Creda S036E User manual

InstructionsforInstallationandUse
ElectricOven
Model S036E

2
CONTENTS
Introduction
For Your Safety
Know your Oven
The Controls
Electronic Programmer
Cooking Advice
Cooking Chart
Care and Cleaning
Installation
Electrical Connection
Key Contacts
3
4
5
5
6
7
8
9
10
11
Back Cover
Retention of this Instruction Book
ThisInstructionBookmustbekepthandyforreferenceasitcontainsimportantdetailsonthesafeandproperuseofthe
appliance.
Ifyousellorpasstheappliancetosomeoneelse,ormovehouseandleaveit behind, make sure this Book is alsoprovided
sothenewowner can become familiar with the applianceandsafetywarnings.
IftheBook is lost or damageda copy may be obtainedfrom:
GDALTD.,MorleyWay,Peterborough,PE29JB

3
Yournewelectric oven is guaranteed* and willgivelasting service. This guarantee is only applicableifthe appliance has
beeninstalled in accordance withtheinstallationinstructionsdetailed in this booklet.
Tohelpmakebestuseofyourcookingequipment,pleasereadthis booklet carefully.
Theovenisdesignedspecificallyfor domestic use and responsibility will not be accepted foruseinanyotherinstallation.
Introduction
Tohelp removethe'new'smell, heattheemptyoven tomaximumtemperaturefor aminimumoftwo tothreehours,keeping
the door/s closed. Ensure that the room is well ventilated (eg. open a window or use an extractor fan) and that persons
whomay be sensitive to the odour avoid anyfumes. Itissuggestedthatanypetsbe removed from the room until the smell
has ceased.
Thisodouris due to any temporary finishonoven linings and elements and anymoistureabsorbed by the insulation.
Note: When the oven is first used, an odour may be omitted - this will cease after a short period of use.
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with this booklet.
(b) Has been properly connected to a suitable supply voltage as stated on the rating plate, attached to the
appliance.
(c) Has not been subjected to misuse or accident or been modified or repaired by any person other than the
manufacturersauthorised employee or agent.
(d) Has been correctly installed.

4
For Your Safety
ALWAYS:
- make sure you remove all packaging and literature from
insidethe appliance before switching on for the firsttime.
- check the soundness of the appliance after it has been
unpacked.
- make sure you understand the controls before using the
appliance.
- keep children away from the appliance during use, as
surfaceswillgetextremelyhotduringandaftercooking.Care
shouldbetakentoavoidtouchingtheheatingelementsinside
theoven during use.
-makesurethecontrolsareturnedoffwhenyouhavefinished
cookingand when not in use.
-gripthehandleinthecentrewhenopeningthedoor.
- stand back when openign the door to allow any build up
ofsteamor heat to disperse.
-usedry, good quality oven gloves whenremovingitems.
- take care to avoid heat/steam burns when operating the
controls.
- switch off the electricity supply at the wall switch, and
allowtocool,beforecleaningorperformingmaintenance..
- make sure the shelves are in the correct position before
switchingontheoven.
-keepthedoorpartiallyopenwhengrilling.
-keep the door closed when the appliance is not in use.
- keep the appliance clean as a build up of grease or fat
fromcooking can cause a fire.
-followthe basic principles of food handling and hygiene to
preventthepossibilityofbacterialgrowth.
-keepanyventilationslotsclearofobstructions.
NEVER:
- attempt to install or repair the appliance without the
assistanceof qualified personnel.
-operate thegrillwiththe door closedasthismay cause the
appliancetooverheat.
-remove the oven shelves whilst the ovenis hot.
-allow anyone to sit or stand on any part of the appliance.
-store items above the appliancethatchildrenmayattempt
toreach.
-heatupunopened food containers, as pressure can build
upcausingthecontainertoburst.
-use the appliance to heat up anything other than food.
-use the appliance as a room heater.
-use the grill to warmplates.
-dryitemson the oven doors.
-installtheappliancenexttocurtainsofothersoftfurnishings.
-allowchildrento play with or tamper with thecontrols.
-usesteamcleaners.
-use the oven forstorage purposes.
-useflammableliquids near the appliance.
-useadapters,multiple sockets and/or extension leads.
- pull on the appliance or the supply able to unplug it from
theelectricaloutlet.
-allowpowercablesofotherappliancestocomeintocontact
withhot parts of this appliance.
- expose the appliance to atmospheric agents, such as
rainorsunlight.
- operate the appliance with wet hands.
-operate the appliance whenbarefoot.
When used properly your appliance is completely safe but as with any electrical product there are certain
precautions that must be observed.
PLEASE READ THE BELOW PRECAUTIONS BEFORE USING YOUR APPLIANCE.
Tomaintaintheefficiencyandsafety of this appliance, we recommend you do the following:
-only call the Service Centres authorised by themanufacturer.
- always use genuine spare parts.

5
Know your Oven
A. ControlPanel
B. Function / Temperature selector
C. VariableGrill control
D. Timer
E. Ovenindicator light
- When lit, it indicates the oven is heating up to the
chosentemperature.
F. GrillPan / BakingTray
G. Oven Shelf
H. Guidesfor slidingthe shelvesor grillpan/baking tray
in and out
I. Electronicprogrammer -Allowsyoutoprogrammethe
ovenbyselectingthecookingtimeandtheendcooking
time. It can also be used as a timer.
The Controls
Thevarious features offered by your oven areselected by
meansof function/temperature selector “B”and grill control
“C”situatedonthecontrolpanel.
Notice: Never place anything on the bottom of the oven
when it is in operation because this could damage the
enamel. Always place your cookware (dishes, aluminium
foil, etc. etc.) on the shelf provided with the appliance in-
sertedalongtheshelfguides“H”.
N.B.:Should the appliancebeequipped with an electronic
programmer,to use theelectric oven, justpress button (
(themsymbol willappearonthe display) before selecting
thedesiredcookingfunction.
Thermostatically controlled oven (Fan Assisted Mode)
When the oven control knob (B) is turned in a clockwise
direction to the symbol "Light/Defrost" the fan and oven
lightwill come on to assist in the defrosting of frozen food.
Rotatingfurtherthroughtherangeof temperatures offered
you can choose which is most suitable for the food you
are going to cook.The temperature is controlled by the
oventhermostat (between 60°C to MAX).
Note: Whilst using the oven for conventional cooking the
variablegrillcontrol (C) must be setwith “MAX” in line with
the reference mark on the control panel.
Grill
1 Turnthefunction/temperatureselector “B”clockwise
untiltherequiredgrillingsymbolisinlinewiththemark
onthecontrolpanel. Theelementisnow"on".
2 Thevariablegrillcontrol“C”cannowbeusedtoselect
therequiredheat.
The variable grill control "C" provides varying grilling
temperatureswhen rotated from"max"to"min" and maybe
adjusted to vary the level of heat at any time during the
grillingoperation.
NOTE:Grilling mustbedonewith the door partially open.
The oven light
Set the function/temperature selector “B” to the "Light/
Defrost" symbol to turn it on. It lights the oven and stays
onwhen any of the electricalheating elements in theoven
comeon.
Coolingventilation
In order to cool down the exterior of the appliance, it is
equippedwitha cooling fan which comes onautomatically
whenthe oven is hot.
Whenthe fan ison,anormal flow ofaircanbeheard exiting
betweentheoven door and the controlpanel.
Note: When cooking is finished, the fan stays on until the
ovencools down sufficiently.
G
A
F
H
BIC
E

6
Theprogrammermakesitpossibletopresettheovenandthe
grillintermsof:
• delaystartwithapresetlengthoftimeforcooking;
• immediatestartwithapresetlengthoftimeforcooking;
• timer.
Buttonfunctions:
:Timerwithhourandminutes;
$:Lengthofcookingtime;
%:Endcookingtime;
(:Manual change;
):Change time(backwards);
*:Changetime(forwards).
How to Reset the Digital Clock
Aftertheappliancehas beenconnectedtothepower source
orfollowingapoweroutage,theclockdisplaywillbegintoblink
andread:0:00
• Pressthe$and %buttons at the same time.Thenuse
(within 4 seconds) the )and *buttons to set the
exacttime.
Usethe*buttontomovethetimeforwards.
Usethe)buttontomovethe timebackwards.
Thetime canalsobe changedinthefollowing twoways:
1. Repeatalloftheforegoingsteps.
2. Press the (button, and then use the )and *buttons
toresetthetime.
ManualOperation Modefor the Oven
Afterthetimehasbeenset, theprogrammerisautomatically
settomanualmode.
Note:Pressthe (buttontoreturntheoventomanualmode
afterevery“Automatic”cookingsession.
Delayed Start Time with Preset Cooking Length
The length and the end cooking times must be set. Let us
suppose that the display shows 10:00.
1. Turntheovencontrolknobtothecookingsettingandtem-
peraturedesired(example:convectionovenat200°C).
2. Press the $and the use (within 4 seconds) the )and
*buttons to set the length of the cooking time. Let us
supposethat30minuteswassetforthelengthofthecook-
ingtime.Inthiscase,the displaywillshow:
+
Releasethebutton,andwithin4seconds,thecurrenttimewill
reappear with the msymbol and “auto.”
3. Press the %button, and then use the )and *buttons
tosettheendcookingtime.Letussupposethat itis13:00
=
4. Release the button and the display will show the current
timewithin4seconds:
?
When“auto”islighted,itindicatesthatthelengthandend
cookingtimehavebeenpresettooperateinautomaticmode.
Atthispoint,theovenwillturnonautomaticallyat12:30in
ordertofinishthecookingsessionwithin30minutes.When
theoven is on, the msymbol (cooking pot)willappearon
thedisplayfortheentirelengthofthecookingprocess.The
$buttoncanbepressed at any time to display thesetting
forthelengthofthecookingtime,whilethe%buttoncanbe
pressedtodisplaytheendcookingtime.
Atthe endof the cookingtime, anacoustic signal will
sound. Press any button it turn it off (except the )and
*buttons).
Immediate Start Time with Preset Cooking Length
Whenonlythelengthofthecookingtimeisset(points1and2
oftheparagraphentitled,“DelayedStartTimewithPresetCook-
ingLength”),thecookingsessionstartsimmediately.
CancellingaPreset CookingTime
Pressthe$button,and usethe)button tosetthetime to:
,
Thenpressthemanualcookingmodebutton(.
TimerFeature
The timer can be used to count down from a given length of
time.Thisfeaturedoesnotcontrolwhentheovencomesonor
turnsoff,but,rather,itonlyemitsanacousticsignalwhenthe
presettimehasrunout.
Pressthebutton,and thedisplaywill read:
,
Thenusethe*and)buttonstosetthe desiredtime.
Releasethebutton,andthetimerwillstartatthatsecond.The
displaywillshowthecurrenttime.
.
At the end of the preset time, an acoustic signal will sound,
whichcanbeturnedoffbypressinganybutton(exceptthe *
and)buttons), andthesymbolwill turnoff.
ChangingandCancellingSettings
• Thesettings canbechanged atanytimeby pressingthe
correspondingbuttonandusingthe*or)button.
• Whenthelengthsettingforthecookingtimeiscancelled,the
endcookingtimesettingisalsocancelled,andviceversa.
• When in automatic cooking mode, the appliance will not
acceptendcookingtimespriortothestartcookingtimepro-
posedbytheappliance itself.
Electronic Programmer

7
from below, use the low shelf positions.
When Using the Grill
Use the "Grill" mode, place the food in the centre of the
grill pan, situated on the 3rd or 4th shelf from the bottom.
BakingCakes
When baking cakes, always preheat the oven. Make
sureyouwait until the oven has preheated thoroughly (the
redoven indicator light "E" willgoout).Donotopen the
ovendoor duringbakingtoprevent thecakefromdropping.
Ingeneral,if:
Pastry is too dark on top
Place it on a lower rack, lower the temperature, and
increase the cooking time.
Pastry dropped
Use less liquid or lower the temperature by 10°C.
Cooking Advice
When cooking in the oven, use only one baking tray or
shelf at a time. Select an upper or lower shelf position
based on whether the dish needs more or less heat from
the top.
Preheating
Ifthefoodbeingcookedneedstogointoapreheated
oven(thisisgenerallythecasewhencookingleavened
foods),we recommend youwaituntilpreheating is over,
whichis indicated by theredovenindicatorlight “E”going
out,beforeaddingfood.
CookingFish and Meat
When cooking white meat, fowl and fish, use temperature
settings from 180 °C to 200 °C.
For redmeat that should bewelldoneon the outside while
tender and juicy in the inside, it is a good idea to start with
ahigh temperaturesetting (200°C-220°C)fora shorttime,
then turn the oven down afterwards.
In general, the larger the roast, the lower the temperature
setting.Placethemeatonthe centre of the shelf and place
thegrillpan/bakingtraybeneathittocatchthefat.
Makesurethattheshelfisinsertedsothatitisinthecentreof
the oven. If you would like to increase the amount of heat
Cooked well on the inside but sticky on the
outside
Use less liquid, lower the temperature, and increase
the cooking time.
The pastry sticks to the pan
Grease the pan well and sprinkle it with a dusting of
flour or use greaseproof paper.
Pastry is too dry
Increase the temperature by 10°C and reduce the
cooking time.
Pastry has dropped
It is cooked well on the inside but is sticky on the
outside
Placeitonalower shelf, lower thetemperatureandincrease
thecookingtime.

8
Food to be cooked Wt.
(wt) Cooking position of
shelves from
bottom
Temperature
(°C) Variable grill Pre-heating time (min) Cooking time
(min.)
Pasta
Lasagne 2.5 3 210 - 75-80
Cannelloni 2.5 3 210 MAX - 75-80
Oven-baked noodles 2.5 3 210 - 75-80
Meat
Veal 1.7 3 230 - 85-90
Chicken 1.5 3 220 - 110-115
Turkey 3.0 3 MAX MAX - 95-100
Duck 1.8 3 230 - 120/125
Rabbit 2 3 230 - 105/110
Pork 2.1 3 230 - 100/110
Lamb 1.8 3 230 - 90-95
Fish
Mackerel 1.1 3 210-230 - 55-60
Dentex 1.5 3 210-230 MAX - 60-65
Trout baked in paper 1.0 3 210-230 - 40-45
Pizza
Napolitan 1.0 3 MAX MAX 15 30-35
Cake
Biscuits 0.5 3 180 15 30-35
Tarts 1.1 3 180 MAX 15 30-35
Chocolate cake 1 3 200 15 45-50
Raised Cakes 1 3 200 15 50/55
Grill cooking
Toast n.° 4 4 10
Pork chops 1.5 4 MAX-MIN 30
Mackerel 1.1 4 35
Note: cooking times are approximate and may vary according to personal taste.
Troutbaked inpaper 40-45
31.0
Cooking Chart
210-230

9
Care and Cleaning
Before cleaning or carrying out any maintenace on your
oven,youmustdisconnect it from the power supply.
Insidethe oven
Werecommend you clean youroven each time youuse it,
especiallyaftercookingroasts.Infact,itisadvisabletoprevent
foodresiduefrombuildingupduringcooking:theresiduewould
bere-cookedeachtimetheovenisusedandwouldcharand
releasesmokeandunpleasantodours.
Oven exterior
Cleanthe enamelled or stainless steel exterior surfaces of
your oven using a sponge soaked in soapy water, making
sureyourinseanddrythesethoroughly,withoutusingabrasive
orcorrosiveproductswhichcoulddamagethem.
Stainlesssteel
Rinsestainlesssteelpartsanddry themthoroughlyusinga
soft cloth. Use a specific non-abrasive product to remove
tougherstains,
DONOTusealuminiumfoiltoline thebottomoftheoven.
Toavoidhavingtocleanthebottomoftheoven,youmaybe
temptedtolineitwithsomealuminiumfoil.Westronglyadvise
againstthis.Thealuminiumfoilsheetindirectcontactwiththe
heatedenamelcoatingcouldmeltand damagetheenamel
coatinginsidetheovenirreversibly.
Rubber Seal
Thereisarubber sealsurroundingtheovenopening which
guaranteesitsperfectfunctioning. Checktheconditionofthis
seal on a regular basis. If necessary, clean it using warm
wateranddrythoroughly.
DONOTuseabrasiveproductsorobjectstodoso. Should
thesealbecomedamaged,pleasecontactHotpointService
(see KEY CONTACTS, back page). We recommend you
avoidusingtheovenuntilithasbeenrepaired.
How to Remove the Oven Door
The oven door can easily be removed to clean the space
betweenthe bottomofthedoor andthefrontof theoven.To
disassemblethedoor,proceedasfollows:
-opentheovendoorfully,
-liftupandturnthesmallleverssituatedonthetwohinges,
-shutthedoor,butnotcompletely,
-grip the door on the two external sides and pull it towards
you,pullingitoutofitsseat.
Reassemblethedoor by following the aboveprocedures
inreverseorder.
Replacing the Oven Lamp
• Disconnect the oven from the power supply by means
ofthe omnipolar switchusedtoconnect the applianceto
theelectricalmains.
• Removetheglasscoverofthelamp-holder;
• Remove the lamp and replace with a lamp resistant to
hightemperatures(300°C) with the following character-
istics:
- Voltage:230/240V
- Wattage 25W
- TypeE14
• Replacethe glass cover and reconnect the ovento the
mainssupply.
123

10
Installation
The appliance must be installed only by a qualified
person in compliance with the instructions provided.
The manufacturer declines all responsibility for improper
installationwhich mayharmpersonsand animals anddam-
ageproperty.
Important: The power supply to the appliance must be
cut off before any adjustments or maintenance work is
done on it.
Installation of Built-in Ovens
Inorderto ensure that the built-inappliance functions prop-
erly, the cabinet containing it must be appropriate. The
figurebelowgivesthe dimensions of the cut-out for instal-
lation under the counter or in a wall cabinet unit.
In order to ensure adequate ventilation, the back panel of
the cabinet unit must be removed. Installing the oven so
that it rests on two strips of wood is preferable.If the oven
rests on a continuous, flat surface, there must be an ap-
erture of at least 45 x 560 mm.
Thepanelsoftheadjacentcabinetsmustbemadeofheat-
resistantmaterial.In particular,cabinets with aveneerex-
terior must be assembled with glues which can withstand
temperatures of up to 100 °C.
In compliance with current safety standards, contact with
the electrical parts of the oven must not be possible once
it has been installed.
All parts which ensure the safe operation of the appliance
must be removable only with the aid of a tool.
For the correct centring of your appliance, position the 4
tabs on the sides of the oven in correspondence with the
4 holes on the perimeter of the frame. In particular, if the
cabinet side panel:
•is 20 mm thick:the removable part of the tab must be
removed (Fig.A);
•is 18 mm thick: use the first groove, which is factory-
set (Fig. B);
•is 16 mm thick:use the second groove (Fig.C)
Fig.A Fig. B
Fig.C
To fasten the oven to the cabinet, open the door of the
oven and attach it by inserting the 4 wood screws into the
4 holes located on the perimeter of the frame.
595 mm.
595 mm.
24 mm. 545 mm.
5 mm.
567 mm.
23 mm.
593 mm.
45 mm.
558 mm.
N.B.: Installation in compliance with the consumption declaration
595 mm.
595 mm.
24 mm. 545 mm.
5 mm.
567 mm.
23 mm.
575-585 mm.
558 mm.
595 mm.
45 mm.
min.
45 mm.
min.
560 mm.
45 mm.

11
Thisapplianceconforms to the following EEC Directives:
LowVoltageEquipment
73/23/EEC
93/68/EEC
ElectromagneticCompatibility
89/336/EEC
93/68/EEC
Inner dimensions of the oven:
width 43.5cm
depth 40.0cm
height 32.0cm
Voltage and frequency of power supply:
230-240V50-60Hz2250-2400W
ENERGY LABEL
Directive 2002/40/EC on the label of electric ovens
NormEN50304
DeclaredenergyconsumptionforForcedconvectionClass
heating mode:Fan assisted
Electrical Connection
Electrical connection
The electrical connection to the mains must be made on
the appliance. The power voltage and frequency are as
indicated on the rating plate.
WARNING:THIS APPLIANCE MUST BE EARTHED.
Mounting the power supply cable
Toopen the terminal board:
•Usingascrewdriver, press on the tabssituatedon each
side of the terminal board cover.
•Pull open the terminal board cover.
To mount the power supply cable, proceed as follows:
•Unscrewthecableclampscrewandthecontactscrews
L-N-6.
• Fastenthewiresbeneaththescrewheadsusingthefollowing
colourscheme:Blue(N)Brown(L)Yellow-Green6
• Fasten the power supply cable in the corresponding
cable clamp and close the cover.
ElectricalConnection:
Voltage Frequency:230V-1+N 50Hz
Fuse Section: 16A
Supplycable: 3x1.5mm2
You can connect your oven to the system means of a
terminalboard. Refer to above information for the
minimal cable sections and the calibration of the
protective elements according to the connection.
If the appliance is installed with a junction box, an
omnipolar circuit breaker - with a minimum contact
opening of 3mm - should be installed between the
applianceand the mains.
Power cable supply connection to the electrical
mains:
We recommend you use a power supply cable which is
longenough to allow you to take the oven out of its recess
in the event of maintenance operations (only use HAR - H
05- RRF quality cablesfitted with a plugconforming to the
regulationsin force.
The plug must be accessible at all times.
Unplug the appliance before all operations, even when
replacing the oven lamp.
Using the appliance without correct earthing is highly
dangerous.
IMPORTANT:
Afterconnectingthe appliance to the flexiblecable, tighten
all the screws on the terminal board.
42
NL

195.039.455.01 September 2003 Part no.FP142 - 01
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in
both the appliances and services we offer.
Repair Service and Information Desk
UK:08709066066
(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)
www.theservicecentre.co.uk
Republicof Ireland: 1850 302 200
Note: Our operators will require the following information:
Model number:
Serialnumber:
Extended Warranties
UK:08709088088
(Open 8 to 8 Mon - Sun)
www.theservicecentre.co.uk
Republicof Ireland: 1850 502 200
Genuine Parts and Accessories
UK: 08709 077 077
(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)
www.theservicecentre.co.uk
Republicof Ireland: [phone]
GeneralDomestic AppliancesLimited,Morley Way,Peterborough,PE2 9JB.
Key Contacts
After Sales Service
