Crestron DM NAX DM-NAX-4ZSP User manual

DM-NAX-4ZSP QuickStart
DM NAX™ 4-Zone Streaming Preamplifier
The Crestron DM-NAX-4ZSP is a next generation Audio-over-IP (AoIP) preamplifier that puts Crestron multiroom audio distribution on the network.
Front Panel
In the Box
1 DM-NAX-4ZSP
Additional Items
2 Bracket, Rack Ear, 2 RU (2032122)
1 Power Cord, approx. 6.5 ft (2 m) (2001134)
2 Connector, 4-Pin (2003576)
3 Connector, 5-Pin (2003577)
4 Feet, Adhesive (2002389)
1

Install the Device
Refer to the Safety Instructions (Doc. 6607) prior to installation.
The device can be placed on a table or installed in a rack.
Place on a Flat Surface
Place the device on a flat surface such as a table.
Install in a Rack
This device occupies 1U of rack space.
1. Use a Phillips screwdriver (not included) to remove the three screws
from each side of the device as shown in the illustration.
2. Use the screwdriver and the six screws (removed earlier) to attach
the included rack ears to the device.
3. Mount the device into the rack using four rack mounting screws (not
included).
DM-NAX-4ZSP QuickStart
DM NAX™ 4-Zone Streaming Preamplifier
2

Rack Mounting Safety Precautions
Elevated Operating Ambient Temperature: If installed in a closed or
multi-unit rack assembly, the operating ambient temperature of the
rack environment may be greater than the room ambient temperature.
Therefore, consideration should be given to installing the equipment in
an environment compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
Reduced Airflow: Installation of the equipment in a rack should be such
that the amount of airflow required for safe operation of the equipment
is not compromised.
Mechanical Loading: Mounting of the equipment in the rack should be
such that a hazardous condition is not achieved due to uneven
mechanical loading.
Circuit Overloading: Consideration should be given to the connection of
the equipment to the supply circuit and the effect that overloading of
the circuits might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be
used when addressing this concern.
Reliable Earthing: Reliable earthing of rack-mounted equipment should
be maintained. Particular attention should be given to supply
connections other than direct connections to the branch circuit (e.g., use
of power strips).
Connect the Device
Make the necessary connections as called out in the following
illustration. Connect power last.
CAUTION:
lKeep the device unplugged until all of the input, network, output,
and speaker wiring is complete.
NOTES:
lEnsure that the unit is properly grounded by connecting the
chassis ground lug to an earth ground (building steel).
lTo prevent overheating, do not operate this product in an area
that exceeds the environmental temperature range of 32° to
104°F (0° to 40°C).
lDo not bundle power cords together with connection cables.
Doing so can result in noise.
3
DM-NAX-4ZSP QuickStart
DM NAX™ 4-Zone Streaming Preamplifier

Rear Panel
4
DM-NAX-4ZSP QuickStart
DM NAX™ 4-Zone Streaming Preamplifier

Digital Inputs
Refer to the following illustration when connecting digital audio sources.
NOTE: Only 2-channel PCM digital audio is supported at the digital
inputs.
Analog Inputs
Refer to the following illustration when connecting analog audio sources.
Balanced/Unbalanced Audio Output
Refer to the following table and illustration for analog audio output pin
assignments and connection information.
Signal Name Balanced Audio Output Unbalanced Audio Output
+ L+ L+
- L− L Shield
G Shield/ground G, L Shield, and R Shield
+ R+ R+
- R- R Shield
Configure the Device
For detailed information on configuring the device, refer to
DM NAX™ Product Manual (Doc. 9045).
5
DM-NAX-4ZSP QuickStart
DM NAX™ 4-Zone Streaming Preamplifier

Observe the LED Indicators
Refer to the following table for information about the LED indicators on
the device.
LED Indicator Color Meaning
PWR White Device is powered on with audio
passing.
Red Device is in standby mode.
Off Device is not powered on.
LAN White The device is powered on and has a
valid IP address.
Off Device is not connected to a network
or the IP address is invalid.
NAX White AoIP is ready to pass and the unit's
PTP clock is synced.
Off No AoIP is passing to or from the unit
and/or PTP is not synced.
SOURCE 1-8 White Signal is detected on the specified
input/source.
Red There is clipping on an analog input or
bitstream audio detected on a digital
input.
Off There is no signal detected on the
specified input/source.
ZONE 1-4 White There is audio output on the indicated
zone.
Red Clipping is detected on the output
audio.
LED Indicator Color Meaning
SETUP Solid Red The SETUP button is pressed.
Blinking Red A network reset or factory restore has
been initiated via the adjacent SETUP
button.
Reset the Device
A network reset or factory restore may be performed when
troubleshooting.
Network Reset
1. Ensure the device is powered on.
2. Press and hold the SETUP button for up to 15 seconds until the
SETUP LED flashes red.
The device will reboot, and the default network settings will be reset,
such as default Hostname, DHCP enabled, no static IP.
Factory Restore
1. Turn off the device by disconnecting the power cable from the device.
2. Press and hold the SETUP button and then reconnect the power
cable while still holding the SETUP button. Continue holding the
SETUP button for up to 30 seconds until the SETUP LED flashes.
The device will reboot, and all the factory default settings will be
restored, such as Zone settings, names, multicast addressing, etc.
CAUTION: Performing a factory restore will clear all settings from
the device configuration.
6
