CrimeStopper Platecam SV-5350 User manual

INSTALLATIONINSTRUCTIONS:
The SV-5350 isaspecialdesignedlicenseplatemetalbarback up camerawithasuperwide
viewangle.TheSV-5350isdesigned tobeinstalled intheback ofthelicenseplateonany
vehicle.Itiseasytoinstallwithnodrillingrequired,requiringminimalinstallationtime.This
uniquelydesignedproductcan be used foranypassengercar,SUVandVan.Itcanalsobe
used on manylarge SemiTrucks, SchoolBuses, and Transit Buses
FEATURES:
•Revolutionarydesign integratesaColorrearvision camerawithyourrearlicenseplate
•Enhancethe lookof yourCar, SUV, Truck orVan.
•The 170°ultrawide-angleCCD colorcameraprovidesrearimagesinrealtimeand
eliminatesthedangerous“blind-spot”directlybehind yourvehiclewhen backing.
•Works wellindayornight, on most vehicles.
•Simpleinstallation: Nomajortoolsrequired. Video monitorrequired,notincluded.
•The platecameasilyconnectswithotherSecurViewproductssuchasthe SV-8200 and
SV-8400 3.5”LCD monitors.Itcan alsobe integrated withyourexisting OEMor
aftermarket LCD/TFTdisplays.
•The PlateCam™isdesignedforvehiclesinwhichthe licenseplatelocationiscentered
and abovetheleveloftherearbumper.The PlateCam™maynotperformwell on
vehicleswithloworoffsetlicenseplatepositions.
SV
-
5350
Hide-
Away Bracket
LicensePlateCamera

INSTALLATION
MOUNTING:
1.The PlateCam™SV-5350RearVisionSystemusesasuperwide-anglelensforbestall
aroundperformance.TheCamerawill displaythefull widthofmostparkingspacesupto8
feet orevenwider.
2.The SV-5350isdesignedtoworkbeston vehiclesthathavealicenseplatelocatedatthe
centerand abovetherearbumper.If yourvehiclehasaplatelocation thatisoffsettothe left
side,rightside,oryourplateislocatedunderthe bumperthen thePlateCam™maynot
provideoptimumperformance.
3.The design oftheSV-5350allowsthecameratobe angledtowardstherear“Blind Spot”
behind the vehicle.The bar-bracketisdesigned tobe mountedbehindthelicenseplateso
that onlythecameraisvisible.
4.The SV-5350isdesignedtousetheexistingLicensePlatemounting equipment
SIDE VIEW
LicensePlate
CameraLens
Mounting
Surface
Cable
Mounting
Bracket
FactoryLicense
PlateBolt
NOTE
MountingBracket shouldbe
behindlicenseplate
CAMERA:
1.The Camerahasbuilt-incircuitrytoreversethe imagesoobjectsontherightofvehicle
appearon therightandobjectsontheleftappearon the left when lookingatastandard
monitor.(See ReverseImaging next sectionformoreinformation.)
2.The colorCCD cameraismaintenance-free, waterproof (IP-68)andvibrationresistant.
3.ThiscameraisNOTanightvision Infra-red camera,howeverthebackuplightsonyour
vehicleand/oranyambientlightintheareashouldallowthe systemtostill be usefulatnight
inmostinstallations.
4.The cameraiscompletelyelectronic.ThereareNO manualadjustmentsforfocus,etc.

PICTUREQUALITY:
The 1/4”CCD cameraprovidesthebestqualitypictureavailable.Objectsonthemonitorarecloser
thantheyactuallyappear.
REVERSE (MIRROR)IMAGING:
TheSV-5350Camerahasbuilt-incircuitryto“mirror” theimagesoobjectsontherightofvehicle
appearon the rightand objectsontheleftappearon theleftwhenlooking atastandardmonitor.If
yourexistingmonitororin-dashmonitorhasareversecamerainput wherethemonitoritselfperforms
the mirrorimage,thenyourpicturewill notbe correct. Thisisduetothefactthe image isbeing
mirrored bytheplatecam and mirrored byyourmonitor.Check tosee if youcancontrolthesettings
inyourmonitortoturnoff themirrorimagefeature.Ifnot,theSV-5350hasawirethatcan be
groundedtoreversetheimagebacktonormal. (See WiringDiagram)
WIRING:
1.Carefullychooseahiddenout-of-sightlocation(possiblybehindtheplate)fordrillingthecable
hole.Somevehiclesmayhavean existinghidden rubbergrommetorplugavailabletoavoid
havingtodrill intothebody.Besuretodouble-check foranywiring orobstructionsbehind the
surfacewhereyouaregoingtodrill the cablehole. Usetherubbergrommet tomakeawatertight
sealforthecablewhereitpassesintothevehicle.
2.Chooseaconvenientplacetorunthecameracableuptheleft,rightorcenterofthe vehicle.As
aruleof thumb,trytoavoidmainfactoryharness loomsthatmaycontainhigh levelsorRFnoise
orinterference.
3.You canconnectthecamerapowerattherearofthevehiclebehindthereverselights.You may
alsoconnect powerinsidethevehicleunderthe dashorinthe trunk. TheRed powerwiregoesto
ReverseLight+12V,and the BlackwiretoGround.The Whitewireisforreverseimaging.Leave
thiswireunconnectedforReverseImage orGround thiswireforNormalImage.
4.Run theBlack RCAvideocabletoyourmonitor’svideoinputorreversecamerainput.
RED
BLACK
Connectto+12V
ReverseLight
Ground
SV-5350
ConnecttoRCA
VideoInput of RearView
Monitor MONITOR

TECH SUPPORT:[phone]
DISCLAIMER:
Undernocircumstancesshall themanufacturerordistributorofthePlateCam™beheldliablefor
consequentialorincidentaldamagessustained inconnectionwiththeuseofthePlateCam™RearVision
System.ThePlateCam™isdesigned asasafetyenhancementdeviceandisinnowayintended asa
replacementforrear-viewmirrors,side-viewmirrorsorphysicallycheckingthesurroundingswhen
backing avehicle.Always checksurroundingsforsafetywhenbacking!Objectsonthemonitorare
closerthantheyappear.Forthebestfit, modification ofthe vehiclelicensemayormaynotbe
necessary.Itisthe soleresponsibilityofthe vehicleownertocheck andverifyanyandall Stateor
FederalMotorvehiclecodeswithregardstomodificationsof vehiclelicenseplates.Themanufacturerof
the PlateCam™assumesnoliabilityorresponsibilitywhatsoeverwithregardsmodificationsofthe
licenseplate.
www.crimestopper.com
[e-mail]
Phone [phone]
FAX[phone]
©2009 CrimestopperSecurityProducts
SPECIFICATIONS:
1/4InchColorCCD SensorVideoOutput: 1.0VP-P composite(75Ohmload)
Dimension: 7¾”(W)× ¾”(H)×1¼”(D)SupplyVoltage: +12VDC
Weight: 4Oz.Power Consumption: 80mA
Pixels: 512 (H)x492 (V) ElectronicShutter: 1/50 s–1/100000s
Resolution: >250,000 pixelsWhiteBalance: Automatic
Morethan 330 TVlinesGamma Correction: 0.45
MinimumIllumination: 2LUX/ F1.2S/NRatio: Morethan 48dB
LensType: Wide AngleOperating Temp: -13 to185 F(-20 to75 C)
HorizontalAngle: 170°GainControl: Automatic
Vertical Angle: 90°Digital SignalProcessorw/10 BitA/DConverter
