Network Stream Player
The Crestron®CEN-NSP-1 provides a wireless or wired interface for Apple®iOS®devices using
AirPlay®or USB. The CEN-NSP-1 provides multiple easy ways to share music from an iPod®,
iPhone®, or iPad®through a whole-house audio system.
Introduction
13Dimensions (Shown with Mounting Bracket)
5.36 in
(137 mm)
5.10 in
(130 mm)
5.04 in
(128 mm) 1.77 in
(45 mm)
1.35 in
(35 mm)
2Application Drawing
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
AVIS:RISQUEDECHOC ELECTRIQUE NE PAS OUVRIR
LEFT BRIDGE RIGHT
+ - + -
8OHMSONLY
+ -
LEFT RIGHT LEFT RIGHT LEFT RIGHT LEFT RIGHT LEFT RIGHT LEFT RIGHT LEFT RIGHT LEFT RIGHT
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -
12345678
SPEAKEROUTPUTS
8Ω 120 W 4Ω 240 W
CLASS 2 WIRING
ELECTRONICS INC. ROCKLEIGH, N.J. 07647 USA
ANALOGSOURCES
BALANCED
+ - G + -
BALANCED
+ - G + -
BALANCED
+ - G + -
BALANCED
+ - G + -
SPDIFOUT
LOOPTHRU
24 Y Z G 24 Y Z G SETUP
SPDIFSOURCES
DIGITALOUT
L
R
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4
5 6 7 8
17 18 19 20
21 22 23 24
13 14 15 16
10
9
LAN
G
SWAMP-24x8
PoE/LAN USB SPDIFOUT AUDIO OUT
LR
Color Key
Audio
LAN
USB
Touch Screen
Phone
Wi-Fi
RMK-IFE-1U
CEN-NSP-1
PoE/LAN USB SPDIFOUT AUDIO OUT
LR
PoE/LAN USB SPDIFOUT AUDIOOUT
LR
CONNECTORS
AND INDICATORS
DESCRIPTION
4Connectors and Indicators
PWR
NET
RESET
SETUP (LED and Button)
ACTIVE STREAM
AUDIO OUT L/R
AUDIO OUT S/PDIF
iPod/iPhone
LAN/PoE
G
(1) Dual-color green and amber LED, indicates operating power supplied
via PoE, lights amber while booting and green when operating
(1) Amber LED, indicates Ethernet link status
(1) Recessed push button for hardware reset
(1) Red LED and (1) recessed push button, for Ethernet setup
(1) Amber LED, indicates the CEN-NSP-1 is actively streaming audio
from an iOS device
(1) pair RCA female;
Unbalanced stereo line-level output;
Output Impedance: 100 ohms;
Maximum Output Level: 2 Vrms
(1) RCA female S/PDIF coaxial digital audio output;
Output Impedance: 75 ohms
(1) Input port for connection to an Apple iOS device;
Provides power for charging an iPhone or iPod device;
Does not charge iPad devices
(1) 8-pin RJ-45 female with two LED indicators;
10BASE-T/100BASE-TX Ethernet port;
802.3af Power over Ethernet compliant;
Green LED indicates link status;
Amber LED indicates Ethernet activity
(1) 4-40 screw, chassis ground lug
* Only one AUDIO OUT port can be used at a time. The factory setting uses the analog channel.

NOTE: Ensure the unit is properly grounded by connecting the chassis ground lug to an earth
ground (building steel).
NOTE: To prevent overheating, do not operate this product in an area that exceeds the
environmental temperature range listed in the table of specifications.
2
quickstart guide
CEN-NSP-1
www.crestron.com
888.273.7876 201.767.3400
Specifications subject to
change without notice.
CEN-NSP-1
Network Stream Player
5Hardware Hookup
To use the CEN-NSP-1, it must be programmed in a SIMPL Windows or Crestron Studio™
program. All VT Pro-e®projects in the system must contain device controls using traditional
programming methods or a Media Player object. For details, refer to the SIMPL Windows help file,
the VT Pro-e help file, or the Media Player Programming Guide, which can be found at
http://support.crestron.com/app/answers/detail/a_id/5316/kw/media%20player.
6Program for Use
The CEN-NSP-1 can receive audio from an iOS device over a wired connection or an AirPlay
wireless connection.
NOTE: While the CEN-NSP-1 can connect with a wired device and an AirPlay connection
simultaneously, only one device can be selected for listening through the control system
program or media player.
Wired Connection
To use a wired connection between the CEN-NSP-1 and an iOS device, connect the charging
cable that is supplied with the iOS device to the iPod/iPhone port on the CEN-NSP-1 and the
iOS device.
NOTE: Only iOS devices can be connected to the iPod/iPhone port. If a device is connected
to the iPod/iPhone port, it cannot be connected over AirPlay.
NOTE: Only one iOS device can be connected to the iPod/iPhone port at a time. Multiple
devices cannot be connected over a hub.
NOTE: An iPad cannot be connected to the iPod/iPhone port.
7Connect an iOS Device
To Audio Receiver
From iOS Device
To LAN/PoE
Ground
When a connection is made with an iOS device (wired or wireless), the device controls are displayed
on a touch screen or mobile device in a media player session. The device’s transport controls are
displayed on the left side while the device’s menus and track listings are displayed on the right side.
Touch or tap the desired function:
hStart or resume playback.
bPause playback.
f Rewind to the beginning of track. If a
track has just started playing, the
previous track plays.
dRewind through a track. To resume
normal playback, touch or tap h.
cFast forward through a track. To
resume normal playback, touch or tap
h.
e Skip to the next track.
NOTE: Media player cannot browse the library of a device connected over AirPlay.
8Control via Media Player
AirPlay Connection
Perform the following to use an AirPlay connection:
NOTE: Only one device can be connected via AirPlay at a time. If a second
device is connected, the device that was originally connected is
disconnected.
NOTE: To use AirPlay, the CEN-NSP-1, wireless router, and iOS device
must be connected to the same subnet.
NOTE: Crestron recommends using the latest version of iOS.
1. On the iOS device, open the Control Center (swipe up from the bottom
of the screen). The selected AirPlay option is displayed.
2. Tap the AirPlay button to display a list of devices that are compatible with
AirPlay.
3. Tap the hostname of the CEN-NSP-1 that is to be connected. The iOS
device establishes a connection with the CEN-NSP-1.
