Creda E430E Guide

You must read these instructions prior to using the
appliance and retain them for future reference.
N230E / E430E / R430E
Installation & User Instructions

For more information on our exciting product range ring
Creda Answer Centre 08701 54 64 74
OR
Visit us on the NET at
http://www.creda.co.uk
General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB
Creda Answer Centre 08701 54 64 74
Web http://www.creda.co.uk
It may be necessary from time to time to change the specification outlined in this booklet
without notice. Any change which is made will not affect your statutory rights.
Our site invites you to make use of our interactive cookbook and product selector. Feel
free to browse our product range to see what’s bubbling away at the moment or to ask
for help on our products and services

Contents
3
Introduction 4
Safety Information 5
Features 7
Controls 8
Oven Timer Operation 9
Using the Top Oven for Solarplus Grilling 15
Grill Pan and Handle 16
Operation when using Top Oven for Grilling 17
Solarplus Grill Chart 18
Conventional Grilling 19
Using the Top Oven as a Convection Oven 20
Operation when using the Top Oven as a Convection Oven 21
Using the Main Oven for Fan Cooking 22
Using the Main Oven for Other Functions 23
Temperature Conversion Chart 25
Oven Temperature Charts 26
Cooking Results Not Satisfactory? 28
Care and Cleaning 29
Installation 33
Something Wrong? 37
Key Contacts Back Cover

Introduction
4
This appliance conforms to the following EEC Directives:
Electromagnetic Compatibility Low Voltage Equipment
89/336/EEC 73/23/EEC
92/31/EEC 93/68/EEC
93/68/EEC
To minimise the risk of injury to children please dispose of your product carefully and safely.
Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the
appliance and always ensure that no plug is left in a condition where it could be connected to
the electricity supply.
To help the environment, Local Authority instructions should be followed for the disposal of
you product.
Disposal of your product
Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable
if the appliance has been installed in accordance with the installation instructions detailed in
this booklet.
To help make best use of your cooking equipment, please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not be accepted for
use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a window or use
an extractor fan) and that persons who may be sensitive to the odour avoid any fumes.
It is suggested that any pets be removed from the room until the smell has ceased. This odour is
due to temporary finish on oven liners and elements and also any moisture absorbed by the
insulation.
When the cooker is first used an odour may be emitted,
this will cease after a period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on the
rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or repaired by
any person other than the authorised employee or agent.
(d) Has been correctly installed.

Always
●Always make sure you remove all packaging and literature from inside the oven
and grill compartments before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces will
get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of steam or
heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on the
oven.
●Always keep the oven and grill doors closed when the appliance is not in use.
●Always take care when removing utensils from the top oven when the main oven
is in use as the contents may be hot.
●Always keep the appliance clean as a build up of grease or fat from cooking can
cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●During use the oven becomes hot. Care should be taken to avoid touching
heating elements inside the oven,
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the
flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT.
Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of
the extinguisher is likely to tip the pan over. Never use water to extinguish
oil or fat fires.
5
Safety Information
When used properly your appliance is completely safe but as with any electrical product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.

Never
●Never leave children unsupervised where a cooking appliance is installed as all
cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this will cause the appliance to
overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the appliance controls.
●Never use ‘steam cleaners’.
6
Safety Information

Features
7
TOP OVEN
TEMPERATURE
& GRILL SELECTION
CONTROL
MAIN OVEN
TEMPERATURE
& FUNCTION
CONTROL CLOCK & OVEN
TIMER
SOLARPLUS
GRILL (not
all models)
OVEN LIGHT
(not all models)
MAIN OVEN
PILOT LIGHT
TOP OVEN
PILOT LIGHT
GRILL PAN
TOP OVEN
DOOR
OVEN LIGHT
INNER DOOR
GLASS (not
all models)
OVEN SHELF
DOOR SWITCH
(not all models)
RATING PLATE
GRILL
SETTING
CONTROL
GRILL
ELEMENT
EASY GLIDE™
SHELF (not all
models)
CREDACLEAN
LINER (E430E /
N230E),
VITREOUS ENAMEL
LINER (R430E)
OVEN FAN
CREDACLEAN
LINER (E430E /
N230E),
VITREOUS
ENAMEL LINER
(R430E)
MEAT PAN
INNER DOOR
GLASS
MAIN OVEN
DOOR

Cooling Fan: A gentle flow of air will be blown below the control panel when any selector
switch is used.
Note: Whenever the appliance has been used, the cooling fan may run on or
restart itself after all the controls have been turned off.
This indicates that the appliance is still warm.
Oven Interior The oven lights are operated when their respective oven control is
Lights used. (N.B. Not all models have a top oven interior light).
The main oven has a light only position.
Slow Cooking The main oven has a “Slow Cook Setting”, 90˚C, this can be used for slow
cooking, keeping food warm and warming plates for a short period.
Element and Fan The oven is fitted with a safety device which disconnects the heating
Cut-off element and oven fan when the door is opened.
(Not on N230) The heating element and oven fan will not operate until the oven door is
closed.
model)
Controls
Control Markings
Note: It is advisable to check that all oven controls have been switched off when you have
finished using the appliance.
8
Control Knob Description
Grill Setting Control
Top Oven Temperature &
Grill Selection Control
Main Oven Temperature &
Function Control
A
AC
B
B
C
Function
Selects the heat at which the grill will cook the
food. 1 – 6 Grill Settings Control:
1 = Low, 6 = High
Note: To grill you must first select a grill
function using control (B).
Selects the cooking temperature
(Degrees Centigrade) when using the top
oven as a conventional oven.
Switches the top oven to “Half Grill”
mode.
Switches the top oven to “Full Grill”
mode.
Fan Only Setting
- This is used to decrease the amount
of time required to defrost food items.
Oven Light Only
- Switches on the Main Oven Interior
Light Only.
Main Oven Temperature Scale (In
Degrees Centigrade).
- When cooking select the required
cooking temperature.
100 -
220
Half
Grill
Full
Grill
Fan
Only
Oven
Light
80 -
230
GRILL SETTING CONTROL MAIN OVEN TEMPERATURE AND FUNCTION CONTROL
TOP OVEN TEMPERATURE AND GRILL SELECTION CONTROL TIMER

Oven Timer Operation
9
The oven timer offers you the following features:
1. Time of Day
2. Automatic Cooking
3. Minute Minder
The Main Oven (only) can be controlled by the automatic timer.
Never operate the grill or top oven when the main oven is set to cook
automatically because the oven cavity can become warm and this may cause
bacterial growth in food.
1. Select foods which will take the same time to cook and require
approximately the same temperature.
2. Set the oven timer so that the food has just finished or about to
finish cooking on your return to the oven. This will ensure the
food has not cooled down and does not require reheating
before serving.
3. Food should be as cold as possible when it goes into the oven,
ideally straight from the refrigerator. Frozen meat and poultry
should be thawed thoroughly before it is put in the oven.
4. We advise that warm food should never be placed in the oven if
there is to be a delay period. Stews prepared by frying the meat
and vegetables should be cooked as soon as possible.
5. We advise dishes containing left-over cooked poultry or meat,
for example Shepherds Pie, should not be cooked automatically
if there is to be a delay period.
6. Stews and joints should be cooked by the long slow method, so
that the delay period is kept to a minimum.
7. On warm days, to prevent harmful bacterial growth in certain
foods (ie poultry, joints, etc) the delayed start should be kept to
a minimum.
8. Wine or beer may ferment and cream may curdle during the
delay period, so it is best to add these ingredients just before
serving.
9. Foods which discolour should be protected by coating in fat or
tossing in water to which lemon juice has been added, prior to
placing food in the oven.
10. Dishes containing liquid should not be filled too full to prevent
boiling over.
11. Food should be well sealed (but not airtight) in a container to
prevent the loss of liquid during cooking. Aluminium foil gives a
good seal.
12. Ensure food is cooked thoroughly before serving.
1. Make sure all oven controls are turned Off.
2. Check that the electricity supply to the oven is turned On.
3. Check that the oven clock is at the right time of day.
Automatic Cooking
Hints on
Automatic
Cooking
Timer
Operation

10
Know Your Timer
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure the correct time of day is always set, before using you cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00
HOURS AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the display will
return to normal brightness for a few seconds and then dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will remain lit for the
period set. At the end of the Minute Minder Period, the timer will emit an audible
tone for 2 minutes, the symbol will start to flash and will continue to flash until
the Minute Minder function is cancelled.
This “Cookpot” symbol will light up either:–
– When you press the Cook Period Button and set a length of time for an Auto
Cooking Programme. (It will go out again a few seconds after you release the
timer buttons).
– During the actual Cook Period.
“AUTO” will light up:–
– When the timer is first turned on it will flash. (It will go out when a time of day
is set.
– When an Auto Cooking Programme has been set.
The “Auto” symbol will flash at the end of an Auto Cooking programme to indicate
that the programme has finished.
(When the “Auto” symbol is flashing, to return the oven to Manual operation,
turn the oven controls off, ensure that the correct time of day is set, and press the
“Manual” button twice – The “Auto” symbol will go out).
Here you can set a time period of up to 23 hours 59 minutes, that will count down.
When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.
Cook Period is the actual length of time for which, the timer will switch the oven(s)
on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The
timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will hear
a audible tone at 11:00, to indicate that the Auto Cooking Programme has finished.
Notes:
- When setting an Auto Cooking programme you will need to set the oven
controls(s) to the required temperature(s) when you set the timer.
- If an Auto Cooking programme has been set the oven(s) will only operate during
the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return the ovens(s)
to Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME
Note: If at any time the display shows a ‘KEY’ symbol, it is likely that the timer has been set incorrectly. OVEN
COOKING IS NOT POSSIBLE. The ‘KEY’ symbol can be deleted and the cooker returned to manual operation by:
- Simultaneously pressing the Minute Minder and the Cook Period buttons for a period of approximately 8
seconds.
- Releasing the buttons and pressing the ‘+’ button.

Electronic Clock and Automatic Oven Timer Operation
11
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and Auto symbol will be
flashing intermittently.
Step 4 Press & hold in both the “Minute Minder” & “Cook Period” button together.
Step 5 With the “Minute Minder” & “Cook Period” buttons still held in, press either
the “+” or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set for an Auto
Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder Button, a symbol will light up.
Step 3 With the “Minute Minder” button held in, set the required Minute Minder
time using the “+” and “–” buttons.
Release all buttons and the timer display will revert back to the time of day. Bell
symbol will remain lit to signify that a Minute Minder period has been set.
At the end of the set time a bleeping sound will be heard, and the symbol will
flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop and the symbol will
go out automatically.
Step 4 To cancel the bleeping sound within the two minutes press the Minute
Minder button.
Note 1 When the Minute Minder has been set, the time remaining can be checked at any
time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone sounds by pressing
and holding the Minute Minder button and then at the same time pressing the “–”
button until 0.00 appears in the display window.

Electronic Clock and Automatic Oven Timer Operation
12
Step 3 Press and hold in the Cook Period button.
The display will read 0.00 with the cookpot ( ) symbol lit.
Step 4 With the Cook Period button still held in, set the required Cook Period
using the “+” and “–” buttons.
Release the buttons and the timer display will revert to the time of day with the
Auto symbol and Cookpot ( ) symbol lit.
Step 5 Press and hold in the “End Time” button.
The display will read the earliest possible end time for the Cook Period that
you have set above.
The Auto symbol and Cookpot ( ) symbol lit.
Step 6 With the End Time button still held in, use the “+” and “–” buttons to set
the “End Time” (i.e. The time you require the oven to switch off).
Release all the buttons and the timer will revert back to the time of day.
The “Auto” symbol will remain lit to signify that an Auto Cooking Programme has
been set. The ( ) symbol will go out.
Step 7 Turn the oven control(s) to the required temperature, and if
necessary select the appropriate oven function.
Note: If your appliance has two ovens: When the timer has been set for one oven
it is possible to use the other oven onlyduring the same Automatic programme.
At the end of the Automatic Cook Period the Auto Symbol will flash and an
intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless cancelled.
The “Auto” symbol will continue to flash until the timer is returned to Manual
operation (see below).
Step 8 Press the Manual button to cancel the bleeping sound.
(If 2 minutes has not elapsed).
Step 9 Turn the oven control(s) to the OFF position.
Step 10 Press the manual button again to return the oven(s) to Manual Operation.
(The Auto symbol will go out)
AUTO COOKING PROGRAMMES
There are two Auto Cooking programmes that can be selected using your timer:–
(a) To set the timer to switch the oven(s) On and Off Automatically
(b) To set timer to switch on immediately and OFF automatically after a set cook period.
a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY
This allows you to cook at a specified time for a chosen period before the oven switches
off Automatically.
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).

Electronic Clock and Automatic Oven Timer Operation
13
Step 4 Press & hold in the “Cook Period” button, the display will read 0.00 and the
cookpot ( ) symbol will light up.
With the Cook Period button still held set the required Cook Period using the “+”
and “–” buttons. Example: 1hr 30 minutes (as shown).
Note: Cook Period is the length of time the food requires to cook.
Step 5 Release all buttons.
The timer display will revert to the time of day with the Auto symbol lit & Cookpot
symbol remaining lit.
At the end of the Cook Period the “Auto” symbol will flash and an intermittent
bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless cancelled.
The “Auto” symbol will continue to flash until the timer is returned to Manual
operation (see below).
Step 6 Press the manual button to cancel the bleeping.
(If 2 minutes has not elapsed)
Step 7 Turn the oven control(s) to the OFF position.
Step 8 Press the “Manual” button again to return the cooker to Manual operation.
(The Auto symbol will go out).
b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY AFTER A SET COOK
PERIOD
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven
function.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply
pressing the Cook Period button.
Note 2 When cooking automatically the End Time can be checked at any time by simply
pressing the End Time button.
NOTE: The Cookpot symbol disappears

Electronic Clock and Automatic Oven Timer Operation
14
OTHER NOTES ON TIMER OPERATION
1. When cooking Automatically the Cook Period can be checked at any time simply by pressing the Cook
Period button.
2. When cooking Automatically the End Time can be checked at any time by simply pressing the End Time
button.
3. Having set a Cook Period and End Time an electronic device stores the information. The device within the
timer will switch the oven(s) on and off at the required times.
4. When setting an Auto Cooking Programme and a mistake is made, to clear:–
(a) Press and hold in the “Cook Period” button.
(b) With the Cook Period button still held in, return the display to by pressing the “–” button.
(c) Release the “Cook Period” & “–” buttons, and the display will revert to the time of day and the “Auto”
symbol will flash.
(d) Press & release the “Manual” button.
(e) Start the sequence again.
5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply to the oven
has been interrupted. Reset the timer to the correct time of day.
Food in the oven may, therefore, not have been cooked, before serving check food is thoroughly heated
and completely cooked.
6. To set each function always press and hold the required function button and at the same time press “+” or
“–” buttons.
Note: Between the hours of 22.00 & 06.00 the display dims to prevent glare.
However, if you should operate a button during this period, the timer will return to normal
brightness for a few seconds and then dim again.
A
U
T
O
TO CANCEL AN AUTO COOKING PROGRAMME BEFORE
THE COOK PERIOD HAS FINISHED.
Step 1 Turn the oven control(s) to the OFF position.
Step 2 Press and hold in the “Cook Period” button.
Step 3 With the “Cook Period” button still held in, return the display to 0.00 by
pressing the “–” button.
Step 4 Release the “Cook Period” and “–” buttons and the display will revert to
the time of day and the “Auto” symbol will flash.
Step 5 Press the “Manual” button to return the oven(s) to “Manual” operation.
The “Auto” symbol will go out.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing
the Cook Period button.

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove the screw and washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace the screw and washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace the screw and
washers.
Grill Pan Food Grid and Anti-Splash Tray
Top Oven Shelf Positioning for Grilling
Grill Pan and Handle
15
Note: If a fixed handle is required, the grill pan cannot be kept in the main oven with the
door closed but may be stored in the top oven with the door closed, when the top oven is
not in use..
Step 1 Step 2 Step 3 Step 4
GRILL PAN FOOD GRID
GRILL PAN ANTI-SPLASH
TRAY (Not on N230
model)
(a)
(b) (c)
(d)
NOTE: Preheat the grill if indicated on grill chart.
The grill pan must be placed on the correct shelf and positioned centrally under the grill
element.
Leave the control at 6 for toast, and for fast cooking of foods.
For thicker foods requiring longer cooking, turn the switch to a lower setting after the
initial sealing on both sides at 6. The thicker the food, the lower the control should be set.
DO NOT line the grill pan with aluminium foil, as this increases the amount of fat spitting
which can cause a fire.
After use always return both controls to their OFF (0) position.
ENSURE SHELVES ARE FITTED CORRECT WAY UP.
DO NOT PLACE FOOD/UTENSILS DIRECTLY ON THE OVEN FLOOR
3
2
1
3
2
1
Note: To stop fat splashing onto the grill mesh, it is important to use the anti-splash tray as
shown in the grilling chart. Always clean the grill pan, anti-splash tray and food grid after
each use.

Your cooker is not fitted with a conventional grill. Creda have developed a Solarplus
high speed grill which is designed to reduce your grilling times. It is quicker because it
takes less time to warm up from cold. Conventional grills require 5 minutes pre-heat
before food is placed beneath them, but for normal grilling the Solarplus grill can be
used directly from cold without any pre-heat.
However, when toasting, optimum performance is achieved by pre-heating the grill for
about 1 minute.
During use the mesh may become soiled. Do not attempt to clean it while the grill is
still on. Turn off at the control and allow to cool before cleaning. Care must be taken
to ensure the grill mesh is not distorted – do not store the grill pan handle on the food
grid when the shelf is in the highest position.
IMPORTANT
GRILLING SHOULD NEVER BE UNDERTAKEN WITH THE GRILL/TOP OVEN DOOR
CLOSED.
Grilling procedure:
1. Open the grill/top oven door fully.
2. Ensure that the Easy Glide™ Shelf is located in the correct position (see ‘Guide to
Grilling’).
3. Preheat the grill, if necessary, with the Easy Glide™ Shelf pulled out (see Fig 1).
4. Locate the grill pan in the Easy Glide™ Shelf (see Fig 2) and push back under the
element.
5. The grill pan should be withdrawn, always using the grill pan handle, to the
stop position to turn or remove cooked food. (There is no need to remove the grill
pan from the Easy Glide™ Shelf).
6. NEVER line the grill pan with aluminium foil as this may cause over heating of fat in
the grill pan.
NOTE: To stop fat splashing onto the grill element mesh, it is important to use the anti-
splash tray. Always clean the grill pan anti-splash tray and food grid after each use.
Using the Top Oven for Solarplus Grilling
16
Note: You will notice that the grill elements are protected by a wire mesh. This stops
you from touching live parts.
DO NOT under any circumstances insert objects into the grill mesh as this could
damage the element wire, break the glass tubes or if the grill is on, cause electric
shock.
Fig 1 Fig 2
●Only use the grill pan supplied.
●Never attempt to remove the Easy Glide™ Shelf with the grill pan in position.
●Always withdraw the Easy Glide™ Shelf to its stop position before removing the
grill pan (to avoid damaging the grill).

Step 1 Ensure that the timer is set to manual.
Step 2 Place the grill pan runner/support in the correct position (see Grilling Guide).
Locate the grill pan in the runner/support, position centrally under the grill
element.
Leave the door fully open.
Step 3 Turn knob (B) clockwise to select grill function setting:
Set to: For Half Grill (Left hand side only).
For Full Grill.
Step 4 Turn knob (A) clockwise to select the Grill Setting (1–6). (1=Low, 6=High).
Grill Controls Example:
= Full Grill Function
= Maximum Grill Setting
NOTE: Do not grill with the grill/top
oven door closed.
Step 5 After use, turn both controls A & B
anti clockwise to their off (●) position.
Operation when using the Top Oven for Grilling
17
NOTE: As you turn past the end of the oven temperature scale you will feel resistance on the
knob – continue turning clockwise until the grill setting position is selected.
Half
Grill
Full
Grill
Full
Grill
6
6Full
Grill
DO NOT allow young children near to the appliance when the grill is in use as the surfaces
get extremely hot.
GRILL SETTING CONTROL
TOP OVEN TEMPERATURE
AND GRILL SELECTION CONTROL TIMER
DOOR POSITION
FOR GRILLING.
A
B

Guide to Solarplus Grilling
18
Food Preheat for one
minute
Easy Glide™ Shelf
Position from base of
oven. Setting Approximate
Cooking Time Pan to be used
Grill pan and food
support
3-5 minutes
10-15 minutes
25-30 minutes
6-8 minutes
10-15 minutes
10-15 minutes
10-12 minutes
10-12 minutes
5-10 minutes
Setting 6
Setting 6 for 4 minutes
then reduce to Setting 5
Setting 6 for 6-8 minutes
then reduce to Setting
4 or 5
Setting 6
Setting 4
Setting 4
Setting 6
Toasting of Bread
Products
Small cuts of meat,
Sausage, Bacon
Chops etc.
Gammon steaks
Fish Whole
Fillets
Fingers
Pre-cooked Potato
products
Pizzas
Browning of food
eg. Cauliflower
Cheese
3 or 2
3 or 2
2
2
3
3
3 or 2
3 or 2
3 or 2
Setting 6
None
None
None
None
None
None
None
Setting 6
Grill pan, anti-splash
tray and grid
Grill pan, anti-splash
trivet & food support
Grill pan and food
support
Grill pan and food
support
Grill pan and grid
Dish placed directly
on the shelf

CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN
SHOULD BE KEPT AWAY. GRILLING SHOULD NEVER BE UNDERTAKEN WITH THE
GRILL/TOP OVEN DOOR CLOSED.
The grill control is designed to provide variable heat control of either the twin grill elements
on together or the single left hand grill element only, depending upon which direction the
control knob is rotated. With the control rotated clockwise the numbers in the window will
show 1through to 6the twin elements will come on together. With the control turned anti-
clockwise the window will show 1through to 6and the single left hand element will come on
only.
The control is Off at O.
Note: The grill will not operate unless the top oven control is in the OFF position.
Food which requires browning only should be placed under the hot grill, directly on the shelf
in the first or second runner from the bottom of the oven, according to the depth of the dish.
Open the Grill door to the grilling position. i.e. fully.
With the grill door in the grilling position, heating the grill is achieved by turning the control
clockwise to the desired ‘grill setting’ on the control panel, as described under ‘setting the grill’.
Never: line the grill pan with aluminium foil.
Note: When the door is open, air will be blown from beneath the controls by the cooling fan,
and when controls are in the Off position. Preheat the grill at setting 4for approximately 5
minutes. The grill pan is placed on the shelf and should be correctly positioned under the grill
element. Leave the control at HI for toast, sealing and fast cooking of foods. For thicker foods
requiring longer cooking, turn the switch to a lower setting after the initial sealing on both
sides at 4. The thicker the food the lower the control should be set.
Grill pan handle
The grill pan handle is detachable from the pan, to facilitate cleaning and storage. The handle
can be either detachable from or fixed to the pan. For a fixed handle remove the screw and
washers from the grill pan bracket, tilt the handle over the recess adjacent,to the bracket. (A)
Slide the handle towards the centre of the pan (B) and let the handle locate over the bracket.
(C)
Replace screw and washers and ensure that they are fully tightened up. For a detachable
handle remove screw and washers from grill pan and keep safe.
Please note that if a fixed handle is required, the grill pan cannot be kept in the Fan Oven with
the door closed but may be stored in the Top Oven.
Warning: Ensure when using grill pan handle in the detachable manner it is centralised
and secure.
19
AB C
Conventional Grilling (N230E)

The top oven should be used to cook small quantities of food. The oven is designed so
that the grill element operates at a reduced heat output, this is combined with a
heating element situated underneath the floor of the oven. To ensure even cooking of
the food it is important that cooking utensils are positioned correctly on the oven
shelf so that the element is directly above. As a guide, the front of the utensil should
be approx. 100mm (4”) from the front of the shelf.
Easy Glide™ Shelf
The Easy Glide™ Shelf, in conjunction with the grill pan supplied can be used for
cooking in the oven(s), ie. meat, poultry etc. also for roasting vegetables.
Place the Easy Glide™ Shelf in the oven on the same runner position as stated in the
meat cooking chart.
Important:
Always remove the grill pan handle from the grill pan, when the pan is being used for
oven cooking.
Always use oven gloves when basting, turning or removing food from the oven, as the
Easy Glide™ Shelf and the pan will be hot.
Never remove the Easy Glide™ Shelf from the oven with pan and food still in position.
Shelf Positioning
There should always be at least 25mm (1 inch) between the top of the food and
the grill element.
DO NOT PLACE FOOD/UTENSILS DIRECTLY ON THE OVEN FLOOR
3
2
1
ENSURE SHELVES ARE FITTED THE CORRECT WAY UP
Using the Top Oven as a Convection Oven
Note: Charts are a guide only, to suit personal taste and requirements, it may be
necessary to increase or decrease temperatures by 10oC. It may also be necessary to increase
or decrease cooking times.
WARNING: Items stored in the top oven will get hot when the main oven is in use.
DO NOT allow young children near to the appliance when the top oven is in use as the
surfaces get extremely hot.
20
