CrossHelmet X1 User manual

USER GUIDE

USER GUIDE
Features 7 Limited Warranty Notice 14
Quick Start 5 Security Information 14
Rear-View Camera 8 Battery Safety Precautions 17
Touch Panel 9 Correct Disposal 17
Safety Light 10 Modifications 18
Connectivity 10 FCC Compliance 18
Tech Specs 19
Sound Control 8 Limitation of Liability 16
43

65
1
1
2
3
3
HELMET
USB CABLE
ADAPTER
QUICK START
2
CONTENTS OF THE PACKAGING
1. POWER ON
3. APP LAUNCH 4. GO RIDE
2. CONNECT
Turn on the helmet on the power
button.
Launch the app and configure
your personal settings
Experience the CrossHelmet
with all it’s functions on it’s
first ride.
Turn on bluetooth and
connect the helmet
with your mobile device.

87
1
2
2
3
34
4
5
5
6
HEAD-UP DISPLAY
SOUND CONTROL
REAR-VIEW CAMERA
SAFETY LIGHT
TOUCH PANEL
CONNECTIVITY
1
CROSSHELMET X1 FEATURES

109
- Clockwise goes left
HEAD UP DISPLAY
SOUND CONTROL
REAR-VIEW CAMERA
1
2
Use the dials to adjust the HUD to personal
preference and best visibility. The left and
right dials control the display image
respectively. When turning clockwise the
image goes left and when turning counter-
clockwise the image goes right.
The rear-view is projected onto the HUD.
For best image quality and vision adjust
the HUD according to personal preference.
SAFETY LIGHT
The Safety light is located underneath the Touch
panel and increases visibility of the rider at night
adding to overall safety.
Customize SoundControl with the sliders
in the CrossHelmet Application and adjust
every value to your preference.
3
4
LOW
-2
-1
0
1
2
MID HIGH

1211
PLAY/PAUSE SKIP SONG
REWINDTAKE CALL
TOUCH PANEL
Tap to play or pause
your music player.
Tap to take a call
or end a call.
Swipe forwards to skip
the currently playing song.
Swipe backwards to go
back to the previous song.
5
5TOUCH GESTURES
CONNECTIVITY
6
Connect your phone with the CrossHelmet.

1413
- Do not disassemble, open, drop (mechanical abuse), crush, bend, deform,
puncture, or shred.
- Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, or expose to fire or excessive heat
including soldering irons, or put into the microwave.
- Only use the battery with the charging system specified by the manufacturer/supplier.
- Do not short-circuit a battery or allow metallic or conductive objects to contact both
battery terminals simultaneously.
- Replace the battery only with another battery that has been qualified with same
characteristics. Use of an unqualified battery may present a risk of fire, explosion,
leakage, or other hazard.
- Dispose of used batteries promptly according to the manufacturer/supplier’s
instructions.
- Improper battery use may result in a fire, explosion, or other hazard.
- Battery usage by children should be supervised.
SECURITY INFORMATION
The CrossHelmet X1 and accessories purchased through our official distribution
channels is warranted by Borderless Inc. for a period of two years from date of
original purchase in connection with any defects in material and/or workmanship. This
warranty shall put a limit to repair of defects in material and/or workmanship. This
will be provided under the condition of free charge by the Borderless Inc. However,
LIMITED WARRANTY NOTICE
insurance handling, transportation and other incidental charges in relation to repair
work must be borne by the owner. Borderless Inc. will not assume the responsibility
for damages or loss encountered in transit. In case the warranty service is needed
and the valid claim is received within the Warranty period, purchaser’s name, address,
serial number and a copy of proof of purchase receipt is required and must be taken
or mailed to Borderless. The original receipt is recommended to present the proof of
the original purchase. This warranty shall not apply, if the defector or malfunction was
caused by damage resulting any misuses or abuses of the product, improper testing,
spillage of foods or liquids, wrong voltage disassembly or from any other operation
of the product contrary to instructions contained in the manual. This warranty does
not cover any defect that has occurred as a result of any modification or servicing
performed by anyone other than the designated Borderless Inc. service. Routine
cleaning and normal cosmetic and mechanical wear are not covered under the terms
of this warranty. Borderless Inc. shall not be liable for any consequential or incidental
damages (such as traffic accidents, data loss) resulting from any breach of warranty,
express or implied, applicable to this product. No refunds will be made on repairs per-
formed by un-designated service stations. This warranty is valid for only CrossHelmet
X1. This warranty policy does not affect the consumer’s statutory rights under the
applicable national law in force.borne by the owner. Borderless Inc. will not assume
the responsibility for damages or loss encountered in transit. In case the warranty
service is needed and the valid claim is received within the Warranty period, purchas-
er’s name, address, serial number and a copy of proof of purchase receipt is required
and must be taken or mailed to Borderless. The original receipt is recommended to
present the proof of the original purchase. This warranty shall not apply, if the defector
or malfunction was caused by damage resulting any misuses or abuses of the product,
improper testing, spillage of foods or liquids, wrong voltage disassembly or from any
other operation of the product contrary to instructions contained in the manual. This
warranty does not cover any defect that has occurred as a result of any modification
or servicing performed by anyone other than the designated Borderless Inc. service.

1615
Except for the express warranties set forth above, Borderless grants no warranties,
express or implied, by status or otherwise, regarding the CrossHelmet X1, fitness
for any purpose or otherwise. Consumer law in some countries does not permit
limitations under a Product warranty and therefore certain limitations set out in this
warranty document not apply. As a consumer your use of the CrossHelmet X1 shall be
non-commercial. Borderless shall therefore not be liable for any loss of profit or antic-
ipated savings. In any event, Borderless and it’s supplier’s liability under this limited
warranty shall be limited to the amount actually paid by consumer for the Product or
the current replacement value, whichever is greater. The Warranty shall not touch the
shell replacement program, which allows to renew the helmet’s shell for a reduced
price. Nothing in this warranty shall exclude or limit Borderless’ liability for death or
personal injury caused by its negligence, frau or any other liability that can not be
limited or excluded by law. If you CrossHelmet X1 arrives damaged, you must notify
Borderless within ten (10) days.
www.crosshelmet.com
LIMITATION OF LIABILITY
Routine cleaning and normal cosmetic and mechanical wear are not covered under
the terms of this warranty. Borderless Inc. shall not be liable for any consequential or
incidental damages (such as traffic accidents, data loss) resulting from any breach of
warranty, express or implied, applicable to this product. No refunds will be made on
repairs performed by un-designated service stations. This warranty is valid for only
CrossHelmet X1. This warranty policy does not affect the consumer’s statutory rights
under the applicable national law in force.
The trash mark shown on the product or its literature indicates that it should not
be disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly. Reset to
promote the sustainable reuse of material resources. Household users should contact
either the retailer where they purchased this product, or their local government office
for details of where and how they can take this item for environmentally safe recycling.
Business users should contract their supplier and the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes
for disposal.
CORRECT DISPOSAL (WASTE ELECTR. +
ELECTRONICAL EQUIPMENT)
Only use the charging unit provided. Never use a damaged charger. Remember to
charge the device before storing for a long period of time. Do not leave your device in
hot or cold areas (car in direct sunlight or parked in a garage in winter). Always store in
area where temperatures remain stable. The charger and the device can become hot
during charging. Do not cover. Do not disassemble the device. In the event of of battery
leakage, avoid contact of the liquid with skin and eyes. If contact occurs, rinse affected
areas with plenty of water and contact a physician.
BATTERY - SAFETY PRECAUTIONS

1817
The explanations and specifications in this guide are given for information purposes
only and may be modified without prior notice. They are deemed to be correct at the
time of going to press. The utmost care has been taken when writing this guide as
part of the aim to provide you with accurate information. However, CrossHelmet shall
not be held responsible for any consequences arising from any errors or omissions in
the guide, not for any damage or accidental loss of data resulting directly or indirectly
from the use of the information herein. CrossHelmet reserves the right to amend
and improve the product design or user guide without any restrictions and without
any obligation to notify users. If so, a later version of this guide might be available in
electronical format at www.crosshelmet.com.
MODIFICATIONS
This device complies with FCC Rules Part 15.
Operation is subject to the following two conditions:
- This device may not cause harmful interference.
- This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the Federal Communications
Commission (FCC) rules.
FEDERAL COMMUNICATIONS
COMMISSION STATEMENT
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment causes harm-
ful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by doing
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution Any changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. To maintain compliance with FCC exposure
compliance requirement, please follow operation instruction as documented in this
manual.
The FCC ID is displayed on the bottom left of the Head-Up Display of the CrossHelmet.
FCC ID 2AUQACRSX1V001

2019
Please follow the instructions here:
firmware.crosshelmet.com
FIRMWARE UPDATE

2221
Model name X1 - Cross One
Operational Frequency Range 2.4 GHz Bluetooth transceiver
Antenna information 1x antenna at 2.5 dBi gain
Usage environment Outdoor
Frequency channel bandwidth Bandwidth period 0.5
Modulation GFSK modulation
Safety certifications DOT, ECE, JIS
Shell material Polycarbonate +ABS
Weight 1,780g
Flash storage 8GB
Bluetooth 4.1, BLE
Main processor Quad ARM Cortex A53, 1.2 GHz
Mobile application iOS, Android
Inputs USB type-C
Radio used Bluetooth/WiFi WCN3620
chipset with WiFi deactivated
Output Power 100 mW output power
(WCN3620 Class 1 Bluetooth)
HUD 0.23 nHD+ resolution (3281 ppi)
Camera angle 170 degrees
LED safety light White
Sizing Medium (58-60cm),
Large (61-63cm)
Visor Clear, Tinted, Photochromic
Operational time 6-8 hours
Color Luster Black
TECH SPECS
