the
bottom of the pan could cause a fire hazard.
• After use, always return both controls to their OFF (O) position.

GUIDE TO GRILLING SUCCESSFULLY
The temperatures below relate to heat setting recommended on food packs.
High = No. 6
Medium High = No. 5
Medium = No. 4
Medium Low = No. 3
Low = No. 2
Very Gentle = No. 1
Food
Preheat
for
5 mins.
Shelf Position
from Base
of Oven
Approx.
Cooking
Time
Toasting of
Bread Products No. 6 6 or 5 Time depending on type of food.
Small cuts of meat,
sausages, bacon, etc. No. 3 6 or 5 10-20 mins.
Chops, gammon steaks
etc. No. 4 6 or 5 20-30 mins. depending on thickness.
Fish whole Fillets,
e.g. Fish Fingers No. 4 5 10-20 mins.
Pre-cooked potato
products No. 5 5 10-20 mins.
Pizzas No. 4 or 3 5 Preheat pan first, time depending on size and
type.
Browning of food No. 6 6 5-10 mins.
17

Since a circulaire fan oven heats up more quickly, and generally cooks food at a
lower temperature than a conventional oven, pre-heating is often unnecessary.
For guides on “pre-heating”, “cooking temperatures” and “cooking times”, see
“Oven Temperature Charts” later in book.
OVEN SHELF POSITIONING FOR FAN OVEN
Most foods will cook satisfactorily on any shelf position, due to even distribution
of heat in the oven, but the shelves must be evenly spaced.
Food or utensils should never be placed directly on the floor of the oven for
cooking as air circulation is restricted.
OVEN UTENSILS
Do not use: Meat pans larger than 375mm x 300mm (15” x 12”)
Baking Trays larger than 325mm x 250mm (13” x10”)
An additional oven shelf can be purchased from your oven supplier if a third one
is required for batch baking. Never use more than three shelves in the oven as
air circulation will be seriously restricted.
TEMPERATURE & TIME
If three shelves are in use to cook large quantities of food, it may be necessary
to increase the cooking times given in the temperature charts by a few minutes,
to allow for the loss of heat due to extra time taken to load the oven, and the
larger mass of food. Baking trays should have an even gap around the oven.
USING THE OVEN FOR FAN COOKING
18
NOTE: Charts are a guide only, to suit personal taste and requirements, it may be
necessary to increase or decrease temperatures by 10˚C. It may also be necessary
to increase or decrease cooking times.
DO NOT allow young children near to the appliance when the oven is in use as the
surfaces get extremely hot.
Fan
Oven

FAN OVEN OPERATION
Step 1 Ensure oven timer is set to manual (Cordialle only).
Ensure that the oven shelf is in the correct position.
Place food centrally on the shelf ensuring the oven door is fully closed.
Turn knob A clockwise to Fan Oven function.
Step 2 Turn knob (B) clockwise and select the required cooking temperature
(70˚C to 230˚C). The pilot light (●) will immediately come on, and remain
on until the oven reaches the required temperature. The light will then
automatically go off and on during cooking as the oven thermostat
maintains the correct temperature.
Step 3 After use turn both controls to their Off (O) position.
NOTE: At the end of a cooking period there may be a momentary puff of steam
when the door is opened. This will disperse in a few seconds and is a
perfectly normal characteristic of an oven with a good door seal.
USING THE OVEN FOR FAN COOKING
Fan
Oven
Credaplan Fan Oven
Minute Minder
Selector Fan oven/grill
Cordialle Select
Alarm
pm
Auto
Minute
Minder Alarm
Stop
Time
Cook
Period
Minute
Minder On
Set
Selector Fan oven/grill
●●●●●●
Oven & Grill Selector Oven & Grill Temperature Control
AB
AB
19

“SLOW” SETTING
This is used for slow cooking, keeping food warm and warming plates for short
periods. Extra care should be taken when warming bone china, as it may be
damaged in a hot oven.
ADVANTAGES OF SLOW COOKING ARE:
The oven stays cleaner because there is less splashing.
Timing of food is not as critical, so there is less fear of overcooking.
Inexpensive joints of meat are tenderised.
Fully loading the oven can be economical.
Cooking times can be extended in some cases by up to 2 hours.
The kitchen stays cooler.
OPERATION:
1. Place the prepared food in the main oven and ensure the door is fully closed.
2. Turn knob A to Fan Oven function.
Turn knob B to (slow cooking temperature).
STORAGE & RE-HEATING OF FOOD:
1. If food is to be frozen or not used immediately, place it in a clean container
and cool as soon as possible.
2. Always thaw frozen food completely in the refrigerator before re-heating.
3. Always reheat food thoroughly and ensure it is piping hot before serving.
4. Only re-heat food once.
POINTS TO CONSIDER WHEN PREPARING FOOD FOR SLOW COOKING
1. Make sure that the dishes to be used will fit into the oven ensuring enough room
for air to circulate.
2. All dishes cooked on the slow setting will require a minimum of 6 hours, however,
it they are cooked for 1-2 hours longer then deterioration in their appearance may
be noticed.
3. Never cook joints of meat over 2.7kg (6 lb) or poultry over 2.0kg (4lb 8oz).
We do not recommend that joints of meat or poultry are stuffed before cooking on
the slow setting.
4. To seal in the meat juices, always cook meat or poultry at 170oC for 30 minutes
before wrapping in foil and placing on a rack over a tin (to allow good air
circulation) before turning the control to the slow setting and cooking immediately.
5. Always ensure that joints of pork and poultry are thoroughly cooked by checking
with a meat thermometer before serving.
6. Always thaw frozen foods completely before cooking. We do not recommend
placing frozen food in the oven to cook.
7. Always bring soups, liquids and casseroles to the boil before placing in the oven.
8. Ensure that casserole dishes have a good seal (not airtight) and cover to the
top with foil to prevent loss of moisture.
9. Ensure that fruit and vegetables are cut into even sized small pieces to cook
properly.
10. Always adjust seasoning before serving.
11. If using dried red kidney beans it is important that the beans are soaked and then
boiled for a minimum of 10 minutes before using in any dish to destroy any toxins.
12. When cooking fish or egg dishes it may be necessary to check during cooking to
avoid overcooking.
USING THE OVEN FOR OTHER FUNCTIONS
20
90
DO NOT place food or plates directly on the oven floor as this could damage both
the oven lining and the plates which are being warmed.
90
E
