Crosley CW5100 User manual

User Manual for CW5100 CPE
Country Wireless, LLC
1403 South Maple Avenue, Marshfield, Wisconsin 54449, United States
Tel: [phone] ; Fax: [phone]

Copyright© 2016
II
Table of Contents
Table of Contents...........................................................................................................................................II
Index of Pictures............................................................................................................................................II
Index of Table................................................................................................................................................II
User Manual for CW5100 CPE ............................................................................................................1
1Product Overview .......................................................................................................................................1
1.1 Product Orientation ..................................................................................................................................... 1
1.2 Product Features.......................................................................................................................................... 1
1.3 Product Description ..................................................................................................................................... 2
1.4 Product Appearance .................................................................................................................................... 2
1.4.1 Appearance Index ................................................................................................................................. 2
1.4.2 Appearance........................................................................................................................................... 2
1.5 Interface and Button.................................................................................................................................... 2
1.6 LED Indicators .............................................................................................................................................. 3
2Technical Specifications...............................................................................................................................3
2.1 Basic Specification ....................................................................................................................................... 3
2.2 RF Specifications .......................................................................................................................................... 3
2.3 Function Specification.................................................................................................................................. 4
2.3.1 SW Specification.................................................................................................................................... 4
2.4 Device Management.................................................................................................................................... 4
2.5 Environment Specification ........................................................................................................................... 4
3Product List ................................................................................................................................................5
Index of Pictures
Pic 1. Appearance of CW5100............................................................................................................................. 2
Index of Table
Table 1. CW5100 Product description................................................................................................................. 2
Table 2. CW5100 Appearance index ................................................................................................................. 2
Table 3. CW5100 Interface and button ............................................................................................................... 2
Table 4. LED Indicators ........................................................................................................................................ 3
Table 5. Basic Specification ................................................................................................................................. 3
Table 6. RF Specification...................................................................................................................................... 3
Country Wireless, LLC

Copyright© 2016
1
User Manual for CW5100 CPE
1 Product Overview
1.1 Product Orientation
we are a high -tech company dedicated in wireless broadband access solutions and service
operation. With the advent of the Internet+ era, the development of WBB is imminent. Through
continuous innovation, we launch the world first mobile broadband system based on the
Internet architecture and unlicensed spectrum. we can provide serious CPEs, include indoor
and outdoor unit on different spectrums.
CW5100
is ahigh performance outdoor CPE. CW5100
has the superior wireless access
performance and comprehensive routing capabilities, which have the abilities to bring the
end-users WBB services.
1.2 Product Features
CW5100 is designed according to the simplicity principle, which can evolve in a short period and
realize fast customization, delivery and deployment as well. The main features of CW5100 is as
follows:
Support TD-LTE network according to the operator’s choice.
LTE comply to 3GPP Release9 CAT4,
LTE TDD 3650MHz-3700MHz
Support the 100Mbps Ethernet WAN.
Intuitionist and convenient Web-based management.
Built-in LTE bipolar directional high gain antenna.
Support TR069 and OMA-DM network management protocol.
Support Cell lock. SIM lock.Pin lock
User-friendly design of LED indicator.
Power supply with PoE
Support pole installation or wall mounting.
Country Wireless, LLC

Copyright© 2016
2
1.3 Product Description
CW5100 CPE product is shown in Table 1.
Table 1. CW5100 Product description
Product
Description
CW5100
3.65G LTE Customer Premise Equipment
1.4 Product Appearance
1.4.1 Appearance Index
Table 2. CW5100 Appearance index
Index
Description
Dimension
246mm * 135mm * 50mm
Weight
About 600g
Color
French grey
1.4.2 Appearance
Pic 1. Appearance of CW5100
1.5 Interface and Button
Table 3. CW5100 Interface and button
Connectors
Description
ETH RJ45
One LAN
USIM Slot
Support 1.8V/3.0V USIM
Restore Button
Long press over 10s to restore the factory settings
Country Wireless, LLC

Copyright© 2016
3
1.6 LED Indicators
Table 4. LED Indicators
LED Name
Description
Color
LED Behavior
Status Indicator
PWR
Power
Indicator
Green
OFF
No Power Supply
Steady On
Power On
LTE Signal
3 LTEs,
Indicate
connection
state and
signal
strength
Green
All OFF
No Connected
ALL blanking
Connecting
One LED Steady
On
Connected, the signal
is weak
Two LED Steady
On
Connected, the signal
is medium
Three LED Steady
On
Connected, the signal
is strong
LAN
Eth
Indication
Green OFF
Ethernet connection
is not established
Steady On
Ethernet connection
is normal
Blanking
Ethernet interface
data being
transmitted
2 Technical Specifications
2.1 Basic Specification
Table 5. Basic Specification
Specification
Description
LTE Standard
3GPP Release 9
Ethernet LAN Port
One RJ-45 port 10/100 auto-sensing,
auto-MDX, 24V PoE
LED Indicators
Power/LET Signal/LAN Indicator
USIM
Support 1.8V/3.3V 2FF USIM
Restore Button
Tact Button
Power Supply
Input: Universal range 100~240V AC
Output: 12V 1A
2.2 RF Specifications
Table 6. RF Specification
Feature
Capability
Value
Unit
Mode
TDD
Channel Bandwidth
5/10/15/20
MHz
Max Output Power
17.34
dBm
LTE Standard
3GPP R9
Frequency
3650 ~ 3700
MHz
Antenna Gain
12.5
dBi
Country Wireless, LLC

Copyright© 2016
4
2.3 Function Specification
2.3.1 SW Specification
Item
Description
Language Settings
English
Network Mode
Bridge / NAT / Router
SIM
PIN Management
SIM Lock
Network Connection setup
1. Create, delete, and edit APNs
2. Set up dial-up connection automatically
3. Set up dial-up connection manual
LTE Scan Mode
1. Full Band
2. Cell Lock
3. Band / Frequency Preferred
VPN
1. Support VPN pass through
2. Support PPTP tunnel mode
NAT
1. Port forwarding
2. Port trigger
3. DMZ
4. UPnP
Statistics
1. LAN Link Status
2. Transmit / Receive traffic
3. Running Time
2.4 Device Management
Item
Description
Maintenance
1. Date & Time setting
2. Reset
3. Restore factory settings
4. Restore/Backup Configuration File
5. Local upgrade
6. FOTA upgrade
TR069
Can enable or disable TR069 Management
Port mirror
Can enable or disable the port mirror function
Syslog
Support the syslog function can send the log to the PC via LAN
Diagnostics
Support the Ping and trace route
2.5 Environment Specification
Country Wireless, LLC

Copyright© 2016
5
Feature
Capability
Value
Unit
Operating Temperature
-40 ~ 55
℃
Storage Temperature
-40 ~ 70
℃
Operating Humidity
5 ~ 95
%
Drop
0.8
m
Protected Level
IP65
3 Product List
Article Number
Content
Comments
CW5100
1*Assembled product
1*12V/1A PoE adapter
1*User Manual
Detail Delivers need to be defined by
customer agreement
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 50 cm
between the radiator & your body.
Country Wireless, LLC

Copyright© 2016
6
IC Compliance
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interferenc
e, and (2) This device must accept any interference, including interference that may cause und
esired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
The antenna(s) used for this transmitter must be installed to provide a separation distance of
at least 50 cm from all persons and must not be collocated or operating in conjunction with
any other antenna or transmitter, End-Users must be provided with transmitter operation
conditions for satisfying RF exposure compliance.
