Crestron iLux CLS-C6 User manual

iLux™Lighting Systems
Each unit is available in three colors: almond, black, or
white. The letter at the end of the product name, ‘A’, ‘B’,
or ‘W’, denotes the color (e.g., a CLS-C6MA is an
almond unit).
Introduction
Features and Functions
The iLux™units, CLS-C6 and CLS-C6M, are wall-
mounted complete integrated lighting systems that can
function as standalone devices and/or be part of a
Crestron®solution total control system network
(Cresnet®). The units are functionally identical except that
the CLS-C6M includes a built-in motion sensor.
Specifications
Following are specifications for the iLux units.
CLS-C6 & CLS-C6M Specifications
SPECIFICATION DETAILS
Power Requirements Line Power, 120 VAC, 60Hz
Load Ratings
Max load per channel:
Max load per unit:
800 W/VA
(6.6 Amps @ 120 VAC)
1920 W/VA
(16 Amps @ 120 VAC)
Note that if the unit is fed from an arc fault circuit interrupter
(required if controlling loads in a bedroom), the maximum total
load is 1000 W/VA
Load Types Incandescent, magnetic low
voltage, neon/cold cathode,
dimmable 2-wire fluorescent,
and non-dim lighting
(also: electronic low voltage,
3-wire and 4-wire fluorescent,
and 277V via expansion
modules; sold separately)
IR Receiver For use with Crestron IR
remote (sold separately).
Motion Detector
(CLS-C6M only)
Type
Range
Infrared
20 to 30 feet at 4-foot elevation
Default Net ID 1F
Control System Update Files1, 2
2-Series Control System Version 2.004.CUZ or later
Firmware CLS-C6.v1.0.upg or later
Environmental Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH
(non-condensing)
Overall Dimensions:
Height
Width
Depth
4.48 in (11.38 cm)
8.89 in (22.58 cm)
2.47 in (6.25 cm) for CLS-C6
2.60 in (6.61 cm) for CLS-C6M
Weight 22.8 oz (646.37 g)
CLS-C6M with Cover Open, Shown in Almond
Each unit provides automated control of up to six
channels of lighting loads, including incandescent,
magnetic low-voltage, neon/cold cathode, and two-wire
dimmable fluorescent (e.g., Advance Mark X)*. Each unit
also provides automated control of up to six groups of
shade and drape controllers for motorized window
treatments, screens, and lifts.
Front panel operation provides manual control of lighting
loads and shade groups as well as access to up to sixteen
scenes (lighting level/shade position combinations).
A built-in IR receiver allows for wireless operation using
an optional infrared remote generating standard RC5
commands; a built-in motion detector (CLS-C6M only)
enables automated control based on room occupancy.
Up to 16 Crestron keypads (sold separately) can be used
with each unit for control of rooms that have several
entrances or work areas. Each unit also supports up to
eight additional CLS-C6 units, enabling systems of up to
54 lighting channels and 54 shade groups.
1. The latest versions can be obtained from the Crestron website. Refer
to NOTE after last footnote.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult
the latest Crestron Product Catalog for a complete list of 2-Series
control systems.
Each unit provides control system integration through two
separate Cresnet control networks; one for local devices
and one for connection to a 2-Series control system.
NOTE: Crestron software and any files on the website
are for Authorized Crestron dealers and Crestron
Authorized Independent Programmers (CAIP) only. New
users may be required to register to obtain access to
certain areas of the site (including the FTP site).
*Other load types can be controlled via optional interface modules.
Crestron Electronics, Inc. Installation Guide – DOC. 6394
15 Volvo Drive Rockleigh, NJ 07647 (2013406)
Tel: 888.CRESTRON 09.05
Fax: [phone] Specifications subject to
www.crestron.com change without notice.

iLux™Lighting Systems
Physical Description Installation
The following illustration shows the overall dimensions
for the CLS-C6 and CLS-C6M. WARNING: Turn off power at the distribution panel
circuit breaker. Installing with power on can result in
serious personal injury and damage to the device.
CLS-C6M Overall Dimensions
CAUTION: To reduce the risk of overheating and
possible damage to other equipment, do not install to
control a receptacle or a motor-operated appliance.
NOTE: The CLS-C6 units require a neutral wire for
operation. If no neutral is present, contact a licensed
electrician for installation.
The following tools/hardware are required for installation.
• A 4-gang electrical box (not supplied), 3.5 inches
deep, minimum.
• Phillips torque screwdriver (not supplied)
Industry Compliance • Four 7/8-inch pan head Phillips screws
(supplied)
These units have been manufactured to comply with UL’s
Standards for Safety in the United States and Canada.
Formal approval is pending. If the planned configuration includes connection to shade
controllers, keypads, and/or a Crestron 2-Series control
system, the following items are also required. Refer to the
latest version of the Crestron CLS-C6 & CLS-C6M iLux
Lighting System Operations Guide, Doc. 6347, for
detailed configuration options.
NOTE: This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation.
• Cresnet network cable(s) (not supplied)
• Terminal block connector(s) (two supplied)
Check that any required Cresnet wiring has been installed
and verified. Then, use the following procedure to install
the iLux unit (CLS-C6M is shown in the illustrations).
Important Notes
Read before installation.
1. Feed the wires (power line from the distribution
panel, load wires, plus any required Cresnet
cables) through the holes in the wallbox. Then
install the box in the wall.
• Codes: Install in accordance with all local and
national electrical codes.
• Wiring: Use copper wire only. For supply
connections, use wires rated for at least 75°C.
• Lighting Load Types: incandescent, magnetic
low voltage, neon/cold cathode, dimmable
2-wire fluorescent, and non-dim lighting
(also: electronic low voltage, 3-wire and 4-wire
fluorescent, and 277V via expansion modules;
sold separately).
• Temperature: The iLux units are designed for
use where temperatures are between 32° to
104°F (0° to 40°C).
• Wallboxes: The iLux units mount in standard
4-gang wallboxes; 3.5 inches deep, minimum.
• Make certain that power is turned off, and
ensure that there is at least 4.5 inches of open
space above and below the electrical box
location to permit heat dissipation. 2. Hold the rear of the CLS-C6M unit and remove
the front panel and cover assembly by carefully
pulling out and up from the bottom edge.
2 •iLux™Lighting Systems: CLS-C6 & CLS-C6M Installation Guide – DOC. 6394

iLux™Lighting Systems
3. Remove the control panel overlay from the unit
(it lifts off – is held in place by small tabs) to
reveal the upper mounting screw holes.
6. If Cresnet cabling is part of the installation,
attach the supplied terminal block connector(s)
to the Cresnet cable(s) and plug into the
appropriate port(s) on the unit. Make certain that
there is a minimum 1/4-inch separation between
the Class 2 Cresnet wiring and the Class 1 AC
wiring.
4. Refer to the following diagram for connection of
the AC wiring. All wires to be inserted in the
screw terminals should be stripped 7/16-inch,
and screws should be tightened to between 8 and
10 in.-lbs. (0.90 Newton meters to 1.13 Newton
meters). The maximum wire size is 12 AWG. 7. Carefully tuck all wires into the wallbox and fasten the unit to the wallbox using the four
7/8-inch Phillips screws supplied.
5. Connect each load wire to the corresponding
LOAD terminals on the unit, connect the power
line hot wire from the circuit breaker to the HOT
terminal on the unit, connect all neutral wires to
the NEUTRAL terminal on the unit, and connect
all ground wires to the (ground) terminal on
the unit.
8. Reattach the control panel overlay to the front
panel by inserting the four tabs into the slots
provided, and install the hinged front cover
assembly by lining it up at the top and pressing
the bottom edge until it snaps into position.
Verify the basic installation and wiring connections as
follows:
Power up and Testing
The following illustration shows the front panel of the
unit and the controls used during installation. 1. Press the Lights button to enable manual light
control, and press the right side and the left side
of each of the function buttons to increase and
decrease the lighting level of those loads. Verify
that the intended loads and corresponding LED
bargraphs respond appropriately.
Front Panel Controls and Indicators
2. Press the OFF button to turn off all loads. The
loads will ramp down to off while the two-digit
display counts down to off (blank). Two seconds
after all lights have turned off, the unit’s master
air-gap relay opens making it safe to service the
lighting installations.
Installation Guide – DOC. 6394 iLux™Lighting Systems: CLS-C6 & CLS-C6M •3

iLux™Lighting Systems
Return and Warranty Policies
Problem Solving Merchandise Returns / Repair Service
Troubleshooting 1. No merchandise may be returned for credit, exchange, or
service without prior authorization from CRESTRON. To
obtain warranty service for CRESTRON products, contact
the factory and request an RMA (Return Merchandise
Authorization) number. Enclose a note specifying the nature
of the problem, name and phone number of contact person,
RMA number, and return address.
The table after this paragraph provides corrective action
for possible trouble situations. If further assistance is
required, please contact a Crestron customer service
representative.
CLS-C6/C6M Installation Troubleshooting 2. Products may be returned for credit, exchange, or service
with a CRESTRON Return Merchandise Authorization
(RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J., or
its authorized subsidiaries, with RMA number clearly marked
on the outside of all cartons. Shipments arriving freight
collect or without an RMA number shall be subject to refusal.
CRESTRON reserves the right in its sole and absolute
discretion to charge a 15% restocking fee, plus shipping
costs, on any products returned with an RMA.
TROUBLE POSSIBLE
CAUSE(S) CORRECTIVE ACTION
Unit is not
receiving
line power.
Verify that the unit is properly
connected to the power line and
that the circuit breaker is
closed.
Unit does not
function.
Loads are
not
connected.
Verify that the loads are
operational and that they are
connected to the iLux unit.
Loads turn on
and off, but do
not dim.
Wrong load
type
settings.
Correct load type settings. *
Lights flicker
at low levels Incorrect low-end
limit setting.
Change low-end limit setting. *
3. Return freight charges following repair of items under
warranty shall be paid by CRESTRON, shipping by standard
ground carrier. In the event repairs are found to be non-
warranty, return freight costs shall be paid by the purchaser.
CRESTRON Limited Warranty
CRESTRON ELECTRONICS, Inc. warrants its products to be free from
manufacturing defects in materials and workmanship under normal use
for a period of three (3) years from the date of purchase from
CRESTRON, with the following exceptions: disk drives and any other
moving or rotating mechanical parts, pan/tilt heads and power supplies
are covered for a period of one (1) year; touchscreen display and overlay
components are covered for 90 days; batteries and incandescent lamps
are not covered.
* Refer to the latest version of the Crestron CLS-C6 & CLS-C6M iLux
Lighting System Operations Guide, Doc. 6347, for details on setting
load types and low-end limits.
Further Inquiries
If you cannot locate specific information or have
questions after reviewing this guide, please take
advantage of Crestron's award winning customer service
team by calling the Crestron corporate headquarters at
1-888-CRESTRON [1-888-273-7876]. For assistance in
your local time zone, refer to the Crestron website
(www.crestron.com) for a listing of Crestron worldwide
offices.
This warranty extends to products purchased directly from CRESTRON
or an authorized CRESTRON dealer. Purchasers should inquire of the
dealer regarding the nature and extent of the dealer's warranty, if any.
CRESTRON shall not be liable to honor the terms of this warranty if the
product has been used in any application other than that for which it was
intended, or if it has been subjected to misuse, accidental damage,
modification, or improper installation procedures. Furthermore, this
warranty does not cover any product that has had the serial number
altered, defaced, or removed.
You can also log onto the online help section of the
Crestron website to ask questions about Crestron
products. First-time users will need to establish a user
account to fully benefit from all available features.
This warranty shall be the sole and exclusive remedy to the original
purchaser. In no event shall CRESTRON be liable for incidental or
consequential damages of any kind (property or economic damages
inclusive) arising from the sale or use of this equipment. CRESTRON is
not liable for any claim made by a third party or made by the purchaser
for a third party.
Future Updates CRESTRON shall, at its option, repair or replace any product found
defective, without charge for parts or labor. Repaired or replaced
equipment and parts supplied under this warranty shall be covered only
by the unexpired portion of the warranty.
As Crestron improves functions, adds new features, and
extends the capabilities of the CLS-C6 and CLS-C6M,
additional information may be made available as manual
updates. These updates are solely electronic and serve as
intermediary supplements prior to the release of a
complete technical documentation revision.
Except as expressly set forth in this warranty, CRESTRON makes no
other warranties, expressed or implied, nor authorizes any other party to
offer any warranty, including any implied warranties of merchantability
or fitness for a particular purpose. Any implied warranties that may be
imposed by law are limited to the terms of this limited warranty. This
warranty statement supercedes all previous warranties.
Check the Crestron website periodically for manual
update availability and its relevance. Updates are
identified as an “Addendum” in the Download column. Trademark Information
All brand names, product names, and trademarks are the sole property of their respective
owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP
and WindowsNT/2000 are trademarks of Microsoft Corporation
4 •iLux™Lighting Systems: CLS-C6 & CLS-C6M Installation Guide – DOC. 6394
