Dynojet Power Commander III User manual

Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 [phone] www.powercommander.com
Parts List
1 Power Commander
1 USB Cable
1 CD-ROM
1 Installation Guide
1 Power Adapter
2 Power Commander Decals
2 Dynojet Decals
1 Velcro®Strip
1 Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port
i113-411 02-04 Honda CBR 1100 XX (2001-2004 European Model) - PCIII USB - 1
2002 - 2004 HONDA CBR 1100 XX
(2001 – 2004 European Model)

4 Plug the PCIII connectors in-line of
the stock connector (Fig. B).
5 Attach the ground wire from the PCIII
to the NEGATIVE side of the battery
(Fig. C).
1 Remove the seat.
2 Lift the front of the fuel tank up.
3 Unplug the grey connector from the
wiring harness (Fig. A). This connec-
tor is located on the left hand side of
the bike and comes from the throttle
bodies.
Fig. B
Fig. C Fig. A
i113-411 www.powercommander.com 02-04 Honda CBR 1100 XX (2001-2004 European Model) - PCIII USB - 2
Unplug this connector
PCIIIr connectors
Stock connector
Ground wire from PCIII
PCIII harness

6 With the supplied self adhesive vel-
cro, attach the PCIII onto the top of
the ECU (Fig. D). Make sure to clean
both surfaces first with the supplied
alcohol swab.
7 Bolt the front of the fuel tank back
down. Install the seat.
Fig. D
i113-411 www.powercommander.com 02-04 Honda CBR 1100 XX (2001-2004 European Model) - PCIII USB - 3
