Crestron C2N-TAMFMXM User manual

quickstart guide
C2N-TAMFMXM
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
C2N-TAMFMXM
AM/FM and XM® Satellite Radio Tuner
QUICKSTART DOC. 7290A (2032396, Sheet 1 of 2) 11.11
1For Regulatory Compliance information, refer to the latest
version of Doc. 7291.
To Cresnet® Devices
NET
From Included AC Power Pack
24 VDC 2A
To Analog or Digital Audio Receiver
AUDIO OUT
Tie to Ground
G
From Included Antennae
FM XM Attach to XM port using
included adapter
AM Connector End of AM Antenna
Connect to
Connect to
AANNTT
ANTENNA (FM, AM, and XM)
Make the necessary connections as called out in the diagram below. Connect power last.
1Hardware Hookup
Notes on Antenna Orientation:
AM: Orient the AM loop antenna so that the flat surface of the loop antenna faces the metropolitan area originating the broadcast signals. This is particularly necessary
when signals are weak. If you are not aware of the source or directions of the signals to which you will listen, simply rotate the loop antenna in clear space for maximum
signal strength. The supplied antenna has a folding stand that allows the antenna to stand on a flat surface.
FM: The recommended FM antenna is an outdoor type available in electronics stores. Use the included FM antenna if an outdoor antenna cannot be used. The
included antenna may require reorientation if the signal is weak. Best results can occur if the length of the antenna faces the metropolitan area from which the desired
FM signal originates. The supplied antenna has a fitting at its end that will enable you to fasten it in place.
XM: Aim the antenna toward the southern sky, where the satellite is located. If the antenna is placed outdoors, it should be in an area where there are no obstacles
within 20 to 60 degrees of elevation facing the southern sky. The antenna should be placed on a flat surface that is parallel to the ground. If the antenna is placed
where obstacles such as buildings or trees are in the path to the satellite, the antenna may not receive radio waves from the satellite. Certain areas provide satellite
radio ground repeaters that retransmit satellite radio signals. Extension cables are available from Crestron®.
Use Crestron Toolbox™ for communicating with the C2N-TAMFMXM;
refer to the Crestron Toolbox help file for details.
There is a single method of communication: Indirect communication.
NOTE: Required for setting the Net ID and loading firmware.
2Establish Communication
Cresnet
Control System
PC Running
Crestron Toolbox
or USB
Serial,
LAN C2N-TAMFMXM
Indirect Communication
The NET port on the C2N-TAMFMXM connects to the control system
via Cresnet:
1. Establish communication between the PC and the control system
as described in the latest version of the 2-Series Control Systems
Reference Guide (Doc. 6256) which is available from the
Crestron Web site (www.crestron.com/manuals).
2. Use the Address Book in Crestron Toolbox to create an entry for
the C2N-TAMFMXM using the expected communication protocol
(indirect). Select the Cresnet ID of the C2N-TAMFMXM as listed
in section below and the address book entry of the control
system that is connected to the C2N-TAMFMXM.
3. Display the C2N-TAMFMXM’s “System Info” window (click the
icon); communications are confirmed when the device
information is displayed.
The Net ID of the C2N-TAMFMXM has been factory set to 9F. The
Net IDs of multiple C2N-TAMFMXM devices in the same system must
be unique. The Net ID may also be set from a personal computer
(PC) via Crestron Toolbox (refer to “Establish Communication” in
section ).
3Net ID
3
2

quickstart guide
C2N-TAMFMXM
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
C2N-TAMFMXM
AM/FM and XM® Satellite Radio Tuner
Select a Band
• To listen to AM radio press AM.
• To listen to FM radio, press FM.
• To listen to XM Satellite radio, press XM.
Tuning
The C2N-TAMFMXM can tune stations manually, scan through the band (AM and FM bands only), tune by
category (XM), or store/recall presets.
Manual Tuning
To manually tune a station:
1. Select a band as described in “Select a Band” above.
2. Press MENU to display the band’s list of options.
3. Press j or k to display Manual Tuning and press ENTER.
4. Press and hold j or k to tune down or up (respectively) until the desired station is displayed.
5. (XM only) Press ENTER to select the displayed station
Scan Tuning (AM and FM Bands Only)
To scan within a band:
1. Select the AM or FM band as described in “Select a Band” above.
2. Press MENU to display the band’s list of options.
3. Press j or k to display Scan Stations and press ENTER.
4. Press and releasej or k to scan down or up (respectively) to the next received station.
Category Tuning (XM Only)
To tune by category:
1. Select the XM tuner as described in “Select a Band” above.
2. Press MENU to display the list of options.
3. Press j or k to display Categories and press ENTER.
4. Press j or k until the desired category is displayed and press ENTER.
5. Press j or k until the desired channel is displayed and press ENTER.
Store/Recall Presets
Each band of the C2N-TAMFMXM can store and recall up to 20 preset stations.
To store a preset:
1. Tune to a station as described in “Manual Tuning”, “Scan Tuning (AM and FM Bands Only)”,
or “Category Tuning (XM Only)” above.
2. Press MENU.
3. Press j or k until Presets is displayed.
4. Press ENTER to display the list of presets.
5. Press j or k until the desired preset location is displayed.
6. Press and hold ENTER for three seconds until the “Saving Preset” message is displayed.
(Continued in next column.)
4Operation
QUICKSTART DOC. 7290A (2032396, Sheet 1 of 2) 11.11
2For Regulatory Compliance information, refer to the latest
version of Doc. 7291.
To recall a preset:
1. Select a band as described in “Select a Band”.
2. Press MENU to display the list of options.
3. Press j or k to display Presets and press ENTER.
4. Press j or k until the desired preset location is displayed.
5. Press ENTER to recall the preset.
Display Station Information
A tuned station may contain information about the station, the artist, or the song that is currently
playing.
To view available information, press DISP. Press DISP again to view additional information.
Advanced Features (XM Band)
The C2N-TAMFMXM can display information about the XM radio tuner such as the Radio ID and
signal strength.
To view the Radio ID:
1. Select the XM tuner as described in “Select a Band”.
2. Press MENU to display the list of options.
3. Press j or k to display Radio ID and press ENTER. The Radio ID will be displayed.
4. Press MENU to return to the list of options.
To view the signal strength:
1. Select the XM tuner as described in “Select a Band”.
2. Press MENU to display the list of options.
3. Press j or k to display Antenna Aiming and press ENTER. The signal strength will be
displayed.
4. Press MENU to return to the list of options.
4Operation (Continued)

quickstart guide
C2N-TAMFMXM
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
C2N-TAMFMXM
AM/FM and XM® Satellite Radio Tuner
QUICKSTART DOC. 7290A (2032396, Sheet 2 of 2) 11.11
3For Regulatory Compliance information, refer to the latest
version of Doc. 7291.
5Dimensions
2.36 in
(60 mm)
8.12 in
(206 mm)
5.08 in
(129 mm)
5.93 in
(151 mm)
6Specifications
SPECIFICATION DETAILS
AM Tuner
Frequency Range
Sensitivity
Selectivity
Alternate Channel Selectivity
Image Rejection
IF Rejection
FM Tuner
Frequency Range
Usable Sensitivity
S/N Ratio
IF Rejection
AM Rejection
Stereo Separation
XM Tuner
THD+N
S/N Ratio
Crosstalk
Power Requirements
Environmental
Temperature
Humidity
Heat Dissipation
Enclosure
Chassis
Faceplate
Mounting
Dimensions
Height (with feet)
Width
Depth
Weight
530 to 1710 kHz (9 or 10 kHz steps)
3.5µV (RF input level 10dB S+N/N)
10kHz
55dB
35dB
60dB
87.50 to 108 MHz (50 or 100 kHz steps)
11dBf mono; 60dBf stereo
64dB @ 65dBf mono; 56dB @ 65dBf stereo
100dB
55dB
27dB
<0.01% @1kHz
>97dB balanced, >95dB unbalanced, 20Hz-22kHz A-weighted
>-90dB 20Hz-22kHz
8 Watts (0.34 Amps @ 24 Volts DC)
PW-2407W (included): 100-240 Volts AC, 50/60 Hz
41° to 113°F (5° to 45°C)
10% to 90% RH (non-condensing)
27 BTU/Hr
Steel, black matte powder coat finish
Extruded aluminum, black matte plastic finish with polycarbonate label overlay
Freestanding or 0.5U 19-inch rack-mountable (adhesive feet included)
2.36 in (60 mm)
8.12 in (206 mm)
5.93 in (151 mm)
4.3 lb (2.0 kg)
Notes on XM Radio
It is prohibited to copy, decompile, disassemble, reverse engineer, or manipulate any technology incorporated in receivers compatible
with the XM Satellite Radio system. Furthermore, the AMBE® voice compression software included in this product is protected by
intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this or any
other software contained in an XM Radio is explicitly prohibited from attempting to copy, decompile, reverse engineer, or disassemble the
object code, or in any other way convert the object code into human-readable form. The software is licensed solely for use within this
product.
Hardware and required basic monthly subscription sold separately. Installation costs and other fees and taxes, including a one-time
activation fee may apply. Subscription fee is consumer only. All fees and programming subject to change. Subscriptions subject to
Customer Agreement available at xmradio.com. Only available in the 48 contiguous United States. ©2011 XM Satellite Radio Inc. All
rights reserved.
Crestron, the Crestron logo, Cresnet and Crestron Toolbox, are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United
States and/or other countries. AMBE is either a trademark or registered trademark of Digital Voice Systems, Inc. in the United States and/or other
countries. XM is either a trademark or registered trademark of Sirius XM Radio Inc. in the United States and/or other countries. Other trademarks,
registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Crestron disclaims any proprietary interest in the marks and names of others.
©2011 Crestron Electronics, Inc.
