CDi Series
CDi SERIES
The CDi Series of Crown®amplifiers are
professional tools designed and built for
installed sound applications. The series
includes three models which are identical
except for output power: CDi 1000, CDi 2000,
and CDi 4000. All are rugged and lightweight,
and offer unmatched value in their class.
CDi-Series amplifiers feature an intuitive front-
panel LCD screen to guide installers through
their configurations. CDi amplifiers also offer
onboard DSP for loudspeaker signal process-
ing. Other features include a switch-mode
universal power supply, useful function indica-
tors, proportional-speed fan-assisted cooling,
removable Phoenix-style inputs, barrier strip
outputs for low-Z or 70V/100V/140V loads,
short-circuit protection and more.
Your investment in a CDi-Series amplifier is
backed by Crown’s Three-Year, No-Fault, Fully
Transferable Warranty.
For more details about the Crown CDi Series,
contact the Crown Technical Support Group at
800-342-6939 or 574-294-8200. Also, visit the
Crown Audio website at www.crownaudio.com.
Specifications
Output Power: See power charts below.
Voltage Gain at 1kHz, 8 ohm rated output:
CDi 1000: 30.5 dB
CDi 2000: 32.9 dB
CDi 4000: 34.2 dB.
Frequency Response: +0/–1 dB from 20 Hz to
20 kHz at 1 watt into 4 ohms.
Load Impedance: Safe with all types of loads.
Rated for 2 to 8 ohms in Stereo mode, 4 to 16
ohms in Bridge-Mono mode.
Sensitivity: 1.4V.
Signal to Noise Ratio (below rated 8-ohm
power at 1 kHz): 100 dB (A weighted).
Damping Factor: Better than 500 from 20 Hz
to 400 Hz.
Crosstalk: > 70 dB below rated power, 20 Hz
to 1 kHz.
Input Stage: Input is electronically balanced
and employs precision 1% resistors.
Input Impedance (nominal): 20 k ohms, bal-
anced; 10 k ohms, unbalanced.
Maximum Input Signal: +22 dBu typical.
AC Line Voltage and Frequency Configura-
tions Available: 100V, 120V, 220-240V,
50/60 Hz.
AC Line Current:
CDi 1000: 11.50A
CDi 2000: 11.93A
CDi 4000: 11.75A
At Idle: Draws no more than 45 watts.
Operating Temperature: 0° C to 40° C at 95%
relative humidity (non-condensing).
DSP Section
Input EQ: 6 parametric filters per channel with
adjustable Q, ±15 dB boost/cut. Also adjust-
able high and low shelving filters. This 8-filter
EQ section can be bypassed.
Crossover Filters: Highpass and lowpass per
channel. Butterworth 6/12/18/24 dB per octave
and Linkwitz-Riley 24/48 dB per octave. Also
includes ±15 dB bandpass gain and polarity
control.
Output EQ: 8 parametric filters per channel with
adjustable Q, ±15 dB boost/cut. This 8-filter
EQ section can NOT be bypassed. Filters are
enabled individually.
Delay: Up to 50 msec total delay per channel.
Output Limiter: Prevents clipping and protects
loudspeakers. Choice of –3, –6, or –12 dB
threshold per channel.
Presets: 20 presets. 19 are user-definable.
Front Panel Controls and Indicators
Level: Detented rotary level control, one per
channel.
Power Switch: On/off switch applies AC power
to the amplifier.
Sel/Prev/Next Buttons: Three buttons near the
LCD screen are used to access menu items and
front panel lockout.
LCD Screen: Backlit liquid crystal display
shows speaker presets and signal processing.
Features
• Accurate, uncolored sound with very low
distortion for the best in music and voice re-
production
• Extremely versatile; rated for 2, 4, 8 ohm loads
and 70V/100V and 140V outputs
• Advanced protection circuitry guards against:
shorted outputs, open circuits, DC, mis-
matched loads, general overheating, high-fre-
quency overloads and internal faults
• Intuitive front-panel LCD screen for quick,
easy configuration
• Switch-mode universal power supply
• Onboard digital signal processing includes
crossovers, EQ filters, delay, and output limit-
ing
• All products fill 2U rack spaces and weigh under
19 pounds
• Barrier strip outputs for low-Z or 70V/100V/
140V loads, removable Phoenix-style inputs
• Three-Year, No-Fault, Fully Transferable War-
ranty completely protects your investment and
guarantees its specifications
8 ohm Dual (per channel)
1 kHz
Power
275W
500W
700W*
1,000W
1,400W*
4 ohm Bridge-Mono
140V Bridge-Mono
2 ohm Dual (per channel)
4 ohm Dual (per channel)
CDi 1000
With 0.5% THD.
*With 1% THD.
70V Dual (per channel)
500W
100V** Dual (per channel)
500W
**100Vp
8 ohm Dual (per channel)
1 kHz
Power
475W
800W
1,000W*
1,600W
2,000W*
4 ohm Bridge-Mono
140V Bridge-Mono
2 ohm Dual (per channel)
4 ohm Dual (per channel)
CDi 2000
With 0.5% THD.
*With 1% THD.
70V Dual (per channel)
800W
100V** Dual (per channel)
800W
**100Vp
8 ohm Dual (per channel)
1 kHz
Power
650W
1,200W
1,600W*
2,000W
3,200W*
4 ohm Bridge-Mono
140V Bridge-Mono
2 ohm Dual (per channel)
4 ohm Dual (per channel)
CDi 4000
With 0.5% THD.
*With 1% THD.
70V Dual (per channel) 1,000W
100V** Dual (per channel) 1,000W
**100Vp

Crown International
1718 W. Mishawaka Rd.
Elkhart, IN 46517-9439
TEL:[phone]
FAX: [phone]FAX
www.crownaudio.com
8/07 139648-3
Crown’s Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for every new Crown ampli-
fier—an unsurpassed industry standard. With this unprecedented No-Fault protection, your new
Crown amplifier is warranted to meet or exceed original specifications for the first three years of
ownership. During this time, if your amplifier fails, or does not perform to original specifications,
it will be repaired or replaced at our expense. About the only things not covered by this warranty
are those losses normally covered by insurance and those caused by intentional abuse. And the
coverage is transferable, should you sell your amplifier.
See your authorized Crown dealer for full warranty disclosure and details. For customers outside
of the USA, please contact your authorized Crown distributor for warranty information or call
574-294-8200.
CDi Series
Signal Indicator: Green LED, one per chan-
nel, illuminates when a very low-level signal is
present at input.
–10 Indicator: Green LED flashes when output
signal exceeds –10 dB below clip.
–20 Indicator: Green LED flashes when output
signal level exceeds –20 dB below clip.
Ready Indicator: Green LED, one per chan-
nel, illuminates when the amplifier is ready to
produce audio.
Clip Indicator: Red LED, one per channel, turns
on at the threshold of audible distortion.
Temp Indicator: Red LED, one per channel,
illuminates under excessive temperature
conditions.
Power Indicator: Blue LED illuminates when
the amplifier has been turned on and has
power.
Rear Panel Controls and Connectors
AC Line Connector: NEMA 5-15P (15A).
Input Connector: Two 3-pin removable
Phoenix-type connectors each accept a
balanced line-level input signal.
Output Connectors: 4-position barrier strip
with connectors for dual louspeakers or bridge-
mono loudspeaker. Dual connectors work with
2-8 ohm or 70V/100V loads. Bridge-mono con-
nectors work with 4-8 ohm or 140V loads.
HiQnet USB Connector: Type B, connects to a
USB port on a PC.
Protection
CDi-Series amplifiers are protected against
shorted, open or mismatched loads; overloaded
power supplies; excessive temperature; chain
destruction phenomena; excessive output
current, and input overload damage. They also
protect loudspeakers from input/output DC,
large or dangerous DC offsets and turn-on/
turn-off transients.
Included Accessories
Non-touch cover
Locking level-control knobs.
Construction
Chassis: Steel.
Cooling: Proportional speed fan with front-to-
rear airflow.
Dimensions: EIA Standard 19-in. rack mount
width (EIA RS-310-B), 3.5 in. (8.9 cm) high and
12.25 in. (31.11 cm) deep behind mounting
surface.
Net Weight:
19 lb (8.6 kg).
Shipping Weight:
22 lb (10.0 kg).
Specifications subject to change without prior notice. Latest
information available at www.crownaudio.com.
Crown, Crown Audio and Macro-Tech are registered
trademarks of Crown International. Other trademarks are the
property of their respective owners. ©2007 Crown Audio®,
Inc. Printed in U.S.A.
CDi 1000 | 1200W CDi 2000 | 1225W CDi 4000 | 1250W
