CrimeStopper SecurView SV-6713 User manual

SV-6713 INSTRUCTIONMANUAL
Rear ViewColor Camera
TV SYSTEM H
V
H
V
HORIZONTALRESOLUTION
SHUTTERSPEED
IMAGEPICK-UPDEVICE
SCANNINGSYSTEM
SYNC.SYSTEM
S/N RATIO (AGCoff)
MIN.SENSITIVITY
GAMMACORRECTION
GAIN CONTROL
VIDEO OUTPUT
LENS
POWERSOURCE
POWERCONSUMPTION
OPERATINGTEMP.
DIMENSIONS/ mm
WEIGHT
1/4" ITCOLORCCDImageSensor
NO.OF PIXELS 510
492
NTSC
SV-6713
PAL
500
582
SCANNINGFREQUENCY 59.94 Hz 50 Hz
380 TV Lines 380 TV Lines
15.734 Khz 15.625 Khz
Internal
2:1 Interlaced
DC 12V 300mA Regulated Power Supply
Composite Video1.0Vp-p/75Ohm
0.45 Approx
Automatic
f=1.7mm (155deg)
Morethan48 dB
0.5Lux- at F:2.0/30 IRE
45g
Max2W
-10 - +50
33(W) X33(H)X36(L)
1/60~1/100,000 sec 1/50~1/100,000 sec
MOUNTING &WIRING DIAGRAM
CAUTION
RISK OF ELECTRICSHOCK
DONOTOPEN
CAUTION: TOREDUCETHERISK OF ELECTRICSHOCK,
DONOTREMOVECOVER(ORBACK)
NOTUSE ASERVICEABLEPARTSINSIDE
REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL
Thissymbolisintendedtoalert theusertothepresenceof
uninsulated"dangerousvoltage"withintheproduct's
enclosurethat maybeof sufficient magnitudetoconstitutea
riskof electricshocktopersons.
Thissymbolisintendedtoalert theusertothepresenceof
important operating and maintenanceinstructionsinthe
literatureaccompanying theappliance.
Connection
WARING: TOREDUCETHERISK OF FIREOR ELECTRIC SHOCK
DONOTEXPOSE THISAPPLIANCETORAINOR MOISTURE
CAUTION:PleaseUseRegulated
PowerSupply12VDC 300mA
RCAMale: Monitor
Video
EXTENTION CABLE
Dimensions
①②③
1. GND
2. 12V
3.
VIDEO
Black: GND
Red : Battery+
ReverseLamp
+
Specification
Mounting
Screw
Mounting Bracket
SV-6713 CCDCamera
SideView
Front View
Mounting Bracket
WARNING
TheSV-6713 Back upcamerasystemisstrictlyadriverassistant device.
It shouldnot be considered safetydeviceforanypurposes. Manufacturer
anddistributorsoftheproduct do not guarantee orassumeliabilityfor
collisionordamagesthat takeplacewhenbackingupyourvehicle.
ONLINETECHNICALSUPPORT
www.crimestopper.com
www.crimestopper.com
Phone:[phone]
Fax:[phone]
©2008 CrimestopperSecurity Products
RCAJack
20ftcable
RearViewMonitor
MiniJackConnector
Plug
Fuse
+12VReverse
Light ChassisGround
SV-6713

CABLE
ACCESSORIES ExtentionCable,Bracket
3p Phonejack
