CREE LIGHTING ZR-MT Series User manual

ZR-MT Series with
SmartCast®Technology
Commercial Specification Troffers with Emergency Driver
Includes: ZR14MT-SC1, ZR22MT-SC1 and ZR24MT-SC1
1 of 5 LPN00696X0001A0_A
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D’INSTALLATION
ZR14MT-SC1
ZR22MT-SC1
ZR24MT-SC1
• The ZR-MT Series of specification troffers is for non-insulated
ceiling applications using T-Bar ceiling grid, drywall grid adaptors,
and suspended mount.
• Designed for use in 120-277V 50-60 Hz protected circuit (fuse
box, circuit breaker). Supply wire sized as per NEC or governing
code(s), 90C rated.
• Make sure to cap off all unused leads.
•
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER - RISQUE DE CHOC - COUPER L’ALIMENTATION
AVANT L’INSTALLATION
2. CAUTION – Installation and servicing should be performed by
qualied personnel only. De-energize before opening.
ATTENTION – L’installation et l’entretien doivent être effectués
par du personnel qualié seulement. Mettre hors tension avant
l’ouverture
3. To reduce the risk of electric shock, disconnect both standard
and emergency power supplies and converter connector of the
emergency driver before servicing.
Pour réduire le risque de décharge électrique, vous devez
déconnecter à la fois le disjoncteur divisionnaire ou les fusibles et
les alimentations d’urgence avant l’entretien.
4. Do not use outdoors.
Ne pas utiliser à l’extérieur.
5. Do not let power supply cords touch hot surfaces.
Ne laissez pas les cordons d’alimentation toucher les surfaces
chaudes.
6. Do not mount near gas or electric heaters.
Ne montez PAS près des appareils de chauffage de gaz ou
électriques.
7. DO NOT use this equipment for other than its intended use.
NE PAS utiliser cet équipement à d’autres ns que celle qui est
prévue.
8. Equipment should be mounted in locations and heights where it will not readily be subjected to tampering by unauthorized
personnel.
L’équipement doit être monté dans des endroits et à des hauteurs où il ne sera pas soumis à des altérations par des personnes
non autorisées.
9. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
L’utilisation d’accessoires non recommandés par le fabricant peut causer une situation dangereuse.
10. Suitable for suspended ceilings.
11. Max. mounting height: 15 ft.
Hauteur de montage max.: 15 pieds.
12. Access above ceiling required. Do not install insulation within 3” (76mm) of any part of the luminaire.
Accès requis au-dessus du plafond. Ne pas mettre l’isolant à moins de 3 po (76 mm) de toute partie du luminaire
13. Suitable for suspended ceilings.
Convient aux plafonds suspendus.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

2 of 5 LPN00696X0001A0_A
3Power Supply
Junction Box Cover
TO INSTALL:
T BAR CEILING MOUNTING
STEP 1:
Bring the ZR-MT troffer up into the
T-Bar grid.
STEP 2:
Locate the luminaire hooks and
bend them out 90 degrees for
installation. See Figure 1.
NOTE: The luminaire hooks ship
bent in and need to be bent out for
installation.
STEP 3:
Then bend the luminaire hooks
against the T-Bar to secure the
luminaire. See Figure 1.
SUSPENDED MOUNTING
STEP 1:
Disconnect power to circuit by
turning circuit breaker OFF before
installation.
STEP 2:
Attach customer supplied cables
to the (2) cable slots on each side
of the housing. See Figure 2 and 3.
STEP 3:
Attach customer supplied cables
to mounting surface using
customer supplied hardware.
Ensuring that mounting surface
can support the luminaire.
STEP 4:
Make wiring connections per the
Electrical Connection section.
STEP 5:
Switch the circuit BREAKER on.
STEP 6:
Make sure the WIM blue LED has
a double blink pattern. If not,
please proceed to Troubleshooting
section. Otherwise, you can
proceed to commission the zone
controller. Please refer to the
Smartcast® document ion for
details. See Figure 4 on the next
page.
2
Cable Slots
1
Luminaire Hooks
T-bar
1st:
90° Bend
2nd: Bend
Against T-bar
T-bar

3 of 5 LPN00696X0001A0_A
Test Switch
Large Trim Ring
Small Trim Ring
Ceiling
5
RESET
STEP 1:
Actuate RESET button through the access hole. Press
and hold Test/Reset button until the LED flashes fast
(approximately 5 seconds). See Figure 4.
STEP 2:
Release the Test/Reset button for 1 second (Fast flashing
continues). Press and hold Test/Reset for 1 second until fast
flashing stops. If the blue LED does not respond with the
two-blink sequence, please repeat the RESET procedure..
INSTALLING TEST SWITCH
STEP 1:
Install test switch assembly into ceiling by drilling a 1” hole
into the ceiling.
STEP 2:
Unscrew the small trim ring and place test switch assembly
through the ceiling. See Figure 5.
STEP 3:
Secure the test switch assembly by screwing the small trim
ring removed in Step 5 back onto the test switch assembly.
Tighten the larger trim ring above the ceiling until it is
snugged tight against the ceiling. See
Figure 5.
CLEANING LENS
STEP 1:
Remove lens and endcap by pulling down gently on one end
near endcap. See Figure 6.
STEP 2:
Before installing lens, ensure that one endcap is already
installed.
STEP 3:
After cleaning is complete, place loose endcap back onto
lens and angle lens into fixed endcap. After getting lens
seated into fixed endcap, rotate upwards to engage loose
endcap into position. See Figure 6. Lens may need to be
squeezed together to help guide into pan.
STEP 4:
Confirm there are no visible gaps along entire length of lens
and around endcaps. If necessary, push endcaps against
end panel or lens against luminaire to eliminate gaps
NOTE: If fixed endcap comes loose during removal, push
upwards while using end panel as a stop to engage clips
See Figure 7.
6
Fixed End Cap
Loose End Cap
Lens
4
Ambient Light Sensor /
Blue LED indicator
Motion Sensor
Reset Button
7
Fixed End Cap

4 of 5 LPN00696X0001A0_A
TROUBLESHOOTING:
Out of the box, if the light does not turn on when power is applied:
• Check Wiring with power off
• If wired correctly, check to see if Blue LED has a double blink
pattern. If not, please proceed to RESET procedure.
• If Blue LED is blinking, then perform a RESET (See RESET
section).
• If Blue LED is on solid or off, call Cree Lighting Customer
Service.
• If you have done a RESET, and the light is still off, call Cree
Customer Service..
If light is unresponsive, use Cree Lighting Configuration Tool to verify
configuration.
EMERGENCY DRIVER CHECK
NOTE: For short-term testing of the emergency function, the battery
must be charged for at least one hour. The emergency driver must be
charged for at least 24 hours before conducting a long-term test.
STEP 1:
When AC power is applied, the charging indicator light is illuminated,
indicating the battery is being charged. When power fails, the
emergency driver automatically switches to emergency power,
operating the LED array. When AC power is restored, the emergency
driver returns to the charging mode.
STEP 2:
Although no routine maintenance is required to keep the emergency
driver functional, it should be checked periodically to ensure that it is
working. The following schedule is recommended:
• Visually inspect the charging indicator light monthly. It should be
illuminated.
• Test the emergency operation of the fixture at 30-day intervals
for a minimum of 30 seconds. When the test switch is depressed,
the LED array should operate.
• Conduct a 90-minute discharge test once a year. The LED array
should operate for at least 90 minutes.
If the luminaire fails any of these checks, consult service personnel.
REFER ANY SERVICING INDICATED BY THESE CHECKS TO
QUALIFIED PERSONNEL
EMERGENCY DRIVER AND AC DRIVER MUST BE FED FROM THE
SAME BRANCH CIRCUIT.
FCC NOTICE
CAUTION: Changes or modifications not expressly approved could void
your authority to use this equipment.
This device complies with Part 15 of the FCC Rules. Operation to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The LED in the front of this device operates within Risk Group 1 levels
per IEC 62471.
This device has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the device is operated in a commercial environment.
This device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this device in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
INDUSTRY CANADA STATEMENT
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device. In addition, this device complies with ICES-003
of the Industry Canada (IC) Regulations.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
RF EXPOSURE NOTICE:
To comply with the FCC/IC RF exposure compliance requirements,
this device and its antenna must not be co-located or operating to
conjunction with any other antenna or transmitter.
This equipment shall be installed and operated with minimum distance
5 cm between the radiator & your body. No other antenna is authorized
for use with this product.
Pour correspond aux requis d’exposition au FCC/IC RF, cet appareil
et son antenne ne doivent etre localisee tout pret ou operer en
conjunction ave d’autres antennes ou transmetteurs. Cet equipement
doit etre installe et opere avec une distance minimum 5 cm entre
l’emetteur et votre corps. Aucune autre antenne externe n’est
autorisee a etre utilise avec ce produit.

5 of 5 LPN00696X0001A0_A
www.creelighting.com
© 2020 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content
is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree®and the Cree logo
are registered trademarks a of Cree, Inc. SmartCast®, is a registered trademark of Cree Lighting, A company of IDEAL
INDUSTRIES.
ELECTRICAL CONNECTIONS
NOTE: The emergency driver must be fed from
the same branch as the AC Driver.
STEP 1:
Remove the cover of the junction box and bring in appropriate
power supply to the junction box using one of the knock-outs.
See Figure 3.
STEP 2:
Using customer supplied 90°C minimum rated wire
connectors, make the following electrical connections:
a. Connect the black luminaire lead to the
unswitched voltage supply lead.
b. Connect the white luminaire lead
to the neutral supply lead.
c. Connect ground wire lead to the supply ground lead.
STEP 3:
Locate the two red leads in the junction box and connect them.
STEP 4:
Push all leads into the junction box. Reattach junction box
cover that was removed in Step 1 , make sure no wires are
pinched.
NEUTRAL
WHITE
SUPPLY WIRING
LUMINAIRE
GROUND
** NOTE: DO NOT mate leads until installation
is complete and AC power is supplied
**RED
**RED
UNSWITCHED HOT
BLACK
ZRMT TROFFER
1. SUITABLE FOR DAMP LOCATIONS.
4 ACCESS ABOVE CEILING REQUIRED. .
5 TYPE NON-IC. INHERENTLY PROTECTED.
6 CAUTION - RISK OF SHOCK. DISCONNECT POWER BEFORE
SERVICING.
9 SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 35°C.
10 This Luminaire complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: 1. It may not cause harmful
interference. 2. It must accept any interference received, including
interference that may cause undesired operation. CAN ICES-005 (A)/
NMB-005
11 CAUTION - RISK OF SHOCK - DO NOT INSTALL INSULATION WITHIN
76 mm (3in) OF ANY PART OF THE LUMINAIRE E.
12 MIN. 75°C SUPPLY CONDUCTORS.
ZRMT EB
1. MAX. MOUNTING HEIGHT: 15 FT. SUITABLE FOR USE IN 35C AMBIENT
TEMPERATURE.
2 Risk of Electric Shock. SUITABLE FOR DAMP LOCATIONS. IP20 TYPE
IC. INHERENTLY PROTECTED. ACCESS ABOVE CEILING REQUIRED.
4 EMERGENCY OPERATION: 90 MINUTES. CAUTION - SEE INSTRUCTION
MANUAL FOR INSTALLATION, OPERATING, AND MAINTENANCE
INSTRUCTIONS. MIN 75°C SUPPLY CONDUCTORS.
5 CAUTION - SERVICE BY QUALIFIED PERSONNEL ONLY. DE-ENERGIZE
BEFORE OPENING.
7 CAUTION - RISK OF SHOCK - DO NOT INSTALL INSULATION WITHIN 76
mm (3in) OF ANY PART OF THE LUMINAIRE
8 This Luminaire complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: 1. It may not cause harmful
interference. 2. It must accept any interference received, including
interference that may cause undesired operation. CAN ICES-005 (A)/
NMB-005.
10 This equipment is not self-testing in conformance with the Life Safety
Code, ANSI/NFPA 101. CSA C22.2 NO. 141 EMERGENCY LIGHTING
EQUIPMENT.
11 CAUTION - THIS UNIT HAS MORE THAN ONE POWER SUPPLY
CONNECTION POINT. TO REDUCE THE RISK OF ELECTRIC SHOCK,
DISCONNECT BOTH THE BRANCH CIRCUIT BREAKER/FUSES AND THE
EMERGENCY POWER SUPPLY BEFORE SERVICING.
CCEA APPROVED
Contains FCC ID: 2ACQ6-WIM Contains IC: 11481A-WIM
