Crestron Adagio®ATC-AMFMSRD
AM/FM and SIRIUS®Satellite Radio
Tuner Card with Digital Output
Operations & Installation Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
Introducing SIRIUS Satellite Radio
Over 130 channels of the best entertainment and completely commercial-free music
for your car, home or office.
Only SIRIUS has more than 69 original music channels, from today’s hits to R&B
oldies to classical masterpieces. From authentic country and real bluegrass to cool
jazz, hot Latin, reggae, rock and many more. Best of all, it is all completely
commercial-free.
SIRIUS also has more than 60 channels of world-class sports, news and entertainment.
Included as part of your subscription, you get up to 16 NFL games a week, up to 40
NBA games a week and up to 40 NHL games a week. (Games are broadcast during
their respective seasons.) Coupled with great sports news from ESPN, the SIRIUS
sports offering is unrivaled. And do not forget a host of other great news and
entertainment like NPR, CNBC, Fox News, Radio Disney and E! Entertainment
Radio. For more information, visit www.sirius.com.
Activating your SIRIUS Subscription
You must activate your SIRIUS tuner before you can begin to receive the SIRIUS
Satellite Radio service.
In order to activate your radio subscription, you will need the SIRIUS ID (SID) which
uniquely identifies your tuner. The SID may be found on a sticker located on the
ATC-AMFMSRD card or by selecting channel 0 on the radio, in which case the SID
will appear on your Ad
tent.
agio®system or CEN-TRACK screen. Note channel 0 has no
audio con
A tuner that has not been activated will automatically tune to the SIRIUS preview
channel.
Contact SIRIUS on the Internet:
https://activate.siriusradio.com/
Follow the prompts to activate your subscription or you can also call SIRIUS toll-free
at:
1-888-539-SIRIUS (1-888-539-7474)
Once the subscription process is completed, your tuner is ready to use.
©2008 SIRIUS Satellite Radio Inc. “SIRIUS” and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.
All brand names, product names and trademarks are the property of their respective owners.
©2008 Crestron Electronics, Inc.

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Contents
AM/FM and SIRIUS Satellite Radio Tuner Card with Digital Output:
Adagio®ATC-AMFMSRD 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Specifications ..............................................................................................................2
Physical Description....................................................................................................3
Industry Compliance ...................................................................................................5
Setup ..........................................................................................................................................6
Installation................................................................................................................... 6
Regional Configuration ...............................................................................................7
Hardware Hookup ....................................................................................................... 8
Antenna Orientation .................................................................................................... 8
Uploading and Upgrading........................................................................................................ 11
Establishing Communication..................................................................................... 11
Firmware ...................................................................................................................11
Operation .................................................................................................................................12
Problem Solving ...................................................................................................................... 13
Troubleshooting......................................................................................................... 13
Reference Documents................................................................................................13
Further Inquiries ........................................................................................................ 14
Future Updates .......................................................................................................... 14
Appendix: RBDS/RDS Function Support...............................................................................15
Return and Warranty Policies .................................................................................................. 17
Merchandise Returns / Repair Service ...................................................................... 17
CRESTRON Limited Warranty.................................................................................17
Operations & Installation Guide – DOC. 6629A Contents •i

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
AM/FM and SIRIUS Satellite Radio
Tuner Card with Digital Output:
Adagio®ATC-AMFMSRD
Introduction
The ATC-AMFMSRD tuner card is designed for use with the Crestron®
CEN-TRACK Tuner Rack multi-tuner. On a single card, the ATC-AMFMSRD
provides one AM/FM tuner and one SIRIUS Satellite Radio tuner. Each tuner may
be operated independently and simultaneously.
In addition to its two analog audio output signals, the ATC-AMFMSRD also
supports digital output from the satellite radio tuner portion, making it ideal for use
with the CEN-TRACK. It can also be used with any Adagio®system that features
tuner card slots. Except where noted, references to Adagio systems will be used to
describe both Adagio systems featuring tuner card slots and the CEN-TRACK.
Features and Functions
• AM/FM/SR Tuner Card slides easily into place to become an integral
part of its control system
• Independent AM/FM/SIRIUS Satellite Radio tuners on a single plug-in
card
• Tuners are ready for routing to additional rooms on attached Adagio®
Audio Expanders (AAE)
• Adagio®system front panels and other supported user interfaces control
the tuners with out-of-the-box functionality (Does not pertain to
CEN-TRACK).
• Full control of each tuner is available through the CEN-TRACK LCD
front panel, and from Crestron touchpanels.
• RBDS/RDS compatible*
* The Radio Broadcast Data System (RBDS), a North American standard and Radio Data System
(RDS), a European standard, permit broadcasters to use a sub-carrier frequency to transmit inaudible
digital data along with their regular FM programming to receivers equipped to process the data. Refer
to “Appendix: RBDS/RDS Function Support” on page 15 for more information.
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •1

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
Specifications
Specifications for the ATC-AMFMSRD are listed in the following table.
ATC-AMFMSRD Specifications
SPECIFICATION DETAILS
Audio
Maximum Output 1 Vrms @ 1 kHz (AM/FM);
2 Vrms (SIRIUS)
FM Tuner
Frequency Range 87.50 to 108 MHz (50 or 100 kHz steps)
Intermediate Frequency 10.7 MHz
Usable Sensitivity 11 dBf mono
S/N Ratio 64 dB @ 65 dBf mono;
60 dB @ 65 dBf stereo
IF Rejection 100 dB
AM Rejection 55 dB
Stereo Separation 40 dB
AM Tuner
Frequency Range 530 to 1710 kHz (10 kHz steps)
Sensitivity 3.5 µV (RF input level 10dB S+N/N)
Selectivity 10 kHz
Up/Dn Freq Increments (US) 10 kHz
Up/Dn Freq Increments (Europe) 9 kHz
Alternate Channel Selectivity 55 dB
Image Rejection 35 dB
IF Rejection 60 dB
Power Requirements 24 VDC provided from backplane at
400 mA max. (estimated 9.6 Watts)
Environmental
Temperature 32º to 140ºF (0º to 60ºC)
Humidity 10% to 90% RH (non-condensing)
Dimensions
Height 1.39 in (3.51 cm)
Width 4.91 in (12.46 cm)
Depth 6.69 in (16.98 cm)
2 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Physical Description
This section provides information on the connections, controls and indicators
available on your ATC-AMFMSRD.
ATC-AMFMSRD Physical View (Head On)
ATC-AMFMSRD Physical View (Angled)
Conversion Connector Coax (RG6)/F Type (Antenna) to IEC Type Connector (Tuner)
Conversion Connector Coax (RG6)/F Type (Tuner) to SMB Type Connector (Antenna)
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •3

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
ATC-AMFMSRD Overall Dimensions
6.69 in
(16.98 cm)
6.19 in
(15.72 cm)
4.91 in
(12.46 cm)
1.39 in
(3.51 cm)
1
2
3
4
5
Connectors, Controls & Indicators
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
1 EXTERNAL AM
ANTENNA IN
(1) 8-wire RJ-45 female; Reserved for future
remote AM antenna (not yet available).
2 EXTERNAL AM
ANTENNA OUT
(1) 2-pin detachable terminal block; AM
antenna signal pass-through from remote
antenna.
3 AM ANTENNA
(1) 2-pin spring-loaded terminal; AM shielded
loop antenna included; Impedance: 50 Ω.
4 FM ANTENNA (1) IEC 169-2 coaxial (IEC to F adapter
included); FM wire antenna included;
Impedance: 75 Ω.
5 SIRIUS ANTENNA
(1) F-type coaxial (F to SMB adapter
included); Indoor/outdoor high-gain antenna
included; Impedance: 75 Ω.
4 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Industry Compliance
As of the date of manufacture the ATC-AMFMSRD has been tested and found to
comply with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •5

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
Setup
This section contains hardware installation and setup instructions for the
ATC-AMFMSRD.
Required Tools/Hardware
1. Small flat bladed screwdriver
2. Grounding strap (encouraged)
Installation
CAUTION: The ATC-AMFMSRD and the Adagio®systems contain electrostatic
discharge (ESD) sensitive devices. Crestron encourages you to wear a grounding
strap to avoid damaging the card and/or the host system.
When inserting a card into an Adagio system you may need to move other source
connections if designated connectors are occupied by other sources. For
programming purposes, slots and source connections are matched according to the
following table:
Slot 1 Slot 2 Slot 3
Source
Connections 1&2 3&4 Refer to
note below.
CAUTION: Do not connect external sources to SOURCES connectors used by tuner
cards.
CAUTION: Be certain to insert tuner card before applying power to the Adagio
system.
NOTE: If the user intends to use the out-of-the-box functionality, do not to use
SLOT 3 for tuner cards; otherwise, SLOT 3 uses source connections 5 and 6. Does
not pertain to the CEN-TRACK.
Begin the card insertion procedure with these steps:
1.
2.
3.
4.
Disconnect power from the Adagio system.
Remove the slotted screws securing any cover plate that may be
fastened the slot you intend to use. Set the screws and the cover plate
aside.
Unpack the ATC-AMFMSRD card.
As shown in the photo following this step, position the
ATC-AMFMSRD card so the print on the faceplate is right side up and
the side rails of the card slide into the plastic slots mounted on the left
and right inside walls of the Adagio system.
6 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
ATC-AMFMSRD Installation
5.
6.
7.
8.
Push the ATC-AMFMSRD card into the slot until it stops at the rear
connector, then push again until the ATC-AMFMSRD card snaps into
place.
Secure the card in place by tightening the two slotted screws by hand.
The screwdriver slots are provided for removal only.
Connect antenna(s).
Apply power to the Adagio system.
Regional Configuration
Once the tuner card is installed, users may change the AM/FM tuner configuration
for North American and European signal reception. For instructions on changing the
regional configurations refer to the latest revision of the Crestron CEN-TRACK
Operations Guide (Doc. 6646) or the operations guide for your particular Adagio
system that feature tuner card slots which can be obtained from the Crestron website
(http://www.crestron.com/manuals).
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •7

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
Hardware Hookup
Make the necessary connections as called out in the following illustration.
Hardware Connections for the ATC-AMFMSRD
EXTERNAL AM
ANTENNA OUT
FM ANTENNA
(SUPPLIED)
SIRIUS ANTENNA
(SUPPLIED)
EXTERNAL AM
ANTENNA IN
AM ANTENNA
(SUPPLIED)
The supplied AM antenna is connected as shown in the following illustration.
AM Antenna Connection
CONNECTOR END OF AM ANTENNA INSULATED CENTRAL
CONDUCTOR
SHIELD
(CONNECT TO: )
(CONNECT TO: )
Antenna Orientation
AM
Once your antennas have been connected it may be necessary to orient the AM loop
antenna so the flat surface of the loop antenna faces the metropolitan area from
which the broadcast signals originate. This is particularly necessary when signals are
weak. If you are not aware of the source or direction of the signals to which you will
listen, simply rotate the loop antenna in clear space for maximum signal strength.
The supplied antenna has a folding stand that allows you to place the antenna on a
flat surface.
FM
The recommended FM antenna is an outdoor type commonly available in electronics
stores. Use of the supplied indoor FM antenna is recommended only if you cannot
use an outdoor antenna. Outdoor antennas are particularly important in rural areas,
some distance from FM radio signal sources. The FM wire antenna supplied with
8 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
your tuner should be stretched to its full length. Some reorientation may be necessary
if signals in your area are weak. Best results can usually be achieved if the length of
the antenna faces the metropolitan area from which the FM signals you wish to
receive originate. The supplied antenna has a fitting at its end that will enable you to
fasten it in place.
SIRIUS
For correct operation and best reception of the SIRIUS signal, it is important that the
antenna is located in a place where it will have a clear view of the SIRIUS satellites
in the sky. Obstructions such as bushes, trees, other homes or buildings, overhangs,
soffits, chimneys, gables, dormers, etc., will impair or prevent the antenna from
receiving a signal.
The best reception is obtained if the antenna is located outside and where the pod
portion of the antenna (where the SIRIUS logo is printed) has a clear 360 degree
view of the sky.
If you cannot obtain a clear 360 degree view of the sky outdoors or you will be
locating the antenna indoors, you will need to place the antenna in a window (or
outdoor location) which has a clear view of the sky in the direction of the satellites
and aim the antenna in the direction of the satellites, as shown in the diagram below.
Use the map in the diagram to find the area in which you are located (1 to 5). Then
find the direction in which you need to have a window (or outdoor location) with a
clear view of the sky:
Area 1: You will need a window/location with a clear view of the sky facing EAST
or NORTHEAST or SOUTHEAST.
Area 2: You will need a window/ location with a clear view of the sky facing
NORTH or NORTHEAST.
Area 3: You will need a window/ location with a clear view of the sky facing
NORTH or NORTHWEST.
Area 4: You will need a window/ location with a clear view of the sky facing
WEST or NORTHWEST or SOUTHWEST.
Area 5: You will need a window/ location with a clear view of the sky facing
STRAIGHT UP (antenna cannot be located indoors).
For example, suppose you live in Area 2. You determined that your antenna will
need to have a window (or outdoor location) with a clear view of the sky facing
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •9

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
North or Northeast. The exact direction is determined by your specific location in
Area 2 relative to the X on the map; if you live in Texas, you will need a more North
facing clear view of the sky whereas if you live in southern California, you will need
a more Northeast facing clear view of the sky.
In major US cities, you may be able to receive the SIRIUS signal from the SIRIUS
ground repeaters, which would allow you to place the antenna away from a window
if the signal is strong enough.
If the tuner has not yet been subscribed, be sure to set the tuner to the preview
channel. Refer to the latest version of your Adagio system’s operations guide to
determine if you are receiving an adequate signal.
When you have installed the antenna in a suitable location, check the signal strength
display of your SIRIUS-ready receiver to verify that you are receiving a suitable
signal. For instructions on how to access the signal strength display, refer to the
latest version of your Adagio system’s operations guide. If the signal is weak or the
tuner loses reception at times, this is indication that the antenna is not aimed in the
optimal direction. Try adjusting the antenna by changing the orientation in small
increments to see if you can obtain better signal reception.
The following antennas are supplied with your AM/FM/SR tuner card:
AM Loop Antenna FM Wire Antenna
SIRIUS Antenna
10 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Uploading and Upgrading
NOTE: Using this tuner card in a system that goes beyond out-of-the-box
functionality requires programming. Since the ATC-AMFMSRD is inserted into an
Adagio system, refer to the latest version of the operations guide for your particular
Adagio system for details.
Crestron recommends using the latest programming software and that each device
contains the latest firmware to take advantage of the most recently released features.
However, before attempting to upload or upgrade it is necessary to establish
communication.
Establishing Communication
Consult the latest version of the operations guide for your particular Adagio system
for details.
Firmware
Firmware files may be distributed from programmers to installers or from Crestron
to dealers. Firmware upgrades are available from the Crestron website as new
features are developed after product releases. For details on upgrading refer to the
Crestron Toolbox™ help file.
Check the Crestron website to find the latest firmware. (New users may be required
to register to obtain access to certain areas of the site, including the FTP site.)
Upgrade ATC-AMFMSRD firmware via Crestron Toolbox.
• Display the network device tree (Tools | Network Device Tree) to
show all network devices connected to the control system. Right-click
on the ATC-AMFMSR to display actions that can be performed on the
ATC-AMFMSRD.
Select Functions | Firmware to upgrade the ATC-AMFMSRD firmware.
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •11

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
Operation
Please refer to the latest version of the Crestron CEN-TRACK Operations Guide
(Doc. 6646) or the operations guide for your particular Adagio system for control of
the AM/FM/SRD tuner card.
12 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Problem Solving
Troubleshooting
The following table provides corrective action for possible trouble situations. If
further assistance is required, please contact a Crestron customer service
representative.
ATC-AMFMSRD Troubleshooting
TROUBLE POSSIBLE
CAUSE(S)
CORRECTIVE ACTION
Tuner muted. Mismatched slot. Place card in proper slot.
Antenna not
connected or not
connected properly.
Verify proper antenna
connection.
Mute turned on. Press the Mute button to
disengage muting.
Station detuned or
weak.
Tune station; adjust antenna.
Unsubscribed SIRIUS
tuner not on preview
channel.
If unsubscribed, be sure tuner
is on preview channel.
Subscribed SIRIUS
tuner not on a
subscribed channel.
If subscribed, be sure tuner is
on a subscribed channel.
Adagio system
volume is turned
down.
Check Adagio system volume
setting.
Cannot access
tuner card controls
from Adagio
system front panel.
Dusty contacts. Clean contacts with cotton
swab or clean cloth. Apply
Isopropyl alcohol as needed
for cleaning.
Noisy AM/FM
reception.
Improper antenna
connection.
Verify proper antenna
connection.
AM/FM scan does
not operate.
Station signal strength
too weak.
Check antenna placement
and orientation for good
signal strength.
Reference Documents
The latest version of all documents mentioned within the guide can be obtained from
the Crestron website (http://www.crestron.com/manuals). This link will provide a list
of product manuals arranged in alphabetical order by model number.
List of Related Reference Documents
DOCUMENT TITLE
Adagio AES Entertainment System
Adagio AMS Media System
Adagio AMS-AIP Media System with Advance Image Processing
CEN-TRACK Tuner Rack
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •13

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
Further Inquiries
If you cannot locate specific information or have questions after reviewing this
guide, please take advantage of Crestron's award winning customer service team by
calling Crestron at 1-888-CRESTRON [1-888-273-7876].
You can also log onto the online help section of the Crestron website
(www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time
users will need to establish a user account to fully benefit from all available features.
Future Updates
As Crestron improves functions, adds new features and extends the capabilities of
the ATC-AMFMSRD, additional information may be made available as manual
updates. These updates are solely electronic and serve as intermediary supplements
prior to the release of a complete technical documentation revision.
Check the Crestron website periodically for manual update availability and its
relevance. Updates are identified as an “Addendum” in the Download column.
14 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A

Crestron Adagio®ATC-AMFMSRD AM/FM/SR Tuner Card
Appendix: RBDS/RDS Function Support
Many radio stations transmit additional information such as traffic information, radio
text, real time clock etc., with their regular FM programming. The FM tuner contains
circuitry that retrieves this information.
The US format for such information is called the Radio Broadcast Data System
(RBDS) and in Europe this format is called the Radio Data System (RDS). There are
some differences between the US and European standards.
The tables in this appendix describe information included in the standard.
When this feature becomes available and it is accessed by the user the Display
button will bring to the screen the various tables containing this data.
RBDS/RDS Supported Feature Overview
FEATURES DESCRIPTION
Program type name
(PTY)
There are 31 program types such as jazz, classic etc.
Each station that supports RDS will report its program
type. (Refer to program type list following this table.)
Program service
name (PS)
The station reports its service name such as WIRL, KTU
etc.
Program type
additional Info
(PTYN)
The station will sometimes report additional information
about its program type. For example, a program type
“Sport” station may report a PTYN of “Football”.
Radio text display
support (RT)
The station will report radio text information such as
phone numbers, artist, song, station name, etc., in this
field. This field could be either 32 or 64 characters in
length.
Universal real time
clock (UTC)
Some stations transmit the universal time clock year,
month, day, hour, minute and GMT offset.
Traffic information
report (TA/TP)
From stations that support traffic information.
Station search by
TA, TP or TA&TP
traffic information
types
The FM Tuner can search for stations which either
broadcast or know about other stations that transmit
traffic information.
TA = This station has information about other stations
that carry traffic announcements.
TP = This station broadcasts traffic announcements but
none is being broadcasted right now.
TA&TP = This station is currently broadcasting the
traffic announcements.
Station search by
PTY
The FM Tuner is able to search for stations with
specified program type.
Operations & Installation Guide – DOC. 6629A AM/FM/SR Tuner Card: ATC-AMFMSRD •15

AM/FM/SR Tuner Card Crestron Adagio®ATC-AMFMSRD
RBDS/RDS Program Types
PTY
CODE
RBDS PROGRAM TYPE
(US)
RDS PROGRAM TYPE
(EUROPE)
0 No program type or undefined No program type or undefined
1 News News
2 Information Current Affair
3 Sports Information
4 Talk Sports
5 Rock Education
6 Classic Rock Drama
7 Adult Hits Culture
8 Soft Rock Science
9 Top 40 Varied
10 Country Pop Music
11 Oldies Rock Music
12 Soft M.O.R Music
13 Nostalgia Light classical
14 Jazz Serious Classic
15 Classical Other Music
16 Rhythm and Blues Weather
17 Soft Rhythm and Blues Finance
18 Language Children’s Program
19 Religious Music Social Affairs
20 Religious Talk Religion
21 Personality Phone In
22 Public Travel
23 College Leisure
24 Unassigned Jazz Music
25 Unassigned Country Music
26 Unassigned National Music
27 Unassigned Oldies Music
28 Unassigned Folk Music
29 Weather Documentary
30 Emergency Text Alarm Test
31 Emergency Alarm
16 •AM/FM/SR Tuner Card: ATC-AMFMSRD Operations & Installation Guide – DOC. 6629A
