Creda HBE230 Product guide

Note: Timer must be set to ‘Time of Day’ and ‘Manual’
before the ovens can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.
Double Ovens
Users Instruction & Installation Book for:
This appliance shall be installed in accordance with the
regulations in force and only used in a well
ventilated space.
Read the instructions before installing or using the
appliance and retain them for future use
Europa Gas

2
For more information on our exciting product range ring
Creda Answer Centre 0541 54 64 74
OR
Visit us on the NET at
http://www.creda.co.uk
General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB
Creda Answer Centre 0541 54 64 74
Web http://www.creda.co.uk
It may be necessary from time to time to change the specification outlined in this booklet
without notice. Any change which is made will not affect your statutory rights.
Our site invites you to make use of our interactive cookbook and product selector. Feel
free to browse our product range to see what’s bubbling away at the moment or to ask
for help on our products and services

Introduction 4
CONTENTS
For Your Safety – Always 5
For Your Safety – Never 6
Features 7
Controls 8
Oven Timer Operation 9
Know Your Timer 10
Electronic Clock & Automatic Oven Timer Operation 11-14
Grill Pan and Handle 15
Using The Grill 16
Using the Top Oven 17
Using the Main Oven 20
Care and Cleaning 25
Installation 28
Something Wrong? 35
Service Back Cover
3
DISPOSAL OF YOUR PRODUCT
To minimise the risk of injury to children please dispose of your product
carefully and safely. Remove all doors and lids (where fitted). Remove the mains cable
(where fitted) by cutting off flush with the appliance and always ensure that no plug is
left in a condition where it could be connected to the electricity supply.
To help the environment, Local Authority instructions should be followed for the
disposal of your product.

INTRODUCTION
Your new cooker is guaranteed* and will give lasting service. This guarantee is only applicable if
the appliance has been installed in accordance with the installation instructions detailed in this
booklet.
To help make best use of your cooking equipment,
please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not be accepted for
use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a window or use
an extractor fan) and that persons who may be sensitive to the odour avoid any fumes.
It is suggested that any pets be removed from the room until the smell has ceased. This odour is
due to any temporary finish and also any moisture absorbed by the insulation.
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage and gas
supply as stated on the Data badge attached to this equipment.
(c) Has not been subjected to misuse or accident or has not been modified
or repaired by any person other than the authorised employee or agent.
(d) Has been correctly installed.
4
This appliance conforms to the following EEC Directives:
Low Voltage Equipment Gas Appliances
73/23/EEC 90/396/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC

FOR YOUR SAFETY
When used properly, your appliance is completely safe but as with any product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.
ALWAYS
●Always make sure you remove all packaging and literature from inside the oven
and grill compartments before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces will get
extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking and
when not in use.
●Always stand back when opening an oven door to allow any build up of steam or
heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and allow
the appliance to cool.
●Always make sure the shelves are in the correct position before switching on the
oven.
●Always keep the oven and grill doors closed when the appliance is not in use.
●Always take care when removing utensils from the top oven when the main
oven is in use as the contents may be hot.
●Always keep the appliance clean as a build up of grease or fat from cooking can
cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a CORGI registered service engineer.
5

FOR YOUR SAFETY
NEVER
●Never leave children unsupervised where a cooking appliance is installed as all
cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never allow children to play with the controls.
6
NOTE: The use of a gas cooking appliance results in the production of heat and moisture
in the room in which it is installed. Ensure that the kitchen is well ventilated; keep
natural ventilation holes open or install a mechanical ventilation device (mechanical
extractor hood).
Prolonged intensive use of the appliance may call for additional ventilation, for example
opening of a window, or more effective ventilation, for example increasing the level of
mechanical ventilation where present.

FEATURES
7
TOP OVEN
TEMPERATURE
& GRILL
CONTROL
CLOCK & OVEN TIMER
OVEN
LIGHT
GRILL PAN
TOP OVEN
DOOR OVEN LIGHT
INNER DOOR
GLASS
OVEN SHELF
DATA BADGE – Record the Model No.
and the Serial No. on the Service Page.
MAIN OVEN
TEMPERATURE
CONTROL
GRILL BURNER
STAY CLEAN LINER
MEAT PAN
INNER DOOR GLASS
MAIN OVEN DOOR

Cooling Fan: A gentle flow of air will be blown below the control panel when any
control is used.
Note: Whenever the appliance has been used, the cooling fan may
continue to run or restart itself after all the controls have been turned off.
This indicates that the appliance is still warm.
Oven Interior The oven lights are operated when their respective oven control is used.
Lights
"Slow Cook The main oven has a “Slow Cook Setting” this can be used for slow
Setting” cooking, keeping food warm and warming plates for a short period.
CONTROLS
CONTROL MARKINGS
Note: It is advisable to check that all oven controls have been switched off when you
have finished using the appliance.
8
Control
Knob Description
Main Oven Temperature Control
Grill Control
Top Oven Temperature Control
A
B
B
Function
Push in and turn the control knob fully
anti-clockwise, wait for the oven burner to ignite,
and then turn to the required gas mark number.
Note: The oven burner will only operate when the
door is closed.
Push in and turn the control knob clockwise to the
large flame symbol, wait for the burner to ignite,
and then turn to the required setting.
Push in and turn the control knob fully
anti- clockwise, wait for the oven burner to ignite,
and then turn to the required gas mark number.
Note: The oven burner will only operate when the
oven door is closed..
AB
MAIN OVEN TEMPERATURE CONTROL TIMER
TOP OVEN TEMPERATURE & GRILL CONTROL

OVEN TIMER OPERATION
AUTOMATIC COOKING
The Top Oven and Main Oven can be controlled by the automatic timer. When the timer
control has been set for one oven, it is possible to use the other oven only during the
same automatic cooking programme.
HINTS ON AUTOMATIC COOKING
1. Select foods which will require the same cooking time and temperature.
2. To ensure food does not cool down and require reheating, set the end time so the
food is ready when you require it.
3. Always ensure that meat and poultry is defrosted before placing in the oven.
4. Whenever possible, take food out of the refrigerator and keep it as cool as possible.
5. If cooking food that requires frying before placing in the oven for auto cooking,
keep the delay start time to a minimum.
6. Never place hot or warm food in the oven for delay start cooking as it could cause
the oven to be warm and produce harmful bacteria in the food.
7. We advise that dishes containing left-over cooked poultry or meat, e.g.
Shepherd's Pie, should not be cooked automatically if there is to be a delay period.
8. Ensure that delay start times are kept to a minimum to prevent bacterial growth in
food.
9. Wine or beer may ferment and cream may curdle during the delay period so it is
best to add these ingredients just before serving.
10. Foods which discolour should be protected by coating in fat or tossing in water to
which lemon juice has been added, prior to placing food in the oven.
11. Dishes containing liquid should not be filled too full to prevent boiling over.
12. Food should be well sealed (but not airtight) in a container to prevent the loss of
liquid during cooking. Aluminium foil gives a good seal.
13. Always ensure that food is piping hot and cooked thoroughly before serving.
14. Only reheat food once.
9
Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the ovens can be used.

10
KNOW YOUR TIMER
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure the correct time of day is always set, before using you cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00
HOURS AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the display will
return to normal brightness for a few seconds and then dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will remain lit for the
period set. At the end of the Minute Minder Period, the timer will emit an audible
tone for 2 minutes, the symbol will start to flash and will continue to flash until
the Minute Minder function is cancelled.
This “Cookpot” symbol will light up either:–
– When you press the Cook Period Button and set a length of time for an Auto
Cooking Programme. (It will go out again a few seconds after you release the
timer buttons).
– During the actual Cook Period.
“AUTO” will light up:–
– When the timer is first turned on it will flash. (It will go out when a time of day
is set.
– When an Auto Cooking Programme has been set.
The “Auto” symbol will flash at the end of an Auto Cooking programme to indicate
that the programme has finished.
(When the “Auto” symbol is flashing, to return the oven to Manual operation,
turn the oven controls off, ensure that the correct time of day is set, and press the
“Manual” button twice – The “Auto” symbol will go out).
Here you can set a time period of up to 23 hours 59 minutes, that will count down.
When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.
Cook Period is the actual length of time for which, the timer will switch the oven(s)
on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The
timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will hear
a audible tone at 11:00, to indicate that the Auto Cooking Programme has finished.
Notes:
- When setting an Auto Cooking programme you will need to set the oven
controls(s) to the required temperature(s) when you set the timer.
- If an Auto Cooking programme has been set the oven(s) will only operate during
the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return the ovens(s)
to Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME
Note: If at any time the display shows a ‘KEY’ symbol, it is likely that the timer has been set incorrectly. OVEN
COOKING IS NOT POSSIBLE. The ‘KEY’ symbol can be deleted and the cooker returned to manual operation by:
- Simultaneously pressing the Minute Minder and the Cook Period buttons for a period of approximately 8
seconds.
- Releasing the buttons and pressing the ‘+’ button.

ELECTRONIC CLOCK & AUTOMATIC OVEN
TIMER OPERATION
11
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and Auto symbol will be
flashing intermittently.
Step 4 Press & hold in both the “Minute Minder” & “Cook Period” button together.
Step 5 With the “Minute Minder” & “Cook Period” buttons still held in, press either
the “+” or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set for an Auto
Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder Button, a symbol will light up.
Step 3 With the “Minute Minder” button held in, set the required Minute Minder
time using the “+” and “–” buttons.
Release all buttons and the timer display will revert back to the time of day. Bell
symbol will remain lit to signify that a Minute Minder period has been set.
At the end of the set time a bleeping sound will be heard, and the symbol will
flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop and the symbol will
go out automatically.
Step 4 To cancel the bleeping sound within the two minutes press the Minute
Minder button.
Note 1 When the Minute Minder has been set, the time remaining can be checked at any
time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone sounds by pressing
and holding the Minute Minder button and then at the same time pressing the “–”
button until 0.00 appears in the display window.

ELECTRONIC CLOCK & AUTOMATIC OVEN
TIMER OPERATION
12
Step 3 Press and hold in the Cook Period button.
The display will read 0.00 with the cookpot ( ) symbol lit.
Step 4 With the Cook Period button still held in, set the required Cook Period
using the “+” and “–” buttons.
Release the buttons and the timer display will revert to the time of day with the
Auto symbol and Cookpot ( ) symbol lit.
Step 5 Press and hold in the “End Time” button.
The display will read the earliest possible end time for the Cook Period that
you have set above.
The Auto symbol and Cookpot ( ) symbol lit.
Step 6 With the End Time button still held in, use the “+” and “–” buttons to set
the “End Time” (i.e. The time you require the oven to switch off).
Release all the buttons and the timer will revert back to the time of day.
The “Auto” symbol will remain lit to signify that an Auto Cooking Programme has
been set. The ( ) symbol will go out.
Step 7 Turn the oven control(s) to the required temperature, and if
necessary select the appropriate oven function.
Note: If your appliance has two ovens: When the timer has been set for one oven
it is possible to use the other oven onlyduring the same Automatic programme.
At the end of the Automatic Cook Period the Auto Symbol will flash and an
intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless cancelled.
The “Auto” symbol will continue to flash until the timer is returned to Manual
operation (see below).
Step 8 Press the Manual button to cancel the bleeping sound.
(If 2 minutes has not elapsed).
Step 9 Turn the oven control(s) to the OFF position.
Step 10 Press the manual button again to return the oven(s) to Manual Operation.
(The Auto symbol will go out)
AUTO COOKING PROGRAMMES
There are two Auto Cooking programmes that can be selected using your timer:–
(a) To set the timer to switch the oven(s) On and Off Automatically
(b) To set timer to switch on immediately and OFF automatically after a set cook period.
a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY
This allows you to cook at a specified time for a chosen period before the oven switches
off Automatically.
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).

ELECTRONIC CLOCK & AUTOMATIC OVEN
TIMER OPERATION
13
Step 4 Press & hold in the “Cook Period” button, the display will read 0.00 and the
cookpot ( ) symbol will light up.
With the Cook Period button still held set the required Cook Period using the “+”
and “–” buttons. Example: 1hr 30 minutes (as shown).
Note: Cook Period is the length of time the food requires to cook.
Step 5 Release all buttons.
The timer display will revert to the time of day with the Auto symbol lit & Cookpot
symbol remaining lit.
At the end of the Cook Period the “Auto” symbol will flash and an intermittent
bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless cancelled.
The “Auto” symbol will continue to flash until the timer is returned to Manual
operation (see below).
Step 6 Press the manual button to cancel the bleeping.
(If 2 minutes has not elapsed)
Step 7 Turn the oven control(s) to the OFF position.
Step 8 Press the “Manual” button again to return the cooker to Manual operation.
(The Auto symbol will go out).
b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY AFTER A SET COOK
PERIOD
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven
function.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply
pressing the Cook Period button.
Note 2 When cooking automatically the End Time can be checked at any time by simply
pressing the End Time button.
NOTE: The Cookpot symbol disappears

ELECTRONIC CLOCK & AUTOMATIC OVEN
TIMER OPERATION
14
OTHER NOTES ON TIMER OPERATION
1. When cooking Automatically the Cook Period can be checked at any time simply by pressing the Cook
Period button.
2. When cooking Automatically the End Time can be checked at any time by simply pressing the End Time
button.
3. Having set a Cook Period and End Time an electronic device stores the information. The device within the
timer will switch the oven(s) on and off at the required times.
4. When setting an Auto Cooking Programme and a mistake is made, to clear:–
(a) Press and hold in the “Cook Period” button.
(b) With the Cook Period button still held in, return the display to by pressing the “–” button.
(c) Release the “Cook Period” & “–” buttons, and the display will revert to the time of day and the “Auto”
symbol will flash.
(d) Press & release the “Manual” button.
(e) Start the sequence again.
5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply to the oven
has been interrupted. Reset the timer to the correct time of day.
Food in the oven may, therefore, not have been cooked, before serving check food is thoroughly heated
and completely cooked.
6. To set each function always press and hold the required function button and at the same time press “+” or
“–” buttons.
Note: Between the hours of 22.00 & 06.00 the display dims to prevent glare.
However, if you should operate a button during this period, the timer will return to normal
brightness for a few seconds and then dim again.
A
U
T
O
TO CANCEL AN AUTO COOKING PROGRAMME BEFORE
THE COOK PERIOD HAS FINISHED.
Step 1 Turn the oven control(s) to the OFF position.
Step 2 Press and hold in the “Cook Period” button.
Step 3 With the “Cook Period” button still held in, return the display to 0.00 by
pressing the “–” button.
Step 4 Release the “Cook Period” and “–” buttons and the display will revert to
the time of day and the “Auto” symbol will flash.
Step 5 Press the “Manual” button to return the oven(s) to “Manual” operation.
The “Auto” symbol will go out.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing
the Cook Period button.

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove screw & washers from the grill pan bracket.
Step 2 Tilt the handle over the recess (a).
Step 3 Slide it towards the centre of the pan (b).
Step 4 Locate the handle over the bracket (c).
For a fixed handle, replace screw & washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace screw
& washers.
GRILL PAN & HANDLE
15
NOTE: Ensure that when using the grill pan handle in the detachable manner it is
centralised and secure.
The grill pan can be stored in the top compartment with the handle attached by
placing the shelf in the middle or lower position and tilting the grill pan over the
rear edge of the shelf.
ABC

USING THE GRILL
16
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS USED.
YOUNG CHILDREN SHOULD BE KEPT AWAY.
B
TOP OVEN TEMPERATURE AND GRILL CONTROL
Step 1 Open the top oven door and remove the grill pan.
Step 2 Place the shelf in the chosen position (see grilling chart).
Step 3 Push in and turn the control knob clockwise to the large flame symbol.
Sparking will continue until the grill burner is lit.
Step 4 Slide the grill pan along the shelf towards the rear of the compartment until it
stops.
Step 5 Turn the control knob clockwise to the desired setting. Only turn the control
between the large and the small flame symbols.
Note: DO NOT line the grill pan with aluminium foil, as this increases the amount of
fat spitting and can cause a fire.
The grill burner will only operate when the door is open. If the grill door is closed
while the grill is on, the grill burner will be shut off. When the door opened again the
grill burner will turn on and be reignited.
Note: At the end of grilling always turn the control knob anti - clockwise to the off
symbol ●.
GRILLING CHART
The following chart is a guide. Grilling can be started from cold but for best results preheat
for approximately two minutes. Most cooking is done with the heat on full, but it may be
desirable to reduce it for thicker pieces of meat or for keeping food warm.
SHELF POSITION FOOD
High Position
Centre position
Low Position
Toast, Pikelets / Crumpets, Bacon, Thin Sausages, Beef Burgers, Tomato Halves, Steak
(rare and medium), Kippers, Gammon, Kidneys and Toasted Snacks.
Toast, Toasted Snacks, Thick Sausages, Beef Burgers, Fishfingers, Steak (well done), Gammon,
Chops (with heat turned down for part of cooking time).
Whole Fish, Fish Fillets, Fish Steaks (on base of pan).
Chicken Portions (with heat turned down for part of cooking time).
For au gratin dishes e.g. macaroni cheese and meringue toppings e.g. baked alaska, place
the dish on the floor of the grill compartment. The base of the grill pan can be used for
warming fruit garnishes on the reduced setting.

USING THE TOP OVEN
Note: DO NOT allow young children near to the appliance when the top oven is in
use as the surfaces get extremely hot
WARNING: Items stored in the top oven will get hot when the main oven is in use.
The top oven can be used to cook small quantities of food or used in conjunction with the main
oven to provide additional cooking space.
SHELF POSITIONING
The shelf can be used in three different positions. It has a safety stop to prevent it being
pulled out too far when attending to food. The shelf is removed from the oven
by pulling it out to the stop and the lifting at the front to withdraw.
TOP OVEN UTENSILS
The baking dish and the grill pan without the handle can be used in the oven. To
ensure good air circulation in the oven, the maximum size of baking tray that should be
used is 300mm X 350mm (12" X 14").
USING THE TOP OVEN
B
TOP OVEN TEMPERATURE AND GRILL CONTROL
NOTE:The oven burner only operates when the oven door is closed. The oven burner will
shut off when the door is opened, and will turn on and reignite when the door is closed
again.At the end of cooking always turn the control knob clockwise to the off symbol ●
1. Check that the timer is set to manual.
2. Place the shelf in the correct position. ( see cooking chart ).
3. With the top oven door closed, push in and turn the control knob fully anti-clockwise.
Sparking will continue until the burner is lit. Turn the control knob clockwise to the
required setting ( see cooking chart ). There is a delay of about one minute whilst the
safety device operates before the burner comes fully on.
4. Place the food on the shelf and ensure that the oven door is closed.
GUIDANCE ON USING THE TOP OVEN
1. Best results are obtained by pre - heating for about fifteen minutes.
2. The tray or dish on which the food is cooked should be pushed to the back of the
shelf.
3. Food which is higher than or will rise above 100mm (4") cannot be cooked in the top
oven.
PLATE WARMING
Place the plates / dishes on the bottom shelf position and turn the control knob
to mark 1 for 10 - 15 minutes. Never use the grill for warming plates. 17

TOP OVEN COOKING CHART
The following times and setting are for guidance only. You may wish to alter the setting to give a
result more to your satisfaction. When a different setting to that shown below is given in a
recipe, the recipe instructions should be followed. Allow 15 minutes preheat for best results.
Always turn the thermostat knob to Mark 1 before selecting the required gas Mark.
Shelf position 1 is the highest.
Gas Shelf
Food Mark Position Approx. Cooking Time and Comments
FISH
Oily and white fish 5 2 20-30 mins.
MEAT AND POULTRY
Beef (medium) 4 or 5 3 25-30 mins per lb + 25-30 mins
Ham (covered in foil) 5 3 40 mins per lb + 40 mins
Lamb 5 3 30-35 mins per lb + 30 mins
Pork 5 3 40 mins per lb + 40 mins
Chicken 5 3 25 mins per lb + 25 mins
Duckling & Goose 5 3 25 mins per lb + 25 mins
Turkey 4 315-20 mins per lb + 15-20 mins
Casseroles 3 3 2-4 hrs. depending on meat used.
VEGETABLES
Baked jacket potatoes 5 2 11/2 - 2 hrs.
PUDDINGS
Milk Puddings (500ml/1pt) 3 2 11/2 - 2 hrs.
Baked Custard (500ml/1pt) 3 2
45 mins - 1 hr. in bain-marie of cold water.
Baked Sponge Puddings 4 2 30 - 45 mins
Baked Apples 3 2 45 mins - 1 hr. depending on size
Meringue Topped Puddings 1 2 25 mins until tinged with brown
Apple Tart (1 x 205mm/8”) 6 2 60 mins
Fruit Crumble 5 2 45 - 50 mins
If using aluminium foil:
1. Remember it is important to increase the cooking time by one third.
2. Do not allow the foil to touch the sides of the oven.
3. Do not cover the oven interior with foil.
4. Do not cover the oven shelves with foil.
Push dish right to
back of shelf.
18

TOP OVEN COOKING CHART
Gas Shelf
Food Mark Positions Approx. Cooking Time and Comments
CAKES, PASTRIES AND BISCUITS
Small Cakes (16 per tray) 5 2 20 - 25 mins.
Victoria sandwich (2 x 180mm / 7”) 4 2 25 - 30 mins.
Swiss Roll (3 egg quantity) 6 2 10 - 12 mins.
Christmas cake (1 x 205mm / 8”) 2 2 4 - 5 hrs depending on recipe
Madeira cake (1 x 180mm / 7”) 4 2 1 hr.
Rich Fruit cake (1 x 180mm / 7”) 2 2 21/4- 21/2hrs.
Gingerbread 3 2 11/2- 13/4hrs.
Scones - 16 per tray 7 2 12 - 15 mins.
Shortbread (1 x 180mm / 7”) 2 2 45 mins. – 1 hr. depending on thickness
Biscuits 4-6 2 15 - 25 mins.
Shortcrust Pastry 6 2 15 mins. – 1 hr. depending on recipe
Rich Short Crust 5 2 20 - 30 mins.
Flaky/Puff Pastry 7 2 10 - 30 mins. depending on recipe
Choux Pastry 6 2 25 - 35 mins.
YEAST MIXTURES
Bread - rolls, plait 7 2 or 3 25 - 35 mins
Tea breads etc. 5 2 25 - 30 mins
MISCELLANEOUS
Yorkshire Pudding - small 7 2 20 - 25 mins
- large 7 2 30 - 40 mins
Meringues 1 3 21/2- 4 hrs. turn when necessary
Soft Margarine – Use the oven settings recommended by the margarine manufacturer and not
those indicated on the cooking chart.
19

USING THE MAIN OVEN
20
Note: DO NOT allow young children near to the appliance when the main oven is in use as
the surfaces get extremely hot
The oven has different heat zones - the temperature control settings refer to the
temperature on the middle shelf; above this shelf it is hotter and below it is cooler.
SHELF POSITIONING
The two shelves can be used in six different positions. Each shelf has a safety stop to prevent
it being pulled out too far when attending to food. Shelves are removed from the oven by
pulling them out to the stop and the lifting at the front to withdraw.
MAIN OVEN UTENSILS
The baking dish and the grill pan without the handle can be used in the oven. To
ensure good air circulation in the oven, the maximum size of baking tray that should be
used is 300mm X 350mm (12" X 14").
MAIN OVEN OPERATION
A
MAIN OVEN TEMPERATURE CONTROL
1. Check that the timer is set to manual.
2. Place the shelves in the correct position. ( see cooking chart ).
3. With the main oven door closed, push in and turn the control knob fully anti-clockwise.
Sparking will continue until the burner is lit. Turn the control knob clockwise to the
required setting ( see cooking chart ). There is a delay of about one minute whilst the safety
device operates before the burner comes fully on.
4. Place the food on the shelf and ensure that the oven door is closed.
Note: The oven burner only operates when the oven door is closed. The oven burner will
shut off when the door is opened, and will turn on and reignite when the door is closed
again.
At the end of cooking, always turn the control knob clockwise to the off symbol ●
