PARTS LIST, DIRECT STEAM KETTLES MOUNTED ON CABINET BASE,
MODELS DMT-6-(6, 10, 12), DMT-10-(6, 10, 12), DMT-12-(6, 10, 12)
FIGURE 1
Part No. 10266R0 2 2019-06-04

PARTS LIST, DIRECT STEAM KETTLES MOUNTED ON CABINET BASE,
MODELS DMT-6-(6, 10, 12), DMT-10-(6, 10, 12), DMT-12-(6, 10, 12)
FIGURE 1
ITEM PART NO. DESCRIPTION QTY.
1. 3819-1 Hole Plug 2
2. 9061-9 Hex Socket Set Screw, Cup Point 2
5/16-18 UNC x 3/8 Lg.
3. 9047-87 External Retaining Ring, i7/8 Shaft 2
4. 2-115R O Ring Seal, 7/8 OD x 11/16 ID 4
5. 2-014R O Ring Seal, 5/8 OD x 1/2 ID 2
6. 3796-1 Foot Nut, Brass, 1/2-14 NPSL 2
7. 2-W0C7 Flat Washer, 1-3/4 OD x 31/32 ID x 1/8 Thk 2
8. 3-D034 Nut, Brass, 1/2-14 NPS 2
9. 3-SC06 Steam Control Knob 1
10. 3-SC11 Steam Control Valve 1
11. 3520-1 Foot, Nylon 1
12. 9031-7 Acorn Nut, 3/8-16 UNC 1
13. 3589-1 Tilt Handle 1
14. 2-KB01 Knob, Red 1
** 15. 3799-1 Condensate Leg Assembly (6 Gallon) 1
3799-2 Condensate Leg Assembly (10, 12 Gallon) 1
** 16. 3800-1 Steam in Leg Assembly (6 Gallon) 1
3800-2 Steam in Leg Assembly (10, 12 Gallon) 1
** 17. 9085-1 O Ring Lubricant, 2 Grams, - 65EF to 400EF 1
* NOT SHOWN.
** SELECT AS REQUIRED.
Part No. 10266R0 3 2019-06-04

PARTS LIST, DIRECT STEAM KETTLES MOUNTED ON CABINET BASE,
MODELS DMT-6-(6, 10, 12), DMT-10-(6, 10, 12), DMT-12-(6, 10, 12)
FIGURE 2
Part No. 10266R0 4 2019-06-04

PARTS LIST, DIRECT STEAM KETTLES MOUNTED ON CABINET BASE,
MODELS DMT-6-(6, 10, 12), DMT-10-(6, 10, 12), DMT-12-(6, 10, 12)
FIGURE 2
CABINET 28" HEIGHT
ITEM PART NO. DESCRIPTION 24" WIDE
QTY.
36" WIDE
QTY.
42" WIDE
QTY.
1. 3563-1 Lower Panel Assembly 2 2 2
2. 5-MC02 Magnetic Catch 1 2 2
* M93X-632-14 Pan Hd. Screw,
# 6-32 UNC x 1/4 Lg.
4 8 8
** 3. 3373-1 Door Assembly,
23-3/4W x 20H
1
* 3204-1 Door Assembly, R.H.
17-7/8W x 20H
1
* 3209-1 Door Assembly, L.H.
17-7/8 W x 20 H
1
* 6009-1 Door Assembly, R.H.
20-7/8 W x 20H
1
* 6010-1 Door Assembly, L.H.
20-7/8 W x 20 H
1
4. 3-666D Connector, Brass,
3/8 C x 1/2 FPT
1 1 1
* NOT SHOWN.
** SELECT AS REQUIRED.
Part No. 10266R0 5 2019-06-04
