Crown COMMERCIAL AUDIO 160MA User manual

100V
70V
8
COM
TELEPHONE
(MOH)
PREAMP
OUTPUT
8600
Input 3Input 4
Input 2
Input 1
1 - CH1 MicOn/LineOff
2 - CH1 Normal
3 - CH1 Priority
4 - CH1 VOX
5 - CH1 to MOH
6 - CH2 to MOH
7 - CH3 to MOH
8 - Phantom
PRIORITY
CROWN 135MA AND 160MA MIXER-AMPLIFIER
QUICK-START GUIDE
In this example of connections to a 135MA or 160MA,
the paging mic mutes the CD player and satellite receiver.
Music-On-Hold from the satellite receiver plays over the
telephone system.
Speakers with 70V transformers
+
–
+
–
CD player
Amp Config
DIP switch detail
1 CH1 Mic/Line: ON
2 CH1 Normal: OFF
3 CH1 Priority: ON
4 CH1 VOX: OFF
5 CH1 to MOH: OFF
6 CH2 to MOH: ON
7 CH3 to MOH: OFF
8 PHANTOM: OFF
To switch in mic.
Switch mutes other channels.
®
To mic
5-terminal removable
barrier block (Phoenix-type)
8-Ohm
Speaker
Satellite Receiver
Paging mic
Crown Audio, Inc.
1718 W. Mishawaka Rd.
Elkhart, IN 46517-9439
TEL: [phone]
FAX: [phone]FAX
www.crownaudio.com
Specifications subject to change without
prior notice. Latest information available
at www.crownaudio.com. Crown and
Crown Audio are registered trademarks of
Crown International.
© 2007 Crown Audio , Inc. 11/07 140496-1
®
Amp Config
DIP switch detail
1 CH1 Mic/Line: ON
2 CH1 Normal: OFF
3 CH1 Priority: OFF
4 CH1 VOX: ON
5 CH1 to MOH: OFF
6 CH2 to MOH: ON
7 CH3 to MOH: OFF
8 PHANTOM: OFF
For Voice-Activated Ducking (VOX)
No contact closure needed
(no mic switching needed)
