Creda D010E Guide

D010E
Installation & User Instructions
You must read these instructions prior to using the
appliance and retain them for future reference.

For more information on our exciting product range ring
Creda Answer Centre 08701 54 64 74
OR
Visit us on the NET at
http://www.creda.co.uk
General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB
Creda Answer Centre 08701 54 64 74
Web http://www.creda.co.uk
It may be necessary from time to time to change the specification outlined in this booklet
without notice. Any change which is made will not affect your statutory rights.
Our site invites you to make use of our interactive cookbook and product selector. Feel
free to browse our product range to see what’s bubbling away at the moment or to ask
for help on our products and services

Introduction 4
Contents
3
Safety Information 5
Features 7
Controls 8
Clock / Minute Minder Operation 9
Grill Pan and Handle 11
Grilling 12
Guide To Grilling Successfully 13
Using the Oven for Fan Cooking 14
Using the Oven for Other Functions 16
Temperature Conversion Chart 17
Oven Temperature Charts 18
Cooking Results Not Satisfactory 20
Care and Cleaning 21
Installation 25
Something Wrong? 30
Key Contacts Back Cover

Introduction
4
This appliance conforms to the following EEC Directives:
Electromagnetic Compatibility Low Voltage Equipment
89/336/EEC 73/23/EEC
92/31/EEC 93/68/EEC
93/68/EEC
To minimise the risk of injury to children please dispose of your product carefully and safely.
Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the
appliance and always ensure that no plug is left in a condition where it could be connected to
the electricity supply.
To help the environment, Local Authority instructions should be followed for the disposal of
you product.
Disposal of your product
Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable
if the appliance has been installed in accordance with the installation instructions detailed in
this booklet.
To help make best use of your cooking equipment, please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not be accepted for
use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a window or use
an extractor fan) and that persons who may be sensitive to the odour avoid any fumes.
It is suggested that any pets be removed from the room until the smell has ceased. This odour is
due to temporary finish on oven liners and elements and also any moisture absorbed by the
insulation.
When the cooker is first used an odour may be emitted,
this will cease after a period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on the
rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or repaired by
any person other than the authorised employee or agent.
(d) Has been correctly installed.

Safety Information
When used properly your appliance is completely safe but as with any electrical product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.
Always
●Always make sure you remove all packaging and literature from inside the oven
and grill compartments before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces will
get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of steam or
heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on the
oven.
●Always keep the oven and grill doors closed when the appliance is not in use.
●Always keep the appliance clean as a build up of grease or fat from cooking can
cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●During use the oven becomes hot. Care should be taken to avoid touching
heating elements inside the oven,
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the
flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT.
Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of
the extinguisher is likely to tip the pan over. Never use water to extinguish
oil or fat fires.
5

Safety Information
Never
●Never leave children unsupervised where a cooking appliance is installed as all
cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this will cause the appliance to
overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the appliance controls.
●Never use ‘steam cleaners’.
6

Oven
Indicator
Light
Features
7
Clock/Minute Minder
Inner Door Glass
Oven & Grill
Selector
Oven & Grill
Temperature
control
Grill Element
Credaclean Liners
Oven Shelves
Door Switch
Oven Light
Meat/Grill pan
Oven Fan
Rating plate
Oven Door

A gentle flow of air will be blown below the control panel when the selector
switch is used.
The oven light is operated when the Fan Oven is selected.
The oven has a “Slow Cook Setting” this can be used for slow cooking, keeping
food warm and warming plates for a short period.
When Oven / Grill selector (A) is set to fan oven there is a safety device which
disconnects the heating element and oven fan when the door is opened.
The heating element and oven fan will not operate until the oven door is
closed.
Cooling Fan
Oven Interior
Lights
Slow Cooking
Element and
Fan cut-off
Control Panel
CONTROL MARKINGS
Note: It is advisable to check that all oven controls have been switched off after you
have finished using the appliance.
8
Control
Knob Description
Oven & Grill Selector
Oven/Grill Temperature
Control
A
B
Function
Turning Selector clockwise allows use of fan oven.
Turning Selector anti-clockwise allows use of grill.
Oven Temperature scale (in degrees centigrade)
When cooking turn clockwise to the required setting.
1 = Low Setting when grilling
6 = High Setting when grilling
80 -
230
Fan
Oven
Grill
1-6
AOVEN / GRILL SELECTOR BOVEN & GRILL TEMPERATURE CONTROL
OVEN PILOT LIGHT

Clock/Minute Minder Operation
9
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure the correct time of day is always set before using your
cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00 HOURS
AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the
display will return to normal brightness for a few seconds and then
dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will
remain lit for the period set. At the end of the Minute Minder Period,
the timer will emit an audible tone for 2 minutes, the symbol will
start to flash and will continue to flash until the Minute Minder function
is cancelled.
NB.
If at any time the display shows a ‘KEY’ symbol, the operation of the
timer is unaffected.
The ‘KEY’ symbol can be deleted by pressing both buttons for a period
of approximately 8 seconds, followed by a single press of the ‘+’ button.
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on, the display will show 0.00 / AUTO.
THIS NEXT STEP SHOULD BE COMPLETED WITHIN 4 SECONDS...
Step 4 Press and release both the ‘+’ and ‘-’ buttons together.
Press the ‘+’ button and the display will show 12.00
Then press the ‘+’ or ‘-’ button to set the correct time of day.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Step 4 above.
0.00
A
U
T
O
0.00
A
U
T
O
0.00
A
U
T
O
12.00

10
Clock/Minute Minder Operation
TIMER FUNCTION BUTTONS
Minute Minder
Here you can set a time period of up to 23 hours 59 minutes, that will
count down. When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20
minutes later.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and release the ‘-’ button, a symbol will light up.
Step 3 Within 4 seconds press the ‘+’ button to set the correct
period of time required.
Release the ‘+’ button.
The time is set and will continue to count down and the symbol will
be lit.
At the end of the set time a bleeping sound will be heard and the
symbol will flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop.
To cancel the symbol flashing, press the ‘-’ button once.
Step 4 To cancel the bleeping sound and the symbol, within the
2 minutes, press the ‘-’ button.
To cancel the minute minder period press the ‘-’ button.
Press the ‘-’ button again until the display shows 0.00
After 5 seconds the display will return to the time of day.
If at any time the display shows flashing zero’s / AUTO, it is likely that
the electricity supply has been interrupted.
Reset the timer to the correct time of day.
NOTE: WHEN THE MINUTE MINDER HAS BEEN SET, THE DISPLAY
WILL REVERT TO SHOW THE TIME OF DAY.
ANY REMAINING TIMED PERIOD CAN BE VIEWED BY
PRESSING THE ‘-’ BUTTON.
13.23
0.20
Bell Symbol

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove screw & washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace screw & washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace screw &
washers.
GRILL PAN AND FOOD GRID
DOOR POSITION FOR GRILLING
Grill Pan and Handle
11
Note: If a fixed handle is required, the grill pan is unable to be stored in the oven with the
door closed and cannot be used as a meat pan.
Step 1 Step 2 Step 3 Step 4
GRILL PAN FOOD GRID
(a)
(b) (c)
(d)
Note: DO NOT grill with the grill/oven door
closed.

Grilling Procedure
12
Note: DO NOTallow young children near to the appliance when the grill is in use as the
surfaces get extremely hot.
AB
Step 1 Ensure the oven shelf is in the correct position (see Guide to Grilling
Successfully).
Ensure door is in the grilling position (see grilling page)
Step 2 Turn knob (A) clockwise to GRILL function
Step 3 Turn knob (B) anti-clockwise to select the Grill Setting (1–6).
NOTE: When using the grill, a gentle flow if air will be detected coming from
beneath the control panel.
Step 4 After use, turn both controls A & B to their off (0) position.
Notes: • Preheat the grill at setting 6 on the grill control for approximately 5 minutes.
• The grill pan must be placed on the correct shelf and positioned centrally under
the grill element.
• Leave the control at 6 for toast, and for fast cooking of foods.
• For thicker foods requiring longer cooking, turn the switch to a lower setting
after the initial sealing on both sides at 6. The thicker the food, the lower the
control should be set.
• If excessive smoke is emitted reduce the setting.
•Do not line the grill pan with aluminium foil as this increases the amount of fat
spitting.
• Ensure that the Grill Pan is cleaned after use. Excessive fat build-up in the
bottom of the pan could cause a fire hazard.
• After use, always return both controls to their OFF (O) position.
Oven / Grill Selector Oven & Grill Temperature Control

Guide to Grilling Successfully
Food
Preheat
for
5 mins.
Shelf Position
from Base
of Oven
Approx.
Cooking
Time
Toasting of
Bread Products 6 6 or 5 Time depending on type of food.
Small cuts of meat,
sausages, bacon, etc. 3 6 or 5 10-20 mins.
Chops, gammon steaks
etc. 4 6 or 5 20-30 mins. depending on thickness.
Fish whole Fillets,
e.g. Fish Fingers 4 5 10-20 mins.
Pre-cooked potato
products 5 5 10-20 mins.
Pizzas 3 or 4 5 Preheat pan first, time depending on size and
type.
Browning of food 6 6 5-10 mins.
13

Since a circulaire fan oven heats up more quickly, and generally cooks food at a lower
temperature than a conventional oven, pre-heating is often unnecessary.
For guides on “pre-heating”, “cooking temperatures” and “cooking times”, see “Oven Temperature
Charts” later in book.
OVEN SHELF POSITIONING FOR FAN OVEN
Most foods will cook satisfactorily on any shelf position, due to even distribution of heat in the
oven, but the shelves must be evenly spaced.
Food or utensils should never be placed directly on the floor of the oven for cooking as air
circulation is restricted.
OVEN UTENSILS
Do not use: Meat pans larger than 375mm x 300mm (15” x 12”)
Baking Trays larger than 325mm x 250mm (13” x10”)
An additional oven shelf can be purchased, from our Parts Department or your nearest retailer, if
a third one is required for batch baking. Never use more than three shelves in the oven at one
time as air circulation will be restricted.
TEMPERATURE & TIME
If three shelves are in use to cook large quantities of food, it may be necessary to increase the
cooking times given in the temperature charts by a few minutes, to allow for the loss of heat due
to extra time taken to load the oven, and the larger mass of food. Baking trays should have an
even gap around the oven.
Using the Oven for Fan Cooking
14
NOTE: Charts are a guide only, to suit personal taste and requirements, it may be necessary
to increase or decrease temperatures by 10˚C. It may also be necessary to increase or
decrease cooking times.
DO NOT allow young children near to the appliance when the oven is in use as the surfaces
get extremely hot.
Fan
Oven

FAN OVEN OPERATION
Step 1 Ensure that the oven shelf is in the correct position.
Place food centrally on the shelf ensuring the oven door is fully closed.
Turn Oven / Grill selector, knob A anti-clockwise to FAN OVEN function.
Step 2 Turn knob (B) anti-clockwise and select the required cooking temperature
(80˚C to 230˚C). The pilot light will immediately come on, and remain on until
the oven reaches the required temperature. The light will then automatically
go off and on during cooking as the oven thermostat maintains the correct
temperature.
Step 3 After use turn both controls to their Off (O) position.
NOTE: At the end of a cooking period there may be a momentary puff of steam
when the door is opened. This will disperse in a few seconds and is a
perfectly normal characteristic of an oven with a good door seal.
Using the Oven for Fan Cooking
Fan
Oven
15
AB
Oven / Grill Selector
Oven Pilot Light
Oven & Grill Temperature Control

“SLOW” SETTING
This is used for slow cooking, keeping food warm and warming plates for short
periods. Extra care should be taken when warming bone china, as it may be
damaged in a hot oven.
ADVANTAGES OF SLOW COOKING ARE:
The oven stays cleaner because there is less splashing.
Timing of food is not as critical, so there is less fear of overcooking.
Inexpensive joints of meat are tenderised.
Fully loading the oven can be economical.
Cooking times can be extended in some cases by up to 2 hours.
The kitchen stays cooler.
OPERATION:
1. Place the prepared food in the main oven and ensure the door is fully closed.
2. Turn knob A to Fan Oven function.
Turn knob B to (slow cooking temperature).
STORAGE & RE-HEATING OF FOOD:
1. If food is to be frozen or not used immediately, place it in a clean container
and cool as soon as possible.
2. Always thaw frozen food completely in the refrigerator before re-heating.
3. Always reheat food thoroughly and ensure it is piping hot before serving.
4. Only re-heat food once.
POINTS TO CONSIDER WHEN PREPARING FOOD FOR SLOW COOKING
1. Make sure that all the dishes to be used will fit into the oven ensuring enough room
for air to circulate.
2. All dishes cooked on the slow setting will require a minimum of 6 hours, however,
it they are cooked for 1-2 hours longer then deterioration in their appearance may
be noticed.
3. Never cook joints of meat over 2.7kg (6 lb) or poultry over 2.0kg (4lb 8oz).
We do not recommend that joints of meat or poultry are stuffed before cooking on
the slow setting.
4. To seal in the meat juices, always cook meat or poultry at 170oC for 30 minutes
before wrapping in foil and placing on a rack over a tin (to allow good air
circulation) before turning the control to the slow setting and cooking immediately.
5. Always ensure that joints of pork and poultry are thoroughly cooked by checking
with a meat thermometer before serving.
6. Always thaw frozen foods completely before cooking. We do not recommend
placing frozen food in the oven to cook.
7. Always bring soups, liquids and casseroles to the boil before placing in the oven.
8. Ensure that casserole dishes have a good seal (not airtight) and cover to the
top with foil to prevent loss of moisture.
9. Ensure that fruit and vegetables are cut into even sized small pieces to cook
properly.
10. Always adjust seasoning before serving.
11. If using dried red kidney beans it is important that the beans are soaked and then
boiled for a minimum of 10 minutes before using in any dish to destroy any toxins.
12. When cooking fish or egg dishes it may be necessary to check during cooking to
avoid overcooking.
Using the Oven for Other Functions
16
90
DO NOT place food or plates directly on the oven floor as this could damage both the oven
lining and the plates which are being warmed.
90

oF
Gas
Mark
1/2
1
250 100
120
130
140
160
170
180
200
210
220
120
140
150
160
180
190
200
220
–
–
275
300
325
350
375
400
425
450
475
2
3
4
5
6
7
8
9
Main
Conventional
Oven
Main
Fan
Oven
Temperature Conversion Chart
17

Fan Oven Cooking
Meat
Beef
Lamb
Pork
Veal
Chicken/Turkey
up to 4kg (8lb)
Turkey up to 5.5kg
(12lb)
Turkey over 5.5kg
(12lb)
Casserole / Stews
Food
Temperature
oC
Time
(approx.)
Pre-
heat
No 160/180 20-25 mins per 450g (1lb)
+ 20 mins extra
25 mins per 450g (1lb)
+ 25 mins extra
25 mins per 450g (1lb)
+ 25 mins extra
25-30 mins per 450g (1lb)
+ 25 mins extra
18-20 mins per 450g (1lb)
+ 20 mins extra
13-15 mins per 450g (1lb) e.g. 5kg
(11lb) = 143-165 mins
12 mins per 450g (1lb) e.g.
10kg (22lb) = 264 mins
11⁄2- 2 hours
160/180
160/180
160/170
160/180
150/160
150
140/150
No
No
No
No
No
No
No
Note: Up to three shelves may be used in this oven. The position
of
these is not important providing they are evenly spaced.
IF USING ALUMINIUM FOIL
1. Never allow foil to touch sides of oven. 2. Never cover interior with foil.
3. Never cover shelves with foil.
The most accurate method of testing the readiness of joints of meat or whole
poultry is to insert a meat thermometer into the thickest part of a joint of meat, or
the thickest part of poultry thighs, during the cooking period. The meat
thermometer will indicate when the required internal temperature has been
reached.
Oven Temperature Chart - Meat
Beef
Rare 60OC Medium 70OC90
OC80 OC90 OC75 OC
Well Done 75OC
Pork Lamb Poultry Veal
18

Fan Oven Cooking
Food
Scones
Small Cakes
Victoria Sandwich
Sponge Sandwich
(Fatless)
Swiss Roll
Semi-rich
Fruit Cake
Rich Fruit Cakes
Shortcrust
Pastry
Puff Pastry
Yorkshire Pudding
Individual Yorkshire
Pudding
Milk Pudding
Baked Custard
Bread
Meringues
Baking
Temperature
oC
Time
Pre-
heat
Yes 210/220 9-12 mins
15-25 mins
20-25 mins
15-20 mins
12-15 mins
11⁄4-11⁄2hours
Time depending on use
Time depending on use
Time depending on use
40-45 mins
20-45 mins
11⁄2-2 hours
35-45 mins
20-30 mins
3-4 hours
170/180
160/170
170/190
180/200
140/150
130/140
190/200
190/200
180/190
190/200
130/140
140/150
200/210
70/90
No
No
Yes
Yes
No
No
No
No
Yes
Yes
No
No
Yes
No
Note: Up to three shelves may be used in this oven. The position
of
these is not important providing they are evenly spaced.
Oven Temperature Charts - Baking
Note: If soft tub margarine is being used for cake making, we would recommend using the all in one
method and to reduce the temperature by 10˚C. Temperatures recommended in this chart refer to
cakes made with block margarine or butter only.
19

Cooking Results Not Satisfactory
GRILL
Uneven cooking front to back Ensure that the grill pan is positioned centrally
below the grill element.
Fat splattering Ensure that the grill pan is not lined with foil.
Ensure that the grill setting is not too high.
BAKING GENERAL
Uneven rising of cakes Ensure that the oven shelves are level.
Sinking of cakes The following may cause cakes to sink:
1. Pre-heating of fan ovens – not always necessary.
2. Cooking at too high a temperature – reduce
standard temperatures by 25˚C for fan ovens.
3. Using normal creaming method with a soft
margarine. If using soft margarine, use an all in
one method instead of the traditional creaming of
the margarine and sugar. Remember when using
a food mixer or processor not to over-cream soft
margarine.
Over/undercooking Refer to the cooking times and temperatures given in
the Oven Temperature Charts provided, however, it
may be necessary to increase or decrease
temperatures by 10˚C to suit personal taste.
Do not use utensils greater than 56mm (2l⁄4'') in
height for roasting.
20
